Security Camera King NVR-LT-128 User Manual

128ch nvr
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
This is our highest end NVR and probably the highest end NVR on the market. With this NVR you can manage and record up to 128 IP
cameras. Of course, all of our IP cameras are compatible, but you can also use other ONVIF compliant IP cameras with it.
This NVR is in a 3U server case. It can hold up to 16 hot swap able hard drives of 3TB each for a total of 48TB internal storage! There
are 2 HDMI video output ports and 1 VGA port. This unit supports up to a total of 2 monitors. You can record up to 128 D1 resolution
IP cameras, or 64 x 720p IP cameras or 32 x 1080p (2 Megapixel) IP cameras. This high end unit uses multiple Intel Core i5 processors
and has an embedded LINUX operating system for incredible reliability. It comes with 4GB DDR3 ram which can be upgraded to 8GB.
This Network Video Recorded supports multiple RAID con gurations and has 4 separate Gigabit Ethernet ports which can each work
independently or together. All the great features of our NVRs are also packed into this unit including motion detection and alarm
inputs and outputs. The optional front cover supports a hot swappable 7" HD LCD monitor, there are 4 USB ports and 1 eSATA port
for back up.
***Please note that this item is available by special order only. The lead time from the order date is 14-28 days and this item is non
refundable, though it does come with our 3 year warranty****
1
yr
3
MP
Resolution
Warranty
Our units do not support PAL.
128ch NVR User's Manual
PTZ
Control
Motion
Activated
Recording
NVR-LT-128

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NVR-LT-128 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Security Camera King NVR-LT-128

Summary of Contents for Security Camera King NVR-LT-128

  • Page 1 128ch NVR User's Manual NVR-LT-128 Control Motion Activated Resolution Warranty Recording Our units do not support PAL. This is our highest end NVR and probably the highest end NVR on the market. With this NVR you can manage and record up to 128 IP cameras.

  • Page 2: Table Of Contents

    Table of Contents FEATURES AND SPECIFICATIONS..............1 Overview ..............................1 Features ..............................1 Specifications ............................2 OVERVIEW AND CONTROLS ................4 Front Panel ............................. 4 Rear Panel.............................. 5 Alarm Input and Output Connection ....................6 2.3.1 Alarm Input and Output Details....................... 6 2.3.2 Alarm Input Port ..........................
  • Page 3 3.4.5 Online Users ............................ 20 3.4.6 Remote Device Information......................20 Setting ..............................21 3.5.1 General............................. 22 3.5.2 Encode ............................. 23 3.5.3 Schedule ............................26 3.5.4 Network ............................27 3.5.5 Alarm..............................36 3.5.6 Detect ............................... 39 3.5.7 Display.............................. 43 3.5.8 Default .............................. 45 3.5.9 Remote Device..........................
  • Page 4 5.2.6 Color and More Setup ........................66 Configuration ............................68 5.3.1 System Information......................... 68 5.3.2 System Configuration ........................69 5.3.3 Advanced ............................85 5.3.4 Additional Function ......................... 94 Search ..............................94 Alarm ..............................97 About ..............................98 Log out ..............................99 APPENDIX H TOXIC OR HAZARDOUS MATERIALS OR ELEMENTS ....
  • Page 5 Welcome Thank you for purchasing our NVR! This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about this series NVR features and functions, as well as a detailed menu tree.
  • Page 6 Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation. 2．Transportation security Heavy stress, violent vibration or water splash are not allowed during transportation, storage and installation.

  • Page 7: Features And Specifications

    1 FEATURES AND SPECIFICATIONS 1.1 Overview This series product is designed for the management, storage and applications of high definition video data. It adopts the LINUX OS and professional customized hardware platform. It consists of several HDDs management systems, front-end high definition device management system, high definition analysis system, and large-capacity video storage system.

