Summary of Contents for Volvo 2015 S60

Page 1 W E B E D I T I O N O W N E R ' S M A N U A L...
Page 3 Volvo, an automobile designed drive. with your safety and comfort in mind. We encour- Your Volvo is designed to meet all applicable fed- age you to familiarize yourself with the equipment eral safety and emission standards. If you have...
Page 4: Table Of Contents
Contents 00 Introduction 01 Safety 02 Locks and alarm Important information......... 6 Occupant safety........16 Remote key and key blade....... 56 Environment..........12 Reporting safety defects......17 Valet locking ..........65 Important warnings........13 Seat belts ..........18 Keyless drive..........66 Supplemental Restraint System (SRS) ..
Page 5 03 Your driving environment 04 Driver support 05 Comfort and driving pleasure Instruments and controls......78 Stability system........148 Volvo Sensus.......... 212 Ignition modes.......... 88 Road sign information (RSI)* ....151 Menus and messages......213 Seats............90 Cruise control.......... 153 The MY CAR menus.......
Page 6 Contents 06 Infotainment 07 During your trip 08 Wheels and tires Introduction..........244 Driving recommendations....... 288 General information ....... 306 Radio............253 Refueling..........292 Tire inflation..........309 Media player........... 262 Loading........... 297 Inflation pressure ........312 AUX/USB sockets........267 Towing a trailer........300 Tire designations ........
Page 7 Contents 09 Maintenance and 10 Specifications 11 Index specifications Label information........380 Index............394 Volvo maintenance........338 Specifications......... 382 Maintaining your car....... 339 Overview of information and warning symbols........... 390 Hood and engine compartment....342 Volvo programs........393 Engine oil..........344 Fluids............
Page 8: Introduction
Before you operate your vehicle for the cle whose purpose is to provide important first time, please familiarize yourself with Volvo Cars of North America, LLC information in a clear and concise way. The the information found in the chapters...
Page 9 Introduction Important information Risk of damage to the vehicle Information Types of lists used in the manual Procedures Procedures (step-by-step instructions), or actions that must be carried out in a certain order, are arranged in numbered lists in this manual. If there is a series of illustrations associ- ated with step-by-step instructions, each step in the procedure is numbered in the...
Page 10 • Coolant or other reproductive harm. In addition, • Volvo reserves the right to make model • Engine oil certain fluids contained in vehicles and changes at any time, or to change certain products of component wear con-...
Page 11: Crash Event Data
The EDR in this vehicle is When your vehicle is parked, the gear selec- your Volvo not certifiable for legal opera- designed to record such data as: tor is locked in the P (Park) position. To tion in the U.S., Canada and other coun-...
Page 12 Volvo is responsi- Volvo has always been and continues to be a equipment, can read the information if they ble for ensuring that the information transmit- leader in automotive safety.
Page 13 License, regarding your rights under said available at www.volvocars.com. • busybox (based on version 1.13.2.) licenses. Volvo Car Corporation (VCC) offers to provide the source code of said free/open In order to read a QR code, a QR reader is GCC runtime library exception: http://...
Page 14: Environment
® trols and cleaner fuels are bringing us closer to our goal. In addition to continuous environ- Volvo is committed to the well being of its mental refinement of conventional gasoline- customers. As a natural part of this commit- powered internal combustion engines, Volvo...
Page 15: Important Warnings
Your new tested, or if you allow accessories to be your programmed presets to make radio Volvo is, or can be, equipped with many fea- installed by someone unfamiliar with your use quicker and simpler.
Page 16 Occupant safety..................16 Reporting safety defects................. 17 Seat belts ....................18 Supplemental Restraint System (SRS) ........... 22 Occupant Weight Sensor ............... 27 Side impact protection (SIPS) airbags ........... 31 Inflatable Curtain (IC) ................33 Whiplash Protection System – WHIPS........... 34 Crash mode....................
Page 17 S A F E T Y...
Page 18: 01 Safety
If you are taking any medication, consult your vehicle, please contact your authorized your physician about its potential effects dates back to 1927 when the first Volvo rolled Volvo retailer. If your retailer is unable to on your driving abilities.
Page 19: Reporting Safety Defects
Trans- could cause injury or death, you port Canada in addition to notifying Volvo Volvo strongly recommends that if should immediately inform the Cars of Canada Corp.
Page 20: Seat Belts
Correct height adjustment booster seat determined by age, weight and height. Volvo also believes no child should sit in the front seat of a vehicle. Most states and provinces make it mandatory for occupants of a vehicle to use seat belts.
Page 21 01 Safety Seat belts Seat belt retractor When wearing the seat belt remember: WARNING • The seat belt retractor will lock up in the The belt should not be twisted or turned. Never use a seat belt for more than one following situations: •...
Page 22 • It provides information about which seat Volvo service technician only. belts are fastened in the rear seat. A mes- • Any device used to induce slack into sage will appear in the information display the shoulder belt portion of the three- when a belt is being used.
Page 23 01 Safety Seat belts Seat belt use during pregnancy should strive to position the seat with as large a distance as possible between their belly and the steering wheel. Child seats Please refer to page 41 for information on securing child seats with the seat belts. The seat belt should always be worn during pregnancy.
Page 24: Supplemental Restraint System (Srs)
See also page 81 for more information about indicator and warning lights. Models with an digital instrument panel* As an enhancement to the three-point seat belts, your Volvo is equipped with a Supple- mental Restraint System (SRS). Volvo's SRS Option/accessory, for more information, see Introduction.
Page 25 (see below). This may cause airbag deployment which could result in serious injury. Have the vehicle towed to a trained and qualified Volvo service technician for repairs. Before attempting to tow the vehicle: Location of the passenger's side front airbag 1.
Page 26 SRS system, please contact a (e.g., a snow drift or bush), or a rigid, seating position, one may experience trained and qualified Volvo service technician fixed object at a low speed, the front air- abrasions, bruises, swellings, or other or Volvo customer support: bags will not necessarily deploy.
Page 27 Richmond Hill, Ontario L4B 0B9 fire. • 1-800-663-8255 Volvo's front airbags use special sen- Airbag decal on the outside of both sun visors sors that are integrated with the front www.volvocars.com/ca seat buckles. The point at which the...
Page 28 Feet must be on the floor, e.g., not on the steering wheel or the passenger's the dash, seat or out of the window. side dashboard. This should only be done by a trained and qualified Volvo service technician. • Failure to follow these instructions can result in injury to the vehicle occu- pants.
Page 29: Occupant Weight Sensor
Weight Sensor should be inspected by a of Federal Motor Vehicle Safety Standard front passenger's seat. trained and qualified Volvo service techni- (FMVSS) 208 and is designed to disable (will The OWS uses a PASSENGER AIRBAG OFF cian as soon as possible.
Page 30 Volvo recommends that children always be properly restrained in appropriate child restraints in the rear seats. rear seat. Do not assume that the passenger's side front airbag is...
Page 31 OWS system. Failure to front passenger's seat. If a child is follow these instructions could Volvo Cars of North America, LLC seated in the front passenger's seat adversely affect the system's function Customer Care Center...
Page 32 01 Safety Occupant Weight Sensor WARNING • Do not place any type of object on the front passenger's seat in such a way that jamming, pressing, or squeezing occurs between the object and the front seat, other than as a direct result of the correct use of the Automatic Locking Retractor/Emergency Locking Retractor (ALR/ELR) seat belt (see...
Page 33: Side Impact Protection (Sips) Airbags
01 Safety Side impact protection (SIPS) airbags General information NOTE SIPS airbag deployment (one airbag) occurs only on the side of the vehicle affected by the impact. The airbags are not designed to deploy in all side impact situa- tions. Components in the SIPS airbag system This SIPS airbag system consists of a gas generator, the side airbag modules built into...
Page 34 Never try to open or repair any compo- nents of the SIPS airbag system. This should be done only by a trained and qualified Volvo service technician. • In order for the SIPS airbag to provide its best protection, both front seat...
Page 35: Inflatable Curtain (Ic)
IC system. This should be restraint system. Only adults should sit in done only by a trained and qualified the front seats. Children must never be Volvo service technician. allowed in the front passenger seat, see page 39 for guidelines. Failure to follow •...
Page 36: Whiplash Protection System - Whips
Volvo service technician, support the occupant's head before moving even if the seats appear to be undam- slightly rearward.
Page 37 01 Safety Whiplash Protection System – WHIPS WARNING WARNING • Any contact between the front seat back- Boxes, suitcases, etc. wedged behind rests and the folded rear seat or a rear- the front seats could impede the func- facing child seat could impede the function tion of the WHIPS system.
Page 38: Crash Mode
Safety mode is a feature that is triggered if ing status should only be done by a one or more of the safety systems (e.g. front trained and qualified Volvo service or side airbags, an inflatable curtain, or one or technician.
Page 39 (pulled by another vehicle). There may be concealed damage that could make it difficult or impossible to control. The vehicle should be transported on a flatbed tow truck to a trained and qualified Volvo service technician for inspection/repairs.
Page 40: Child Safety
Volvo recommends the proper use of restraint of injuring or increasing the injury of a child. systems for all occupants including children.
Page 41: Automatic Locking Retractor
1. Attach the seat belt to the child seat Why does Volvo believe that no child should child’s reach. Unsupervised children according to the child seat manufactur- sit in the front seat of a car? It's quite simple could lock themselves in an open really.
Page 42 01 Safety Child safety Volvo recommends that you do not dis- connect the airbag system in your vehi- cle. • Volvo strongly recommends that every- one in the vehicle be properly restrained. • Volvo recommends that ALL occupants (adults and children) shorter than 4 feet...
Page 43: Child Restraint Systems
01 Safety Child restraint systems Child restraints Convertible seat Booster cushion Infant seat WARNING WARNING There are three main types of child restraint A child seat should never be used in the Always refer to the child restraint manufac- systems: infant seats, convertible seats, and front passenger seat of any vehicle with a turer's instructions for detailed information booster cushions.
