Security Camera King NVR-ELE4ME-WS User Manual

Elite series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NVR-ELE4ME-WS
1
yr
PTZ
1080p
Control
View From
Motion
Resolution
Anywhere
Activated
Warranty
Recording

Advertisement

Table of Contents
loading

Related Manuals for Security Camera King NVR-ELE4ME-WS

Summary of Contents for Security Camera King NVR-ELE4ME-WS

  • Page 1 NVR-ELE4ME-WS 1080p Control View From Motion Resolution Anywhere Activated Warranty Recording...

  • Page 2: Table Of Contents

    Table of Contents Features and Specifications Overview Features Specifications Front Panel and Rear Panel Front Panel Rear Panel Alarm Connection Alarm Port 2.3.1 Alarm input port 2.3.2 Alarm input and output port 2.3.3 Alarm relay specifications 2.3.4 Bidirectional talk Device-end to PC-end 2.4.1 PC-end to the device-end 2.4.2...
  • Page 3 4.3.2 Navigation bar Preview Control Interface 4.3.3 Right Click Menu 4.3.4 4.3.5 Edit View (Sequence) Preview Display Effect Setup 4.3.6 Fisheye (Optional) 4.3.7 PTZ Settings 4.4.1 PTZ Control 4.4.2 Record File Playback and Search Instant Playback 4.6.1 4.6.2 Search Interface Smart Search Playback 4.6.3 Mark Playback...
  • Page 4 4.10.4 RS232 4.10.5 Broadcast 4.10.6 4.10.7 Auto Maintain Backup 4.10.8 Default 4.10.9 4.10.10 Update 4.11 Logout /Shutdown/Restart Web Operation General Introduction Preparation 5.1.1 Device Initialization 5.2.1 Log in Reset Password LAN Mode Real-time Monitor Image/Alarm-out 5.7.1 Image Alarm output 5.7.2 Zero-channel Encode WAN Login 5.10 Setup...
  • Page 5 5.15 Log out 5.16 Un-install Web Control Glossary Appendix A HDD Capacity Calculation Appendix B Compatible Network Camera List...
  • Page 6 Copyrights  Any or full contents of the user’s manual cannot be copied, transmitted, distributed, partially or wholly, by any means, without the prior written notice of us.  We or the third party may reserve the right of the product described in this user’s manual. Without the prior written approval of the corresponding party, any person cannot (including but not limited to) copy, distribute, amend, reverse compile, disassemble, engineering, rent, reverse engineer, reverse compile or disassemble the software.
  • Page 7 equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help.
  • Page 8 Welcome Thank you for purchasing our network video recorder! This user’s manual is designed to be a reference tool for your system. Please open the accessory bag to check. Contact your local retailer ASAP if something is missing or damaged in the bag. Important Safeguards and Warnings 1．Electrical safety ...
  • Page 9  Before installation, please open the package and check all the components are included.  Contact your local retailer ASAP if something is broken in your package. 7. Lithium battery  Improper battery use may result in fire, explosion, or personal injury! ...

  • Page 10: Features And Specifications

    1 Features and Specifications 1.1 Overview This series NVR is a high performance network video recorder. This series product support local preview, multiple-window display, recorded file local storage, remote control and mouse shortcut menu operation, and remote management and control function. This series product supports center storage, front-end storage and client-end storage.
  • Page 11  Through network, sending audio/video data compressed by IPC or NVS to client-ends, then the data will be decompressed and display.  Support max 128 connections at the same time. Network  Transmit audio/video data by HTTP, TCP, UDP, MULTICAST, Monitor RTP/RTCP and etc.

  • Page 12: Specifications

    1.3 Specifications Audio and Video Technical Specification IP Camera Input 4 Channel System Two-way Talk Main Processor Dual-core embedded processor Recording Embedded LINUX Operating System Compression H.264/MJPEG Display Resolution 5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P etc. Interface 1 HDMI, 1 VGA Record Rate 80Mbps Resolution...

  • Page 13: Front Panel And Rear Panel

    2 Front Panel and Rear Panel 2.1 Front Panel Figure 2-4 Please refer to the following sheet for front panel button information. Icon Name Function HDD status indicator The blue light is on when the HDD is malfunction. light Network status indicator The blue light is on when the network connection is light abnormal.
  • Page 14 2.2.8 Compact 1U Wireless Series The rear panel is shown as below. See Figure 2-35. Figure 2-35 Please refer to the following sheet for detailed information. Icon Name Function Power input Power socket. Input DC12V/2A. socket. 10M/100Mbps self-adaptive Ethernet port. Connect to Network port the network cable.

  • Page 15: Alarm Connection

    2.3 Alarm Connection 2.3.1 Alarm Port The alarm port is shown as below. See Figure 2-81. The following figure is based on the professional 2U series. Figure 2-81 Icon Function 1～16 ALARM1～ALARM16. The alarm becomes activated in the low level. Four NO activation output groups.

  • Page 16: Alarm Input And Output Port

    Figure 2-82 Note  There are two alarm input types: NO/NC.  When connect the ground port of the alarm device to the NVR, you can use any of the GND ports  Connect the NC port of the alarm device to the alarm input port (ALARM) of the NVR. ...

  • Page 17: Bidirectional Talk

    Between touches with different 1000VAC 1minute polarity Between touch and winding 1000VAC 1minute Between touches with same Surge voltage 1500V (10×160us) polarity Length of open 3ms max time 3ms max Length of close time Longevity Mechanical 50×106 (3Hz) Electrical 200×103 (0.5Hz) Temperature -40℃...

  • Page 18: Mouse Operation

    Login the Web and then enable the corresponding channel real-time monitor. Please refer to the above interface (Figure 2-83) to enable bidirectional talk. Listening Operation At the PC-end, speak via the speaker or the pickup, and then you can get the audio from the earphone or sound box at the device-end.

  • Page 19: Remote Control

    In multiple-window mode, double left click one channel to view in full-window. Double left click current video again to go back to previous multiple-window mode. Right click In real-time monitor mode, pops up shortcut menu. mouse Exit current menu without saving the modification. Press middle In numeral input box: Increase or decrease numeral value.
  • Page 20 Forward Various forward speeds normal speed playback. Slow play Multiple slow play speeds or normal playback. Next record In playback mode, playback the next video. Previous record In playback mode, playback the previous video. Play/Pause In pause mode, click this button to realize normal playback.
  • Page 21 In motion detection interface, working with direction keys to complete setup. In text mode, click it to delete character. 0-9 number key Input password, channel switch channel. Shift is the button to switch the input method.

  • Page 22: Device Installation

    3 Device Installation Note: All the installation and operations here should conform to your local electric safety rules. 3.1 Check Unpacked NVR When you receive the NVR from the forwarding agent, please check whether there is any visible damage. The protective materials used for the package of the NVR can protect most accidental clashes during transportation.
  • Page 23 horizontally . After the HDD is in the proper position, the columns on the two sides can lock the screw holes of the HDD to secure When you remove the HDD, please refer to the following figure to pull the spring up and then remove the HDD.
  • Page 24 3.3.3 Mini 1U/Compact 1U Series ○ ○ ○ . Loosen the screws of the upper Connect the one end of the Connect the other end of the cover and side panel. HDD data cable and the power HDD data cable and the power cable to the mainboard.
  • Page 25 ④ ⑤ Connect the HDD cable and power Put the cover in accordance with cable. the clip and then fix the screws on the rear panel and side panel. 3.3.5 1.5U Series ① Use the screwdriver to loose the screws of the rear ②...
  • Page 26 ① ①Use the screwdriver to loose the screws ② ②Put the HDD to the HDD bracket in of the rear panel and then remove the front the chassis and then line up the four cover. screws to the four holes in the HDD. Use the screwdriver to fix the screws firmly to secure HDD on the HDD bracket...
  • Page 27 ④Put the front panel back and use the key to fix ③ Put the HDD to the slot and adjust the handle to secure it. firmly. HDD Handle Installation ①Line up the handle to the HDD side (without ②Use the screwdriver to fix the handle on the the interface) HDD.

  • Page 28: Cd-Rom Installation

    ③Please pull the handle up when you are ④Put the HDD to the HDD box at the front inputing the HDD box in case the the handle panel of the device. . collides with the front panel 3.3.9 Beneficio Vertical 1U Series ①...
  • Page 29 ① Open top cover and then remove the ② Take off the bottom of the HDD bracket and CD-ROM HDD bracket bracket. ③ Fix the CD-ROM bracket at the HDD ④ Install a pair of the CD-ROM bracket. Please make bracket.

  • Page 30: Connection Sample

    ⑦ Put the bracket back. Please adjust the ⑧ Connect the SATA cable and power wire. CD-ROM to the proper position so that the button of the front panel is directly facing the pop-up button of the CD-ROM. ⑨ Secure the HDD bracket and put the top cover back.
  • Page 31 Figure 3-1 3.5.2 Entry-level smart 1U/ Entry-level smart 1U with 1 PoE port / Beneficio smart 1U / Beneficio smart 1U with 1 PoE port / Beneficio smart 1U with 8 PoE ports / Beneficio smart 1U with wireless/ Beneficio Smart 1U(S2)/ 4K smart 1U (S2) Series Please refer to Figure 3-2 for connection sample.
  • Page 32 Figure 3-2 3.5.3 Entry-level mini 1U / Entry-level mini 1U with 1 PoE port/ Beneficio mini 1U / Beneficio mini 1U with 1 PoE port / Beneficio mini 1U with 8 PoE ports Series Please refer to Figure 3-3 for connection sample. Here we take beneficio mini 1U as an example.
  • Page 33 Figure 3-3 3.5.4 Compact 1U Series Please refer to Figure 3-4 for connection sample.
  • Page 34 Figure 3-4 3.5.5 Compact 1U Wireless Series Please refer to Figure 3-5 for connection sample.
  • Page 35 Figure 3-5 3.5.6 Compact 1U（S2）/4K compact 1U (S2) Series Please refer to Figure 3-6 for connection sample. Please note the following figure is based on the compact 1U (S2) with 8 PoE ports series.
  • Page 36 Figure 3-6 3.5.7 Beneficio 1U (S2) Series Please refer to Figure 3-7 for connection sample. Please note the following figure is based on the 8 PoE ports series.
  • Page 37 Figure 3-7 3.5.8 Beneficio Entry-level 1U Series Please refer to Figure 3-8 for connection sample. Figure 3-8...
  • Page 38 3.5.9 Beneficio 1U / Beneficio 1U with 1 PoE port / Beneficio 1U with 8 PoE ports/ Beneficio 1U with 16 PoE ports/ Professional 4K 1U/ Professional 4K 1U with 8 PoE ports/ Professional 4K 1U with 16 PoE ports Series Please refer to Figure 3-9 for connection sample.
  • Page 39 Figure 3-10 3.5.11 Beneficio 4K 1U with 8 PoE ports/4K 1U (S2) with 4 PoE ports/4K 1U (S2) with 8 PoE ports/4K 1U (S2) with 16 PoE ports Series Please refer to Figure 3-11 for connection sample. The following figure is based on our beneficio 4K 1U with 8 PoE ports series product. Figure 3-11...
  • Page 40 3.5.12 Beneficio 4K 1.5U / Beneficio 4K 2U/ Professional 4K 1.5U/ Professional 4K 1.5U with 16 PoE ports/ Professional 4K 2U / Professional 4K 2U with 16 PoE ports Series Please refer to Figure 3-11 for connection sample. The following interface is based on the beneficio 4K 1.5U series product. Figure 3-12 3.5.13 Beneficio 1.5U / Beneficio 1.5U with 8 PoE ports / Beneficio 1.5U with 16 PoE ports/4K 1.5U (S2) Series...
  • Page 41 Figure 3-13 3.5.14 Beneficio 2U / Beneficio 2U with 16 PoE ports/4K 2U (S2) Series Please refer to Figure 3-14 for connection sample. The following interface is based on the beneficio 2U with 16PoE ports series product. Figure 3-14...
  • Page 42 3.5.15 Professional 1U Series Please refer to Figure 3-15 for connection sample. Figure 3-15 3.5.16 Professional 1U with 8 PoE ports Series Please refer to Figure 3-16 for connection sample.
  • Page 43 Figure 3-16 3.5.17 Professional 1.5U Series Please refer to Figure 3-17 for connection sample.
  • Page 44 Figure 3-17 3.5.18 Professional 1.5U with 8 PoE ports / Professional 1.5U with 16 PoE ports Series Please refer to Figure 3-18 for connection sample. The following figure is based on the professional 1.5U with 8 PoE ports series product.
  • Page 45 Figure 3-18 3.5.19 Professional 2U Series Please refer to Figure 3-19 for connection sample.
  • Page 46 Figure 3-19 3.5.20 Professional 2U with 16 PoE ports Series Please refer to Figure 3-20 for connection sample.
  • Page 47 Figure 3-20 3.5.21 Professional 2U with RAID series Please refer to Figure 3-21 for connection sample.
  • Page 48 Figure 3-21 3.5.22 Professional 3U Series Please refer to Figure 3-22 for connection sample.
  • Page 49 Figure 3-22 3.5.23 Professional 3U with two HDMI ports Series Please refer to Figure 3-23 for connection sample.
  • Page 50 Figure 3-23 3.5.24 Beneficio Vertical 1U Series Please refer to Figure 3-24 for connection sample.
  • Page 51 Figure 3-24...