  • Page 8: Specifications

    1.3 Specifications Specifications 128-channel Series 64-channel Series Main Processor SandyBridge i5 Socket 1155- SandyBridge i3 Socket 1155- pin 32nm CPU pin 32nm CPU Operation System Embedded LINUX system Power Support hot swap Redundant dual ball bearing fan MTBF>100 thousand hours Support online replacement.
  • Page 9 Working Altitude -60m~3000m Dimensions 516.5mm(without length)×485mm(With ear)×133.2mm（L*W*H） Net Weight 20Kg (front panel:0.4Kg) Installation Mode Standard 19-inch rack installation...

  • Page 10: Overview And Controls

    2 Overview and Controls This section provides information about the rear panel. When you install this series NVR for the first time, please refer to this part first. 2.1 Front Panel The front panel is shown as below. See Figure 2-1. Figure 2-1 Please refer to the following sheet for detailed information.

  • Page 11: Rear Panel

    Please refer to the following sheet for detailed information. Name Function Power button Press it once to turn on the device. Press it for a long time to turn off the device (Usually we do not recommend). Press power button for a long time or pull out the power cable may result in device auto restart.

  • Page 12: Alarm Input And Output Connection

    The redundant power series rear panel is shown as in Figure 2-5. Figure 2-5 Please refer to the following sheet for rear panel button information. Function Function Power socket Video VGA output Audio Input eSATA port Audio output USB port Bidirectional talk input HDMI port Network port...

  • Page 13: Alarm Input Port

    Figure 2-6 Please refer to the following sheet and Figure 2-6 for detailed information. ALARM 1 to ALARM 16. The alarm becomes active in low voltage. 1，2，3，4，5， 6，7，8，9，10， 11，12，13，14， 15，16 Eight groups of normal open activation output (on/off button) 1-ON C，2- ON C， 3- ON C，4- ON C，5- ON C，6- ON C，7 - ON C，8-...

  • Page 14: Alarm Output Port

    2.3.3 Alarm Output Port Provide power to peripheral alarm device. To avoid overloading, please read the following relay parameters sheet carefully. RS485 A/B cable is for the A/B cable of the PTZ decoder. Relay Specification Silver Material of the touch Rating Rated switch capacity 30VDC 2A, 125VAC 1A...

  • Page 15: Overview Of Navigation And Controls

    3 Overview of Navigation and Controls Connect the device to the monitor and then connect a mouse and power cable. Click the power button at the front panel and then boot up the device to view the video output. You can use the mouse to implement some GUI operation.
  • Page 16 Preview control bar When you move your mouse on the top middle pane of the preview window, you can see the following preview control bar. See Figure 3-3. Figure 3-3 Please refer to the following sheet for detailed information. Main stream and extra Monitor source zoom in stream switch Front-end...
  • Page 17 ⑤：Record Search It is a shortcut search menu. Please refer to chapter 3.3 for detailed information. ⑥：Event Info The event information is shown as below. See Figure 3-6. It is for you to set the alarm information of current channel. Figure 3-6 ⑦：Network Setup It is the shortcut network setup button.

  • Page 18: Main Menu

    Figure 3-7 ⑩ ：HDD management It is the shortcut HDD management button. Please refer to chapter 3.6.1 for detailed information. 3.2 Main Menu After you logged in, the system main menu is shown as below. See Figure 3-8. There are total seven icons: search, Information, setting, remote device, backup, advanced and shutdown.

  • Page 19: Search & Playback

    Figure 3-8 3.3 Search & Playback Click search button in the main menu, or you can right click mouse and then select the Search item. Search interface is shown as below. See Figure 3-9. Please note the initial version does not support smart search, card number search and picture operation.
  • Page 20 window Support 1/4/9/16-window playback. Search Here you can select to search extra stream, main stream or picture. type Select play from read-write disk or play from thee peripheral devices. The blue highlighted date means there is picture or file. Otherwise, there is no picture or file.

  • Page 21: Information

    Smart search The volume of the playback Current series device does not support snapshoot function now. It is to display the record type and its period in current search criteria. In 4-window playback mode, there are corresponding four time bars. In other playback mode, there is only one time bar.