Page 44 • A small child's head represents a con- siderable part of its total weight and its neck is still very weak. Volvo recom- mends that children up to age 4 travel, properly restrained, facing rearward. In addition, Volvo recommends that chil-...
Page 45: Infant Seats
01 Safety Infant seats Securing an infant seat with a seat WARNING belt A child seat should never be used in the front passenger seat of any vehicle with a front passenger airbag – not even if the "Passenger airbag off" symbol near the rear-view mirror is illuminated (on vehicles equipped with Occupant Weight Sensor).
Page 46 01 Safety Infant seats NOTE WARNING The locking retractor will automatically It should not be possible to move the child release when the seat belt is unbuckled restraint (child seat) more than 1 in. and allowed to retract fully. (2.5 cm) in any direction along the seat belt path.
Page 47: Convertible Seats
• A small child's head represents a con- siderable part of its total weight and its neck is still very weak. Volvo recom- mends that children up to age 4 travel, properly restrained, facing rearward. In addition, Volvo recommends that chil- dren should ride rearward facing, prop- erly restrained, as long as possible.
Page 48 01 Safety Convertible seats NOTE WARNING The locking retractor will automatically It should not be possible to move the child release when the seat belt is unbuckled restraint (child seat) more than 1 in. and allowed to retract fully. (2.5 cm) in any direction along the seat belt path.
Page 49 01 Safety Convertible seats WARNING A child seat should never be used in the front passenger seat of any vehicle with a front passenger airbag – not even if the "Passenger airbag off" symbol near the rear-view mirror is illuminated. If the severity of an accident were to cause the airbag to inflate, this could lead to serious injury or death to a child seated in this...
Page 50: Booster Cushions
01 Safety Booster cushions Securing a booster cushion 3. Fasten the seat belt by inserting the latch plate into the buckle (lock) until a distinct click is audible. Position the child correctly on the booster cush- Booster cushions are recommended for chil- Positioning the seat belt dren who have outgrown convertible seats.
Page 51: Isofix/Latch Lower Anchors
4. Firmly tension the lower child seat straps according to the manufacturer's instruc- tions. WARNING Volvo's ISOFIX/LATCH anchors conform to FMVSS/CMVSS standards. Always refer to the child restraint system's manual for weight and size ratings. Fasten the attachment correctly to the ISOFIX/...
Page 52 01 Safety ISOFIX/LATCH lower anchors WARNING • Be sure to fasten the attachment cor- rectly to the anchor (see the illustra- tion). If the attachment is not correctly fastened, the child restraint may not be properly secured in the event of a collision.
Page 53: Top Tether Anchors
• Child restraint anchorages are designed to withstand only those Your Volvo is equipped with child restraint loads imposed by correctly fitted child top tether anchorages in the rear seat. They restraints. Under no circumstances are are located on the rear parcel shelf.
Page 54: Child Safety Locks
01 Safety Child safety locks Manual child safety locks Child safety locks – rear doors The controls are located on the rear door jambs. Use the remote control's key blade or a screwdriver to adjust these controls. The rear doors can only be opened from the outside when the slot is in the hori- zontal position.
Page 55 01 Safety...
Page 56 Remote key and key blade..............56 Valet locking ................... 65 Keyless drive................... 66 Locks....................... 69 Alarm....................... 74...
Page 57 L O C K S A N D A L A R M...
Page 58: 02 Locks And Alarm
If either of the remote keys is lost, the other NOTE • by calling Volvo Customer Care at should be taken with the car to a Volvo 1-800-458-1552 In the remainder of this chapter, all refer- retailer. As an anti-theft measure, the code of...
Page 59 02 Locks and alarm Remote key and key blade Key memory: door mirrors and driver's Confirmation when locking/unlocking FCC ID:KR55WK49266 + Siemens VDO 5WK49233 seat the vehicle The position of the side door mirrors, power Settings can be made in the menu system for FCC ID:KR55WK49233 driver's seat* and the selected instrument audible and visual confirmation when the...
Page 60 Remote key not recognized you misplace a key, take the other keys to a Settings Car settings Lock during start. Try to start the trained and qualified Volvo service technician Audible settings and select vehicle again. for reprogramming as an anti-theft measure.
Page 61 02 Locks and alarm Remote key and key blade Remote key/Personal Car accept any interference received, including Communicator (PCC)* - common interference that may cause undesired opera- tion. functions Canada–IC: 3659A-WFS125VO Operation is subject to the following condi- tions: (1) this device may not cause interfer- ence, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Page 62 02 Locks and alarm Remote key and key blade After a short pause, press the Unlock button NOTE NOTE a second time within 10 seconds to unlock Any excess weight (snow, etc.) on the Buildings or other obstacles may interfere the other doors and the trunk.
Page 63 Both red lights flash alternatively: the several times from different places in rela- alarm was triggered less than 5 minutes tion to the vehicle, contact an authorized Volvo service technician. ago. Range The indicator lights provide information The PCC's lock and unlock functions have a according to the illustration: range of approximately 60 ft.
Page 64 02 Locks and alarm Remote key and key blade Detachable key blade Removing the key blade or unlock the vehicle will show the vehicle's most recently received status. The indicator The key blade can be removed from the lights will not flash when the information but- remote key.
Page 65 02 Locks and alarm Remote key and key blade Unlocking the driver's door with the 3. Insert the key blade as far as possible in the driver's door lock. Turn the key blade detached key blade to unlock the driver's door. This will trig- ger the alarm.
Page 66 Old batteries should be disposed of prop- NOTE erly at a recycling center or at your Volvo Re-assembling the remote key retailer. 1. Press the remote key's cover into place. Turn the remote key with the buttons upward so that the batteries do not fall out 2.
Page 67: Valet Locking
02 Locks and alarm Valet locking Blocking access to the trunk Activating the valet locking function you to block access to the trunk and glove compartment for e.g., valet parking or when the vehicle is brought to the retailer for serv- ice.
Page 68: Keyless Drive
02 Locks and alarm Keyless drive Keyless drive* (models with Personal system. Press MY CAR and go to NOTE Car Communicator only) settings Lock settings Keyless entry. • The gear selector must in the P posi- See page 215 for a description of the menu tion before the vehicle can be locked Keyless locking and unlocking system.
Page 69 02 Locks and alarm Keyless drive Locking the vehicle Keyless drive remote key and driver's When at least one PCC has been returned to the car, the message will be erased in the dis- seat/door mirror memory play and the audible signal will stop when: •...
Page 70 02 Locks and alarm Keyless drive Location of the keyless drive harmful interference, and (2) this device must WARNING antennas accept interference received, including inter- People with implanted pacemakers should ference that may cause undesired operation. not allow the pacemaker to come closer CAUTION than 9 inches (22 cm) to any of the keyless drive system's antennas.
Page 71: Locks
02 Locks and alarm Locks Locking and unlocking the vehicle unlocked with the detachable key blade. See – Insert the key blade into the slot and turn page 63. it 90 degrees to lock that door (the slot in From outside the vehicle a particular door locks that door only).
Page 72 02 Locks and alarm Locks From inside the vehicle (central locking Locking If only the driver's door has a central locking • button: button) Press the lock button : all of the doors that are closed will lock. • If the light is on, this indicates that all of the doors are locked.
Page 73 02 Locks and alarm Locks • The door can be unlocked by pulling the Glove compartment Opening the trunk manually door handle once and opened by pulling the handle again. Automatic relocking If the doors are unlocked, the locks will auto- matically reengage (re-lock) and the alarm will rearm after 2 minutes unless a door or the trunk has been opened.
Page 74 02 Locks and alarm Locks Locking/unlocking the trunk Locking the trunk with the remote key The alarm indicator light on the dashboard will stop flashing to indicate that the alarm is – Press the lock button on the remote, see not monitoring the entire vehicle.
Page 75 02 Locks and alarm Locks Opening the trunk from the inside (U.S. WARNING models only) • Keep vehicle doors and trunk locked and keep keys out of a child’s reach. Unsupervised children could lock themselves in an open trunk and risk injury.
Page 76: Alarm
(2) this device must accept any slot and the ignition is put in mode I: the tem. Contact a trained and qualified Volvo interference, including interference that may alarm has been triggered.
Page 77 02 Locks and alarm Alarm Disarming the alarm Remote key not functioning If the remote key is not functioning properly, – Press the Unlock button on the remote the alarm can be turned off and the vehicle key. can be started as follows: >...
Page 78 Instruments and controls................ 78 Ignition modes..................88 Seats....................... 90 Steering wheel..................96 Lighting....................98 Wipers and washers................106 Windows....................108 Mirrors....................110 Digial compass*..................113 Power moonroof................... 115 ® HomeLink Wireless Control System*..........117 Starting the engine................120 Transmission..................125 Eco Guide* and Power Meter*..............
Page 79 Y O U R D R I V I N G E N V I R O N M E N T...
Page 80: 03 Your Driving Environment
03 Your driving environment Instruments and controls Instrument overview...
Page 81 03 Your driving environment Instruments and controls Instrument panel information displays Function Page Function Page Controls for menus and 215, Hazard warning flashers messages, turn signals, 103, Controls for the infotain- 215, high/low beams, trip 98, 230 ment system and menus 244, 224 computer Climate system controls...
Page 82 03 Your driving environment Instruments and controls trol, the trip computer and messages. The needle moves on the scale, the more information is shown with text and symbols. economically the vehicle is being driven. Speedometer More detailed information can be found in the descriptions of the functions that use the Tachometer: Shows engine speed in information displays.
Page 83 03 Your driving environment Instruments and controls Indicator and warning symbols Theme Eco: gauges and indicators Theme Performance: gauges and indicators Fuel gauge. When the indicator shows a Fuel gauge. When the indicator shows a Indicator and warning symbols: analog instru- ment panel white marking, a yellow indicator light will white marking, a yellow indicator light will...
