Summary of Contents for Certa CT18VCIRCSWA
- Page 2 General Tool Safety Warnings......................2 Work Area............................2 Electrical Safety..........................2 Personal Safety..........................3 Power Tool Use and Care......................3 Battery Tool Use and Care......................4 Additional Warnings Applicable for the Circular Saw...........4 Important Safety Instructions for Battery Charger............5 Important Safety Instructions for the Battery Pack............6 Symbols..............................6 Product Information.........................8 Layout..............................8...
- Page 3 Save all warnings and instructions for future reference. The term “power tool” refers to your mains operated (corded) power tool or battery-operated (cordless) power tool. 1. Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents. 2.
- Page 4 energizing power tools that have the switch on invites accidents. 4. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts. 5.
- Page 5 terminals together may cause burns or a fire. 5. Under abusive conditions, liquid may be ejected from the battery, avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns.
- Page 6 For all other sawing, the lower guard should operate automatically. • An unprotected, coasting blade will cause the saw to walk backwards, cutting whatever is in its path. Be aware of the time it takes for the blade to stop after switch is released. It is •...
- Page 7 — have them • replaced immediately. • Removing the battery pack will not reduce this risk. • The battery pack can explode in a fire. Toxic fumes and materials are created when lithium ion battery packs are burned. • Inserting or removing the battery from the charger may ignite the dust or fumes.
- Page 8 No load speed Rotational speed at no load …/min Revolutions or Revolutions, strokes, surface speed, reciprocation per minute orbits etc.. per minute Off position Zero speed, zero torque... Arrow Action in the direction of the arrow Direct current Type or a characteristic of current Read manual symbol Alerts user to refer to the manual Wear eye protection...
- Page 9 Battery Pack 1300mAh Li-ion Battery Pack Charging Time 1 hour Charger Adapter Input: 100-240V 50-60Hz Output: 21V 2A 1. Remove the battery pack (6) from the handle, press the battery release button (5) downwards to do so. 2. Check that your mains voltage is the same as that marked on the rating plate of the battery.
- Page 10 Assembling Saw Blade 1. Remove battery pack from saw. 2. Retract the lower guard (9). 3. Slip the saw blade onto the inner blade washer. 4. Replace the outer blade washer. 5. Depress the spindle lock button, then replace the blade screw. Turn the blade screw counter-clockwise with the blade wrench.
- Page 11 Your saw is equipped with a lock-off button (2) which reduces the possibility of accidental starting. The lock-off button is located on the handle above the switch trigger. You must depress the lock-off button in order to pull the switch trigger. The lock resets each time the trigger is released.
- Page 12 6. When the blade reaches full speed, slowly feed the blade into the work piece. 7. After you complete your cut, release the trigger and allow the blade to come to a complete stop. After the blade has stopped, you can remove it from the work piece.
- Page 13 Tool will not start. Battery pack not Check battery pack • • installed properly. installation. Battery pack not Check battery pack • • charged. charging requirements. Battery pack will Battery pack not Insert battery pack • • not charge. inserted into charger. into charger until red Charger not plugged LED appears.
