Headphone Output Jack
4
The stereo headphone jack (1/8 inch) is used to connect the Notebook PC's audio out signal to
amplified speakers or headphones. Using this jack automatically disables the built-in speakers.
LAN Port
5
The RJ-45 LAN port with eight pins is larger than the RJ-11 modem port and supports a standard Ethernet
cable for connection to a local network. The built-in connector allows convenient use without additional
adapters.
6 Display (Monitor) Output
The 15-pin D-sub monitor port supports a standard VGA-compatible device such as a monitor or projector to
allow viewing on a larger external display.

Left Side

Refer to the diagram below to identify the components on this side of the Notebook PC.
Knowing the Parts