Page 84 If the engine does not start or if the function panel trained and qualified Volvo service technician check is carried out in ignition mode II, all as soon as possible. High beam indicator...
Page 85 The message can be should be driven to a trained and qualified erased and the symbol can be turned off by Warning symbols Volvo service technician for inspection, see pressing the OK button (see page 213 for page 139 for additional information. Symbol...
Page 86 MIN, the vehicle should be transpor- Low oil pressure 6 seconds if the driver has not fastened his or ted to an authorized Volvo workshop to have If the light comes on while driving, stop the her seat belt.
Page 87 213. The warning symbol can also driven, with great care, to an authorized come on in conjunction with other symbols. ing symbol illuminates, a graphic will be dis- Volvo workshop to have the brake system played in instrument panel and an explana- Action: checked.
Page 88 03 Your driving environment Instruments and controls Setting the clock Odometer display NOTE The clock can be set in the MY CAR menu When the ambient temperature is between The trip odometers are used to system. See page 215 for additional informa- 23°...
Page 89 03 Your driving environment Instruments and controls 5. Turn TUNE to set the correct minute and press OK to confirm the setting and deactivate this box. 6. Turn TUNE to select and press OK to complete the procedure. Settings System Use the menu selection options Time format...
Page 90: Ignition Modes
03 Your driving environment Ignition modes Inserting and removing the remote Removing the remote key Mode Function The remote key can be removed from the ignition slot by pulling it out. The odometer, clock and tem- perature gauge are illuminated. Power seats* can be adjusted Functions and the infotainment system can...
Page 91 03 Your driving environment Ignition modes Ignition modes Emergency towing See page 303 for important information Ignition mode 0 about the remote key when the vehicle is – The vehicle is unlocked. being towed. Ignition mode I – With the remote key fully pressed into the , press START/STOP ignition slot ENGINE briefly.
Page 92: Seats
03 Your driving environment Seats Front seats The front passenger seat backrest can be WARNING folded to a horizontal position to make room • Do not adjust the seat while driving. for a long load. Fold the backrest as follows: The seat should be adjusted so that Move the seat as far back and down as the brake pedal can be depressed...
Page 93 03 Your driving environment Seats Button for storing a position Power seat NOTE • M (memory) button Only one of the power seat's controls can be used at the same time. Programming the seat's memory • The power seats have an overload Three different seating and door mirror posi- protector that activates if a seat is tions can be stored in the driver seat's mem-...
Page 94 03 Your driving environment Seats 1. Insert a remote key in the ignition slot. 2. Exit the vehicle and lock the doors with NOTE the remote key (or close the driver's door 2. Go into the MY CAR menu and go to As a safety precaution, the seat will stop and press the lock button on the door Settings...
Page 95 03 Your driving environment Seats Rear seats Emergency stop The driver's seat and door mirrors will auto- matically move to the position in which you Rear center head restraint left them (if the vehicle has been unlocked WARNING with one of the other keys and new seat/ •...
Page 96 03 Your driving environment Seats Automatically folding down the rear The center head restraint should be adjusted CAUTION according to the passenger's height. The seat’s outboard head restraints The rear head restraints should not be restraint should be carefully adjusted to sup- kept folded down for prolonged periods.
Page 97 03 Your driving environment Seats 1. Pull the release control handle(s). WARNING WARNING 2. Fold the backrest forward. Adjust the • • Keep vehicle doors and trunk locked When one or more sections of the center seat head restraint if necessary. and keep keys out of a child’s reach.
Page 98: Steering Wheel
03 Your driving environment Steering wheel Adjusting Horn WARNING Never adjust the steering wheel while driv- ing. With the optional speed-dependent power steering the level of steering force can be adjusted, see page 237. Keypads and steering wheel paddles* Adjusting the steering wheel Horn Lever for releasing/locking the steering –...
Page 99 03 Your driving environment Steering wheel Electrically heated* steering wheel Button for steering wheel heating With the engine running, press this button once to begin warming the steering wheel (press again to switch off). The indicator light in the button will illuminate when the function is active.
Page 100: Lighting
In Canada: the daytime running lights will Rear fog lights (see page 102) be on Headlight switch With the headlight switch in the Volvo recommends using the posi- position: tion whenever possible. • The daytime running lights will be on (the...
Page 101 03 Your driving environment Lighting • High/low beam headlights Pull the lever toward the steering wheel to position 2 and release it to toggle between low and high beams. High beam flash Pull the lever toward the steering wheel to position 1.
Page 102 03 Your driving environment Lighting Models with an analog instrument panel CAUTION symbol will go out when these mes- sages are displayed. In the following situations, it may be nec- When AHB is activated, the symbol essary to switch between high and low will illuminate in the instrument panel.
Page 103 20 seconds after the vehicle leaves Active Bending Lights or under Settings trained and the tunnel. qualified Volvo Car settings Light settings Active The rain sensor does not have to be activated service techni- Bending Lights.
Page 104 This lighting goes out just ignition is switched off. The auxiliary lights must be connected to the vehicle's electrical system, which should only be done by a trained and authorized Volvo service technician. See page 215 for more information about the menu system.
Page 105 03 Your driving environment Lighting Hazard warning flashers Turn signals The rear fog lights will only function in combi- nation with the high/low beam headlights. – Press the button to switch the rear fog lights on/off. > The rear fog light indicator symbol on the instrument panel and the light in the button illuminate when the rear fog lights are switched on.
Page 106 03 Your driving environment Lighting Courtesy lights/door step lighting* The lighting in the front part of the passenger NOTE compartment is controlled with the buttons The courtesy lights/door step lighting switch • This automatic flashing sequence can (1) and (2) in the roof console. on/off automatically when one of the front be interrupted by immediately moving doors is opened/closed.
Page 107 03 Your driving environment Lighting Approach lighting If the lighting is switched on manually and the vehicle is locked, the courtesy lighting will Approach lighting is activated by pressing the switch off automatically after one minute. approach light button on the remote key (see the illustration on page 59).
Page 108: Wipers And Washers
03 Your driving environment Wipers and washers Windshield wipers/washers Windshield wipers off Rain sensor* Move the lever to position 0 to The rain sensor automatically regulates wiper switch off the windshield wipers. speed according to the amount of water on the windshield.
Page 109 03 Your driving environment Wipers and washers Deactivating Move the lever toward the steering wheel to CAUTION start the windshield and headlight washers. Deactivate the rain sensor by pressing the • Use ample washer fluid when washing After the lever is released the wipers make button or press the lever down to the windshield.
Page 110: Windows
03 Your driving environment Windows Power windows All power windows can be operated using the WARNING control panel in the driver's door. The control • Always remove the ignition key when panels in the other doors only operate the the vehicle is unattended to put the window in the respective doors.
Page 111 03 Your driving environment Windows Resetting When not in use, release the hooks and hold the sun shade while it retracts. If the battery has been disconnected, the auto open function must be reset so that it will work properly. 1.
Page 112: Mirrors
03 Your driving environment Mirrors Power door mirrors Retractable power door mirrors* the vehicle, for example when parallel park- ing. The mirrors can be retracted for parking/driv- ing in narrow spaces: To activate this function, select reverse gear and press the L or R mirror control button to 1.
Page 113 03 Your driving environment Mirrors • Automatically tilting the door mirrors Retract the mirrors with the L and R but- in the respective buttons indicate that the tons. function is active. Switch the function off when parking when then windshield/rear window/mirrors •...
Page 114 03 Your driving environment Mirrors strength of following vehicles' headlights), and work together to help eliminate glare. NOTE Obstructing the forward sensor with e.g., parking stickers, transponders, etc., or the rear sensor by placing objects on the par- cel shelf or the rear seat in such a way that light is prevented from reaching the sensor will reduce the auto-dim function in the interior rearview mirror and optional auto-...
Page 115: Digial Compass
03 Your driving environment Digial compass* Operation brated if the vehicle is driven into a new one 5. Press the button repeatedly until the (see the magnetic zones on the map in the number of the desired magnetic zone following section "Selecting a magnetic 1-15 ) is displayed.
Page 116 03 Your driving environment Digial compass* Selecting a magnetic zone Magnetic zones. The earth is divided into 15 magnetic zones. The correct zone must be selected for the compass to work correctly. 1. Put the ignition in mode II. 2. Using a pen or similar object, press and hold the button on the rear side of mirror for at least 3 seconds.
Page 117: Power Moonroof
03 Your driving environment Power moonroof Introduction Sliding moonroof Manual opening – Pull the switch back to the first stop (the The moonroof controls are located in the position for manual opening) and hold it ceiling console near the rearview mirror. The until the moonroof has opened to the moonroof can be opened vertically and hori- position of your choice.
Page 118 03 Your driving environment Power moonroof Wind blocker Tilt position WARNING • During manual closing, if the moonroof is obstructed, immediately open it again. • Never open or close the moonroof if it is obstructed in any way. • Never allow a child to operate the moonroof.
Page 119: Homelink ® Wireless Control System
03 Your driving environment HomeLink ® Wireless Control System* Introduction Programming HomeLink WARNING • If you use HomeLink to open a garage NOTE door or gate, be sure no one is near the gate or door while it is in motion. Some vehicles may require the ignition to be switched on or be in the “accessories”...
Page 120 03 Your driving environment HomeLink ® Wireless Control System* 3. Firmly press, hold for five seconds and 2. Simultaneously press and hold both the 6. Return to the vehicle and firmly press, chosen HomeLink and hand-held trans- release the programmed HomeLink but- hold for two seconds and release the pro- mitter buttons until the HomeLink indica- ton up to two separate times to activate...
