DFI E586-ICP User Manual

System board
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
E586-ICP
E586-IPE

System Board

User' s Manual
- D23540520 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E586-ICP and is the answer not in the manual?

Questions and answers

Related Manuals for DFI E586-ICP

Summary of Contents for DFI E586-ICP

  • Page 1: System Board

    E586-ICP E586-IPE System Board User’ s Manual - D23540520 -...
  • Page 2 No part of this document may be copied or reproduced in any form or by any means without the prior written consent of DFI, Inc. DFI, Inc. makes no warranties with respect to this documentation and disclaims any implied warranties of merchantability, quality, or fitness for any particular purpose.
  • Page 3 v FCC Statement on Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interfer- ence when the equipment is operated in a residential installation.

  • Page 4: Table Of Contents

    v Table of Contents v Introduction ................. Features and Specifications ..........Package Checklist ..............Installation Overview ..............Preparing the Area ..............Handling the System Board ..........Tips in Handling the System Board ....... Hardware Installation ............. Memory Installation ............Installing the Modules ..........Board Configuration ............
  • Page 5 EISA Configuration Utility ............Troubleshooting Checklist ............Appendix A: Types of Modules ..........Appendix B: System Error Report ......... Appendix C: Memory & I/O Maps ........... Appendix D: EISA I/O Pin Assignments ........ Appendix E: PCI I/O Pin Assignments ........Appendix F: Connector Pin Assignments ......
  • Page 6 This page left intentionally blank.

  • Page 7: Read Me First

    Read Me First The E586-ICP/E586-IPE system board requires the installation of the ECU (EISA Configuration Utility), found on the provided EISA Configuration Utility diskette, for proper operation of this system board. The ECU configures the EISA devices and maintains system...

  • Page 8: Introduction

    BIOS which can be erased in bulk or modified using a software utility. The E586-ICP/E586-IPE comes with an EISA Configu- ration Utility (ECU) that must be installed and run to configure the board and the EISA expansion boards that will be inserted in the EISA expansion slots.

  • Page 9: Features And Specifications

    • BIOS Award system BIOS • Cache Memory 256K or 512K Burst (sync) SRAM for 3-1-1-1 Level 2 cache access (E586-ICP) 256K or 512K Async SRAM for 3-2-2-2 Level 2 cache access (E586-IPE) Supports direct map write-back or write-through cache subsystem Integrated cache tag RAM •...

  • Page 10: Package Checklist

    • Tooling Holes Baby AT form factor • PCB 4 layers Package Checklist The E586-ICP/E586-IPE package contains the following items: • The E586-ICP/E586-IPE system board • The E586-ICP/E586-IPE user’ s manual • One EISA Configuration Utility diskette • One DB-25S hole cover holding the PS/2 mouse port •...

  • Page 11: Installation Overview

    E586-ICP/E586-IPE v Installation Overview This chapter summarizes the steps in installing the E586-ICP/E586-IPE system board into your system unit. It also includes a description of the area in which you must work and directions for memory installation. Before installing the system board, obtain the memory you plan to install.

  • Page 12: Handling The System Board

    Hold modules and connectors by their ends. Hardware Installation Memory Installation The E586-ICP/E586-IPE system board can support 2MB to 128MB of memory using HSIMMs. HSIMM is an acronym for High Density Single In-line Memory Mod- ule. 2-2 u Installation Overview...
  • Page 13 An HSIMM connects to the system board via a 72-pin card-edge connector. The HSIMM sockets are divided into two banks on the system board. The E586-ICP/E586-IPE system board uses 256Kx36, 512Kx36, 1Mx36, 2Mx36, 4Mx36 and 8Mx36 HSIM modules.
  • Page 14 EISA/PCI System Board Memory Size Bank 1 Bank 2 10MB 256Kx36 1Mx36 10MB 1Mx36 256Kx36 12MB 512Kx36 1Mx36 12MB 1Mx36 512Kx36 16MB 1Mx36 1Mx36 16MB 2Mx36 18MB 256Kx36 2Mx36 18MB 2Mx36 256Kx36 20MB 512Kx36 2Mx36 20MB 2Mx36 512Kx36 24MB 1Mx36 2Mx36 24MB 2Mx36...
  • Page 15 E586-ICP/E586-IPE 82433LX 82433LX Bank 2 Bank 1 Pin 1 of the HSIMM socket SL82C101P 82434 82375 Socket 82374 Locations of the HSIMM Sockets on the System Board Installation Overview u 2-5...