  • Page 22: Hdd Information

    Here is for you to view system information. There are total six items: HDD info, BPS (data stream statistics), log, Version, online user and remote device information. See Figure 3-10. Figure 3-10 3.4.1 HDD Information Here is to list hard disk type, total space, free space, and status. See Figure 3-11. ○...
  • Page 23 Figure 3-12 Parameter Function SATA 1-16： 1-16 here means current series product max supports 16 HDD Port HDDs. RAID：1-6 here means current series product max supports 6 SATA HDDs. When HDD is working properly, system is shown as O. . “_” means there is no HDD.

  • Page 24: Bps

    3.4.2 BPS Here is for you to view current video data stream (KB/s) and occupied hard disk storage (MB/h). See Figure 3-13. You can click PgUp/PgDn to view information of more channels. Figure 3-13 3.4.3 Log Here is for you to view system log file. System lists the following information. See Figure 3-14. Start time/end time: Pleased select start time and end time, then click search button.

  • Page 25: Version

    Figure 3-14 Figure 3-15 3.4.4 Version Here is for you to view some version information. See Figure 3-16. Please note the following interface is based on the 128-channel series product and it is for reference only. Channel Alarm in Alarm out System version: Build Date...

  • Page 26: Online Users

    Serial number Figure 3-16 3.4.5 Online Users Here is for you manage online users connected to the local device. See Figure 3-17. You can disconnect one user or block one user if you have proper system right. Figure 3-17 3.4.6 Remote Device Information Here you can view the channel status of the remote device, connection log and network balance information and etc.

  • Page 27: Setting

    Figure 3-18 Connection log: In this interface, you can search the IPC log information of the corresponding channel. It includes IPC online, offline and etc. See Figure 3-19. Figure 3-19 Network Balance: Here you can view network data transmission speed, receive speed. See Figure 3-20.

  • Page 28: General

    In main menu, highlight setting icon and double click mouse. System setting interface is shown as below. See Figure 3-21. Figure 3-21 Important Please note you need to have the proper right to implement the following operation. 3.5.1 General General setting includes the following items. See Figure 3-22. System time: Here is for you to set system time Date format: There are three types: YYYYY-MM-DD: MM-DD-YYYYY or DD-MM-YYYY.

  • Page 29: Encode

    Auto logout: Here is for you to set auto logout interval once login user remains inactive for a specified time. Value ranges from 0 to 60 minutes. Navigation bar: Check the box here, system displays the navigation bar on the interface. IPC Time Sync: You can input an interval here to synchronize the NVR time and IPC time.
  • Page 30 Channel: Select the channel you want. Type: Please select from the dropdown list. There are three options: regular/motion detect/alarm. You can set the various encode parameters for different record types. Compression: According to the front-end parameter, system supports MPEG4, MS_MPEG4, MPEG2, MPEG1, H263, MJPEG, FCC_MPEG4, H.264 and etc.
  • Page 31 Figure 3-25 Figure 3-26 Figure 3-27...

  • Page 32: Schedule

      Figure 3-28   Figure 3-29 3.5.3 Schedule In the main menu, from setting to schedule, you can go to schedule menu. See Figure 3-30. Channel: Please select the channel number first. You can select “all” if you want to set for the whole channels.