Page 121 03 Your driving environment HomeLink ® Wireless Control System* Resetting HomeLink Buttons both the HomeLink and hand-held trans- For questions or comments, contact Home- mitter buttons. Link at: www.homelink.com or phone 1–800– Use the following procedure to reset (erase 355–3515. Proceed with “Programming”...
Page 122: Starting The Engine
10 seconds. If the engine has not these pedals is not impeded. started, repeat the procedure. • Volvo's floor mats are specially manu- factured for your car. They must be CAUTION firmly secured in the clips on the floor...
Page 123 03 Your driving environment Starting the engine WARNING NOTE CAUTION • • • Always remove the remote key from After a cold start, idle speed may be When starting in cold weather, the the ignition slot when leaving the vehi- noticeably higher than normal for a automatic transmission may shift up at cle and ensure that the ignition in...
Page 124 03 Your driving environment Starting the engine Engine Remote Start (ERS)* Information WARNING Introduction Keep the following in mind before using Approach lighting ERS is a feature that makes it possible to Starting the engine remotely start the engine to cool or heat the •...
Page 125 03 Your driving environment Starting the engine Switching off the engine Models with a Personal Car Switching off an engine started with Communicator (PCC) remote key* (see With the engine running, press the START/ page 61) Any of the following will switch off the engine STOP ENGINE button.
Page 126 03 Your driving environment Starting the engine 4. Connect the black jumper cable to the WARNING WARNING auxiliary battery's negative (–) terminal (3) • PROPOSITION 65 WARNING! Do not connect the jumper cable to and to the ground point in your vehicle's any part of the fuel system or to any Battery posts, terminals, and related engine compartment (right engine mount...
Page 127: Transmission
03 Your driving environment Transmission Automatic transmission before the gear lever can be moved from the CAUTION P position. The transmission’s temperature is moni- tored to help prevent damage to the trans- WARNING mission or other drivetrain components. If there is a risk of overheating, the warning Always apply the parking brake when the symbol on the instrument panel will illumi- vehicle is parked, particularly when park-...
Page 128 03 Your driving environment Transmission Gear indicator While driving To shift gears manually, move the • gear selector to the side from D The gear currently being If you select the manual shifting position toward +S–. The +S– symbol in the while driving, the gear that was being used is displayed on the right instrument panel will change from...
Page 129 03 Your driving environment Transmission Geartronic: steering wheel paddles* ment panel will change to the number of Geartronic: Sport mode (S) the gear currently being used. In addition to the manual gearshift function This transmission mode provides sportier using the gear selector, this option makes it Shifting gears: shifting characteristics and enables a more possible to manually shift gears from the...
Page 130 (this selects 2nd gear). Press the selector forward again and release it to select 3rd gear. The optional steering Your Volvo can be equipped with permanent wheel paddles can also be used; see the If the vehicle cannot be driven, for example All Wheel Drive, which means that power is previous section "Geartronic: steering...
Page 131 AWD system. A warning light will also illuminate in the instrument panel. If this occurs, have the system checked by a trained and qualified Volvo service techni- cian.
Page 132: Eco Guide* And Power Meter
03 Your driving environment Eco Guide* and Power Meter* Introduction Power Meter Current (instantaneous) reading This is the current level of economical driving; These gauges help improve driving economy. This gauge indicates the engine power that the higher the reading, the more economically has been utilized and the amount of power To display or remove these functions from the the vehicle is being driven.
Page 133 03 Your driving environment Eco Guide* and Power Meter* higher the reading on the scale, the greater the amount of power that is being utilized. The larger the gap between the two indica- tors, the greater the amount of power remain- ing.
Page 134: Eco
(with the exception NOTE of certain engines). Eco is a function developed by Volvo to give When Eco is activated, several climate the driver the opportunity to actively drive symbol will be displayed in the...
Page 135 03 Your driving environment Eco* Activating Eco Coast Eco Coast limitations engaged from the engine and engine rpm will be reduced to the idle level Eco Coast is activated when the accelerator This function will not be available if: (approx. 700-800 rpm), which helps reduce pedal is released completely if: •...
Page 136 03 Your driving environment Eco* Other ECO-related settings can be made in the vehicle's MY CAR menu. See page 215 for more information. Option/accessory, for more information, see Introduction.
Page 137: Start/Stop
03 Your driving environment Start/Stop* Introduction Deactivating Start/Stop function of certain systems may reduced at this time. For example, blower speed and In certain situations (e.g., Start/Stop is a function that is available with high infotainment system volume may be driving in heavy, stop-and-go certain engines/transmissions.
Page 138 03 Your driving environment Start/Stop* Auto-stop exceptions Auto-start exceptions Condition/situation In certain situations or conditions, the engine In certain situations or conditions, the engine The main battery's temperature is below may not auto-stop when the vehicle comes may auto-start even though the driver is still freezing or too high.
Page 139 03 Your driving environment Start/Stop* If the engine does not auto-start, this Condition/situation could be due to: • The driver's seat belt is not fastened The gear selector is moved from D to S • or "+/–". The gear selector is in P and the driver's door is opened The driver's door is opened with the gear In these cases, the driver will have to restart...
Page 140 Symbol Message Information/action Auto Start/Stop Service Start/Stop is not functioning properly. Contact a Volvo retailer or a trained and qualified Volvo required service technician. Autostart Engine running This is triggered if the driver's door is opened while the engine is auto-stopped.
Page 141: Brakes
DO NOT DRIVE. Have the vehicle towed to a activated. This function causes an additional trained and qualified Volvo service techni- taillight on each side of the vehicle to illumi- cian and have the brake system inspected.
Page 142 03 Your driving environment Brakes The adaptive brake lights activate if: pedal is depressed. To avoid such a delay cle first reaches a speed of approximately when the brakes are needed, depress the 6 mph (10 km/h). The brake pedal will pulsate •...
Page 143 MIN mark in the reservoir or if a brake sys- tem-related message is shown in the infor- mation display: DO NOT DRIVE. Have the vehicle towed to a trained and qualified Volvo service technician and have the brake system inspected.
Page 144: Parking Brake
03 Your driving environment Parking brake Electric parking brake Applying the electric parking brake NOTE An electric parking brake has the same func- • In an emergency the parking brake can tion as a manual parking brake. be applied when the vehicle is moving by holding in the control.
Page 145 03 Your driving environment Parking brake Releasing the electric parking brake Heavy load uphill 3. Press firmly on the brake pedal. A heavy load, such as a trailer, can cause the 4. Pull the parking brake control. vehicle to roll backward when the parking Automatic release brake is released automatically on a steep 1.
Page 146 A fault is preventing the parking brake from being released. Try to apply the parking brake and release it sev- fully released eral times. If the problem persists, contact an authorized Volvo workshop. If you drive off with this error mes- sage showing, a warning signal sounds.
Page 147 03 Your driving environment...
Page 148 Stability system..................148 Road sign information (RSI)* ..............151 Cruise control..................153 Adaptive Cruise Control (ACC)*............155 Distance Alert* ..................166 City Safety™ ..................169 Pedestrian and Cyclist Detection with Full Auto Brake*....... 175 Driver Alert System* ................185 Park assist*................... 194 Rear Park Assist Camera (PAC)* ............
Page 149 D R I V E R S U P P O R T...
Page 150: 04 Driver Support
04 Driver support Stability system Introduction Spin control (SC) This system is automatically deactivated if the driver selects Sport mode. The spin control function is designed to help The Dynamic Stability and Traction Control prevent the drive wheels from spinning while system (DSTC) consists of a number of func- the vehicle is accelerating.
Page 151 • Stop the vehicle in a safe place, turn off the engine and restart it. • If the message is still displayed when the engine has restarted, drive to an authorized Volvo work- shop to have the system inspected. "Message"...
Page 152 04 Driver support Stability system WARNING The stability system is intended to help improve driving safety. It supplements, but can never replace, the driver's judgment and responsibility when operating the vehi- cle. Speed and driving style should always be adapted to traffic and road conditions.
Page 153: Road Sign Information (Rsi)
04 Driver support Road sign information (RSI)* Introduction Operation Displaying the speed limit indication can be deactivated. To do so: • Deselect the alternative in MY CAR Settings Car settings Road Sign Information or cancel by pressing EXIT. Speed alert The driver can opt to be alerted if the vehicle exceeds the posted speed limit by more than 3 mph (5 km/h).
Page 154 04 Driver support Road sign information (RSI)* • Twisted or damaged signs • Obstructed signs • Signs that are partially covered by snow, ice, etc. Option/accessory, for more information, see Introduction.
Page 155: Cruise Control
04 Driver support Cruise control Operation Engaging the cruise control function Adjusting the set speed Before a speed can be set, the cruise control After a speed has been set, it can be system must be engaged (put in standby increased or decreased by using the mode).
Page 156 04 Driver support Cruise control Automatic deactivation WARNING Cruise control is automatically deactivated There may be a significant increase in temporarily if one of the following occurs: speed after the button has been • If the speed drops below approximately pressed.
Page 157: Adaptive Cruise Control (Acc)
When there are no longer Radar sensor in front grille only be performed by a trained and slower moving vehicles ahead, your vehi- qualified Volvo technician. Adaptive Cruise Control consists of: cle will accelerate to resume the set •...
Page 158 04 Driver support Adaptive Cruise Control (ACC)* 2-second interval will vary according the adaptive cruise control system. This is nor- WARNING speed of the vehicles. mal. When Adaptive Cruise Control is in standby mode or is switched off com- WARNING WARNING pletely, the brakes will not be modulated •...
Page 159 04 Driver support Adaptive Cruise Control (ACC)* Operation Putting ACC in standby mode WARNING Before ACC can be used to regulate speed Adaptive Cruise Control only warns of and/or the distance to a vehicle ahead, it vehicles detected by the radar sensor, see must first be put in standby mode.
Page 160 04 Driver support Adaptive Cruise Control (ACC)* pedal, the vehicle's speed when the but- When this symbol has changed col- Different time intervals can ton is pressed will be set. ors from white to green, ACC is in be selected and are shown in active mode and the vehicle will •...
