BOB DUALLIE Owner's Manual

CONGRATULATIONS on getting “BOB’d”! (becoming the
new owner of a BOB Product). BOB is a company that
produces high quality products, which encourage a healthy,
outdoor, car-free lifestyle. In addition to strollers, we also
make single-wheeled cargo trailers for bicycles. See
www.bobtrailers.com for our complete line of products. Before
attempting to assemble or use your new stroller, read and
understand these operating instructions completely to insure
proper assembly and operation. This manual covers assembly,
use, and maintenance instructions.
Thanks for getting BOB’d !!
Features:
2 position shock absorbers for light or heavy loads
padded, individual reclining seat backs
detachable, washable seat
2 hand position handle bars
light weight cro-moly/aluminum alloy frame
multi-position sun canopy
large storage compartments
quick release wheels
quick fold, compact design: folds with wheels attached or removed
WARNINGS
Before using this BOB stroller read and understand this manual in its
entirety for assembly, use, and safety instructions. If you are unclear
on any point, contact your dealer or BOB before use.
Never leave children unattended in the stroller.
Failure to properly assemble or install the quick release hubs on
this stroller may result in the wheels becoming detached while
moving and a subsequent loss of control of the stroller.
Always use seat harnesses to avoid serious injury to children from
sliding or falling out of stroller.
Always use wrist safety strap.
Never allow occupants to stand in stroller.
The parking brake is not designed as a stopping brake. We do
not recommend using the brake to stop the stroller when it is
moving. The brake is intended to park the stroller on flat surfaces
not on inclines. Never leave your children in the stroller unattended
with or without the parking brake set!
Do not strap parcels or bags to the handle as it affects the balance
and stability of the stroller and can cause it to tip over backwards.
The maximum carrying capacity load of the stroller is 100 pounds.
Do not place sharp objects in the seatback pocket as your child
leans against this and can be injured as a result.
When starting out, always make sure that your kid’s hands and
feet are away from wheel spokes.
The Duallie is not equipped for use after dark. If you intend to
use it at night, we recommend installing wheel reflectors and a
lighting system available through your local bike shop.
We do not recommend wearing roller skates or inline skates while
pushing stroller.
AGE RECOMMENDATIONS
child be a minimum of 6 to 8 weeks old before riding in the stroller.
Young babies incapable of holding their head up must be provided
additional head and neck support to ride safely. For jogging and off
road use, children should be at least 6 to 8 months old.
Children develop at different rates. Consult with your pediatrician
regarding the suitability of the stroller use with your child.
ASSEMBLY INSTRUCTIONS:
NOTE: BOB IS NOT RESPONSIBLE FOR INJURY, DAMAGE, OR
FAILURE THAT RESULTS FROM OWNER’S FAULTY ASSEMBLY
OR MAINTENANCE AFTER SHIPPING.
Reference Fig. 1 as it describes the various parts of the Duallie.
DUALLIE OWNER’S MANUAL
Seat Back
Pocket
Seat Recline
Adjusters
Release Button
- It is recommended that your
Handle Bar Seat Tensioning
Strap
& Brake Lever
Clasp
Shock
Absorber
Shock
A.F.O.D.
Swing Arm
Anatomy of the BOB Duallie
1
SWINGARM: Rotate the
swingarm, away from the front of
the stroller until the shocks
engage in the first position as
shown in Fig. 2. The shocks’
locking pins will “snap” and lock
into position.
2
HANDLE: Rotate the stroller
handle up to the fully open
position and secure the clasps as
shown in Fig. 3. To secure the
clasps, rotate them towards the
ground until they “snap” into place.
3
MULTI-POSITION SUN CANOPY:
To open the sun canopy, hold one
support in each hand and rotate them
away from one another until the
canopy is fully opened. The
canopy has a spring-loaded
adjustment system and will click
in place as it reaches each new
position.
4 AFOD: With the stroller in the
opened position, attach the
AFOD (Anti-Fly-Out-Device) around
the cross tube with the plastic
buckle, as shown in Fig. 4. It is
important that the AFOD is
always properly secured, as it is
part of the child’s seat restraint
system.
5
FENDER
INSTALLATION:
Before installing
the front wheel in
step 6, you will
need to attach the
fender. The two
attachment screws
can be found
already installed
Fig. 4
on the frame.
Remove the two
Sun Canopy
Seat Pockets
5 Point
Safety Harness
Foot Well
Brake Cable
Fender &
Assembly
Swing Arm
Pivot
Low Boy
Fig. 1
position #1
position #2
Fig. 2
Swingarm in unfolded position
with shock in position #1
Clasp
Fig. 3
Stroller with handle in the unfolded
position and clasps shut.
AFOD
Cross Tube
AFOD correctly attached
Brake
