Code Retrieval; Troubleshooting; Limited Lifetime Warranty - RCA CRCR4383NR Owner's Manual

Code Retrieval

s,
Once you've programmed the remote to control your devices,
you may want to record the codes for future reference. If
you used the Direct Code Entry method, this is easy. Just
ugh
find the codes you entered and make a note of them in the
e.
boxes below. If you used one of the Code Search methods to
the
program your remote or if you used the Direct Entry method
but don't remember the code, you will need to retrieve each
ck device's five-digit code. Retrieving the actual code and writing
it down will save you time if you ever need to program the
fter
remote again (e.g., if programming is lost when you change
the
the batteries). If the codes are recorded, you can use the
etry Direct Entry method to reprogram your remote to control your
devices, which is quick and easy.
1. Press and hold the device key
Indicator light
(TV, SAT•CBL•DTC, DVD•VCR,
e
DVR•AUX) whose code you
at
wish to retrieve. The Indicator
light turns on. Keep pressing the
device key.
2. While holding the device key down, press and hold the
INFO key. The Indicator light turns off. After holding down
both keys for three seconds, the Indicator light turns back
on.
3. Release both keys. The Indicator light remains on.
4. Starting with the number 1 key, press and release each
number key on the keypad in the following order: 1-9, then
0. The number that causes the Indicator light to blink is the
first number of the code. As you find each number of the
is
code, write it down for future reference.
or
UX
Note: All TV codes begin with the number 1; all VCR and DVR/
ind
PVR codes begin with the number 2; all DVDs, the number 3;
and all satellite receivers and cable boxes, the number 5.
5. Repeat step 4 until you have retrieved all five numbers in
the code. After the fifth number is retrieved, the Indicator
ant
light blinks briefly, then turns off.
TIP: To exit the Code Retrieval Mode at any time, press the
ns
CLEAR key.
Note: If you press an invalid key during the Code Retrieval
process, the remote will not respond. If you do not press
the
a valid Code Retrieval key (TV, SAT•CBL•DTC, DVD•VCR,
.
DVR•AUX, INFO, CLEAR), Code Retrieval times out after 15
mes
seconds. The Indicator light blinks four times, and then turns
VCR.
off.
nual
ces
TV CODE
nt
l TV,
1
u
on.
the
DVD•VCR CODE
trol
DVDZVCR
r
o