Page 161 04 Driver support Adaptive Cruise Control (ACC)* • Standby mode (temporary deactivation) the radar sensor is obstructed by, for NOTE example, wet snow or rain. To temporarily deactivate ACC (put it in If the accelerator pedal is only depressed standby mode): Resuming the set speed for a short time, such as when passing •...
Page 162 04 Driver support Adaptive Cruise Control (ACC)* moving at speed below 18 mph WARNING WARNING (30 km/h)) Please be aware that this function will also Switching from ACC to CC means that: • Automatic standby mode when ACC cause the vehicle to accelerate briefly in •...
Page 163 04 Driver support Adaptive Cruise Control (ACC)* • The vehicle ahead must be within a rea- NOTE WARNING sonable distance (not farther away than ACC can remain active and keep your At speeds above 18 mph (30 km/h), ACC approx. 100 ft/30 meters) vehicle at a standstill for up to 4 minutes.
Page 164 WARNING The parking brake is applied sensor may be damaged in any way, contact a trained and qualified Volvo • automatically The radar sensor has a limited field of service technician as soon as possible.
Page 165 In certain situations, the radar sensor Fault tracing and actions only be performed by a trained and cannot detect vehicles at close quarters, qualified Volvo technician. Radar blocked See manual If the message for example a vehicle that suddenly is displayed, this means that the radar signals...
Page 166 04 Driver support Adaptive Cruise Control (ACC)* System with Auto-brake and Pedestrian The table lists possible causes for this mes- Detection will not function. sage being displayed, and suitable actions. Cause Action The surface of the radar in the grille is dirty or obstructed in some Clean the radar surface, or remove the object causing the obstruction.
Page 167 Cruise control Service ACC is not functioning. required Contact a trained and qualified Volvo service technician. Press Brake To hold The vehicle is at a standstill and ACC will release the brakes before the parking brake engages to keep the vehicle stopped but a problem with the parking brake means that the vehicle may begin to roll.
Page 168: Distance Alert
04 Driver support Distance Alert* Introduction Depending on the optional equipment NOTE selected, there may not be room for a Dis- Distance Alert is part of Adaptive Cruise Con- Distance Alert only monitors distance to tance Alert button in the center console. In trol and is a function that provides informa- the vehicle ahead while Adaptive Cruise this case, the function is controlled through...
Page 169 04 Driver support Distance Alert* Five different time intervals WARNING NOTE can be selected and are Only use a time interval that is suitable in Strong sunlight, reflections, extreme light shown in the display as 1–5 current traffic conditions. contrasts, the use of sunglasses, or if the horizontal bars.
Page 170 See page 162 for information on the radar sensor’s limitations. Collision warn. Serv- Distance Alert or Collision Warning with Full Auto-brake and Pedestrian Detection is not functioning prop- ice required erly. Contact a trained and qualified Volvo service technician. Option/accessory, for more information, see Introduction.
Page 171: City Safety
This is done in order to always give the driver’s actions highest priority. City Safety is a registered trademark of the Volvo Car Corporation...
Page 172 04 Driver support City Safety™ Function tion display to indicate that the system is/has WARNING been active. • City Safety™ only reacts to vehicles traveling in the same direction as your NOTE vehicle and does not react to small • vehicles or motorcycles or to people or When City Safety™...
Page 173: Troubleshooting
04 Driver support City Safety™ Press My Car in the center console control WARNING NOTE Settings Car settings panel and go to • The laser sensor has certain limitations Keep the windshield in front of the Driver support systems City Safety.
Page 174 (magnifiers) – Class • Before the windshield is replaced, 1M laser product. contact a Volvo retailer to ensure that The lower decal describes the laser beam's the correct windshield is ordered and physical data and contains the text: installed.
Page 175 OK button on the turn signal only be done by a trained and qualified NOTE lever. Volvo service technician. The function of aftermarket laser detectors • Do not remove the laser sensor may be affected by City Safety's laser sen- (including removal of the lenses).
Page 176 Remove the obstruction and/or clean the windshield in front of the sensor(s). For more information on the sensor’s limitations, see page 171. City Safety Service City Safety™ is not functioning. required • If this message remains in the display, have the system checked by a trained and qualified Volvo service technician.
Page 177: Pedestrian And Cyclist Detection With Full Auto Brake
04 Driver support Pedestrian and Cyclist Detection with Full Auto Brake* Introduction The system should not be used in such a way WARNING that the driver changes his/her way of operat- Pedestrian and Cyclist Detection with Full • Pedestrian and Cyclist Detection with ing the vehicle.
Page 178 NOTE performed by a trained and qualified is a risk of collision with a vehicle, a cyclist or Volvo technician. The auto-brake and brake support func- a pedestrian, the driver is alerted by a flash- tions are always on and cannot be turned ing red warning light and an audible warning off.
Page 179 04 Driver support Pedestrian and Cyclist Detection with Full Auto Brake* Operation Activating/deactivating the audible WARNING warning signal only Settings are made by pressing MY CAR on • Short The setting should only be used The audible warning signal can be activated/ the center console control panel and using in situations where traffic is light and deactivated by pressing MY CAR on the cen-...
Page 180 04 Driver support Pedestrian and Cyclist Detection with Full Auto Brake* Limitations control panel and going to Settings WARNING Strong sunlight, reflections, extreme light settings Driver support systems • In certain situations, the system can- contrasts, the use of sunglasses, or if the Collision Warning.
Page 181 04 Driver support Pedestrian and Cyclist Detection with Full Auto Brake* information on the radar sensor and its limita- WARNING NOTE tions, see page 162. • • The system is not activated at speeds To help protect the camera in very hot under approx.
Page 182 04 Driver support Pedestrian and Cyclist Detection with Full Auto Brake* Pedestrian detection entire body and the person must be at WARNING least 32 in. (80 cm) tall. • The camera has the same limitations • The system cannot detect a pedestrian as the human eye.
Page 183: Cyclist Detection
04 Driver support Pedestrian and Cyclist Detection with Full Auto Brake* • Cyclist detection The camera's capacity to see a cyclist at dawn or dusk is limited, much as it is for the human eye. • The camera's function is deactivated and will not detect a cyclist in darkness or in tunnels, even if there is street lighting in the area.
Page 184 04 Driver support Pedestrian and Cyclist Detection with Full Auto Brake* WARNING Fault tracing and actions Pedestrian and Cyclist Detection with Full Windscreen Sensors Auto Brake is designed to be a supple- If the message mentary driving aid. It is not, however, blocked is displayed, this means that the intended to replace the driver's attention...
Page 185 Wait a short time. It may take several minutes for the camera to regis- display. ter visibility. The surface between the inside of the windshield and the camera is Contact an authorized Volvo retailer or service technician to have this dirty. surface cleaned. Symbols and messages in the display...
Page 186 162 for more information on the radar sensor’s limitations. Collision warn. Pedestrian and Cyclist Detection with Full Auto Brake is partially or completely not functioning. Service required Contact a trained and qualified Volvo service technician if the message remains in the display. Option/accessory, for more information, see Introduction.
Page 187: Driver Alert System
04 Driver support Driver Alert System* Introduction Driver Alert Control (DAC) DAC is designed to help detect a slowly changing driving pattern. It is primarily The Driver Alert System is designed to help a intended to be used on main roads and is not driver who may be becoming fatigued or who meant for use in city traffic.
Page 188 See page 179 for information on the camera’s limitations. Driver Alert Sys Service The system is not functioning. Contact a trained and qualified Volvo service technician if the message required remains in the display.
Page 189 04 Driver support Driver Alert System* Center console display Symbol Message Description Driver Alert OFF The function is not switched on. Driver Alert Available The function is active. Driver Alert Standby <65 The function has gone into standby mode because the vehicle's speed is below 40 mph (65 km/h). km/h Driver Alert Unavailable The camera is temporarily not functioning, due to snow, ice, or dirt on the windshield.
Page 190 04 Driver support Driver Alert System* WARNING WARNING This feature is only intended to assist the The driver will only be warned once for driver and does not function in all driving, each time the wheels cross a marker line. weather, traffic or road conditions.
Page 191 See page 179 for information on the camera’s limi- tations. Driver Alert Sys Service The system is not functioning. Contact a trained and qualified Volvo service technician if the required message remains in the display.
Page 192 04 Driver support Driver Alert System* Lane Keeping Aid (LKA) If the vehicle crosses a side marker line or the road’s center dividing line, LKA will provide See page 187 for information about determin- active steering assistance to help steer it ing if your vehicle is equipped with Lane back into the lane.
Page 193 04 Driver support Driver Alert System* • On/Off Vibration only : Warning by vibrations in the steering wheel • Steering assist only : Active steering • Full function : Both vibrations and active steering Steering assist LKA attempts to keep the vehicle within the lane's side marker lines.
Page 194 04 Driver support Driver Alert System* Vibration warnings Dynamic cornering more information about the camera's limita- tions. NOTE In certain cases, it may be difficult for LKA to assist the driver correctly. In the follow- ing conditions, it may be preferable to turn LKA off: •...
Page 195 See page 179 for information on the camera’s limitations. Lane Keeping Aid Service The system is not functioning. Contact a trained and qualified Volvo service technician if the required message remains in the display.
Page 196: Park Assist
04 Driver support Park assist* Introduction Function Activating/deactivating The system is activated automatically when The park assist system is designed to assist the vehicle is started. you when driving into parking spaces, garages, etc. It utilizes ultrasound sensors in – Press the Park assist button on the center the front bumper and rear bumper(s) to meas- console to temporarily deactivate the sys-...
Page 197 04 Driver support Park assist* Signals from the park assist system Audible signal Rear park assist The Park Assist system uses an intermittent tone that pulses faster as you come close to an object, and becomes constant when you are within approximately 1 ft (30 cm) of an object in front of or behind the vehicle.