  • Page 52: Local Basic Operation

    4 Local Basic Operation 4.1 Getting Started 4.1.1 Boot up and Shut down 4.1.1.1 Boot up Warning Before the boot up, please make sure:  For device security, please connect the NVR to the power adapter first and then connect the device to the power socket.
  • Page 53 Step 1 Boot up NVR. Device displays device initialization interface. See Figure 4-1. Figure 4-1 Step 2 Set login password of admin.  User name: The default user name is admin.  Password/confirm password: The password ranges from 8 to 32 digitals. It can contain letters, numbers and special characters (excluding “'”,“"”,“;”,“:”,“&”) .
  • Page 54 Figure 4-2 Step 4 Set unlock pattern. After set unlock pattern, device goes to password protection interrface. See Figure 4-3. Note  Device adopts unlock pattern to login by default if you have set pattern here. If there is no unlock pattern, please input the password to login.
  • Page 55 Figure 4-3 Step 5 Set security questions. Note  After setting the security questions here, you can use the email you input here or answer the security questions to reset admin password. Refer to chapter 4.1.3 Reset password for detailed information.

  • Page 56: Reset Password

    Device goes to startup wizard interface. Refer to chapter 4.1.4 Startup wizard for detailed information. Reset Password 4.1.3 If you forgot admin password, you can reset the password by email or by answering the security questions. Please follow the steps listed below. Step 1 Go to the device login interface.
  • Page 57 Figure 4-5 Step 2 Click  If you have not input email address information when you are initializing the device, the interface is shown as in Figure 4-6. Please input an email address and then click Next button, devices goes to Figure 4-7. ...
  • Page 58 Figure 4-7 Step 3 Reset login password. There are two ways to reset the password: Scan QR code and reset by email/security questions (local menu only)  Email In Figure 4-7, follow the prompts on the interface to scan the QR code, and then input the security code you get via the assigned email.
  • Page 59 Figure 4-8 Step 4 Click Next button. Device displays reset password interface. See Figure 4-9. Figure 4-9 Step 5 Input new password and then confirm. WARNING STRONG PASSWORD RECOMMENDED-For your device own safety, please create a strong password of your own choosing. The password shall be at least 8-digit containing at least two types of the following categories: letters, numbers and symbols.

  • Page 60: Startup Wizard

    recommend you change your password periodically especially in the high security system. Step 6 Click OK button to complete the setup. 4.1.4 Startup Wizard After you successfully initialize the device, it goes to startup wizard. Here you can quickly configure your device.
  • Page 61  If you have not set unlock pattern, device displays password login interface. See Figure 4-12. Figure 4-11 Figure 4-12 Step 3 Draw unlock pattern or input login password. Warning  The account becomes locked after five times login failure by default. After each login failure,...
  • Page 62 you can see the remaining login attempts.  Refer to chapter 4.7.11 (Main menu->Setting->Event->Abnormality->User) to set login attempt times (1-10) and account lock time (1 to 30 minutes). Step 4 Click OK button. Device goes to startup wizard, now you can quickly configure the device. 4.1.4.1 Smart Add When the network camera(s) and the device are in the same router or switch, you can use smart add function to add network cameras to the device.
  • Page 63 Figure 4-14 Figure 4-15 Step 2 Set network camera login password. WARNING...
  • Page 64 STRONG PASSWORD RECOMMENDED-For your device own safety, please create a strong password of your own choosing. The password shall be at least 8-digit containing at least two types of the following categories: letters, numbers and symbols. We also recommend you change your password periodically especially in the high security system.
  • Page 65 Figure 4-17 3) After complete DHCP function, device is automatically adding network camera to the corresponding channels. See Figure 4-18. Figure 4-18...
  • Page 66 4) Device pops up following dialog box after it successfully added network cameras. See Figure 4-19. Figure 4-19 Step 4 Click YES button to complete smart add operation. 4.1.4.2 General After you successfully logged in the startup wizard, device goes to General interface. Here you can set NVR basic information.
  • Page 67  Monitor channels when logout: Here you can set channels you want to view when your account has logged out. Click the button and then cancel the channel name box, you need to login to view the corresponding video. The channel window displays in preview interface.
  • Page 68 Note From Main menu->Setting->System->General->Date and time, you can go to the date and time interface.  System time: Here is for you to set system time  Date format: There are three types: YYYYY-MM-DD: MM-DD-YYYYY or DD-MM-YYYY.  Date separator: There are three denotations to separate date: dot, beeline and solidus. ...
  • Page 69 4.1.4.2.3 Holiday Here you can add, edit, delete holiday. After you successfully set holiday information, you can view holiday item on the record and snapshot period. Step 1 Click Holiday button. See Figure 4-22. Note From Main menu->Setting->System->General->Holiday, you can go to the holiday interface. Figure 4-22 Step 2 Click Add new holiday button, device displays the following interface.
  • Page 70 Figure 4-23 Step 3 Set holiday name, repeat mode and holiday mode. Note Click Add more to add new holiday information. Step 4 Click Add button, you can add current holiday to the list. Note  Click the dropdown list of the state; you can enable/disable holiday date. ...
  • Page 71 Figure 4-24 Step 2 Click , device display edit interface. See Figure 4-25.
  • Page 72 Figure 4-25 Step 3 Set parameters.  Network Mode : Includes multiple access, fault tolerance, and load balancing  Multiple-address mode: eth0 and eth1 operate separately. You can use the services such as HTTP, RTP service via etho0 or the eth1. Usually you need to set one default card (default setup is etho) to request the auto network service form the device-end such as DHCP, email, FTP and etc.
  • Page 73  Default gateway: Here you can input the default gateway. Please note system needs to check the validity of all IPv6 addresses. The IP address and the default gateway shall be in the same IP section. That is to say, the specified length of the subnet prefix shall have the same string.
  • Page 74 Warning Before use the P2P function, make sure the device has connected to the WAN. Please follow the steps listed below. Step 1 Click Next button. Enter P2P interface. See Figure 4-26. Note From main menu->Setting->Network->P2P, you can go to P2P interface. Figure 4-26 Step 2 Check the box to enable P2P function.
  • Page 75 Step 3 at the top left corner, you can see the main menu. Step 4 Tap Device manager button, you can use several modes (P2P/DDNS/IP and etc.) to add the device. Click to save current setup. Tap Start Live preview to view all-channel video from the connected device.
  • Page 76 Figure 4-28 Step 2 Set parameters  Channel: It is the device channel number. If you have not added the network camera, the channel number is shown as .  Status: Red circle ( ) means current channel has no video, green circle ( ) means current channel has video.
  • Page 77 Figure 4-29  Manual Add: Click Manual Add button, you can set the corresponding network camera information and then select the channel you want to add. See Figure 4-30.  Manufacturer: Please select from the dropdown list. Note Different series products may support different manufactures, please refer to the actual product.
  • Page 78  Channel No.: Input channel amount or click the Connect button to get the channel amount of the remote device. Note We recommend click Connect button to get remote device channel amount, the manual add operation may result in failure if the input channel amount is not right. ...
  • Page 79 4.1.4.6 Schedule 4.1.4.6.1 Schedule Record All channels are record continuously by default. You can set customized record period and record type. Step 1 Click Next button. Enter schedule interface. See Figure 4-31. Note From main menu->Setting->Schedule->Record, you can go to the record interface. Figure 4-31 Step 2 Set parameters.
  • Page 80  Pre-record: System can pre-record the video before the event occurs into the file. The value ranges from 1 to 30 seconds depending on the bit stream.  Redundancy: System supports redundancy backup function. It allows you backup recorded file in two disks. You can highlight Redundancy button to activate this function. Please note, before enable this function, please set at least one HDD as redundant.
  • Page 81 Note  When the record type is MD (motion detect), alarm, MD&Alarm, IVS, please enable the channel record function when corresponding alarm occurs. For example, when the alarm type is MD, from main menu->Setting->Event->Video Detect->Motion Detect, please select the record channel and enable record function. See Figure 4-35. ...
  • Page 82 Figure 4-36 Step 3 Click Apply button to save schedule record settings. Note Please enable auto record function so that the record plan can become activated. Refer to chapter 4.1.4.6.3 Record control for detailed information. 4.1.4.6.2 Schedule Snapshot It is to set schedule snapshot period. Step 1 Click Snapshot button, device goes to following interface.
  • Page 83 Figure 4-37 Step 2 Select a channel to set schedule snapshot. Step 3 Set snapshot type as schedule. Refer to chapter 4.2.5.3 Snapshot for detailed information. Step 4 Check the box to set alarm type. See Figure 4-38. Figure 4-38 Note ...
  • Page 84 Figure 4-39 Step 5 Refer to chapter 4.1.4.6.1 to set snapshot period. Step 6 Click Apply button to save snapshot plan. Note Please enable auto snapshot function so that the snapshot plan can become activated. Refer to chapter 4.1.4.6.3 Record control for detailed information. Step 7 Click Finish button, system pops up a dialogue box.

  • Page 85: Camera

    You need to have proper rights to implement the following operations. Please make sure the HDD has been properly installed. There are three ways for you to go to manual record menu.  Right click mouse and then select Manual->Record. ...
  • Page 86 Enter change IP interface. See Figure 4-42. Note Check the box before several cameras, change the IP addresses of several cameras at the same time. Figure 4-42 Step 2 Select IP mode. Check DHCP, there is no need to input IP address, subnet mask, and default gateway. Device automatically allocates the IP address to the camera.
  • Page 87 When change IP addresses of several devices at the same time, make sure the cameras user name and passwords are the same. 4.2.1.2 IP Export Device can export the Added device list to your local USB device. Step 1 Insert the USB device and then click the Export button. Enter the following interface.

  • Page 88: Remote Device Initialization

    Figure 4-44 Step 2 Select the import file and then click the OK button. System pops up a dialogue box to remind you successfully imported. Step 3 Click OK button to exit. Note If the imported IP has conflicted with current added device, system pops up a dialogue box to remind you.
  • Page 89 Step 2 Click Device Search and then click Uninitialized. Device displays camera(s) to be initialized. Step 3 Select a camera to be initialized and then click Initialize. Device displays password setup interface. See Figure 4-45 and Figure 4-46. Figure 4-45...
  • Page 90 Figure 4-46 Step 4 Set camera password.  Using NVR password and email: Check the box to use NVR current admin account and email information. There is no need to set password and email. Please go to step 7.  User name/password: The user name is admin.
  • Page 91 Figure 4-47 Step 6 Set email information. Email: Input an email address for reset password purpose. Note Cancel the box and then click Next or Skip if you do not want to input email information here. Step 7 Click Next button. Enter Change IP address interface.
  • Page 92 Figure 4-48 Step 8 Set camera IP address Check DHCP, there is no need to input IP address, subnet mask, and default gateway. Device automatically allocates the IP address to the camera. Check Static, and then input IP address, subnet mask, default gateway and incremental value. Note ...