  • Page 16: Installing The Modules

    EISA/PCI System Board Installing the Modules HSIMMs simply snap into a socket on the system board. Pin 1 of the HSIMM must correspond with Pin 1 of the socket. 1. Position the HSIM module above the HSIMM socket with the chips of the module facing the center of the system board.

  • Page 17: Board Configuration

    E586-ICP/E586-IPE Board Configuration The E586-ICP/E586-IPE is designed with jumpers and connectors onboard. Make sure that the jumpers are set correctly before installing the system board into your system unit. JP22 JP24 JP23 82433LX 82433LX JP18 SL82C101P JP10 JP27 JP15 JP25...
  • Page 18 EISA/PCI System Board JP22 JP23 82433LX 82433LX JP17 SL82C101P JP10 JP15 JP18 PCI Slot - Slave 82434 JP70 JP12 PCI Slot - Master/Slave JP16 PCI Slot - Master/Slave 82375 PCI Slot - Master/Slave Socket EISA Slot 82374 JP11 EISA Slot JP14 EISA Slot JP13...

  • Page 19: Jumper Settings

    E586-ICP/E586-IPE Jumper Settings Jumper JP1 PCI Edge-Triggered Interrupt Jumper JP1 is used to select the PCI edge-triggered interrupt of the E586-ICP/E586-IPE system board. Set JP1 according to the table shown below. 1-2 O n Int. A IRQ15 Int. A 3-4 O n...
  • Page 20 EISA/PCI System Board Jumpers JP3 and JP5 Built-in IDE The E586-ICP/E586-IPE system board is equipped with a built-in IDE disk interface, only if installed with the Symphony SL82C101P chip. Set JP5 to On to enable the built-in IDE. Set JP3 to On to disable the built-in IDE.
  • Page 21 E586-ICP/E586-IPE Jumper JP7 PS/2 Mouse The E586-ICP/E586-IPE package includes a DB-25S hole cover that holds the PS/2 mouse port. The PS/2 mouse port uses IRQ12. If you set Jumper JP7 to IRQ12 enable, make sure you connect the PS/2 mouse port to Connector J1.
  • Page 22 Jumper JP26 Flash EPROM Jumper JP26 should be set to match the type of Flash EPROM installed on the E586-ICP/E586-IPE system board. See page 2-7 and 2-8 for the location of the Flash EPROM installed on your system board. 2-3 On: Normal EPROM...

  • Page 23: Cache Configuration

    The system board supports direct map write-back or write-through cache subsystem with tag RAM integrated into the chipset. The E586-ICP uses Burst SRAM for fast 3-1-1-1 Level 2 cache access. The E586-IPE uses Async SRAM for 3-2-2-2 Level 2 cache access.
  • Page 24 EISA/PCI System Board SRAM SRAM 82433LX 82433LX SRAM SRAM SRAM SRAM SL82C101P SRAM SRAM 82434 82375 Socket 82374 Locations of the SRAMs on the E586-IPE System Board 2-14 u Installation Overview...

  • Page 25: Jumper Settings For Cache Memory

    JP15 as shown below. On: Write Through Off: Write Back (Default) Jumpers JP22 and JP23 Level 2 Cache If you have upgraded the cache size of your E586-ICP/ E586-IPE system board, change Jumpers JP22 and JP23 as shown below. JP23 L2 Cache JP22...

  • Page 26: Cpu Installation

    Make sure the jumpers are set correctly before applying power, or you may damage the CPU or system board. 82433LX 82433LX SL82C101P 82434 82375 Socket 82374 Location of Pin 1 Location of the ZIF Socket on the E586-ICP/E586-IPE System Board 2-16 u Installation Overview...

  • Page 27: Jumper Settings For Cpu

    Reconfiguring these jumpers will cause problems with your E586-ICP or E586-IPE system board. JP10: 2-3 On JP12: On JP14 and JP16 : Off JP17 and JP70: Off (E586-IPE) JP19-JP21, JP24 & JP25: 2-3 On (E586-ICP) JP27: Off (E586-ICP) Installation Overview u 2-17...