Page 198 If a non- the system is not functioning properly and Volvo trailer hitch is being used, it may has been disengaged. Consult a trained and be necessary to switch off the system qualified Volvo service technician.
Page 199 04 Driver support Park assist* Cleaning the sensors with water and a suitable car washing deter- gent. Ice and snow covering the sensors may cause incorrect warning signals. NOTE If the sensors are obstructed by e.g., dirt, snow, or ice, this could result in false warning signals from the park assist sys- tem.
Page 200: Rear Park Assist Camera (Pac)
04 Driver support Rear Park Assist Camera (PAC)* Introduction The driver sees what is behind the vehicle WARNING and if a person or animal should suddenly The Park Assist Camera (PAC) uses the dis- • PAC is designed to be a supplemen- appear from the side.
Page 201 04 Driver support Rear Park Assist Camera (PAC)* Using PAC Guiding lines With the camera zoomed in on the trailer hitch, a guiding line showing the hitch's path Activation toward the trailer will be projected. This fea- ture can be activated in the MY CAR menu. See page 215 for a description of the menu system.
Page 202 04 Driver support Rear Park Assist Camera (PAC)* ners of the body, etc.) extends out from the WARNING Color Distance to object vehicle, even when it turns. Keep in mind that the image on the screen Pale yellow 2.3–5 ft (0.7–1.5 m ) The "wheel tracks"...
Page 203 04 Driver support Rear Park Assist Camera (PAC)* Summary • Pressing CAM will activate the camera even if the gear selector is not in Reverse. • Toggle between normal view and zoom by pressing CAM or by turning TUNE. Limitations Even if a fairly small section of the screen image appears to be obstructed, this may mean that a relatively large area behind the...
Page 204: Park Assist Pilot (Pap)
04 Driver support Park Assist Pilot (PAP)* • Introduction When the stability or ABS systems are NOTE not working actively If a trailer hitch is configured in the vehi- • The vehicle is not towing a trailer cle's electrical system, PAP will take the •...
Page 205 04 Driver support Park Assist Pilot (PAP)* the illustration in the section "2: Backing 2: Backing into the parking space 1. Activate PAP by pressing into the parking space" on page 203. this button on the center console and if necessary 3.
Page 206 04 Driver support Park Assist Pilot (PAP)* 1. Put the gear selector in D, wait until the NOTE NOTE steering wheel has turned and drive for- • • Release the wheel while PAP is steer- PAP will not function correctly if its ward slowly.
Page 207 PAP has selected a suit- times also include suitable actions. cian. able parking space. Contact a Volvo retailer or a trained and • Heavy rain or snow may inhibit PAP's qualified Volvo service technician If a mes- capacity to correctly measure a parking...
Page 208: Blind Spot Information System (Blis)
04 Driver support Blind Spot Information System (BLIS)* Introduction WARNING BLIS is an information system that indicates • BLIS and CTA are information sys- the presence of another vehicle moving in the tems, NOT warning or safety systems same direction as your vehicle on roads with and do not function in all situations.
Page 209 04 Driver support Blind Spot Information System (BLIS)* Activating/deactivating BLIS To erase the message: When BLIS detects a vehicle in zone 1 or a passing vehicle in zone 2, the indicator light in • Press the OK button on the left steering the door panel will glow steadily.
Page 210 04 Driver support Blind Spot Information System (BLIS)* example, when backing out of a parking and approaching vehicles cannot be detected space. until they are too close: It is primarily designed to detect another vehi- cle but in certain cases may also detect pedestrians or smaller objects such as bicy- cles.
Page 211 (see the illustration and qualified Volvo be done by a trained and qualified Volvo in the following "Maintenance" section). service technician. service technician. •...
Page 212 Volvo Sensus..................212 Menus and messages................213 The MY CAR menus................215 Climate system..................221 Trip computer..................230 Active chassis system–Four C*............. 237 Passenger compartment convenience..........238 Option/accessory, for more information, see Introduction.
Page 213 C O M F O R T A N D D R I V I N G P L E A S U R E...
Page 214: 05 Comfort And Driving Pleasure
Introduction systems as well as other options such as the park assist camera(s), etc. Volvo Sensus uses the screen in the center instrument panel to display information and selections are made using this panel’s con- trols and buttons. Certain features can also be controlled using the steering wheel key- pad.
Page 215: Menus And Messages
05 Comfort and driving pleasure Menus and messages Main instrument panel Menu overview The following menu alternatives may vary, depending on the equipment installed in the vehicle. Analog instrument panel Digital speed Trip comp. opt. Service status Messages (##) Digital Instrument panel* and menu controls Digital instrument panel* OK: access to the list of messages and Analog Instrument panel and menu controls...
Page 216 When a warning, information or indicator Service Mainte- Have the vehicle checked If the service intervals are symbol comes on, a corresponding message by an authorized Volvo nance over- not followed, the warranty urgent appears in the information panel. An error workshop immediately.
Page 217: The My Car Menus
05 Comfort and driving pleasure The MY CAR menus • Introduction Operation Reject and incoming phone call • The menu system provides access to The current function will be cancelled Center console controls menus for operating many of the vehi- •...
Page 218 DRIVe tion in the system's memory. thumb wheel to open a submenu with This selectoin describes Volvo's DRIVe con- alternatives that can be selected. cept and displays the following headers: EXIT. 6. Use the thumb wheel to move to the •...
Page 219 05 Comfort and driving pleasure The MY CAR menus Menu settings See page 57 and 66 for more information. See page 105 for more information. The following pages list the main menus/ Side mirror settings Triple indicator submenus and possible selections. The Fold mirrors menus are set up as follows: See page 103 for more information.
Page 220 05 Comfort and driving pleasure The MY CAR menus if one of the buttons (1-4) is pressed, see MY CAR Settings Driver support page 215. DSTC systems Uncheck the selection to turn the screen See page 148 for more information. saver off.
Page 221 • A volume control will be displayed. To set The menu alternatives under Navigation Only on vehicles with the optional Volvo Navigation System the volume level: commands show examples of the voice Voice tutorial 1. Adjust the volume using the thumb wheel commands available for the optional Volvo 2.
Page 222 Bluetooth software version in car High See page 252 for more information. Map and software version Recirculation timer Refer to the optional Volvo Navigation System manual for more information. Automatic rear defroster Interior air quality system Reset climate settings This feature returns the "Climate settings"...
Page 223: Climate System
Side windows and moonroof side of the dashboard. system. Work of this type should only be To ensure that the air conditioning works done by a trained and qualified Volvo service optimally, the side windows, and the optional technician. moonroof should be closed.
Page 224: Air Distribution
388 for the amount of refrigerant in the A/C NOTE system. The system uses PAG oil. Contact your Volvo retailer for IAQS air fil- Passenger compartment filter ter replacement intervals. Replace the cabin air filter with a new one at the recommended intervals.
Page 225 05 Comfort and driving pleasure Climate system Air vents in the dashboard Air vents in the door pillars Open Closed Closed Open Horizontal airflow Horizontal airflow Vertical airflow Vertical airflow Direct the outer air vents toward the side win- Direct the outer air vents toward the side win- dows to defrost.
Page 226 05 Comfort and driving pleasure Climate system Electronic climate control, ECC Temperature control, driver's side Heated front passenger's seat* Heated driver's seat* Temperature control, passenger's side Defroster (maximum effect), electrically Recirculation heated windshield* AUTO Blower A/C on/off Manual air distribution—floor Manual air distribution—dashboard air vents Manual air distribution—defroster...
Page 227 05 Comfort and driving pleasure Climate system Climate system controls Starting the seat heating automatically Blower control This setting starts heating the driver's seat (at Turn the control clockwise to Heated front seats* the highest level) automatically when the increase or counterclockwise engine is started if the ambient temperature is to decrease the blower below approx.
Page 228 05 Comfort and driving pleasure Climate system Air distribution Blower speed in automatic mode can be set Climate settings Automatic blower under adjustment. Choose between Normal High NOTE Selecting the lowest blower speed may increases the risk of fog forming on the windows.
Page 229 05 Comfort and driving pleasure Climate system A/C – ON/OFF Max. defroster and electrically heated front side windows. The indicator light (2) in the defroster button illuminates when When the indicator light in windshield* the function is active. the button is on, the air con- •...
Page 230 05 Comfort and driving pleasure Climate system Recirculation/air quality system Interior Air Quality System–IAQS* NOTE This system consists of a multifilter and an air Recirculation • quality sensor. The filter helps remove gases Triangular areas at the far sides of the This function can be used to and particles from the incoming air, thereby windshield are not heated electrically...
Page 231 05 Comfort and driving pleasure Climate system Air distribution table Air distribution Air distribution Air to windows. Some air To remove de-fog/de- Air to the floor and To ensure comfortable flows from the dashboard air ice the front side win- windows.
Page 232: Trip Computer
05 Comfort and driving pleasure Trip computer • Introduction Trip computer functions Functions To open and make settings in the trip com- • The content and appearance of the trip com- Trip computer information headings in the puter functions: instrument panel puter varies depending on whether the vehi- cle is equipped with an analog or digital 1.
Page 233 05 Comfort and driving pleasure Trip computer Function Description Digital speed This displays the vehicle's speed digitally in the center of the instrument panel • Open by pressing OK, scroll using the thumb wheel, confirm by pressing OK and exit by pressing –...
Page 234 05 Comfort and driving pleasure Trip computer Information headings in the instrument Description panel • T1 and total dist. Press and hold RESET to reset trip odometer T1. Trip odometer • T2 and total dist. Press and hold RESET to reset trip odometer T2. Trip odometer Distance to empty Distance to empty...
Page 235 05 Comfort and driving pleasure Trip computer 3. Use the thumb wheel to scroll among the 4. After completing your selection, exit by The following table lists the digital trip com- functions and select/confirm your choice pressing RESET twice. puter's functions: by pressing OK.