  • Page 93: Short-Cut Menu To Add Camera

    Figure 4-49 Step 10 Click Finish to complete the setup. 4.2.3 Short-Cut Menu to Add Camera In the preview interface, for the channel of no IPC connection, you can click the icon “+” in the center of the interface to quickly go to the registration interface (Figure 4-42.). See Figure 4-50. Figure 4-50 4.2.4 Image From main menu->setting->camera->image, you can see the image interface is shown as below.
  • Page 94  Brightness: It is to adjust monitor window bright. The value ranges from 0 to 100. The default value is 50. The larger the number is, the bright the video is. When you input the value here, th e bright section and the dark section of the video will be adjusted accordingly.

  • Page 95: Encode

    Figure 4-51 4.2.5 Encode 4.2.5.1 Encode Encode setting is to set IPC encode mode, resolution, bit stream type and etc From Main menu->Setting->System->Encode, you can see the following interface. See Figure 4-52.  Channel: Select the channel you want.  Type: Please select from the dropdown list.
  • Page 96 Please highlight icon to select the corresponding function. Figure 4-52 4.2.5.2 Overlay Click overlay button, you can see an interface is shown in Figure 4-53.  Cover area: Here is for you to cover area section. You can drag you mouse to set proper section size. In one channel video, system max supports 4 zones in one channel.
  • Page 97 Figure 4-53 4.2.5.3 Snapshot Here you can set snapshot mode, picture size, quality and frequency. See Figure 4-54.  Snapshot mode: There are two modes: regular and trigger. If you set regular mode, you need to set snapshot frequency. If you set trigger snapshot, you need to set snapshot activation operation. ...

  • Page 98: Channel Name

    Figure 4-54 Figure 4-55 4.2.6 Channel Name From main menu->Setting->Camera-Channel name, you can see an interface shown as in Figure 4-56. It is to modify channel name. It max supports 31-character. Please note you can only modify the channel name of the connected network camera.

  • Page 99: Remote Upgrade

    Figure 4-56 4.2.7 Remote Upgrade Note Right now, the NVR can upgrade the IPC via the USB device or WEB. You can upgrade 8 network cameras of the same model (or the NVR supported) at the same time. It is to update the network camera. From main menu->setting->camera->remote, the interface is shown as below.

  • Page 100: Remote Device Info

    Figure 4-57 4.2.8 Remote Device Info 4.2.8.1 Device Status Here you can view the IPC status of the corresponding channel such as motion detect, video loss, tampering, alarm and etc. See Figure 4-58.  IPC status: : Front-end does not support. : Front-end supports.
  • Page 101 Figure 4-58 4.2.8.2 Firmware It is to view channel, IP address, manufacturer, type, system version, SN, video input, audio input, external alarm and etc. See Figure 4-59. Figure 4-59...

  • Page 102: Preview

    4.3 Preview After device booted up, the system is in multiple-channel display mode. See Figure 4-60.Please note the displayed window amount may vary. The following figure is for reference only. Please refer to chapter 1.3 Specifications for the window-amount your product supported. Figure 4-60 4.3.1 Preview If you want to change system date and time, you can refer to general settings (Main...
  • Page 103 you cannot see the following interface. Figure 4-61 Figure 4-62 4.3.2.1 Main Menu Click button to go to the main menu interface. 4.3.2.2 Dual-screen operation Important This function is for some series only. Click to select screen 2, you can view an interface shown as below. See Figure 4-63. It is a navigation bar for screen 2.
  • Page 104 Click button to enable tour, the icon becomes , you can see the tour is in process. Note Close the tour or the triggered tour operation has cancelled, device restore the previous preview video. 4.3.2.6 PTZ Click , system goes to the PTZ control interface. Please refer to chapter 4.4.2 PTZ for detailed information.

  • Page 105: Preview Control Interface

    Figure 4-65 4.3.2.13 Registration Click , system goes to the registration interface. Please refer to chapter 4.1.4.6.3 Registration for detailed information. 4.3.2.14 Network Click , system goes to the network interface. It is to set network IP address, default gateway and etc. Please refer to chapter 4.8 Network for detailed information.
  • Page 106 Figure 4-66 Instant playback It is to playback the previous 5-60 minutes record of current channel. Please go to the Main menu->Setting->->System->General to set real-time playback time. System may pop up a dialogue box if there is no such record in current channel. Digital zoom It is to zoom in specified zone of current channel.

  • Page 107: Right Click Menu

    Figure 4-68 Right click mouse to cancel zoom and go back to the original interface. Manual record function It is to back up the video of current channel to the USB device. System cannot backup the vide o of multiple-channel at the same time. Click button , system begins recording.
  • Page 108  Window split mode: You can select window amount and then select channels.  Edit view (Sequence): Change channel display sequence on the preview window.  Customized screen: Set customized screen split mode.  PTZ: Click it to go to PTZ interface. ...

  • Page 109: Edit View (Sequence)

    Figure 4-70 4.3.5 Edit View (Sequence) It is to set customized view layout. Warning preview layout restores default channel layout after Default operation. (Main menu->Setting->General->Default). Step 1 On the preview interface, right click mouse and then click Edit view. Enter edit view interface. See Figure 4-71. Note Enter edit view interface, device automatically switches to the max split amount mode.
  • Page 110 Figure 4-71 Step 2 On the edit view interface, drag the channel to the desired window, or drag on the preview window to switch the position. Check the channel number at the right bottom corner to view the current channel sequence. See Figure 4-72.

  • Page 111: Preview Display Effect Setup

    Figure 4-72 Click Apply to save current channel sequence. Step 3 After you change the channel sequence, click Cancel button or right click mouse, device pops up the dialogue box. See Figure 4-73.  Click OK to save current settings. ...
  • Page 112 Figure 4-74 Please refer to the following sheet for detailed information. Item Note Period There are two periods in one day. You can set different sharpness, brightness, and contrast setup for different periods. Effective Time Check the box here to enable this function and then set period time.
  • Page 113 Item Note 0 to 100. The default value is 50. The larger the number, the strong the color is. This value has no effect on the general brightness of the whole video. The video color may become too strong if the value is too high. For the grey part of the video, the distortion may occur if the white balance is not accurate.
  • Page 114 Now you can set corresponding information.  Display the intelligent rule(s): Check the box to enable IVS function, system can display IVS rule on the preview interface. Please note this function is for some series only.  Resolution: There are five options: 1280×1024 (Default), 1280×720, 1920×1080, 1024×768 and 3840×2160.
  • Page 115 Figure 4-76 4.3.6.4 Preview Tour Parameters Set preview display mode, channel display sequence and tour setup.  Set preview display mode: On the preview interface, right click mouse, you can view right-click menu. Now you can select preview window amount and channel. ...
  • Page 116 Figure 4-77 Tips On the navigation bar, click to enable/disable tour. Click Save button to save current setup. 4.3.6.5 Customized split It is to set customized video split mode. Note  This function is for some series products. Please refer to the actual product for detailed information. ...
  • Page 117 Figure 4-78 Click and then click to select basic mode In regular mode, drag the mouse in the preview frame; you can merge several small windows to one window so that you can get you desired split mode. After the setup, the selected window has the red frame. See Figure 4-79. Figure 4-79...

  • Page 118: Fisheye (Optional)

    Select the merging window, the frame is red; you can click to cancel the merge to restore regular mode. Click Save to exit. After the setup, you can go to the preview window, right click mouse and then select custom split. See Figure 4-80.
  • Page 119 Figure 4-81 Now you can see an interface shown as in Figure 4-82. You can set fish eye installation mode and display mode. Note:  For the non-fish eye channel, system pops up dialogue box to remind you it is not a fish eye channel and does not support de-warp function.
  • Page 120 There are three installation modes: ceiling mount/wall mount/ground mount. The different installations modes have different de-warp modes. Please refer to the following sheet for detailed information. Installation modes Icon Note 360° panorama original view （Ceiling mount） 1 de-warp window+1 panorama stretching 2 panorama stretching view （Ground mount）...

  • Page 121: Ptz Settings

    4.3.7.2 Fish eye de-warp during playback On the main menu, click search button. Select 1-window playback mode and corresponding fish eye channel, click to play. Right click the , you can go to the de-warp playback interface. For detailed information, please refer to chapter 4.3.7.1.

  • Page 122: Ptz Control

    Figure 4-84 If you are connecting to network PTZ, the PTZ type shall be remote. See Figure 4-85. Figure 4-85 4.4.2 PTZ Control After completing all the setting please click save button. Right click mouse (click “Fn” Button in the front panel or click “Fn”...
  • Page 123 Figure 4-86 The PTZ setup is shown as in See Figure 4-87. Please note the commend name is grey once device does not support this function. The PTZ operation is only valid in one-window mode. Here you can control PTZ direction, speed, zoom, focus, iris, preset, tour, scan, pattern aux function, light and wiper, rotation and etc.
  • Page 124 zone you dragged, the higher the speed. Figure 4-88 Name Function function Shortcut Function function Shortcut  Zoom Near  ► │ │ Focus Near   Iris close Open In Figure 4-87, click to open the menu, you can set preset, tour, pattern, scan and etc. See Figure 4-89.
  • Page 125 Click , you can go to the following interface to set preset, tour, pattern, and scan. See Figure 4-90. Figure 4-90 Preset Setup In Figure 4-90, click preset button and use eight direction arrows to adjust camera to the proper position. The interface is shown as in Figure 4-91.
  • Page 126 Figure 4-92 Pattern Setup In Figure 4-90, click Pattern button and input pattern number. Click Begin button to start direction operation. Or you can go back to Figure 4-87 to operate zoom/focus/iris/direction operation. In Figure 4-90, click End button. Figure 4-93 Scan Setup In Figure 4-90, click Scan button.
  • Page 127 Figure 4-94 4.4.2.2 Call PTZ Function Call Preset In Figure 4-89, input preset value and then click to call a preset. Click again to stop call. Call Pattern In Figure 4-89, input pattern value and then click to call a pattern. Click again to stop call.

  • Page 128: Record File

    Figure 4-95 4.5 Record File Device adopts 24-hour continuous record by default. It supports customized record period and record type. Refer to chapter 4.1.4.6 Schedule for detailed information. 4.6 Playback and Search 4.6.1 Instant Playback Please refer to chapter 4.3.2 for real-time playback information. 4.6.2 Search Interface From Main menu->Search, or on the preview interface right click mouse and then select search item, you can go to the following interface.
  • Page 129 Figure 4-97 Please refer to the following sheet for more information. Name Function  Here is to display the searched picture or file. Display  Support 1/4/9/16-window playback. (It depends on the product channel window amount).  Here you can select to search the picture or the recorded file. ...
  • Page 130  channel In 4-window playback mode: you can select 4 channels according to your selection requirement.  pane. In 9-window playback mode, you can switch between 1-8, 9-16 and etc channels.  In 16-window playback mode, you can switch between1-16, 17-32 and etc channels.
  • Page 131 │ to begin frame by frame playback. In frame by frame playback mode, click ►/ to restore normal playback. ► Slow play In playback mode, click it to realize various slow play modes such as slow play 1, slow play 2, and etc. Fast forward ...
  • Page 132 supports customized path setup. After select or create new folder, click the Start button to begin the backup operation. The record file(s) will be saved in the specified folder.  Check the file again you can cancel current selection. System max supports to display 32 files from one channel.
  • Page 133 When the system is in full-screen playback mode, left click the mouse in the Digital screen. Drag your mouse in the screen to select a section and then left click zoom mouse to realize digital zoom. You can right click mouse to exit. Manually switch During the file playback process, you can switch to other channel via the...
  • Page 134 Icon Function Click the snapshot button in the full-screen mode, the system can snapshot 1 picture. System supports custom snap picture saved path. Please connect the peripheral device first, click snap button on the full-screen mode, you can select or create path. Click Start button, the snapshot picture can be saved to the specified path.

  • Page 135: Smart Search Playback

    Figure 4-100 Click Backup to begin the process. 4.6.3 Smart Search Playback Note This function is for some series product only. During playback process, it can analyze the motion detect zone in the scene and give the analysis result. This function channel that...

  • Page 136: Mark Playback

    4.6.4 Mark Playback Please make sure your purchased device support this function. You can use this function only if you can see the mark playback icon on the Search interface (Figure 4-96 or Figure 4-97). When you are playback record, you can mark the record when there is important information. After playback, you can use time or the mark key words to search corresponding record and then play.

  • Page 137: Playback Image

    Figure 4-102  Modify Double click one mark information item, you can see system pops up a dialogue box for you to change mark information. You can only change mark name here.  Delete Here you can check the mark information item you want to delete and then click Delete button, you can remove one mark item.