  • Page 33: Network

    Figure 3-30 Figure 3-31 3.5.3.1 Quick Setup Copy function allows you to copy one channel setup to another. After setting in channel 1, click Copy button, you can see current channel name is grey such as channel 1. Now you can select the channel you wan to paste such as channel 5/6/7.
  • Page 34 Load balance: In this mode, device uses bond0 to communicate with the external device. All cards are working now and bearing the network load. Their network load are general the same. The system is shown as offline once these cards are all offline. Important For the IP address of IPv6 version, default gateway, preferred DNS and alternate DNS, the input value shall be 128-digit.
  • Page 35 3.5.4.1 Network Setting Network setting interface is shown as in Figure 3-33. Please draw a circle to enable corresponding function and then double click current item to go to setup interface. Figure 3-33 3.5.4.2 IP Filter IP filter interface is shown as in Figure 3-34. You can add IP in the following list. System supports IPv4 and IPv6 both.
  • Page 36 Manual update: It allows you to synchronize the time with the server manually. Here is a sheet for your time zone setup. City /Region Name Time Zone London GMT+0 Berlin GMT+1 Cairo GMT+2 Moscow GMT+3 New Deli GMT+5 Bangkok GMT+7 Beijing (Hong Kong) GMT+8 Tokyo...
  • Page 37 -224.0.0.0-239.255.255.255 -“D” address space The higher four-bit of the first byte=”1110” Reserved local multiple cast group address -224.0.0.0-224.0.0.255 -TTL=1 When sending out telegraph -For example 224.0.0.1 All systems in the sub-net 224.0.0.2 All routers in the sub-net 224.0.0.4 DVMRP router 224.0.0.5 OSPF router 224.0.0.13 PIMv2 router...
  • Page 38 You need a PC of fixed IP in the internet and there is the DDNS software running in this PC. In other words, this PC is a DNS (domain name server). In network DDNS, please select DDNS type and highlight enable item. And then please input your PPPoE name you get from you IPS and server IP (PC with DDNS).
  • Page 39 Except default domain name registration, you can also use customized domain name (You can input your self-defined domain name.) After successful registration, you can use domain name to login installed of the device IP. User name: It is optional. You can input your commonly used email address. Important Do not register frequently.
  • Page 40 Figure 3-39 Figure 3-40 3.5.4.8 Email The email interface is shown as below. See Figure 3-41. SMTP server: Please input your email SMTP server IP here. Port: Please input corresponding port value here. User name: Please input the user name to login the sender email box. Password: Please input the corresponding password here.
  • Page 41 can see the corresponding dialogue box to see the email connection is OK or not. See Figure 3-42. Please note system will not send out the email immediately when the alarm occurs. When the alarm, motion detection or the abnormity event activates the email, system sends out the email according to the interval you specified here.

  • Page 42: Alarm

    Figure 3-43 3.5.5 Alarm In the main menu, from Setting to Alarm, you can see alarm setup interface. See Figure 3-44. Alarm in: Here is for you to select channel number. Event type: There are four types. Local input/IPC external/IPC offline alarm. Local input alarm: The alarm signal system detects from the alarm input port.
  • Page 43 and etc will not be activated. For example, if you set the anti-dither time as 10 second, you can see the each activation may last 10s if the local alarm is activated. During the process, if system detects another local alarm signal at the fifth second, the buzzer, tour, PTZ activation, snapshot, record channel will begin another 10s while the screen prompt, alarm upload, email will not be activated again.
  • Page 44 Figure 3-44 Figure 3-45 Figure 3-46...

  • Page 45: Detect

    Figure 3-47 3.5.6 Detect Go to Detect Menu In the main menu, from Setting to Detect, you can see motion detect interface. See Figure 3-48.There is three detection types: motion detection, video loss, camera masking. The video loss has no detection region and sensitivity setup and camera masking has no detection region setup.
  • Page 46 Alarm upload: System can upload the alarm signal to the network (including alarm centre) if you enabled current function. Send email: System can send out email to alert you when alarm occurs. Record channel: System auto activates motion detection channel(s) to record once an alarm occurs.
  • Page 47 Figure 3-49 Figure 3-50 Figure 3-51...
  • Page 48 Figure 3-52 Video Loss In Figure 3-48, select video loss from the type list. You can see the interface is shown as in Figure 3-53.This function allows you to be informed when video loss phenomenon occurred. You can enable alarm output channel and then enable show message function. Tips: You can enable preset/tour/pattern activation operation when video loss occurs.

