Connecting To Gate Controller; Other Wiring Tips; Powering Up - BFT Cellular Intercom System Installation & User Manual

Perform a final check of wiring and ensure the antenna is connected before switching on the
power. Once the power is switched on, the power LED should illuminate and the unit will emit a
series of bleeps and then stop after approx. 8 seconds.
Power LED
GSM LED
Searching
Network found
CPU LED
Standby
Busy
P a g e | 6
Connecting to a Gate Controller
GSM Cellular
controller
COM

Other Wiring Tips

Connecting DC magnetic
lock
GSM
Lock
output
Optional
keypad
Separate
output
PSU

Powering Up

GSM
modem
close
open
Intercom
Keypad
N/O COM N/O
Gate motor
controller
Connecting AC/DC strike
lock
GSM
output
Optional
keypad
output
TIPS:
My GSM LED is still searching / Unit Bleeping...
-Check SIM card is registered and can make call in cell
phone.
-Check the SIM card is seated correctly. Power off,
clean the contacts on the SIM and the GSM unit, and
reinsert the SIM. (Lightly sand).
-Check power cable distance and thickness.
-Change network.
-Fit a high gain antenna.
Lock
Separate
PSU