  • Page 138: Smart Playback

    Figure 4-103 Note Select split mode, so that the record can be spliced in several sections. Select splice file.  Click Playback, system playbacks from the first of current date by default.  Click time bar, system playbacks from the time you click. ...
  • Page 139 Figure 4-104 Step 2 Select detection type as behavior analytics. Step 3 Select a channel. Enter the following interface. See Figure 4-105. Note The IVS function is for one-channel mode only.
  • Page 140 Figure 4-105 Step 4 Select a channel number and then click OK. Step 5 Set detection type as IVS and then set start time and end time. Step 6 Click Historic Analysis. Device displays the corresponding image. See Figure 4-106. Figure 4-106 Step 7 Click the image;...
  • Page 141  Select a file and then click , you can save current file to peripheral storage device.  Select a file and then click , you can lock current file in case it will be overwritten in the future  Select a file and then click , you can mark the time of the detected event.
  • Page 142 Figure 4-108 Step 5 Click the image; you can view the record file.  Select a file and then click , you can save current file to peripheral storage device.  Select a file and then click , you can lock current file in case it will be overwritten in the future ...

  • Page 143: File List

    Figure 4-109 Step 2 Set plate number, channel number, start time, end time. Note Device supports fuzzy plate number search function. Device searches all plate numbers by default if you do not input plate number information. The plate number search and playback function is for one-channel mode only. Step 3 Click Historic Analytics.
  • Page 144 Figure 4-110  Check a file name, double click file or click to play.  Input accurate time at the top column, you can search records of current day.  System max displays 128 record files in one list.  Click to go back to the calendar/channel selection interface.

  • Page 145: Other Aux Functions

    Click you can view the locked file. See Figure 4-111. Figure 4-111 Select a file in the above figure and then click Unlock, you can unlock it. 4.6.9 Other Aux Functions 4.6.9.1 Digital Zoom In 1-window playback mode, left click mouse to select any zone on the screen, you can zoom in current zone.
  • Page 146 click Fn button to switch between the arm mode and disarm mode. In arm mode, you can click the direction buttons to move the green rectangle to set the motion detection zone. After you completed the setup, please click ENTER button to exit current setup. Do remember click save button to save current setup.
  • Page 147  Video matrix Check the box here to enable this function. When an alarm occurs, SPOT OUT port displays device video output. It displays video (1-window tour) from alarm activation channel you select at the Record channel item.  Buzzer: Highlight the icon to enable this function. The buzzer beeps when alarm occurs. Please highlight icon to select the corresponding function.
  • Page 148 Figure 4-114 Figure 4-115...
  • Page 149 Figure 4-116 Motion detect here only has relationship with the sensitivity and region setup. It has no relationship with other setups. 4.7.1.2 Tampering When someone viciously masks the lens, or the output video is in one-color due to the environments light change, the system can alert you to guarantee video continuity.
  • Page 150 Figure 4-117 4.7.1.3 Video Loss In Figure 4-112, select video loss from the type list. You can see the interface is shown as in Figure 4-118. This function allows you to be informed when video loss phenomenon occurred. You can enable alarm output channel and then enable show message function.
  • Page 151 Figure 4-118 4.7.1.1 Scene Changing When the detected scene has changed, system can generate an alarm. From main menu->Setting->Event->Video detect->Scene change, the interface is shown as in Figure 4-119. Please refer to chapter 4.7.1.1Motion detect for detailed information.
  • Page 152 Figure 4-119 4.7.2 Smart Plan The smart plan is for the smart network camera. If you do not set a rule here, you cannot use the intelligent functions in IVS (Chapter 4.7.3), Face detection (Chapter 4.7.5) and People counting (Chapter 4.7.6) when you are connecting to a smart network camera.
  • Page 153 Figure 4-120 Please select a channel number and a preset. Click Add. The preset is now on the list. See Figure 4-121. Note Some smart camera does not need to add the preset. Please refer to the actual product for detailed information.

  • Page 154: Ivs (Optional)

    Figure 4-121 Select a smart plant from the dropdown list and then click the corresponding intelligent plan icon. See Figure 4-121. Note  The NVR supports general behavior analytics (IVS), human face detection, heat map, and people counting. Different network camera supports different smart plans. Please refer to the actual product for detailed information.

  • Page 155: Ivs (Behavior Analytics) (Optional)

    shall be more than 15pixels*15 pixels (CIF resolution). The object width shall not be more than 1/3 of the video height and width. The recommended height is 10% of the video.  The object and the background brightness different shall be more than 10 grey levels. ...
  • Page 156  Support one-direction or dual-direction detection.  Support several tripwires at the same scene suitable for complicated environment.  Support object size filter. From main menu->Setting->Event->Behavior analytics, the interface is shown as below. See Figure 4-123. Figure 4-123 Click Draw button to draw the tripwire.
  • Page 157 Figure 4-124 Select direction, and then input customized rule name.  Preset: Select a preset you want to use behavior analytics.  Name: Input customized rule name.  Direction (A→B/B→A/A↔B): System can generate an alarm once there is any object crossing in the specified direction.
  • Page 158  In Figure 4-115, Select icon of several dates, all checked items can be edited together. Now the icon is shown as . Click to delete a record type from one period.  In Figure 4-115. Click button after one date or a holiday, you can see an interface shown as in Figure 4-116.
  • Page 159 Figure 4-126 Figure 4-127...
  • Page 160 Figure 4-128 After you set the corresponding parameters, click OK button in Figure 4-125., and then click the Apply button in Figure 4-123 to complete the setup. 4.7.4.2 Intrusion (Cross warning zone) (Optional) System generates an alarm once there is any object entering or exiting the zone in the specified direction. From main menu->Setting->Event->Behavior analytics, click Add button and then select type as intrusion, the interface is shown as below.
  • Page 161 Figure 4-129 Click draw button to draw the zone. See Figure 4-130.
  • Page 162 Figure 4-130 Select direction, and then input customized rule name.  Preset: Select a preset you want to use behavior analytics.  Name: Input customized rule name.  Direction (A→B/B→A/A↔B): System can generate an alarm once there is any object crossing in the specified direction.
  • Page 163  System supports customized area shape and amount.  Support duration setup.  Support objects filter function. Figure 4-131 Click draw button to draw the zone. See Figure 4-132.
  • Page 164 Figure 4-132  Preset: Select a preset you want to use behavior analytics.  Name: Input customized rule name.  Duration: System can generate an alarm once the object is in the zone for the specified period.  Target filter: Click , you can set filter object size.
  • Page 165 Figure 4-133 Click Draw button to draw a zone. See Figure 4-134. Figure 4-134...
  • Page 166  Preset: Select a preset you want to use behavior analytics.  Name: Input customized rule name.  Duration: System can generate an alarm once the object in the zone is missing for the specified period.  Target filter: Click , you can set filter object size.
  • Page 167 Click draw button to draw the zone. See Figure 4-136. Figure 4-136  Preset: Select a preset you want to use behavior analytics.  Name: Input customized rule name.  Duration: System can generate an alarm once the object is in the zone for the specified period. ...
  • Page 168  Customized zone and amount setup.  Duration setup.  Sensitivity setup.  Min gathering zone setup. Figure 4-137 Click draw button to draw the zone. See Figure 4-138.
  • Page 169 Figure 4-138  Preset: Select a preset you want to use behavior analytics.  Name: Input customized rule name.  Duration: System can generate an alarm once the object is in the zone for the specified period.  Sensitivity: It is to set alarm sensitivity. The value ranges from 1 to 10.The default setup is 5. ...
  • Page 170 Figure 4-139 Click draw button to draw the zone. See Figure 4-140.
  • Page 171 Figure 4-140  Preset: Select a preset you want to use behavior analytics.  Name: Input customized rule name.  Sensitivity: It is to set alarm sensitivity. The value ranges from 1 to 10.The default setup is 5.  Target filter: Click , you can set filter object size.
  • Page 172 Figure 4-141 Click Global config button, the interface is shown as below. See Figure 4-142.  Channel: Please select a channel from the dropdown list.  Preset: Select a preset you want to set the rule. Please note, you need to add a preset first, otherwise, you cannot see the preset dropdown list.

  • Page 173: Face Detect (Optional)

    Figure 4-142 4.7.5 Face Detect (Optional) When camera detects human face, system can generate an alarm. From main menu->Setting->Event->Face detect, the interface is shown as in Figure 4-143.  Face ROI: Check the box here, system can enhance the human face display pane. ...

  • Page 174: People Counting (Optional)

    Figure 4-143 4.7.6 People Counting (Optional) System can calculate the entry/exit people amount in the specified zone. It can generate an alarm when the amount has exceeded the threshold. From main menu->Setting->Event->People counting, you can see an interface shown as in Figure 4-144. ...

  • Page 175: Heat Map

    Figure 4-144 After you set the people counting function, from main menu->Info->Event->People counting, you can view people counting statistics report. Please refer to chapter 4.7.1.1 Motion detect for detailed information. 4.7.7 Heat Map Device can detect the active object state in the specified region. Step 1 From main menu->Setting->Event->Heat map.
  • Page 176 Figure 4-145 Step 2 Select a channel number and then check the box to enable the function. Step 3 Click Setup button. Enter setup interface. See Figure 4-146. Figure 4-146 Step 4 Set arm/disarm period. Refer to chapter 4.7.1.1 Motion detect for detailed setup information.

  • Page 177: Plate Recognition

    Step 5 Click Apply button to complete setup. Note After set the heat map parameters, go to main menu->Info->Event->Heat map to view heat map report. Refer to 4.10.2.6 for detailed setup information. 4.7.8 Plate Recognition 4.7.8.1 Plate recognition settings Device can generate an alarm when it detects the corresponding plate information. Please follow the steps listed below.
  • Page 178 blacklist.  Whitelist: In this interface, device triggers an alarm when it detects plate number in the whitelist. 4.7.8.2 B/W List It is to set the blacklist and the whitelist. It includes add, delete, import, export blacklist/whitelist. After setting the blacklist/whitelist, in the plate snapshot list on the preview interface, the blacklist plate number is red, the whitelist plate number is green, the regular plate number is white.

  • Page 179: Audio Detect (Optional)

    Import/export blacklist/whitelist Device support blacklist/whitelist import/export function via the USB device. The import file supports .csv and xlsx. The export file is .csv.  Import blacklist/whitelist: Set the type as blacklist or whitelist and then click Import button. Select the corresponding file and then click Open button to import.

  • Page 180: Alarm Settings

    Figure 4-149 4.7.10 Alarm Settings In the main menu, from Setting->Event->Alarm, you can see alarm setup interface.  Alarm in: Here is for you to select channel number. In the main menu, from Setting->Event->Alarm, you can see alarm setup interface. See Figure 4-150. There are four alarm types.
  • Page 181 motion detection (MD), Alarm, MD & alarm.  In Figure 4-155, Select icon of several dates, all checked items can be edited together. Now the icon is shown as Click to delete a record type from one period.  In Figure 4-155. Click button after one date or a holiday, you can see an interface shown as in Figure 4-156.
  • Page 182  Finally, you can set the alarm input as the local alarm and then select the record channel. The select channel begins alarm record when an alarm occurred. Please note system begins the alarm record instead of the MD record if the local alarm and MD event occurred at the same time.
  • Page 183 Figure 4-151 Figure 4-152...
  • Page 184 Figure 4-153 Figure 4-154...
  • Page 185 Figure 4-155 Figure 4-156 Please highlight icon to select the corresponding function. After setting all the setups please click save button. 4.7.11 Abnormality There are three types: Disk/Network/User.  Disk: Disk error, no disk, no space. See Figure 4-157.  Network: Disconnection, IP conflict, MAC conflict.
  • Page 186  Alarm output: Please select alarm activation output port (multiple choices).  Less than: System can alarm you when the HDD space is less than the threshold you set here (For HDD no space type only).  Attempts: In user interface, select illegal login from the dropdown list. Here you can set login attempts.

  • Page 187: Alarm Output

    Figure 4-158 Figure 4-159 4.7.12 Alarm output From Main menu->Setting->Event->Alarm output, you can see an interface shown as in Figure 4-160.