Page 236 05 Comfort and driving pleasure Trip computer Heading combinations Description • Press and hold RESET to reset trip odometer T1. Average fuel consumption Trip odometer T1 + mileage Average speed • Press and hold RESET to reset trip odometer T2. Current fuel consumption Trip odometer T2 + mileage Distance to empty...
Page 237 10 miles; the marker at the right will also bination of headings containing the trip in the Volvo Navigation System (VNS)*. odometer to be reset. change according to the scale selected. 2. Press and hold RESET until selected trip...
Page 238 05 Comfort and driving pleasure Trip computer See also the information about Eco Guide on page 130.
Page 239: Active Chassis System-Four C
05 Comfort and driving pleasure Active chassis system–Four C* Active chassis (Four C) Operation NOTE Active chassis, Four-C (Continuously Con- This steering force level menu function trolled Chassis Concept), regulates the cha- cannot be accessed when the vehicle is in racteristics of the shock absorbers so that the motion.
Page 240: Passenger Compartment Convenience
05 Comfort and driving pleasure Passenger compartment convenience Storage spaces...
Page 241 05 Comfort and driving pleasure Passenger compartment convenience Tunnel console Glove compartment Compartment in door panel Storage pocket on the front edge of the front seat cushions Glove compartment Storage compartment Jacket holder Storage compartment, 12-volt socket and AUX input/USB connector Rear seat cup holders Storage pocket Storage compartment (for CDs, etc.)
Page 242 7.5A (90W). The auxiliary sockets can also be used to power a cigarette lighter. Accessory cigarette lighters and ashtrays can be purchased from your Volvo retailer. Vanity mirror with lighting 12-volt socket in the front tunnel console WARNING...
Page 243 05 Comfort and driving pleasure Passenger compartment convenience 12-volt socket in the trunk* Fold down the cover to access the electrical socket. NOTE The 12-volt socket in the trunk provides electrical current even when the ignition is switched off. Using the socket while the engine is not running will drain the battery.
Page 244 Introduction................... 244 Radio..................... 253 Media player..................262 AUX/USB sockets................. 267 ® Bluetooth media ................. 270 ® Bluetooth hands-free connection ............272 Cell phone voice control*..............281 Option/accessory, for more information, see Introduction.
Page 245 I N F O T A I N M E N T...
Page 246: 06 Infotainment
06 Infotainment Introduction General information Audyssey MultEQ NOTE The infotainment system consists of radio To help avoid excessive battery drain, and media player features and also makes it remove the remote key from the ignition possible to communicate via a cell phone. slot if the infotainment system is used The information is displayed on a 7"...
Page 247 06 Infotainment Introduction Infotainment system overview Basic infotainment functions Left/right arrow keys – short press moves between preset radio stations, tracks on a disc or chapters on a DVD. Press and hold to search within tracks or to tune to the next/previous available radio station.
Page 248 06 Infotainment Introduction Eject a disc. Keypad for entering text/numbers, storing radio stations, etc. OK/MENU – press the thumb wheel on * FAV – this button can be used to store a the steering wheel keypad or this button on the center console to confirm a menu selec- shortcut to a commonly used function in tion or accept an incoming phone call.
Page 249 06 Infotainment Introduction Menu navigation An example of menu navigation in MEDIA mode when a CD is playing...
Page 250 06 Infotainment Introduction Mode button (in this example, the MEDIA The * FAV button can be used to store fre- 3. Press and hold * FAV until the "favorite" button). The number of buttons varies, quently used functions, making it possible to menu is displayed.
Page 251 06 Infotainment Introduction audio will be provided using 3 channel 3. Turn TUNE to adjust the sound setting External audio source volume stereo. and confirm the change by pressing OK/ If an external device such as an MP3 player MENU. Do the same for the other fre- •...
Page 252 06 Infotainment Introduction RADIO menus Optimal sound reproduction Main SAT1*/SAT2* menu (SiriusXM™ The infotainment system is pre-calibrated for satellite radio) Main AM menu optimal sound reproduction using digital sig- SAT1 AM menu nal processing. SIRIUS radio off. Press RADIO Show presets This calibration takes into account factors button to activate SIRIUS.
Page 253 06 Infotainment Introduction Advanced SIRIUS settings Main iPod menu Stop iPod menu Skip options Random Random Channel skip list Repeat folder Scan Lock options Change subtitles Audio settings Channel lock list Change audio track Unlock all channels Scan Main USB menu Temporarily Audio settings USB menu...
Page 254 06 Infotainment Introduction TEL menus Receive vCard Memory status Main Bluetooth media menu Bluetooth menu Clear phone book Random Change phone Change device Remove Bluetooth device Remove Bluetooth device Phone settings Scan Discoverable Bluetooth software version in car Sounds and volume Audio settings Download phone book Bluetooth software...
Page 255: Radio
06 Infotainment Radio General functions Menu navigation 2. Turn TUNE slightly in either direction. This displays the list of stations in the RADIO menu selections can be made from area. The currently tuned station will be the center console or the steering wheel key- indicated in the list by magnified text.
Page 256 06 Infotainment Radio If the station list is no longer displayed, turn 2. Press and hold one of the number key NOTE buttons. TUNE in either direction and press The radio is initially set to automatically the keypad on the center console to switch to >...
Page 257 06 Infotainment Radio Radio text More information about HD radio and IBOC NOTE can be found on Ibiquity's website, Some stations transmit information on pro- HD radio volume may fade in and out at www.hdradio.com and www.ibiquity.com. gram content, artists, etc. This information times due to coverage limitations.
Page 258 93.9 WNYC rial in extreme cases can be as much (Volvo uses the symbol ">" to indicate This will disable the radio's capability to as 8 seconds behind the analogue). there are sub-channels available) The receive digital broadcasts but it will continue This will noticeable as a "stuttering"...
Page 259 06 Infotainment Radio Sub-channels main channel, press and hold the left arrow Sub-channels can also be stored as presets, key on the center console or on the steering see page 254 for information on storing sta- wheel keypad for approximately 1 second. To tions.
Page 260 06 Infotainment Radio Selecting SiriusXM™ radio mode SiriusXM™ ID Selecting a channel There are three ways of tuning in a channel: 1. With the infotainment system switched The SiriusXM™ ID (sometimes referred to as on, press RADIO. the Electronic Serial Number or ESN) is •...
Page 261 06 Infotainment Radio Scanning Add current song to song the Song seek feature is activated, the lis- 3. Scroll to tener will be alerted by a text message and an memory and press OK/MENU. Scan automatically searches through the list audible signal.
Page 262 06 Infotainment Radio 5. Press OK/MENU to select All categories Locking a channel WARNING or turn TUNE to scroll to a category and 1. Press OK/MENU. Settings should be made when the vehicle press OK/MENU to select it. Advanced settings 2.
Page 263 3. The current code will be displayed. selection. Your Volvo retailer can also provide you with Temporarily unlock all channels assistance. This function will temporarily unlock all chan- nels and make them available for selection.
Page 264: Media Player
06 Infotainment Media player OK/MENU: Press to confirm your selec- Playing a disc CD/DVD functions tion or access the menus for the currently Press MEDIA ans scroll to Disc . Press OK/ Disc selected source (e.g., ) or press the MENU or the thumb wheel on the steering thumb wheel on the steering wheel key- wheel keypad.
Page 265 06 Infotainment Media player Navigating a disc and playing tracks When a file has been played, the player will NOTE continue to play the rest of the files (of the CD audio discs Some copy protected audio files or home- same type) in the current folder.
Page 266 06 Infotainment Media player Playing video DVDs Navigating in a DVD's menus Random This function plays the tracks in random order Play (shuffle). The random tracks/sound files can When playing a video DVD, a disc menu may be scrolled through in the normal way. To lis- appear on the display, giving you access to ten to tracks in random order: extra functions and settings such as choice of...
Page 267 06 Infotainment Media player Press EXIT to cancel and return to the normal See also www.divx.com/vod for more infor- view (without having made a selection). mation. It is also possible to change chapters by Screen settings pressing on the center console Screen settings can be made (when the vehi- control panel or on the steering wheel key- cle is not moving) for:...
Page 268 06 Infotainment Media player NOTE Dual format (double-sided discs) such as DVD Plus or CD-DVD are thicker than nor- mal discs and may not play in your info- tainment system. If a disc containing both CDDA and MP3 tracks is played, all MP3 tracks will be ignored.
Page 269: Aux/Usb Sockets
Sockets for auxiliary devices in the storage com- problem persists, contact a trained partment between the front seats and authorized Volvo service techni- When this information has been loaded, track ® cian. information will be displayed and a track can...
Page 270 06 Infotainment AUX/USB sockets sound is unmuted. Pause is also available via Scan buttons on the center console the menu system, select Play/Pause or steering wheel keypad can also be used to For information, see page 263. change tracks/files. External sound sources Random The following symbols are used in the dis- For information, see page 264.
Page 271 06 Infotainment AUX/USB sockets USB hub Compatible file formats via the USB A USB hub can be connected to the USB socket socket, making it possible to connect several The following audio and video files are sup- USB devices at the same time. To select one ported by the system when playing a device connected to the USB socket.
Page 272: Bluetooth ® Media
® When the Bluetooth function is active and mode's main view will display a shortcut Volvo retailer or at www.volvocars.us. the most recently used device is within range, menu. it is automatically connected. When the info- TUNE: Turn to navigate among menu...
Page 273 06 Infotainment ® Bluetooth media Switching to another device Disconnecting an external device Scanning audio files on an external device It is possible to switch among paired The external device is automatically discon- ® nected from the infotainment system if it is Bluetooth devices that are in the vehicle.