  • Page 49: Display

    Figure 3-54 3.5.7 Display Display setup interface is shown as below. See Figure 3-55 (general series) and Figure 3-56 (With HD decode card series). You can see there are decode parameters setup for the HD decode card series product. Channel name: Here is for you to modify channel name. System max support 25-digit (The value may vary due to different series).
  • Page 50 Figure 3-55 Figure 3-56 In Figure 3-55 or Figure 3-56, click modify button after channel. You can see an interface shown as in Figure 3-57. Click PgUp/PgDn to view more channels. Please note all your modification here applies to local end only. You need to refresh web or client-end to get the latest channel name.

  • Page 51: Default

    Figure 3-57 In tour mode, you can see the following interface. On the right corner, right click mouse, you can control the tour. There are two icons: stands for enabling window switch and stands for disabling window function. See Figure 3-58. Figure 3-58 3.5.8 Default...

  • Page 52: Remote Device

    3.5.9 Remote Device In the main menu, click the Remote Device icon to go to the corresponding interface. The remote device interface is shown as in Figure 3-59. Device search: Click it to search IP address. Add: Click it to connect to the selected device and add it to the Added device list. Support Batch add.

  • Page 53: Advanced

    Figure 3-60 3.6 Advanced Double click advanced icon in the main window, the interface is shown as below. See Figure 3-61.There are total eight function keys: HDD management, alarm output, abnormity, manual record, account, auto maintenance, configuration backup and RAID management. Figure 3-61 3.6.1 HDD Management Here is for you to view and implement hard disk management.
  • Page 54 Alarm set: Click alarm set button, the interface is shown as below. See Figure 3-63. (This interface is just like the abnormity setup). Please refer to chapter 3.6.2 for detailed information. HDD operation: You can select HDD mode from the dropdown list such as read-only or you can erase all data in the HDD.
  • Page 55 HDD Group is only available for read-write HDD, other types of hard disks cannot be set as HDD Group. Important: Current series software version can only set the HDD group operation of the read-write HDDs. It is not for the redundancy HDD. HDD Setting Click the button “HDD Setting”...

  • Page 56: Abnormity

    Once you change the HDD Group settings, system will pack the records and then begin record again! After you removed one HDD channel group, corresponding channel record will be saved on the HDD of the same group. Figure 3-65 3.6.2 Abnormity Abnormity interface is shown as in Figure 3-66.

  • Page 57: Alarm Output

    3.6.3 Alarm Output Here is for you to set proper alarm output. Please highlight icon to select the corresponding alarm output. After all the setups please click OK button, system goes back to the previous menu. See Figure 3-67. Figure 3-67 3.6.4 Manual Record Note:...
  • Page 58 3.6.4.3 Enable/disable record Please check current channel status: “○” means it is not in recording status, “●” means it is in recording status. You can use mouse or direction key to highlight channel number. See Figure 3-69. Figure 3-69 3.6.4.4 Enable all channel recording Highlight ○...

  • Page 59: Account

    Figure 3-71 3.6.4.5 Stop all channel recording Please highlight “ALL” after “Stop”. See Figure 3-72. System stops all channel recording no matter what mode you have set in the menu (Main menu->Setting->Schedule) Figure 3-72 3.6.5 Account Here is for you to implement account management. See Figure 3-73. Here you can: Add new user Modify user Add group...
  • Page 60 The user name and group name can consist of eight bytes. One name can only be used once. There are four default users: admin/888888/666666 and hidden user “default”. Except user 6666, other users have administrator right. Hidden user “default” is for system interior use only and can not be deleted. When there is no login user, hidden user “default”...

  • Page 61: Auto Maintenance

    3.6.5.2 Add/Modify Group Click add group button, the interface is shown as below. See Figure 3-75. Here you can input group name and then input some memo information if necessary. There are total 29 rights. The modify group interface is similar to the Figure 3-75. Figure 3-75 3.6.5.3 Add/Modify User Click add user button, the interface is shown as in Figure 3-76.

  • Page 62: Config Backup

    Here you can set auto-reboot time and auto-delete old files setup. You can set to delete the files for the specified days. See Figure 3-77. You can select proper setup from dropdown list. After all the setups please click save button, system goes back to the previous menu. Figure 3-77 3.6.7 Config Backup The configuration file backup interface is shown as below.

