BOB Duallie Owner's Manual

BOB is a company that
produces high quality
products, which encourage a
healthy, outdoor, car-free lifestyle.
In addition to strollers, we also
make single-wheeled cargo trailers
for bicycles. See
www.bobgear.com for our complete
line of products. Before
attempting to assemble or use
your new stroller, read and
understand these operating
instructions completely to insure
proper assembly and operation.
If you are unclear on any point, contact your
dealer or BOB before use.
WARNINGS
. Never leave children unattended in the stroller.
. Failure to properly assemble or install the quick release wheels on
this stroller may result in the wheels becoming detached while moving
and a subsequent loss of control of the stroller.
. Always use seat harness to avoid serious injury to child from sliding
or falling out of stroller.
. Never allow occupants to stand in stroller.
. The parking brake is not designed as a stopping brake. The brake
should not be used to slow or stop the stroller. The brake is intended
to park the stroller on flat surfaces, not on inclines. Never leave your
children in the stroller unattended with or without the parking brake
set!
. Do not attach parcels or bags to the handle or frame of stroller except
those recommended by BOB, as stroller can become unstable and
tip over.
. The maximum load of the Duallie stroller is 100 lbs (45 kg). Do not
exceed maximum load (occupant plus luggage weight) as stroller
will become unstable.
. Do not place sharp objects in the seatback pocket as your child leans
against this and can be injured as a result.
. When starting out, always make sure the child’s hands and feet are
away from wheels.
. Follow instructions and use care when folding and unfolding stroller
to prevent finger entrapment (see section 14).
. The Duallie stroller is not equipped for use after dark. If you intend
to use at night, we recommend installing a lighting system available
through your local bike shop.
. We do not recommend wearing roller skates or inline skates while
pushing stroller.
. Do not use stroller on stairs or steep inclines. Stroller can tip over,
resulting in injury.
. Never pull a loaded stroller backwards up stairs. Doing so could
damage the suspension system – leading to frame failure and serious
injury to the user and/or the occupants.
. Always use Wrist Safety Strap.
BOB IS NOT RESPONSIBLE FOR INJURY, DAMAGE, OR FAILURE
THAT RESULTS FROM OWNER’S FAULTY ASSEMBLY OR
MAINTENANCE AFTER SHIPPING.
AGE RECOMMENDATIONS:
child be a minimum of 6 to 8 weeks old before riding directly in the
stroller seat. Young babies incapable of holding their head up must
be provided additional head and neck support to ride safely. For
jogging and off road use, children should be at least 6 to 8 months
old.
Children develop at different rates. Consult with your pediatrician
regarding the suitability of the stroller use with your child.
DUALLIE OWNER’S MANUAL
Handle Bar
& Brake Lever
Handlebar Release Lever
Canopy Flap
Seat Recline Adjusters
Slider Latch
Seat Back Pocket
Shock Absorber
Frame Release Handle
Shock Release Button
Wrist Safety
Strap
- It is recommended that your
Canopy
Seat Tensioning
Drawstring(s)
Strap
A.F.O.D.
Swing Arm
Swing Arm

ASSEMBLY INSTRUCTIONS:

Reference Fig. 1 as it describes the various
parts of the Duallie stroller.
1. UNPACK: Remove stroller,
stroller wheels, front fender and
front quick release from
packaging. Plastic packaging
material was used to protect the
front fork dropouts, the front
wheel axles and the shock slider
brackets. Remove these plastic
pieces.
2. SWINGARM: Rotate the
swingarm away from the front of
the stroller until the shocks
engage in the first position (Fig.
2). Each shock
locking pin will
“snap” and lock into
position 1.
3. HANDLE:
Handlebar Release
Rotate the stroller
handle up to the
fully open position.
Slider Latches will
lock into place (Fig.
3).
4. REAR WHEEL:
Place the rear
wheel quick release
lever in the open
position, as shown
in Fig. 4. Insert the
rear wheel’s stub
axle into the hole in
the rear dropout. If
the axle does not
slide in easily,
loosen the quick
release adjusting
nut (Fig. 4) by hand.
Re-insert the axle fully into the rear dropout until the axle shoulder or
snap ring on the axle comes in contact with the dropout (Fig. 5). Move
the quick release lever to the closed position (Fig. 6). The word
CLOSE should be clearly visible and the quick release lever should
almost touch dropout.
Sun Canopy(s)
Seat Pockets
5 Point
Safety Harness
Foot Well
Fender &
Brake
Assembly
Anatomy of the
Pivot
Low Boy
BOB Duallie
Position 1
Position 2
Fig. 2
Swingarm in unfolded position
with shock in position 1.
Lever
Slider Latch
Fig. 3
Handlebar in the fully open position.
Quick Release
Open Position
Adjusting Nut
Fig. 4
Rear wheel Quick Release with
lever in open position.
Fig. 1
Shock
Release
Button
Lever In