Troubleshooting

Problem: The remote does not operate your device.
• Make sure the remote is in the correct mode by pressing
the corresponding device key (TV, SAT•CBL•DTC, DVD•VCR,
DVR•AUX). This tells the remote which device to operate.
• Remove any obstacles between the remote and the device. Make
sure you're aiming the remote at the device's IR sensor.
• Make sure the batteries are fresh and are properly installed.
Replace the batteries with two new AAA batteries, if necessary
(see the Battery Installation section).
Problem: The remote can't be programmed to operate your
device.
• If you are testing the remote while programming it, you may be
too far away from the device or at a wrong angle. There must be
an unobstructed path between the remote and the IR sensor on
the device. Move closer and make sure you point the remote at the
device you're trying to control.
• If you're using the Direct Entry programming method to enter
the codes for your brand and the unit is still not functioning
properly, try the auto, brand, or manual search method.
• To control combo units, like TV/VCRs or TV/DVDs, you must
program the individual corresponding device keys to control
each part of the combo unit. Once programmed successfully, the
TV key controls the TV functions, and the DVD•VCR key controls
the VCR or DVD functions.
• Make sure the batteries are fresh and are properly installed.
Problem: The remote doesn't perform commands properly.
• Make sure the remote is in the correct mode by pressing
the corresponding device key (TV, SAT•CBL•DTC, DVD•VCR,
DVR•AUX). This tells the remote which device to operate.
• Make sure device is ready (for example, the DVD player has a
disc loaded).
• You may have pressed an invalid key for the mode the remote is in.
• If you're trying to enter a channel number directly, try pressing
the ENTER key after entering the channel number as this is a
requirement of certain models and brands.
• There is a possibility that a programmed code may only be
able to control some of your device features (for example, only
turns a device on and off). To confirm that the device key is
programmed with the correct code for maximum functionality,
test the device. Attempt to control a variety of the device's
functions with the remote. If some of the features of your
devices don't work, try programming the remote with a different
code in the list using the Direct Code Entry Method, until you
find the code that allows the remote to control the majority of
your device's functions. Different codes can provide different
levels of functionality.
SAT•CBL•DTC CODE
Problem: The Indicator light does not light when you press a key.
5
• You may have pressed an invalid key for the mode the remote is
in.
• Make sure the remote is in the correct mode by pressing
SAT CABLE DTV CONVERTER
the corresponding device key (TV, SAT•CBL•DTC, DVD•VCR,
DVR•AUX). This tells the remote which device to operate.
• Make sure the batteries are fresh and are properly installed.
DVR•AUX CODE
Replace the batteries with two new AAA batteries, if necessary
(see the Battery Installation section).
Problem: The remote will not change channels on device.
• Make sure the remote is in the correct mode by pressing
DVR/PVR/VCR DVD TV SAT•CBL•DTC
the corresponding device key (TV, SAT•CBL•DTC, DVD•VCR,
DVR•AUX). This tells the remote which device to operate.
• Press the ENTER key after you enter a channel number.
• Remove any obstacles between the remote and the device. Make
sure to aim the remote at the IR sensor on the device.
Problem: The device's menu does not appear on the TV screen.
• Make sure you have connected the device to your TV properly and
selected the correct input. (See your devices' Owner's Manuals for
proper connection procedures.)
• Make sure the remote is in the correct mode by pressing
the corresponding device key (TV, SAT•CBL•DTC, DVD•VCR,
DVR•AUX). This tells the remote which device to operate.
• Menu access isn't supported for all brands. You may need to use
your original remote control to access menu functions for some
devices.
For more information, please visit www.rcaaccessories.com
Care and Maintenance
• Keep the remote dry. If it gets wet, wipe it dry immediately.
• Use and store the remote only in normal temperature
environments.
• Handle the remote gently and carefully. Don't drop it.
• Keep the remote away from dust and dirt.
• Wipe the remote with a damp cloth occasionally to keep it
looking new.
• Modifying or tampering with the remote's internal devices can
cause malfunction and invalidate its warranty.

Limited Lifetime Warranty

Audiovox Electronics Corporation (the "Company") warrants to you the
original retail purchaser of this product that should it, under normal use and
conditions, be proven defective in material or workmanship during its lifetime
while you own it, such defect(s) will be repaired or replaced (at the Company's
option) without charge for parts and repair labor.
To obtain repair or replacement within the terms of this Warranty, the product
is to be delivered with proof of warranty coverage (e.g. dated bill of sale),
specification of defect(s), transportation prepaid, to the Company at the
address shown below. Do not return this product to the Retailer.
This Warranty does not cover product purchased, serviced or used outside the
United States or Canada.
This Warranty is not transferable and does not extend to costs incurred for
installation, removal or reinstallation of the product. This Warranty does not
apply if in the Company's opinion, the product has been damaged through
alteration, improper installation, mishandling, misuse, neglect, or accident.
THE EXTENT OF THE COMPANY'S LIABILITY UNDER THIS WARRANTY IS
LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO
EVENT, SHALL THE COMPANY'S LIABILITY EXCEED THE PURCHASE PRICE
PAID BY PURCHASER FOR THE PRODUCT.
This Warranty is in lieu of all other express warranties or liabilities. ANY
IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE SHALL
BE LIMITED TO DURATION OF THIS WARRANTY. IN NO CASE SHALL
THE COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL
DAMAGES WHATSOEVER. No person or representative is authorized
to assume for the Company any liability other than expressed herein in
connection with the sale of this product.
Some states/provinces do not allow limitations on how long an implied
warranty lasts or the exclusion or limitation of incidental or consequential
damage so the above limitations or exclusions may not apply to you. This
Warranty gives you specific legal rights and you may also have other rights
which vary from state/province to state/province.
©2011 Audiovox Canada Limited
c/o Genco, 6685 Kennedy Road, Unit 3, Door 16,
Mississauga, Ontario, Canada L5T 3A5
