Right Side

Refer to the diagram below to identify the components on this side of the Notebook PC.
Flash Memory Slot
1
This Notebook PC has a Built-in memory card reader that can read four types of memory cards(Multimedia
Card (MMC) / Secure Digital Card (SD)/MS/MS PRO). The built-in memory card reader is not only
convenient, but also faster than most other forms of memory card readers because it utilizes the high
bandwidth PCI bus.
Enhanced USB Port (2.0/1.1)
2
The USB (Universal Serial Bus) port is compatible with USB 2.0 or USB 1.1 devices such
as keyboards, pointing devices, cameras, hard disk drives, printers, and scanners
connected in a series up to 12Mbits/sec (USB 1.1) and 480Mbits/sec (USB 2.0).
Microphone Input Jack
3
The mono microphone jack (1/8 inch) can be used to connect an external microphone or output signals from
audio devices. Using this jack automatically disables the built-in microphone. Use this feature for video
conferencing, voice narrations, or simple audio recordings.
Knowing the Parts
2-4