  • Page 188: Network Settings

    Here is for you to set proper alarm output (Auto/manual/stop). Click OK button of the alarm reset, you can clear all alarm output status. Figure 4-160 Please highlight icon to select the corresponding alarm output. After all the setups please click OK button. Network 4.8.1 Network Settings 4.8.1.1 TCP/IP...
  • Page 189  Load balance: In this mode, device uses bond0 to communicate with the external device. T he eth0 and eth1 are both working now and bearing the network load. Their network load are general the same. The system is shown as offline once these two cards are both offline. Please note these two cards shall be in the same LAN.
  • Page 190 Figure 4-161 Figure 4-162 4.8.1.2 Connection The connection setup interface is shown as in Figure 4-163.  Max connection: The max client login amount (such as WEB, platform, cellphone and etc). The value ranges from 1 to 128(default).
  • Page 191  TCP port: Default value is 37777.  UDP port: Default value is 37778.  HTTP port: Default value is 80.  HTTPS port: Default value is 443.  RTSP port: Default value is 554. Important: System needs to reboot after you changed and saved any setup of the above four ports. Please make sure the port values here do not conflict.
  • Page 192 Figure 4-164 4.8.1.3.2 Advanced Click Advanced, you can see an interface shown as below. See Figure 4-165.  IPv4 address: Input WIFI AP IP address.  IPv4 net mask: Input WIFI AP network mask.  IPv4 gateway: Input WIFI AP gateway. ...
  • Page 193 Figure 4-165 4.8.1.4 WIFI The WIFI interface is shown as below. See Figure 4-166.  Enable: Check the box here to enable WIFI function.  Refresh: You can click it to search the hotspot list again. It can automatically add the information such as the password if you have set it before.
  • Page 194 Figure 4-166  WIFI working status: Here you can view current connection status. Please note:  After successful connection, you can see WIFI connection icon at the top right corner of the preview interface.  When the hotspot verification type is WEP, system displays as AUTO since the device cannot detect its encryption type.
  • Page 195  APN: It is the wireless connection server. It is to set you access the wireless network via which method.  AUTH: It is the authentication mode. It supports PAP/CHAP.  Dial number: Please input 3G network dialup number you got from your ISP. ...
  • Page 196 Figure 4-168 4.8.1.7 DDNS DDNS setup interface is shown as in Figure 4-169. You need a PC of fixed IP in the internet and there is the DDNS software running in this PC. In other words, this PC is a DNS (domain name server). In network DDNS, please select DDNS type and highlight enable item.
  • Page 197 Figure 4-169 Please note DDNS type includes: CN99 DDNS, NO-IP DDNS, Quick DDNS, Dyndns DDNS and sysdns DDNS. All the DDNS can be valid at the same time, you can select as you requirement. Private DDNS function shall work with special DDNS server and special Professional Surveillance Software (PSS).
  • Page 198 the device IP.  User name: It is optional. You can input your commonly used email address. Important  Do not register frequently. The interval between two registrations shall be more than 60 seconds. Too many registration requests may result in server attack. ...
  • Page 199 Figure 4-170 Figure 4-171 4.8.1.9 IP Filter IP filter interface is shown as in Figure 4-172. You can add IP in the following list. The list supports max 64 IP addresses. System supports valid address of IPv4 and IPv6. Please note system needs to check the validity of all IPv6 addresses and implement optimization.
  • Page 200  Type: You can select trusted site and blacklist from the dropdown list. You can view the IP address on the following column.  Start address/end address: Select one type from the dropdown list, you can input IP address in the start address and end address.
  • Page 201 Figure 4-173 4.8.1.10 Email The email interface is shown as below. See Figure 4-174.  SMTP server: Please input your email SMTP server IP here.  Port: Please input corresponding port value here.  User name: Please input the user name to login the sender email box. ...
  • Page 202 Figure 4-174 4.8.1.11 FTP You need to download or buy FTP service tool (such as Ser-U FTP SERVER) to establish FTP service. Please install Ser-U FTP SERVER first. From “start” -> “program” -> Serv-U FTP Server -> Serv-U Administrator. Now you can set user password and FTP folder. Please note you need to grant write right to FTP upload user.
  • Page 203 Figure 4-176 System also supports upload multiple NVRs to one FTP server. You can create multiple folders under this FTP. FTP interface is shown as in Figure 4-177. Please highlight the icon in front of Enable to activate FTP function. Here you can input FTP server address, port and remote directory.
  • Page 204 4.8.1.12 SNMP SNMP is an abbreviation of Simple Network Management Protocol. It provides the basic network management frame of the network management system. The SNMP widely used in many environments. It is used in many network device, software and system. You can set in the following interface.
  • Page 205 Figure 4-179 Here you can set a multiple cast group. Please refer to the following sheet for detailed information.  IP multiple cast group address -224.0.0.0-239.255.255.255 -“D” address space  The higher four-bit of the first byte=”1110”  Reserved local multiple cast group address -224.0.0.0-224.0.0.255 -TTL=1 When sending out telegraph -For example...
  • Page 206 After you logged in the Web, the Web can automatically get multiple cast address and add it to the multiple cast groups. You can enable real-time monitor function to view the view. Please note multiple cast function applies to special series only. 4.8.1.14 Alarm Centre This interface is reserved for you to develop.
  • Page 207 Figure 4-181 2) The proxy server software developed from the SDK. Please open the software and input the global setup. Please make sure the auto connection port here is the same as the port you set in the previous step. 3) Now you can add device.
  • Page 208 Figure 4-182  Android: Open Google Play app in your smart phone. Search gDMSS Lite or gDMSS Plus, download it and install.  iOS: Open App Store app in your smart phone. Search iDMSS Lite or iDMSS Plus, download it and install. Please follow the steps listed below.
  • Page 209 Figure 4-183 4.8.1.17 Easy Space This function allows you to upload motion detect record or snapshot image to the dropbox and etc. The easy space interface is shown as below. See Figure 4-184. Please select the easy space address from the dropdown list and then input corresponding user name and password.

  • Page 210: Network Test

    Note：  The uploaded file is for sub stream only. Please go to record control interface (main stream->setting->Storage->Record) and then select sub stream.  The easy space function uses upload bandwidth. Usually the recommended upload bandwidth shall be more than 512kbps and please make sure the network is stable. ...
  • Page 211 You can view all connected network adapter names (including Ethernet, PPPoE, WIFI, and 3G), you can click the button on the right panel to begin Sniffer. Click the grey stop button to stop. Please note system cannot Sniffer several network adapters at the same time. After Sniffer began, you can exit to implement corresponding network operation such as login WEB, monitor.

  • Page 212: Hdd Setup

    Figure 4-187 HDD Setup Here you can view HDD information such as type, status, total capacity, record time and etc. The operation includes format, resume from error, change HDD property (Read write, Read-only). Here you can also set alarm and HDD storage position. 4.9.1 Format From Mani-menu->Setting->Storage->HDD Manager, you can go to HDD management interface.

  • Page 213: Hdd Information

    Figure 4-188 b) Select a HDD and then select format from the dropdown list. Click Execute button. c) Click OK button to complete the setup. You can see system needs to restart to activate current setup. 4.9.2 HDD Information Here is to list hard disk type, total space, free space, and status. See Figure 4-189. ○...
  • Page 214 Figure 4-189 In Figure 4-189, click one HDD item, the S.M.A.R.T interface is shown as in Figure 4-190. Figure 4-190...

  • Page 215: Advanced

    Parameter Function SATA 1 here means there is 1 HDD. For different series product, the max HDD amount may vary, When HDD is working properly, system is shown as O. . “_” means there is no HDD. You can view the HDD amount the device connected to; ﹡...
  • Page 216 Figure 4-191 Please select the correspond group from the dropdown list and then click Apply button. Click main stream/sub stream/snapshot button to set corresponding HDD group information. See Figure 4-192 through Figure 4-194. Figure 4-192...

  • Page 217: Hdd Detect

    Figure 4-193 Figure 4-194 4.9.4 HDD Detect Note This function is for some series product only. The HDD detect function is to detect HDD current status so that you can clearly understand the HDD performance and replace the malfunction HDD. There are two detect types:...
  • Page 218  Quick detect is to detect via the universal system files. System can quickly complete the HDD scan. If you want to use this function, please make sure the HDD is in use now. If the HDD is removed from other device, please make sure the write-data once was full after it installed on current device.
  • Page 219 Figure 4-196 Click View, you can see the detailed information such as detect result, backup and S.M.A.R.T. See Figure 4-197 and Figure 4-198. Figure 4-197...

  • Page 220: Raid Manager

    Figure 4-198 4.9.5 RAID Manager Important Please make sure your purchased product support the RAID function, otherwise you cannot see the following interface. Right now, RAID supports Raid0, Raid1, Raid5, Raid6, and Raid10. Local hotspare supports Raid1, Raid5, Raid6, and Raid10. 4.9.5.1 RAID Config It is for you to manage RAID HDD.
  • Page 221 Figure 4-199 4.9.5.2 Hotspare disks Click Hotspare disks tab name, you can add the hot spare HDD. See Figure 4-200. The type includes two options:  Global: It is global hotspare disk. When any RAID becomes degrading, it can replace and build the RAID.

  • Page 222: Device Maintenance And Manager

    Figure 4-200 4.10 Device Maintenance and Manager 4.10.1 Account Here is for you to implement account management. See Figure 4-201. Here you can manage user, user group, and security questions. Warning The default user name of different series products may not the same. Please refer to the actula product for detailed information.
  • Page 223 User group and User The account adopts two-level management mechanism. The group name and user name shall be unique.  The default user amount is 64 and the default group amount is 20.  The factory default user group includes: user and admin. These two groups cannot be deleted. ...
  • Page 224 Figure 4-202 When you create a new user, you can input the corresponding MAC address of current user. If you leave this item in blank, any MAC address user can share this user account to login. Please note system needs to check the validity of MAC.
  • Page 225 Figure 4-203 Click Set button, you can set six periods in one day. See Figure 4-204. Check the box after the period, you can enable current setup. Figure 4-204...
  • Page 226 4.10.1.1.2 Modify user Click , you can go to the following interface to change user information. See Figure 4-205. For admin, 888888, and default (hidden user), you cannot change period setup. Figure 4-205 4.10.1.1.3 Change Password In Figure 4-205, check the Modify password box, you can change password. Please input old password, and then input new password twice to confirm.
  • Page 227 Figure 4-206 Click add group button in Figure 4-206 , the interface is shown as below. See Figure 4-207. Here you can input group name and then input some memo information if necessary. There are total 98 rights such as control panel, shut down, real-time monitor, playback, record, record file backup, PTZ, user account, system information view, alarm input/output setup, system setup, log view, clear log, upgrade system, control device and etc.
  • Page 228 4.10.1.1.5 Security Question The security question is shown as below. See Figure 4-208. Here you can change security questions. Figure 4-208 4.10.1.1.6 ONVIF User When the camera from the third party is connected with the NVR via the ONVIF user, please use the verified ONVIF account to connect to the NVR.
  • Page 229 Figure 4-209 Click Add user button, you can see the following interface. See Figure 4-210. Figure 4-210 Please set user name, password and then select group from the dropdown list. Click Save to complete setup. Tips Click to change user information, click to delete current user.

  • Page 230: System Info

    4.10.2 System Info 4.10.2.1 Version From main menu->Info->System->version, you can go to version interface. Here is for you to view some version information. See Figure 4-211. Please note the following figure for reference only.  Channel  Alarm in  Alarm out ...
  • Page 231 Figure 4-212 4.10.2.3 Online User Here is for you manage online users connected to your NVR. See Figure 4-213. You can click button to disconnect or block one user if you have proper system right. System detects there is any newly added or deleted user in each five seconds and refresh the list automatically.
  • Page 232 Figure 4-213 4.10.2.4 Alarm Status From main menu->info-Event, here you can view the channel status of the remote device, connection log and etc. See Figure 4-214. Figure 4-214...
  • Page 233 4.10.2.5 People Counting It is to search and view the people counting results of each channel. System can export people counting report. The export file extension name is .bmp. From main menu->Info->Event->People Counting, you can go to the following interface. See Figure 4-215.
  • Page 234 Figure 4-216 4.10.3 Voice Note This function is for some series product only. The audio function is to manage audio files and set schedule play function. It is to realize audio broadcast activation function. 4.10.3.1.1 File Manage Here you can add audio file, listen to the audio file, or rename/delete audio file. Here you can also set audio volume.
  • Page 235 Figure 4-217 Click Add button, you can add audio file and import the audio file via the USB device. The audio file format shall be MP3 or PCM. See Figure 4-218. Important The audio file shall be saved on the USB device. You need to connect the USB device all the time; otherwise, the audio link function may fail.