  • Page 28: Installing Upgrade Cpus

    EISA/PCI System Board Installing Upgrade CPUs The E586-ICP/E586-IPE is equipped with a 273-pin Zero Insertion Force (ZIF) socket at location U29 of the system board. Warning: Open the socket only if actually installing a CPU. The warranty on the original CPU will be voided if the S/N seal is broken.
  • Page 29 E586-ICP/E586-IPE To install, simply move the handle upward. Remove the original CPU from the socket. Position the CPU above the socket. Make sure pin 1 of the CPU is aligned with pin 1 of the socket. Lower the chip until the pins are inserted properly in their corresponding holes.
  • Page 30 EISA/PCI System Board Lifting the Handle Positioning the CPU Above the ZIF Socket 2-20 u Installation Overview...
  • Page 31 E586-ICP/E586-IPE Gently push the handle down until the handle locks into place. You will hear a click when the handle is secure. When you want to remove the chip, simply lift the handle and remove the chip. Warning: The cables (floppy drive, hard drive, CD-ROM, etc.) must be routed clear of the CPU with a minimum of 0.25"...

  • Page 32: Installing The System Board

    EISA/PCI System Board Installing the System Board Before installing the system board into your system unit, you should prepare the tools you will use: You will need: • one medium size, flat-bladed screwdriver • one medium Philips screwdriver Step 1 Unlock your system unit.
  • Page 33 E586-ICP/E586-IPE Step 5 Insert the SIM modules into the SIMM banks on the E586-ICP/E586-IPE. The quantity and location of the SIM modules is dependent upon the memory configuration and type of modules you intend to use. Step 6 Set the corresponding jumpers.

  • Page 34: Installing The Ps/2 Mouse Port

    EISA/PCI System Board Installing the PS/2 Mouse Port The E586-ICP/E586-IPE package includes a DB-25S hole cover that holds the PS/2 mouse port attached with a ribbon cable. To install: 1. Use the two screws provided with the package to secure the DB-25S hole cover to the DB-25S hole normally found at the rear of a system chassis.

  • Page 35: Initial Setup Program

    E586-ICP/E586-IPE v Initial Setup Program After you power up your system, the BIOS message appears on your screen and the memory count begins. After the memory test, the following message will appear on the screen: Press CTRL-ALT-ESC/DEL to enter setup If the message disappears before you respond, restart your system or press the “Reset”...

  • Page 36: Award Bios Cmos Setup Utility

    EISA/PCI System Board Award BIOS CMOS Setup Utility Press <Ctrl> <Alt> <Esc> or <Del> to enter the Setup utility. A screen similar to the one below will appear. Use the arrow keys to highlight the option you want and press <Enter>. Standard CMOS Setup Use the arrow keys to highlight the “Standard CMOS Setup”...
  • Page 37 Drive C and Drive D If you have added a hard drive, you must select the appropriate type for the drive. The E586-ICP/E586-IPE has 46 pre-set types and one user-definable type. Use the <Page Up> or <Page Down> keys to select the appro- priate type for the drive.
  • Page 38 EISA/PCI System Board If none of the pre-set types is appropriate for your hard drive, choose “User”, which is the user-definable type. To use this type, highlight either hard disk C or D, depending on your hard drive configuration. Use the arrow keys until type “User”...

  • Page 39: Bios Features Setup

    E586-ICP/E586-IPE All, But Disk/Key: The system will stop for any errors except a keyboard or disk error. Memory The lower right hand corner shows the base memory size, extended memory size, expanded memory size and the other memory size of your system. You cannot alter these items;...
  • Page 40 EISA/PCI System Board The Virus Warning option may be set to “enabled” or “disabled”. When enabled, the BIOS issues a warning when any program or virus sends a Disk Format com- mand or attempts to write to the boot sector of the hard disk drive.

  • Page 41: Chipset Features Setup

    E586-ICP/E586-IPE Chipset Features Setup The E586-ICP/E586-IPE uses the Intel 82430 chipset. The Chipset Features Setup allows you to modify some functions to optimize system performance. If you press <Enter>, a screen similar to the one below will appear. Use the arrow keys to move the highlight bar to the option you wish to change or modify.

  • Page 42: Pci Slot Configuration

    EISA/PCI System Board PCI Slot Configuration Use the arrow keys to highlight the "PCI Slot Configura- tion" and press <Enter>, a screen similar to the one below will appear. The INT of each PCI slot must be set according to the INT of the PCI add-on card installed on the slot.

