An HDMI input is connected to the DVI-I connector on the splitter cable using a DVI-HDMI Adapter:
A Component input is connected to the DVI-I connector on the splitter cable using a DVI-Component
Adapter:
An RGB (VGA) input is connected to the DVI-I connector on the splitter cable using a DVI-VGA Adapter:
Accessories Available - (Contact Datapath sales for details)
Product Name
DVI/ VGA
DVI/ HDMI
DVI/ COMPONENT DVI to YPbPr adapter
Description
DVI-A to VGA adapter
DVI to HDMI adapter
6