  • Page 236: Rs232

    Figure 4-218 4.10.3.1.2 Schedule It is to set schedule broadcast function. You can play the different audio files in the specified periods. See Figure 4-219. Figure 4-219 4.10.4 RS232...

  • Page 237: Pos

    From Main menu->Setting->System->RS232, RS232 interface is shown as below. There are five items. See Figure 4-220.  Function: There are various devices for you to select. Console is for you to use the COM or mini-end software to upgrade or debug the program. The control keyboard is for you to control the device via the special keyboard.
  • Page 238  For the local-end, this function supports one-window display and playback only.  This function is for the cashier of the supermarket and etc. The device can get the information from the POS and then overlay the txt information on the video. Step 1 From main menu->Setting->System->POS, the interface is shown as below.
  • Page 239 Figure 4-222 Step 4 In Figure 4-222, click the Enable box to enable POS function and then input POS device name. Note  The POS device name shall be unique.  POS device name max supports 63-digit. Step 5 Click Setup button after the connection type, the interface is shown as in Figure 4-223. Step 6 Set source IP (POS device IP address) and destination IP (NVR IP address).

  • Page 240: Broadcast

    Step 7 In Figure 4-222, click Channel setup button, select a channel you want to overlay POS information and then click Save button. See Figure 4-224. Note In Figure 4-221, click to change setup, click to delete POS setup. Figure 4-224 4.10.6 Broadcast It is to broadcast to the camera, or broadcast to a channel group.
  • Page 241 Figure 4-225 Step 2 Click Add group. Enter add group interface. See Figure 4-226. Figure 4-226 Step 3 Input group name and select one or more channels.

  • Page 242: Auto Maintain

    Step 4 Click Save button to complete broadcast group setup. Note On the broadcast interface, click to change group setup, click to delete group. After complete broadcast setup, on the preview interface and then click on the navigation bar, device pops up broadcast diaologue box. Select a group name and then click begin broadcast.
  • Page 243 Figure 4-228 4.10.8 Backup 4.10.8.1 File Backup In this interface, you can backup record file to the USB device. a) Connect USB burner, USB device or portable HDD and etc to the device. b) From Main menu->Backup, you can go to the Backup interface. See Figure 4-229 Figure 4-229...
  • Page 244 c) Select backup device and then set channel, file start time and end time. d) Click add button, system begins search. All matched files are listed below. System automatically calculates the capacity needed and remained. See Figure 4-230. e) System only backup files with a √ before channel name. You can use Fn or cancel button to delete √...
  • Page 245 Figure 4-231  Export: Please connect the peripheral device first and then go to the following interface. Click Export button, you can see there is a corresponding “Config_Time” folder. Double click the folder, you can view some backup files.  Import: Here you can import the configuration files from the peripheral device to current device.
  • Page 246 Figure 4-232 b) Select log type and then set start time/end time, click Search button, you can see log time and event information. Click to view detailed log information. c) Select log items you want to save and then click backup button, you can select a folder to save them.

  • Page 247: Default

    Figure 4-233 4.10.9 Default You can restore factory default setup to fix some problems when the device is running slowly. Configuration error occurred. From Main menu->Setting->System->Default, you can go to the default interface. See Figure 4-234. Click default icon, system pops up a dialogue box. You can highlight to restore factory default setup.

  • Page 248: Update

    Figure 4-234 4.10.10Update 4.10.10.1 Local Update From Mani menu->Setting->Info->Update, you can go to the following interface. See Figure 4-235. Insert USB device that contain the upgrade file. Click Start button and then select the .bin file. You can see the corresponding dialogue box after the update process is complete.

  • Page 249: Logout /Shutdown/Restart

    Figure 4-235 4.10.10.2 Uboot When device is booting up, it can auto detect the USB device and the update file on it. It can auto update once there is proper upgrade file. Important  USB device root directory shall have “u-boot.bin.img” and “update.img” files. USB device shall be FAT32 mode.
  • Page 250 Figure 4-236...

  • Page 251: Web Operation

    5 Web Operation 5.1 General Introduction If it is your first time to login the device, please initialize your device first. Refer to chapter 5.2 Device Initialization for detailed information. The device web provides channel monitor menu tree, search, alarm setup, system setup, PTZ control and monitor window and etc.
  • Page 252 Figure 5-1 Step 3 Set login password of admin.  User name: The default user name is admin.  Password/confirm password: The password ranges from 8 to 32 digitals. It can contain letters, numbers and special characters (excluding “'”,“"”,“;”,“:”,“&”) . The password shall contain at least two categories.
  • Page 253 Figure 5-2 Step 5 Set security questions. Note  After setting the security questions here, you can use the email you input here or answer the security questions to reset admin password Refer to chapter 5.3 Reset password for detailed information.
  • Page 254 Figure 5-3 5.2.1 Log in Open the IE and then input the NVR IP address in the address column. For example, if your NVR IP address is 192.168.1.108, then please input http:// 192.168.1.108 in IE address column. See Figure 5-4. Input address here.

  • Page 255: Reset Password

    Figure 5-5 Please input your user name and password. Factory default user name is admin and password is what you set in chapter 5.2 Device initialization. 5.3 Reset Password If you forgot admin password, you can reset the password by email or by answering the security questions (local menu only).

  • Page 256: Lan Mode

    Step 3 Figure 5-7 Step 4 Follow the prompts on the interface and then scan the QR code to get the security code. WARNING  For the same QR code, max scan twice to get two security codes. Refresh the QR code if you want to get security code again.
  • Page 257 Figure 5-8  Section 3: Open all. Open all button is to enable/disable all-channel real-time monitor. Here you can select main stream/sub stream too. See Figure 5-9. Figure 5-9  Section 4: Start Talk button. You can click this button to enable audio talk. Click 【▼】 to select bidirectional talk mode. There are four options: DEFAULT，G711a，G711u and PCM.

  • Page 258: Real-Time Monitor

    Figure 5-12  Section 7: Zero-channel encoding. Please refer to chapter 5.8 for detailed information.  Section 8: PTZ operation panel. Please refer to chapter 5.6 for detailed information.  Section 9: Image setup and alarm setup. Please refer to chapter 5.7 for detailed information. ...

  • Page 259: Ptz

    stream(2202Kbps) and stream type(M=main stream, S=sub stream). See Figure 5-14. Figure 5-14 On the top right corner, there are six unction buttons. See Figure 5-15. 2 3 4 Figure 5-15  1: Digital zoom: Click this button and then left drag the mouse in the zone to zoom in. right click mouse system restores original status.

  • Page 260: Image/Alarm-Out

    Parameter Function  Select Tour from the dropdown list. Tour  Input preset value in the column. Click Add preset button, you have added one preset in the tour.  Repeat the above procedures you can add more presets in one tour.

  • Page 261: Image

    Select one monitor channel video and then click Image button in section 9, the interface is shown as Figure 5-17. 5.7.1 Image Here you can adjust its brightness, contrast, hue and saturation. (Current channel border becomes green). Or you can click Reset button to restore system default setup. Figure 5-17 5.7.2 Alarm output Here you can enable or disable the alarm signal of the corresponding port.

  • Page 262: Wan Login

    Figure 5-19 5.9 WAN Login In WAN mode, after you logged in, the interface is shown as below. See Figure 5-20. Figure 5-20 Please refer to the following contents for LAN and WAN login difference. 1) In the WAN mode, system opens the main stream of the first channel to monitor by default. The open/close button on the left pane is null.

  • Page 263: Setup

    Figure 5-21. Figure 5-21 Important The window display mode and the channel number are by default. For example, for the 16-channel, the max window split mode is 16. 3) Multiple-channel monitor, system adopts extra stream to monitor by default. Double click one channel, system switches to single channel and system uses main stream to monitor.
  • Page 264 Figure 5-22 Please refer to the following sheet for parameter information. Parameter Function Select IP address or the MAC address from the dropdown list and then input the corresponding information, click Search button to view the results. Click Search button, you can view the searched device Search information on the list.
  • Page 265 Parameter Function There are two connection types. You can use the network to Type connect to the camera or use the WIFI. The means current network camera connection mode is general; the means current network camera mode is hotspot. Delete Select a device in the Added device list and then click Delete button, system can disconnect the device and remove it from the Added device list.
  • Page 266 Parameter Function Input RTSP port of the remote device. The default setup is 554. RTSP port Note Skip this item if the manufacture is private or customize. Input HTTP port of the remote device. The default setup is 80. HTTP port Note Skip this item if the manufacture is private or customize.
  • Page 267 Parameter Function Static Check the box here, you can set IP address, subnet mask, default gateway manually. address/subnet You can input corresponding information here. mask/default gateway User name/password The account you login the remote device. Please input here to password verification to change the remote device password.
  • Page 268 You can see “Backup completed ” prompt. Note The export file extension name is .CVS. The file contains IP address, port, remote channel No. manufacturer, user name, password and etc. Import IP You can import the added device list to add the device conveniently. Click Import button, and then select the import file.
  • Page 269 Slight difference may be found since the connected network camera may not be same model. Here you can view device property information. The setups become valid immediately after you set. See Figure 5-26. Figure 5-26 Please refer to the following sheet for detailed information. Parameter Function Channel...
  • Page 270 The larger the number is, the strong the color is. This value has no effect on the general brightness of the whole video. The video color may become too strong if the value is too high. For the grey part of the video, the distortion may occur if the white balance is not accurate.
  • Page 271 Day/Night It is to set device color and the B/W mode switch. The default setup is auto.  Color: Device outputs the color video.  Auto: Device auto select to output the color or the B/W video according to the device feature (The general bright of the video or there is IR light or not.) ...
  • Page 272 H.264, MJPEG. The resolution here refers to the capability of the network Resolution camera. Frame Rate PAL：1～25f/s；NTSC：1～30f/s.  Main stream: You can set bit rate here to change video Bit Rate quality. The large the bit rate is, the better the quality is. Please refer to recommend bit rate for the detailed information.
  • Page 273 Image size It is the same with the resolution of the main stream. It is to set the image quality. There are six levels. Quality It is to set snapshot frequency. The value ranges from 1s to 7s. Interval Or you can set customized value. The max setup is 3600s/picture.