  • Page 43: Load Bios Defaults

    E586-ICP/E586-IPE Load BIOS Defaults If, for some reason, the CMOS becomes corrupted, the system can be reconfigured with the default values stored in the ROM chips. The BIOS Setup default values should provide optimum performance for the system. You should use these values unless you are possibly having hardware problems.

  • Page 44: Password Setting

    EISA/PCI System Board Password Setting If you want to set a password, make sure that the Security Option under the BIOS Features Setup is set to “System” or “Setup”. Refer to the BIOS Features Setup option for more information. Use the arrow keys to highlight the Password Setting option and press <Enter>.

  • Page 45: Ide Hdd Auto Detection

    E586-ICP/E586-IPE IDE HDD Auto Detection This option detects the hard disk parameters for the hard disk drives installed in your system. Highlight this option and press <Enter>. A screen similar to the one below will appear. The screen displays the parameters detected and allows you to accept or reject the parameters.

  • Page 46: Exit Without Saving

    EISA/PCI System Board Type “Y” and press <Enter>. The following message will appear: Reboot System (Y/N)? N Type “Y” and press <Enter>. The modifications you have made will be written into the CMOS memory, and the system will reboot. You will once again see the initial diagnostics on the screen.

  • Page 47: Eisa Configuration Utility

    E586-ICP/E586-IPE v EISA Configuration Utility Overview The E586-ICP/E586-IPE system board requires the use of the EISA Configuration Utility (ECU). The ECU is used to configure EISA (Extended Industry Standard Architecture) computer systems. EISA system boards and EISA adapter cards are much...

  • Page 48: Initial Configuration

    EISA/PCI System Board CMS File The CMS file contains a copy of the configuration information that is written into the system’ s Extended CMOS Memory. Each CMS file should have a corresponding INF file. INF File The INF file contains detailed information about a configuration such as switch and jumper settings, software statements, connection statements, and resource allocation.

  • Page 49: Main Menu

    E586-ICP/E586-IPE 2. Copy your EISA Configuration Utility diskette and the CFG files for all of your EISA boards to this directory. 3. To run the ECU, make sure that you are in the directory created in step 1 and type CFG.
  • Page 50 EISA/PCI System Board EISA CONFIGURATION UTILITY, Release 2.01 - (C)1992 American Megatrends Inc. Step 1: About EISA Configuration Step 2: Add and Remove Boards Step 3: Change Configuration Settings Step 4: Save Configuration Step 5: View Switch/Jumper Settings Step 6: Exit [Select=Enter] [Exit=Esc] [Help=F1]...
  • Page 51 Select the Board to Add Directory: A:\*.CFG !DFI0400.CFG - DFI E586-ICP/E586-IPE SYSTEM BOARD !DFI0300.CFG - DFI EB3486-TN EISA SYSTEM BOARD !DFI1001.CFG - DFI EISANet - 500 EtherNet Adapter !DFI0001.CFG - EISA SYSTEM BOARD !DFI0200.CFG - EISA SYSTEM BOARD [Select=ENTER] [Cancel=ESC]...
  • Page 52 Step 2 - Add and Remove Boards ISA Board Database Select the ISA board to load or press <Esc> to exit. System - DFI EB3486-TN EISA SYSTEM BOARD Slot 1 - Empty Slot 2 - Empty Slot 3 - Empty...
  • Page 53 E586-ICP/E586-IPE Step 2 Add and Remove Boards Adding a board Performing syntax check on "AMIFFF1.CFG System - DFI EB3486-TN EISA SYSTEM BOARD Slot 1 - Empty Slot Selection Slot 2 - Empty Slot 3 - Empty Select a slot for:...
  • Page 54 EISA/PCI System Board Step 2 Add and Remove Boards Confirm System - DFI EB3486-TN EISA SYSTEM BOARD Do you really want to remove: Slot 1 - Empty WG-1200VL Slot 2 - Empty Slot 3 - Empty Slot 4 - Empty...
  • Page 55 E586-ICP/E586-IPE Step 2 Add and Remove Boards System - DFI E586-ICP/E586-IPE SYSTEM BOARD Slot Selection Slot 1 - Empty Slot 2 - Empty Slot 3 - WG-1200VL Select a slot for: Slot 4 - Empty WG-1200VL Slot 5 - Empty Board slot type is ISA16.
  • Page 56 EISA/PCI System Board Step 3 Change Configuration Settings System - DFI E586-ICP/E586-IPE SYSTEM BOARD Slot 1 - DFI EISANet-500 EtherNet Adapter Slot 2 - Empty Slot 3 - Empty Slot 4 - Empty Slot 5 - Empty Slot 6 - Empty...
  • Page 57 E586-ICP/E586-IPE Edit Settings for: DFI E586-ICP/E586-IPE SYSTEM BOARD System Board Memory Functions System Board Memory Use SIMM Memory Module for the 486 System Board. ( ) 2MB ( ) 4MB ( ) 6MB ( ) 8MB ( ) 10MB ( ) 12MB...
  • Page 58 EISA/PCI System Board Edit Settings for: DFI EISANet-500 Ethernet Adapter DFI EISANet-500 I/O Addresses Slot-Specific Only (Default) DFI EISANet-500 EPROM EPROM Disabled (Default) Bus Master Bus Release After Preempt 23 BCLK Cycles DFI EISANet-500 Interrupt Interrupt Edge/Level Edge Triggered Interrupt...
  • Page 59 E586-ICP/E586-IPE Edit Settings for: DFI EISANet-500 Ethernet Adapter This board supports both slot-specific and ISA compatible I/O DFI EISANet-500 I/O Addresses addressing. The ISA mode should only be used for software Slot-Specific Only (Default) compatibility with ISA drivers. DFI EISANet-500 EPROM...