  • Page 63: Shutdown

    Figure 3-79 Click Hotspare management button in Figure 3-79, you can go to the following interface to add or delete hotspare disk. See Figure 3-80. Figure 3-80 3.7 Shutdown Double click shutdown button, system pops up a dialogue box for you to select. See Figure 3-81. Logout menu user: log out menu.
  • Page 64 Please note, sometimes you need to input the proper password to shut down the device. Figure 3-81...

  • Page 65: System Upgrade

    4 System Upgrade There are two ways for you to update the NVR: you can use update tool of the Windows or the flash drive. Please visit our website or contact our technical engineer to get the update tool for Windows. You can use NVR upgrade or ConfigTool.

  • Page 66: Web Operation

    5 WEB OPERATION 5.1 General Introduction The device web provides channel monitor menu tree, search, alarm setup, system setup, PTZ control and monitor window. 5.1.1 Preparation Before log in, please make sure: PC and NVR connection is OK. You have set PC IP address, NVR IP address, subnet mask and gateway. (Please set the IP address of the same section for the PC and NVR.

  • Page 67: Main Interface

    Figure 5-2 IE Safety Setup After installation, the interface is shown as below. See Figure 5-3. Figure 5-3 Login interface Please input your user name and password. Default factory name is admin and password is admin. Note: For security reasons, please modify your password after you first login. 5.2 Main Interface NVR web main interface is shown as in Figure 5-4.

  • Page 68: Monitor Channel Menu Tree

    ② ③ ④ ① ⑤ ⑥ Figure 5-4 Main Interface There are six sections: Section 1: Monitor channel menu tree Section 2: System menu Section 3: PTZ control Section 4: Video setup and other setup Section 5: Preview window Section 6: Monitor window switch 5.2.1 Monitor Channel Menu Tree The monitor channel menu tree is shown as in Figure 5-5.
  • Page 69 Figure 5-5 Monitor Channel Menu Tree Please refer to the following sheet for detailed information. Parameter Function CAM 1 to CAM Channel 1 to channel 128(64). 128(64) Local play Click local play button to select file to play in PC. Refresh Click this button to refresh monitor channel name.

  • Page 70: System Menu

    Parameter Function 1: NVR IP address. Display device 2: Channel number. information 3: Bit stream. 4: Bit stream decode type. S1: Overlay. S2: Off stream. S3:GD1 H1: Overlay H2: off stream decoding from the display card. Click this button and then left drag the mouse in the zone Digital zoom to zoom in.

  • Page 71: Ptz Control

    Figure 5-9 Preview Window Switch 5.2.5 PTZ Control Before PTZ operation, please make sure you have properly set PTZ protocol. Here you can view direction keys, speed, zoom, focus, iris, preset, tour, pan, scan, pattern, aux close, and PTZ setup button. Please note: open menu/close menu/up/down/left/right/confirm/cancel buttons are for speed dome only.

  • Page 72: Color And More Setup

    Figure 5-11 PTZ Setup Please refer to the following sheet for PTZ setup information. Parameter Function Move the camera to you desired location and then click left limit Scan button. Then move the camera again and then click right limit button to set a right limit.
  • Page 73 Figure 5-12 Color Please refer to the following sheet for detailed information. Parameter Function Video It is to adjust monitor video Note: setup brightness. All the operation here applies to WEB end only. It is to adjust monitor video contrast ness.

  • Page 74: Configuration

    5.3 Configuration 5.3.1 System Information 5.3.1.1 Version Information Here you can view device hardware feature and software version information. Please note the following figure is based on our 128-channel series product and it is for reference only. See Figure 5-14. Figure 5-14 Version Information 5.3.1.2 HDD information Here you can view local storage status such as free capacity and total capacity.