  • Page 274: Network

    Here you can set snap image saved path ( in the preview interface) and the record storage path in the preview interface).The default setup is C:\PictureDownload and C:\RecordDownload. Please click the Save button to save current setup. Figure 5-30 5.10.1.4 Channel Name Here you can set channel name.
  • Page 275 Figure 5-32 Please refer to the following sheet for detailed information. Parameter Function Mode There are two modes: static mode and the DHCP mode.  The IP/submask/gateway are null when you select the DHCP mode to auto search the IP. ...
  • Page 276 5.10.2.2 Connection The connection interface is shown as in Figure 5-33. Figure 5-33 Please refer to the following sheet for detailed information. Parameter Function Max connection The max client login amount (such as WEB, platform, cellphone and etc). The value ranges from 1 to 128(default). TCP port The default value is 37777.
  • Page 277 Figure 5-34 Please refer to the following sheet for detailed information. Parameter Function It is to set SSID name. You can use this name to search the SSID device. It is to set SSID password. You can use this password to Password connect to the network.
  • Page 278 Figure 5-35 Please refer to the following sheet for detailed information. Parameter Function Input WIFI AP IP address. IPv4 address Input WIFI AP network mask. IPv4 netmask Input WIFI AP gateway. IPv4 gateway Start IP/End IP Input start IP and end IP. The NVR can allocate the IP address in the range you specified here.
  • Page 279 Please check the box to enable WIFI function and then click the Search SSID button. Now you can view all the wireless network information in the following list. Double click a name to connect to it. Click Refresh button, you can view latest connection status. 5.10.2.5 3G 5.10.2.5.1 CDMA/GPRS The CDMA/GPRS interface is shown as in Figure 5-37.
  • Page 280 or the phone you set to get alarm message. Check send SMS box and then input the phone number in the receiver column. Click to add one receiver. Repeat the above steps you can add more phones. Select a phone number and then click you can delete it.
  • Page 281 Figure 5-39 5.10.2.7 DDNS The DDNS interface is shown as in Figure 5-40. The DDNS is to set to connect the various servers so that you can access the system via the server. Please go to the corresponding service website to apply a domain name and then access the system via the domain.
  • Page 282 Parameter Function User The user name you input to log in the server. Password The password you input to log in the server. Update period Device sends out alive signal to the server regularly. You can set interval value between the device and DDNS server here.
  • Page 283 Figure 5-41 5.10.2.9 Email The email interface is shown as in Figure 5-42. Figure 5-42 Please refer to the following sheet for detailed information. Parameter Function Please check the box here to enable email function. Enable Input server address and then enable this function. SMTP Server Port Default value is 25.
  • Page 284 Parameter Function Anonymity For the server supports the anonymity function. You can auto login anonymously. You do not need to input the user name. password and the sender information. The user name of the sender email account. User Name The password of sender email account. Password Sender email address.
  • Page 285 Figure 5-43 Please refer to the following sheet for detailed information. Parameter Function Check the corresponding box to enable PAT function. Status Display UPnP function status. It is corresponding to the UPnP mapping information on the router. Check the box before the service name to enable current PAT service. Otherwise, the service is null.
  • Page 286 Figure 5-44 Please refer to the following sheet for detailed information. Parameter Function SNMP Port The listening port of the proxy program of the device. It is a UDP port not a TCP port. The value ranges from 1 to 65535. The default value is 161 It is a string.
  • Page 287 packet, multiple-cast is the best option to reduce the broad width and the CPU load. The source host can just send out one data to transit. This function also depends on the relationship of the group member and group of the outer. Figure 5-45 5.10.2.13 Auto Register The auto register interface is shown as below.
  • Page 288 Figure 5-47 5.10.2.15 HTTPS In this interface, you can set to make sure the PC can successfully login via the HTTPS. It is to guarantee communication data security. The reliable and stable technology can secure the user information security and device safety. See Figure 5-48. Note ...
  • Page 289 Figure 5-49 You can see the corresponding prompt. See Figure 5-50. Now the server certificate is successfully created. Figure 5-50 5.10.2.15.2 Download root certificate In Figure 5-48, click button, system pops up a dialogue box. See Figure 5-51. Figure 5-51 Click Open button, you can go to the following interface.
  • Page 290 Figure 5-52 Click Install certificate button, you can go to certificate wizard. See Figure 5-53. Figure 5-53 Click Next button to continue. Now you can select a location for the certificate. See Figure 5-54.
  • Page 291 Figure 5-54 Click Next button, you can see the certificate import process is complete. See Figure 5-55. Figure 5-55 Click Finish button, you can see system pops up a security warning dialogue box. See Figure 5-56. Figure 5-56...
  • Page 292 Click Yes button, system pops up the following dialogue box, you can see the certificate download is complete. See Figure 5-57. Figure 5-57 5.10.2.15.3 View and set HTTPS port From Setup->Network->Connection, you can see the following interface. See Figure 5-58. You can see HTTPS default value is 443.
  • Page 293 Figure 5-59 5.10.3 Event 5.10.3.1 Video detect 5.10.3.1.1 Motion Detect After analysis video, system can generate a video loss alarm when the detected moving signal reached the sensitivity you set here. The motion detect interface is shown as in Figure 5-60.
  • Page 294 Figure 5-60 Figure 5-61...
  • Page 295 Figure 5-62 Figure 5-63...
  • Page 296 Figure 5-64 Figure 5-65 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable motion detection function. Please select a channel from the dropdown list. Period Motion detection function becomes activated in the specified periods.
  • Page 297 Parameter Function setup. If you click ESC button to exit the region setup interface system will not save your zone setup. Record System auto activates motion detection channel(s) to record once channel an alarm occurs. Please note you need to set motion detect record period and go to Storage->...
  • Page 298 Figure 5-66 5.10.3.1.3 Tampering The tampering interface is shown as in Figure 5-67. After analysis video, system can generate a tampering alarm when the detected moving signal reached the sensitivity you set here. For detailed setups, please refer to chapter 5.10.3.1.1 motion detect for detailed information. Figure 5-67 5.10.3.1.4 Scene Change From main window->Setup->Event->Video detect->Scene change, the video diagnosis interface is shown...
  • Page 299 Figure 5-68 For detailed setups, please refer to chapter 5.10.3.1.1 motion detect for detailed information. 5.10.3.2 IVS Plan The smart plan is for the smart network camera. If you do not set a rule here, you cannot use the intelligent functions in IVS (Chapter 5.10.3.3), Face detection (Chapter 5.10.3.4) and People counting (Chapter 5.10.3.5) when you are connecting to a smart network camera.
  • Page 300 Select a channel from the dropdown list. Click Add button, you can see an interface shown as below. See Figure 5-70. Select a channel from the dropdown list and then set preset. Click Add button and then set the corresponding rule. Note Some smart camera does not need to add the preset.
  • Page 301 the video height and width. The recommended height is 10% of the video.  The object and the background brightness different shall be more than 10 grey levels.  The object shall remain on the video for more than 2 seconds. The moving distance is larger than its own width and shall not be smaller than 15pixels (CIF resolution).
  • Page 302 Then you can set corresponding parameters. Click OK button to complete the setup. 5.10.3.3.1.1 Tripwire From main menu->Setup->Event-> Behavior analytics->Behavior analytics, click you can see the following interface. See Figure 5-73. System generates an alarm once there is any object crossing the tripwire in the specified direction. Figure 5-73 Check the Tripwire box to enable tripwire function.
  • Page 303 Figure 5-74 Click to draw filter object. See Figure 5-75. Figure 5-75 Select the blue line and then use mouse to adjust zone size. Note Each rule can set two sizes (min size/max size). Once the object is smaller than the min size or larger than the max size, there is no alarm.
  • Page 304 For detailed setups, please refer to chapter 5.10.3.1.1 motion detect for detailed information. 5.10.3.3.1.2 Intrusion (Cross warning zone) From main menu->Setup->Event-> Behavior analytics->Behavior analytics, click , and then select rule type as intrusion, you can see the following interface. See Figure 4-129. Note: ...
  • Page 305 Figure 5-77 For detailed setups, please refer to chapter 5.10.3.1.1 motion detect for detailed information. 5.10.3.3.1.3 Abandoned Object Detect From main menu->Setup->Event-> Behavior analytics->Behavior analytics, click , and then select rule type as abandoned object detection, you can see the following interface. See Figure 5-78. ...
  • Page 306 Figure 5-78 Check the Object box to enable object detect function.  Period: System can generate an alarm once the object is in the zone for the specified period. Click to draw the rule. See Figure 5-79. Figure 5-79 Now you can draw a rule. Left click mouse to draw a line, until you draw a rectangle, you can right click mouse.
  • Page 307 For detailed setups, please refer to chapter 5.10.3.1.1 motion detect for detailed information. 5.10.3.3.1.4 Missing Object Detect From main menu->Setup->Event-> Behavior analytics->Behavior analytics, click , and then select rule type as missing object detection, you can see the following interface. See Figure 2-7. ...
  • Page 308 Click Ok to complete the rule setup. For detailed setups, please refer to chapter 5.10.3.1.1 motion detect for detailed information. 5.10.3.3.1.5 Loitering From main menu->Setup->Event-> Behavior analytics->Behavior analytics, click , and then select rule type as loitering detection, you can see the following interface. See Figure 2-27. Note ...
  • Page 309 Figure 5-83  Duration: System can generate an alarm once the object is in the zone for the specified period.  Sensitivity: It is to set alarm sensitivity. The value ranges from 1 to 10.The default setup is 5. Click to draw the rule.
  • Page 310 Figure 5-84 Click to draw the rule. Click OK to complete the rule setup. For detailed setups, please refer to chapter 5.10.3.1.1 motion detect for detailed information. 5.10.3.3.2 Global Config From main menu->Setup->Event->Behavior analytics->Global, you can go to the global configuration interface.
  • Page 311 Figure 5-85 5.10.3.4 Face Detect (Optional) When camera detects human face, system can generate an alarm. From main menu->Setup->Event->Face detect, the interface is shown as in Figure 5-86.  Enable face boost: Check the box here, system can enhance the human face display pane. ...
  • Page 312  Channel: Please select a channel from the dropdown list. Check the box to enable people counting function.  OSD overlay: Check the box here; you can view the people amount on the surveillance video.  Direction: It is to set people flow direction. It includes entry/exit. ...
  • Page 313 Figure 5-88 5.10.3.7 Audio Detect (Optional) System can generate an alarm once it detect the audio input is abnormal or audio volume changes. From main menu->Setup->Event->Audio detect, you can see an interface shown as in Figure 5-89.  Input abnormal: Check the box here, system can generate an alarm once the audio input is abnormal.
  • Page 314 5.10.3.8 Alarm Before operation, please make sure you have properly connected alarm devices such as buzzer. The input mode includes local alarm and network alarm. 5.10.3.8.1 Local Alarm The local alarm interface is shown as in Figure 5-90. It refers to alarm from the local device. Figure 5-90 Figure 5-91...
  • Page 315 Figure 5-92 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable this function. Please select a channel from the dropdown list. Period This function becomes activated in the specified periods. There are six periods in one day.
  • Page 316 Parameter Function current channel as schedule record. System can delay the record for specified time after alarm Record Delay ended. The value ranges from 10s to 300s. Alarm out Enable alarm activation function. You need to select alarm output port so that system can activate corresponding alarm device when an alarm occurs.
  • Page 317 Figure 5-93 5.10.3.8.3 IPC external alarm The IPC external alarm interface is shown as in Figure 5-94. Network alarm refers to the alarm signal from the network. System does not anti-dither and sensor type setup. For setup information, please refer to chapter 5.10.3.8.1. Figure 5-94 5.10.3.8.4 IPC Offline Alarm...
  • Page 318 The IPC offline alarm interface is shown as in Figure 5-95. System can generate an alarm once the network camera is offline. For setup information, please refer to chapter 5.10.3.8.1. Figure 5-95 5.10.3.9 Abnormality From main menu->Setup->Event->Abnormality, it includes four types: HDD/Network/User/Device. See Figure 5-96 through Figure 5-99.
  • Page 319 Figure 5-97 Figure 5-98...
  • Page 320 Figure 5-99 Please refer to the following sheet for detailed information. Parameter Function Event The abnormal events include: Type HDD: No disk, disk error, disk no space;  Network: Net disconnection, IP conflict, MAC conflict.  User: Illegal login.  Device: Temperature is too high, fan speed is abnormal.

  • Page 321: Storage

    Parameter Function Alarm System can upload the alarm signal to the center (Including alarm upload center. Send If you enabled this function, System can send out an email to alert you Email when an alarm occurs. Buzzer Check the box here to enable this function. The buzzer beeps when an alarm occurs.
  • Page 322 Figure 5-101 Figure 5-102...
  • Page 323 Figure 5-103 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Pre-record Please input pre-record time here. The value ranges from 0 to 30. Redundancy Check the box here to enable redundancy function. Please note this function is null if there is only one HDD.
  • Page 324 the read-only, read-write, redundancy (if there are more than on HDD) and format operation. Figure 5-104 5.10.4.2.2 HDD The HDD interface is to set HDD group. See Figure 5-105. Figure 5-105 5.10.4.2.3 FTP The FTP interface is to set FTP information. See Figure 5-106. Please set the FTP as your remote storage location.
  • Page 325 The interface is shown as in Figure 5-107. Figure 5-107 Please refer to the following sheet for detailed information. Parameter Function Here you can view channel number. Channel The number displayed here is the max channel amount of your device. Status There are three statuses: schedule, manual and stop.
  • Page 326 Important Please make sure your purchased product support the RAID function, otherwise you cannot see the following interface. 5.10.4.4.1 RAID Config It is for you to manage RAID HDD. It can display RAID name, type, free space, total space, status and etc. Here you can add/delete RAID HDD.
  • Page 327 Figure 5-109 5.10.4.5 Storage 5.10.4.5.1 Main Stream The main stream interface is shown as in Figure 5-110. Here you can set corresponding HDD group to save main stream. Figure 5-110 5.10.4.5.2 Sub Stream The sub stream interface is shown as in Figure 5-111. Here you can set corresponding HDD group to save sub stream.