  • Page 60: Advanced Options

    Change Configuration Settings Advanced Options Global Resource Map Board Details System Details System - DFI EB3486-TN EISA SYSTEM BOARD Physical Board ID Map Slot 1 - DFI EISANet-500 Ethernet Adapter Slot 2 - Empty Slot 3 - Empty [Select=ENTER] [Done=ESC]...
  • Page 61 E586-ICP/E586-IPE Board Details This option informs you about the slot number, ID and the board slot type of a board. System Details This option allows you to view the slot type, the amperage used and EISA CMOS size of the boards installed in the system.
  • Page 62 EISA/PCI System Board Step 5: View Switch/Jumper Settings This step allows you to set DIP switches and jumpers on any board that is switch or jumper configurable. a. After saving the configuration, choose View Switch/ Jumper Settings if you want to configure the switch or jumper from your board.
  • Page 63 E586-ICP/E586-IPE Switch/Jumper View Page 1 of 6: Switches and Jumpers for Slot 0 Slot 0 - DFI E586-ICP/E586-IPE SYSTEM BOARD Confirm Print This board has no Print to: (•) Printer ( ) File Filename: Config. PRN Ok=ENTER Cancel=ESC [Done=ESC] [Print=F7]...
  • Page 64 EISA/PCI System Board Utilities Configuration This screen controls how a configuration is produced. Several options are available, each one can be enabled or disabled by pressing SPACE when an option is highlighted. To configure the Utilities: From the main menu, press <F9> and a Utilities box similar to the one shown below will appear.
  • Page 65 E586-ICP/E586-IPE If Remote Mode is on, the configuration will be stored in the files only. These files can be copied to another computer and the configuration can be copied to that system's EISA CMOS RAM using the “Restore configuration from backup” option on this screen.
  • Page 66 1. Choose Configure Define ISA Board and an ISA Board Definition box similar to the one shown below will appear. ISA Board Definition Board Name: WG-1200VL Manufacturer: DFI Board Type: Slot Type: ( ) 16 bit ( ) Video Board...
  • Page 67 E586-ICP/E586-IPE 2. Highlight “Board Name” and press <Enter>. The cursor will appear for you to type-in the name of the board. After typing-in the board name, press <Enter>. 3. Highlight “Manufacturer” and press <Enter>. The cursor will appear for you to type-in the name of the manufacturer.
  • Page 68 EISA/PCI System Board ISA Board Definition Board Name: WG-1200VL Manufacturer: DFI ISA DMA Definition Board Type: Slot Type: ( ) 16 bit ( ) Video Board ( ) 8 bit Channel: Size: ( ) Multifunction Board [ ] - [ ] Byte...
  • Page 69 E586-ICP/E586-IPE 7. “IRQ” allows you to define up to seven (7) IRQ levels. Select one of the IRQ options and press <Enter>. a. An ISA IRQ Definition box similar to the one shown below will appear. ISA Board Definition Board Name: WG-1200VL...
  • Page 70 Select one of the I/O Port options and press <Enter>. The ISA Port Definition box similar to the one shown below will appear. ISA Board Definition Board Name: WG-1200VL Manufacturer: DFI ISA Port Definition Board Type: Slot Type: ( ) 16 bit...
  • Page 71 E586-ICP/E586-IPE 9. “Memory” allows you to define up to eight (8) memory addresses. a. Select one of the Memory options and press <Enter>. An ISA Memory Definition box similar to the one shown below will appear. ISA Board Definition Board Name: WG-1200VL...
  • Page 72 ECU’ s internal ISA board database. An ISA Board Database box similar to the one shown below will appear. ISA Board Definition Board Name: WG-1200VL Manufacturer: DFI ISA Board Database Board Type: Slot Type: ( ) 16 bit...