  • Page 75: System Configuration

    5.3.1.3 Log Here you can view system log. See Figure 5-16. Figure 5-16 Log Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, data Type management, alarm event, record operation, user management, log clear and file operation.
  • Page 76 Figure 5-17 General Setup Figure 5-18 DST Figure 5-19 DST Please refer to the following sheet for detailed information. Parameter Function Here is for you to modify system time. Please click Save button after System your completed modification Time Sync PC You can click this button to save the system time as your PC current time.
  • Page 77 Please select separator such as – or /. Data Separator There are two options: 24-H and 12-H. Time Format Here you can set day night save time begin time and end time. See Figure 5-18and Figure 5-19. Language Here you can view the system current language. You can select from the dropdown list.
  • Page 78 For the main stream, recorded file only contains video by default. You need to draw a circle here to enable audio function. Audio / video For extra stream, you need to draw a circle to select the video first and then select the audio if necessary.
  • Page 79 Figure 5-22 Schedule Time Figure 5-23 Copy Figure 5-24...
  • Page 80 Please refer to the following sheet for detailed information. Parameter Function Please select a channel first. Channel Pre-record Please input pre-record value here. When alarm record or motion detection record occurs, system can record the several seconds video before activating the record operation into the file.
  • Page 81 Parameter Function Network mode It includes multiple-address, fault tolerance and load balance. Default card You need to select default network card if the network mode is multiple-address. Ethernet port You need to select Ethernet port here if the network mode is multiple-address.
  • Page 82 Figure 5-26 Network Parameter Function Remote Input the user name and password which ISP(Internet service supplier) PPPOE host provided and chose enable. Reboot system after configuration is saved and the device will auto connect to Internet. The IP address is the WAN IP. There are two conditions for reboot, 1.
  • Page 83 Figure 5-27 Email Please refer to the following sheet for detailed information. Parameter Function Input server address and then enable this function. SMTP Server You can also input the corresponding server domain name here, but you need to go to DNS interface (chapter 5.3.2.4.) to set the server IP that can parse the domain.
  • Page 84 Figure 5-28 DDNS Please refer to the following sheet for detailed information. Parameter Function Server Type You can select DDNS protocol from the dropdown list and then enable DDNS function. The private DDNS protocol means you use our self-defined private protocol to realize DDNS function. Server IP DDNS server IP address Server Port...
  • Page 85 3) Operation Before you use Quick DDNS, you need to enable this service and set proper server address, port value and domain name. Server address：www.quickddns.com Port number：80 Domain name：There are two modes: Default domain name and customized domain name. Except default domain name registration, you can also use customized domain name (You can input your self-defined domain name.) After successful registration, you can use domain name to login installed of the device IP.
  • Page 86 Parameter Function Time Zone Device current time zone. Update Interval Time update interval value. Alarm Centre Alarm centre interface is shown as below. See Figure 5-30. Please input alarm centre server IP, port number. Once there is an alarm occurred, system can notify the alarm centre as you specified here.
  • Page 87 5.3.2.5 Alarm Alarm setup interface is shown as in Figure 5-32. Figure 5-32 Alarm Setup Figure 5-33 PTZ Setup...
  • Page 88 Figure 5-34 Please refer to the following sheet for detailed information. Parameter Function Event type: There are four types. Local input/IPC external/IPC Event offline alarm. Type Local input alarm: The alarm signal system detects from the alarm input port. Network input alarm: It is the alarm signal from the network. IPC external alarm: It is the on-off alarm signal from the front-end device and can activate the local NVR.
  • Page 89 Parameter Function Relay Out Enable alarm activation function. You need to select alarm output port so that system can activate corresponding alarm device when alarm occurs. For 6-ch alarm output port device, the 6 channel is the controllable +12V output. System can delay the alarm output for specified time after alarm end Alarm The value ranges from 10 seconds to 300 seconds.
  • Page 90 Figure 5-35 Detect Please refer to the following sheet for detailed information. Parameter Function Event type Motion detect, video loss and video masking Channel select the channel to activate recording function System supports 6 levels. The sixth level has the highest Sensitivity sensitivity.