  • Page 328: Setting

    Figure 5-111 5.10.4.5.3 Snapshot The snapshot interface is shown as in Figure 5-112. Here you can set corresponding HDD group to save snapshot picture. Figure 5-112 5.10.5 Setting 5.10.5.1 General The general interface includes general, date/time and holiday setup. 5.10.5.1.1 General The general interface is shown as in Figure 5-113.
  • Page 329 Figure 5-113 Please refer to the following sheet for detailed information. Parameter Function Device ID It is to set device name. Device No. It is device channel number. Language You can select the language from the dropdown list. Please note the device needs to reboot to get the modification activated.
  • Page 330 Figure 5-114 Please refer to the following sheet for detailed information. Parameter Function Here you can select date format from the dropdown list. Date format There are two options: 24-H and 12-H. Time Format The time zone of the device. Time zone It is to set system time.
  • Page 331 Here you can click Add holidays box to add a new holiday and then click Save button to save. Figure 5-115 5.10.5.2 Display Display interface includes GUI, TV adjust, Tour and Customized split. 5.10.5.2.1 Display Here you can set background color and transparency level. See Figure 5-116. Figure 5-116 Please refer to the following sheet for detailed information.
  • Page 332 Color mode Please select from the dropdown list. Transparency Here is for you to adjust transparency. The value ranges from 128 to 255. Time Check the box here, you can view system time and channel title/channel number on the monitor video. title Image Check the box;...
  • Page 333 Please refer to the following sheet for detailed information. Parameter Function Check the box here to enable tour function. Enable tour Here is for you to adjust transparency. The value ranges from 5 to Interval 120s. The default setup is 5s. Here you can set window mode and channel group.
  • Page 334 Figure 5-119 Please refer to the following sheet for detailed information. Parameter Function Select the corresponding dome protocol. Protocol Default setup is console. Select the baud rate. Baud Rate Default setup is 115200. Data Bit The value ranges from 5 to 8. Default setup is 8.
  • Page 335 Figure 5-120 Figure 5-121 Please refer to the following sheet for detailed information. Parameter Function Select speed dome connected channel. Channel There are two options: local/remote. PTZ Type Please select remote type if you are connecting to the network PTZ. Please select local type if you are using RS485 to the PTZ camera.
  • Page 336 Parameter Function The value ranges from 1 to 2. Default setup is 1. Please set according Stop bit to the speed dome dial switch setup. Parity The options include non/odd/even/space/null. Default setup is none. Please set according to the speed dome dial switch setup. 5.10.5.5 POS Connect the NVR to the POS, it can receive the POS information and overlay on the corresponding record.
  • Page 337 Figure 5-124 Set source IP and destination IP, and then click OK. System goes back to Figure 5-123.  Source IP: POS device IP address.  Destination IP: NVR IP address. In Figure 5-123, click Channel Set button, select the channel you want to overlay POS information. Click OK button to complete the setup.
  • Page 338 Figure 5-126 5.10.5.6.2 Schedule It is to set schedule broadcast function. You can play the different audio files in the specified periods. From main menu->Setup->System->Voice->.Schedule, you can see the following interface. See Figure 5-127. Figure 5-127 Please refer to the following sheet for detailed information. Parameter Function There are six periods.
  • Page 339 Note  The audio file end time depends on the audio file size and the interval setup.  Priority: Bidirectional talk>Event trigger alarm>Trial listening>Audio schedule broadcast. 5.10.5.7 Account Note:  For the character in the following user name or the user group name, system max supports 6-digits. The space in the front or at the end of the string is null.
  • Page 340 Figure 5-129 Modify user It is to modify the user property, belonging group, password and rights. See Figure 5-130. Modify password It is to modify the user password. You need to input the old password and then input the new password twice to confirm the new setup.
  • Page 341 Figure 5-130 5.10.5.7.2 Group The group management interface can add/remove group, modify group password and etc. The interface is shown as in Figure 5-131. Figure 5-131 Add group: It is to add group and set its corresponding rights. See Figure 5-132. Please input the group name and then check the box to select the corresponding rights.
  • Page 342 Figure 5-132 Modify group Click the modify group button, you can see an interface is shown as in Figure 5-133. Here you can modify group information such as remarks and rights. Figure 5-133 5.10.5.7.3 ONVIF User When the camera from the third party is connected with the NVR via the ONVIF user, please use the verified ONVIF account to connect to the NVR.
  • Page 343 User, you can go to ONVIF user interface See Figure 5-134. Figure 5-134 Click Add user button, you can see the following interface. See Figure 5-135. Figure 5-135 Please set user name, password and then select group from the dropdown list. Click Save to complete setup.
  • Page 344 Figure 5-136 5.10.5.9 Import/Export The interface is shown as in Figure 5-137. This interface is for you to export or import the configuration files. Figure 5-137 Please refer to the following sheet for detailed information. Parameter Function Click to select import file. Browse It is to import the local setup files to the system.

  • Page 345: Information

    Figure 5-138 5.10.5.11 Upgrade The upgrade interface is shown as in Figure 5-139. Please select the upgrade file and then click the update button to begin update. Please note the file name shall be as *.bin. During the upgrade process, do not unplug the power cable, network cable, or shutdown the device.

  • Page 346: Log

    Figure 5-140 5.11.2 Log Here you can view system log. See Figure 5-141. Figure 5-141 Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, data Type operation, event operation, record operation, user management, log clear.

  • Page 347: Online User

    Parameter Function You can select log type from the drop down list and then click search Search button to view the list. You can click the stop button to terminate current search operation. You can select one item to view the detailed information. Detailed information Clear...

  • Page 348: Heat Map

    5.11.5 Heat Map From main menu->Info->Heat Map, the interface is shown as in Figure 5-144. Figure 5-144 5.11.6 HDD From main menu->Info->HDD, the HDD interface is shown as in Figure 5-145. Here you can view HDD information. Figure 5-145 5.12 Playback Click Playback button, you can see an interface is shown as in Figure 5-146.

  • Page 349: Search Record

    Figure 5-146 5.12.1 Search Record Please set record type, record date, window display mode and channel name.  Select Date You can click the date on the right pane to select the date. The green highlighted date is system current date and the blue highlighted date means it has record files.

  • Page 350: Playback

    Figure 5-149 5.12.3 Playback Select a file you want to play and then click Play button, system can begin playback. You can select to playback in full-screen. Please note for one channel, system cannot playback and download at the same time.

  • Page 351: Load More

    reference. Please go to you default file saved path to view the files. Figure 5-151 5.12.5 Load more It is for you to search record or picture. You can select record channel, record type and record time to download. Or you can use watermark function to verify file. 5.12.5.1 Download By File Select channel, record type, bit stream type and then input start time and end time.
  • Page 352 Click Download to local, system pops up the following interface for you to set record format and saved path. See Figure 5-153. Figure 5-153 You can click OK to download and view the download process. After the download operation, you can see corresponding dialog box.

  • Page 353: Smart Playback

    Figure 5-155 Set record format and saved path, you can click OK to download and view the download process. After the download operation, you can see corresponding dialog box. 5.12.5.3 Watermark Watermark interface is shown as In Figure 5-156. Please select a file and then click Verify button to see the file has been tampered with or not Figure 5-156 5.13 Smart Playback...

  • Page 354: Ivs (Behavior Analytics)

     There are two types to realize intelligent analytics function.  Smart network camera supports intelligent functions: Some smart camera supports the intelligent functions. For NVR, it just displays the intelligent alarm information from the smart network camera and set or playback the record file. ...

  • Page 355: Plate Recognition

    Figure 5-158 Step 4 Select a channel number and then click OK. Step 5 Set detection type as IVS and then set start time and end time. Step 6 Click Historic Analytics. Device displays the corresponding image. Step 7 Click the image; you can view the record file. ...

  • Page 356: Human Face

    Figure 5-159 Step 2 Set plate number, channel number, start time, end time. Note Device supports fuzzy plate number search function. Device searches all plate numbers by default if you do not input plate number information. The plate number search and playback function is for one-channel mode only. Step 3 Click Historic Analytics.

  • Page 357: Alarm

     Select the file and then click , you can lock the file in case it will be overwrtitten in the future.  Select the file and then click , you can mark the time of the detected event. Note The following human face has been modified for privacy reason.

  • Page 358: Log Out

    Figure 5-161 Please refer to the following sheet for detailed information. Type Parameter Function Alarm Video loss System alarms when video loss occurs. Type Motion detection System alarms when motion detection alarm occurs. Tampering System alarms when camera is viciously masking. Disk full System alarms when disk is full.
  • Page 359 Figure 5-162 5.16 Un-install Web Control You can use web un-install tool “uninstall web.bat” to un-install web control. Please note, before you un-installation, please close all web pages, otherwise the un-installation might result in error...
  • Page 360 6 Glossary  DHCP: DHCP (Dynamic Host Configuration Protocol) is a network protocol. It is one of the TCP/IP protocol cluster. It is principally used to assign temporary IP addresses to computers on a network.  DDNS: DDNS (Dynamic Domain Name Server) is a service that maps Internet domain names to IP addresses.
  • Page 361 7 FAQ Questions Solutions  NVR can not boot up Input power is not correct.  properly. Power connection is not correct.  Power switch button is damaged.  Program upgrade is wrong.  HDD malfunction or something wrong with HDD ribbon. ...
  • Page 362 Questions Solutions  Front panel PTZ error  PTZ decoder setup, connection or installation is not correct.  Cable connection is not correct.  PTZ setup is not correct.  PTZ decoder and NVR protocol is not compatible. NVR can not control PTZ. ...
  • Page 363 Questions Solutions  Alarm setup is not correct. Alarm signal can not been  Alarm output has been open manually. disarmed.  Input device error or connection is not correct.  Some program versions may have this problem. Please upgrade your system.
  • Page 364 Questions Solutions  Please make sure the IPC has booted up.  IPC network connection is right and it is online  IPC IP is in the blacklist.  I can not connect to the The device has connected to the too many IPC. It can not transmit the video.
  • Page 365 Otherwise it may result in HDD malfunction.  Please make sure the device is away from the direct sunlight or other heating sources. Please keep the sound ventilation.  Please check and maintain the device regularly.

  • Page 366: Appendix A Hdd Capacity Calculation

    Appendix A HDD Capacity Calculation Calculate total capacity needed by each device according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte.
  • Page 367 Appendix B Compatible Network Camera List Please note all the models in the following list for reference only. For those products not included in the list, please contact your local retailer or technical supporting engineer for detailed information. Manufact Model Version Video Encode Audio/Vid...
  • Page 368 Manufact Model Version Video Encode Audio/Vid Protocol √ － Cannon VB-M400 H264 Private √ MPix2.0DIR XNETM112011 H264 ONVIF 1229 √ VIPBL1.3MIR XNETM210011 H264 ONVIF 1229 √ IGC-2050F XNETM210011 H264 ONVIF 1229 √ CP PLUS CP-NC9-K 6.E.2.7776 H264 ONVIF/Private √ CP-NC9W-K 6.E.2.7776 H264 Private...
  • Page 369 Manufact Model Version Video Encode Audio/Vid Protocol √ HIDC-0100P h.2.2.1824 H264 ONVIF √ HIDC-1300V 2.0.0.21 H264 ONVIF √ HICC-1300W 2.0.1.7 H264 ONVIF √ HICC-2300 2.0.0.21 H264 ONVIF √ HDZ20HDX H20130114NS H264 ONVIF √ － LW342-FP H264 Private √ － LNB5100 H264 ONVIF √...
  • Page 370 Manufact Model Version Video Encode Audio/Vid Protocol √ D5118 1.7.8.9310-A1. H264 Private 5288 √ IM10C10 1.6.13.9261-O2 H264 Private .4657 √ DD4N-X 01.02.0015 MPEG4 Private √ DD423-X 01.02.0006 MPEG4 Private √ D5220 1.8.3-FC2-2012 H264 Private 0614-1.9320-A 1.8035 √ Samsung SNB-3000P 2.41 H264、MPEG4 ONVIF/Private √...
  • Page 371 Note  This manual is for reference only. Slight difference may be found in the user interface.  All the designs and software here are subject to change without prior written notice.  All trademarks and registered trademarks are the properties of their respective owners. ...

Table of Contents