  • Page 73: Troubleshooting Checklist

    E586-ICP/E586-IPE v Troubleshooting Checklist If you experience difficulty with the E586-ICP/E586-IPE system board, please refer to the checklist below. If you still cannot isolate the problem, please contact your dealer. 1) Check the jumper settings to ensure that the jumpers are properly set.

  • Page 74: Appendix A: Types Of Modules

    EISA/PCI System Board v Appendix A: Types of Modules The E586-ICP/E586-IPE system board allows you to populate memory with 256Kx36, 512Kx36, 1Mx36, 2Mx36, 4Mx36 and 8Mx36 HSIM modules. The follow- ing modules have been tested with this board. Most untested brands will work but a few may fail to do so.
  • Page 75 E586-ICP/E586-IPE For HSIM 2Mx36 Modules Brand Chip Number M511000B For HSIM 4Mx36 Modules Brand Chip Number M514100A-70S For HSIM 8Mx36 Modules Brand Chip Number M514100AL-70K Appendix A u...

  • Page 76: Appendix B: System Error Report

    EISA/PCI System Board v Appendix B: System Error Report POST (hex) Name Description Turn off chipset OEM specific-cache control. cache Processor status (1FLAGS) verification. Processor test 1 Test the following processor status flags carry, zero, sign, overflow. The BIOS will set each of these flags, verify they are set, then turn each flag off and verify it is off.
  • Page 77 E586-ICP/E586-IPE POST (hex) Name Description Chipset default Program chipset registers with power on initialization BIOS defaults. Memory presence OEM Specific-Test to size on-board test memory. Early shadow OEM Specific-Early Shadow enable for fast boot. Cache presence External cache size detection.
  • Page 78 EISA/PCI System Board POST (hex) Name Description Test DMA BIOS checksum test. controller 0 Keyboard detect and initialization. Test DMA controller 1 Test DMA page Test DMA page registers. registers 12-13 Reserved Test timer counter 2 Test 8254 timer 0 counter 2. Test 8259-1 mask Verify 8259 channel 1 masked interrupts by bits...
  • Page 79 E586-ICP/E586-IPE POST (hex) Name Description Enable slot 0 Initialize slot 0 (system board). 21-2F Enable slots 1 - 15 Initialize slots 1 through 15. Size base and Size base memory from 256K to 640K and extended memory extended memory above 1MB.
  • Page 80 EISA/PCI System Board POST (hex) Name Description Initialize hard drive Initialize hard drive controller and any drives. and controller Detect and initialize Initialize any serial and parallel ports (also serial/parallel ports game port). Reserved Detect and initialize Initialize math coprocessor. math coprocessor Reserved Reserved...
  • Page 81 E586-ICP/E586-IPE POST (hex) Name Description Setup NumLock Setup NumLock status according to Setup. Boot attempt Set low stack. Boot via INT 19h. Spurious If interrupt occurs in protected mode. Unclaimed NMI If unmasked NMI occurs, display Press F1 to disable NMI, F2 reboot.

  • Page 82: Appendix C: Memory & I/O Maps

    EISA/PCI System Board v Appendix C: Memory & I/O Maps Memory Address Map Address Name Function 0000000 to 640K System System Board Memory 009FFFF Board RAM 00A0000 to 128K Video Reserved for Graphics Display 00BFFFF Display Memory Memory 00C0000 to 192K I/O Reserved for ROM on I/O 00EFFFF...
  • Page 83 E586-ICP/E586-IPE I/O Address Map I/O Address Function 000-01F DMA Controller 1, 8237A-5 020-03F Interrupt Controller 1, 8259A, Master 040-05F Timer, 8254-2 060-06F 8742 (Keyboard Controller) 070-07F Real-time Clock, NMI (Non-maskable Interrupt) Mask 080-09F DMA Page Memory, 74LS612 0A0-08F Interrupt Controller 2, 8259A...