  • Page 91: Advanced

    Parameter Function Here you can set PTZ movement when alarm occurs. Such as PTZ activation go to preset, tour &pattern when there is an alarm. 5.3.2.2 Default & Backup Default: Restore factory default setup. You can select corresponding items. Backup: Export current configuration to local PC or import configuration from current PC. Please refer to Figure 5-36.
  • Page 92 Figure 5-37 HDD Management Please refer to the following sheet for detailed information. Parameter Function Format Clear data in the HDD. Read/write Set current HDD as read/write Read only Set current HDD as read. Redundant Set current HDD as redundant HHD. Recover Fix the HDD error.
  • Page 93 Click Hotspare management button in Figure 5-38, you can go to the following interface to add or delete hotspare disk. See Figure 5-41. Figure 5-39 5.3.3.3 Abnormaliity The interface is shown as in below. See Figure 5-40 and Figure 5-41. Figure 5-40 Abnormality -1...
  • Page 94 Figure 5-41 Abnormality -2 Please refer to the following sheet for detailed information. Parameter Function Event The abnormal events include: no disk, no space, disk error, offline, IP Type conflict. You need to check the box here to enable this function. Threshold: It refers to the HDD free space.
  • Page 95 Figure 5-42 Alarm I/O Configuration Important The alarm output port should not be connected to high power load directly (It shall be less than 1A) to avoid high current which may result in relay damage. Please use the co contactor to realize the connection between the alarm output port and the load.
  • Page 96 Figure 5-43 Record Please refer to the following sheet for detailed information. Parameter Function System enables auto record function as you set in schedule setup Schedule (chapter 5.3.2.3). Enable corresponding channel to record no matter what period Manual applied in the record setup. Stop current channel record no matter what period applied in the Stop record setup.
  • Page 97 Figure 5-44 Account Figure 5-45 Add user Please refer to the following sheet for detailed information. Parameter Function User Input the user name of the new established account. Reusable The reusable account means that this account can be used in more than one PC at the same time.
  • Page 98 Password Input the password of the new established account. Confirm Input the password of the new established account again. Group Select the group which the new account belongs to. Memo Memo about the new account Authority/All User can select all to entitle this account to all authorities or set authority of each item respectively.
  • Page 99 5.3.3.8 Auto Maintenance Here you can select auto reboot and auto delete old files interval from the dropdown list. See Figure 5-47. Figure 5-47 Auto Maintenance 5.3.3.9 Remote device Remote device interface is shown as in Figure 5-48. Figure 5-48 Remote device Please refer to the following sheet for detailed information.

  • Page 100: Additional Function

    Parameter Function Remote device Here you can see searched remote device name, IP address, TCP port information and manufacturer name. Channel Please select the local device channel number to connect to the remote device. You need to highlight the enable item to activate this function. Now you can see remote device type, IP address and etc.
  • Page 101 Please set record type, record date, window display mode and channel name. You can click the date on the right pane to select the date. The green highlighted date is system current date and the blue highlighted date means it has record files. Figure 5-50 Search Then please click search button, you can see the corresponding files in the list.
  • Page 102 Figure 5-52 Load more It is for you to search record or picture. You can select record channel, record type and record time to download. See Figure 5-53. Figure 5-53 Remote backup In Figure 5-53, there is a remote back pane at the left bottom of the pane. It allows you to backup the record or picture to your local USB storage media via the Web remotely.

  • Page 103: Alarm

    Figure 5-54 Now you can see system begins download and the download button becomes stop button. You can click it to terminate current operation. At the bottom of the interface, there is a process bar for your reference. 5.5 Alarm Click alarm function, you can see an interface is shown as in Figure 5-55.

  • Page 104: About

    Figure 5-55 Alarm Please refer to the following sheet for detailed information. Type Parameter Function Alarm Video loss System alarms when video loss occurs. Type Motion detection System alarms when motion detection alarm occurs, Disk full System alarms when disk is full. Disk error System alarms when disk error occurs.

  • Page 105: Log Out

    Figure 5-56 About 5.7 Log out Click log out button, you can go back to log in interface. See Figure 5-57. Figure 5-57 Alarm...