  • Page 84: Appendix D: Eisa I/O Pin Assignments

    EISA/PCI System Board v Appendix D: EISA I/O Pin Assignments 31 31 31 31 19 19 19 19 H D G C Note: Rows A, C, B and D are ISA contacts Rows E,G, F and H are EISA contacts D-1 u Appendix D...
  • Page 85 E586-ICP/E586-IPE I/O Pin Signal Name -CMD -Start Exrdy -EX32 Access Key -EX16 -SLBurst -MSBurst Reserved Reserved Reserved Access Key -BE1 -LA31 -LA30 -LA28 -LA27 -LA25 Access Key LA15 LA13 LA12 LA11 Power Power XXXXXX XXXXXX Access Key Appendix D u...
  • Page 86 EISA/PCI System Board I/O Pin Signal Name XXXXXX XXXXXX Power M-IO -Loc Reserved Reserved -BE3 Access Key -BE2 -BE0 Power -LA29 -LA26 -LA24 Access Key -LA16 -LA14 Power Power LA10 Access Key SD17 SD19 SD20 SD22 D-3 u Appendix D...
  • Page 87 E586-ICP/E586-IPE I/O Pin Signal Name SD25 SD26 SD28 Access Key SD30 SD31 MREQ Power Access Key SD16 SD18 SD21 SD23 SD24 SD27 Access Key SD29 Power Power M A K Appendix D u...

  • Page 88: Appendix E: Pci I/O Pin Assignments

    EISA/PCI System Board v Appendix E: PCI I/O Pin Assignments Component Side Solder Side -12V - 01 - TRST# +12V - 02 - Ground - 03 - - 04 - - 05 - - 06 - INTA# INTB# - 07 - INTC# INTD# - 08 -...

  • Page 89: Appendix F: Connector Pin Assignments

    E586-ICP/E586-IPE v Appendix F: Connector Pin Assignments Connector J1 PS/2 Mouse Connector Function Mouse Data Reserved Ground Mouse Clock Reserved Connector J2 (optional) IDE Hard Disk Drive Connector Function -Reset Ground Appendix F u...
  • Page 90 EISA/PCI System Board Function Ground Reserved Reserved Ground -IOW Ground -IOR Ground Reserved BALE Reserved Ground IRQ14 IOCS16 Reserved HCS0 HCS1 Ground F-2 u Appendix F...
  • Page 91 E586-ICP/E586-IPE Connector J3 IDE LED Function LED (+) LED (-) Connector J4 Keylock Connector Function LED Signal Reserved Ground Keylock Signal Ground Connector J6 Speaker Connector Function Signal Connector to Buzzer Ground Appendix F u...
  • Page 92 EISA/PCI System Board Connector J7 Reset Switch Connector Function Reset Ground Connector JP2 Legacy Connector Function IRQ1 IRQ5 IRQ14 IRQ15 IRQ6 IRQ7 IRQ8- IRQ9 IRQ10 IRQ11 IRQ12 IRQ3 IRQ4 F-4 u Appendix F...
  • Page 93 E586-ICP/E586-IPE Connector JP28 Fan Connector Function +12V Ground Ground Connectors PL1 and PL2 Power Connectors Function Power Good +12V -12V Ground Ground Ground Ground Appendix F u...

  • Page 94: Appendix G: Award Bios Hard Disk Table

    EISA/PCI System Board v Appendix G: Award BIOS Hard Disk Table Type Size Cylinders Heads Sectors Write Land Example (MB) Precomp Zone Model TEAC SD510, MMI 112, 5412 Seagate ST225, ST4026 None Seagate ST125, Tandon TM262 None Tandon TM 703 None None None...
  • Page 95 E586-ICP/E586-IPE Example Type Size Cylinders Heads Sectors Write Land (MB) Precomp Zone Model 1024 None 1023 Maxtor 1085, Micropolis 1325 None 1023 Maxtor 1105 1120, 4780 None 1023 Maxtor 1170 1024 None CDC 9415 1024 None 1023 1024 None 1023...
  • Page 96 E586-ICP/E586-IPE System Board User’ s Manual - 21840429 -...