Page 274: Bluetooth ® Hands-Free Connection
Not all cell phones are fully compatible ance could void the user’s authority to oper- with the hands-free system. A list of com- ate the equipment. patible phones is available at your Volvo IC RSS-Gen retailer or at www.volvocars.us This equipment complies with FCC/IC radia-...
Page 275: Getting Started
06 Infotainment ® Bluetooth hands-free connection ® Pairing (connecting) external Bluetooth functions in the center steering wheel keypad can be used in the same way. console control panel Bluetooth ® devices OK/MENU: Press to answer an incoming A maximum of 10 cell phones or other devi- call, confirm your selection or access the ces can be paired with the hands-free sys- tem.
Page 276 Changing phones or devices phone’s display as My Volvo Car. directions provided. More than one device can be used in the 5. Turn the thumb wheel or TUNE to select vehicle as long as this device has been 5.
Page 277 06 Infotainment ® Bluetooth hands-free connection Making a call Auto answer The hands-free system is also deactivated when the ignition is switched off (or if the 1. Ensure that This function means that incoming calls will is shown at the top of driver’s door is opened).
Page 278 06 Infotainment ® Bluetooth hands-free connection Sound settings In phone mode, the various call lists can be Phone settings Sounds and volume Phone menu Call lists: displayed in Ring signals Ring signal 1, etc. Call volume • All calls Call volume can be only be adjusted during a NOTE •...
Page 279 06 Infotainment ® Bluetooth hands-free connection connected when the contact is saved. – Activate/deactivate this function in phone first letter of the contact's name. For exam- These contacts will be displayed regard- ple, pressing and holding button 6 would pro- Phone menu Phone settings mode in...
Page 280 06 Infotainment ® Bluetooth hands-free connection 1. Turn TUNE to the desired letter and press Press EXIT briefly to erase a single character. Button Function OK/MENU to confirm. The number/letter Press and hold EXIT to erase all of the char- keys on the center console can also be acters that have been entered.
Page 281 06 Infotainment ® Bluetooth hands-free connection Speed dial New contacts can be added in phone mode When all of the contact's information has Save contact been entered, select in the Speed dial numbers can be added in phone Phone menu Phone book menu to save.
Page 282 06 Infotainment ® Bluetooth hands-free connection Phone menu Phone book Clear phone book. NOTE Clearing the entries in the infotainment system's phone book does not delete entries in the cell phone's phone book. ® Bluetooth version information ® For information about the Bluetooth version Phone menu installed in the vehicle, go to...
Page 283: Cell Phone Voice Control
Voice commands offer convenience and help avoid distractions so that you can concen- trate on driving and focus your attention on road and traffic conditions. Available in vehicles equipped with the Volvo Navigation System* only Option/accessory, for more information, see Introduction.
Page 284 06 Infotainment Cell phone voice control* • Getting started When giving commands, speak at your This feature can be accessed by pressing the usual speed and in a normal tone of voice MY CAR button in the center console and after the tone turning TUNE.
Page 285 06 Infotainment Cell phone voice control* Voice output volume User action The following is a list of features that can be ® voice-controlled with a Bluetooth -connected Begin saying the digits in the phone number. Press MY CAR and go to Settings Voice cell phone.
Page 286 06 Infotainment Cell phone voice control* The user initiates the dialogue by saying: Phone dial voice mail Phone > call contact Continue by responding to the system's prompts. Phone call contact Continue by responding to the system's prompts. When calling contacts, keep the following in mind: •...
Page 287 06 Infotainment...
Page 288 Driving recommendations..............288 Refueling....................292 Loading....................297 Towing a trailer..................300 Emergency towing................302...
Page 289 D U R I N G Y O U R T R I P...
Page 290: 07 During Your Trip
07 During your trip Driving recommendations • General information 127 for additional information about Sport Dragging brakes mode. • Incorrect front end alignment Economical driving conserves natural • Using the engine's optional Eco function Some of the above mentioned items and oth- resources can help improve fuel economy.
Page 291 07 During your trip Driving recommendations the trunk, the less the tendency to under- WARNING CAUTION steer. • • Avoid driving through standing or Engine damage will occur if water is Handling, roadholding rushing water. Doing so can be dan- drawn into the air cleaner.
Page 292: Conserving Electrical Current
It is always worthwhile to have your vehicle The cooling fan may start or continue to • checked by a trained and qualified Volvo Consider your destination. If you will be operate (for up to 6 minutes) after the service technician before driving long dis- driving through an area where snow or ice engine has been switched off.
Page 293 1 part washer solvent and 2 parts water Down to –18 °F (–28 °C): 1 part washer solvent and 1 part water. • Use Volvo Teflon Lock Spray in the locks. • Avoid using de-icing sprays as they can cause damage to the locks.
Page 294: Refueling
"oxygenated" fuel. Deposit control gasoline (detergent loss of emission warranty coverage. State Volvo allows the use of the following "oxy- additives) and local vehicle inspection programs will genated" fuels; however, the octane ratings...
Page 295 07 During your trip Refueling Octane rating TOP TIER Detergent Gasoline NOTE Volvo endorses the use of “TOP TIER Deter- Minimum octane When switching to higher octane fuel or gent Gasoline” where available to help main- changing gasoline brands, it may be nec- tain engine performance and reliability.
Page 296 Volvo service technician for correction. • If you intend to leave your vehicle while it is being refueled, this feature enables you to lock the doors/trunk while leaving the fuel filler door unlocked.
Page 297: Emission Controls
If the fuel filler cap is not closed tightly or if the engine is running when the vehicle is refueled, the Check Engine Light (malfunction indicator lamp) may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps.
Page 298 07 During your trip Refueling help avoid malfunctions that could dam- are fed into a control module that continu- age the three-way catalytic converter. ously monitors engine functions and controls fuel injection. The ratio of fuel to air into the •...
Page 299: Loading
• Volvo Inflatable Curtain. Unstable loads can be secured to the load anchoring eyelets with straps or web lashings to help keep them from shifting.
Page 300 07 During your trip Loading Grocery bag holder* WARNING • Cover sharp edges on long loads to help prevent injury to occupants. Secure the load to help prevent shift- ing during sudden stops. • Always secure large and heavy objects with a seat belt or cargo retaining straps.
Page 301 Use the seat belt to prevent the load from consumption will increase with the size of moving. Using load carriers the load. Load carriers are available as Volvo accesso- WARNING • Drive smoothly. Avoid rapid starts, fast ries. Observe the following points when in cornering and hard braking.
Page 302: Towing A Trailer
Introduction watched when driving in hot climates or WARNING hilly terrain. Use a lower gear and turn off Volvo recommends the use of Volvo trailer • Bumper-attached trailer hitches must the air conditioner if the temperature hitches that are specially designed for the not be used on Volvos, nor should gauge needle enters the red range.
Page 303 7 pins. Use an adapter cable approved The DSTC symbol ( ) in the instru- the driver regains control of the vehicle. by Volvo. Make sure the cable does not drag ment panel will flash when TSA is working on the ground. •...
Page 304: Emergency Towing
07 During your trip Emergency towing Towing eyelet Attaching the towing eyelet WARNING The towing eyelet is located under the • When the vehicle is being towed, the floor of the trunk. This eyelet must be ignition should be in mode II (in mode screwed into the positions provided on I, all of the vehicle's airbags are deac- the right sides of either the front or rear...
Page 305 The vehicle should always be towed in Call for professional help from an authorized the forward direction. • Please check with state and local towing company. Volvo recommends the use • Vehicles with All Wheel Drive (AWD)* authorities before attempting this type of flat bed equipment.
Page 306 General information ................306 Tire inflation................... 309 Inflation pressure ................. 312 Tire designations .................. 314 Glossary of tire terminology ..............316 Vehicle loading ..................317 Uniform Tire Quality Grading ............... 319 Snow chains, snow tires, studded tires ..........320 Temporary Spare ................. 321 Tire Sealing System*................
Page 307 W H E E L S A N D T I R E S...
Page 308: 08 Wheels And Tires
If the tires are rotated, they should a risk of altering the car's roadholding and only be moved from front to rear or Some Volvo models are equipped with an handling characteristics. vice versa. They should never be rota- Ultra High Performance tire and wheel ted left to right/right to left.
Page 309 08 Wheels and tires General information Summer and winter tires with less than 1/16" (1.6 mm) tread offer very process. The temporary spare should also poor traction. be replaced at 6-year intervals, even if it has never been used. When replacing worn tires, it is recommended that the tire be identical in type (radial) and A tire's age can be determined by the DOT size as the one being replaced.
Page 310 The tires with the most tread should WARNING always be at the rear (to reduce the risk of • The wheel and tire sizes for your Volvo skidding). are specified to meet stringent stability • Contact a Volvo workshop if you are and handling requirements.
Page 311: Tire Inflation
08 Wheels and tires Tire inflation Inflation placard NOTE WARNING • • The placards shown indicate inflation Under-inflation is the most common pressure for the tires installed on the cause of tire failure and may result in vehicle at the factory only. severe tire cracking, tread separation, or "blow-out,"...
Page 312 08 Wheels and tires Tire inflation After driving a distance of approximately 3. Replace the valve cap. NOTE 1 mile (1.6 km), the tires are considered to be • If you overfill the tire, release air by hot. If you have to drive farther than this dis- CAUTION pushing on the metal stem in the cen- tance to pump your tire(s), check and record...
Page 313 08 Wheels and tires Tire inflation Speed ratings 168 mph (270 km/h) 186 mph (300 km/h) Load ratings See page 314 for an explanation of the load rating on the sidewall of the tire.
Page 314: Inflation Pressure
Tire inflation pressure table The following tire pressures are recommended by Volvo for your vehicle. Refer to the tire inflation placard (see page 309 for its location) for informa- tion specific to the tires installed on your vehicle at the factory.
Page 315 Using 19” wheels on vehicles equipped the standard chassis presents a safety risk and the risk of damage to the vehicle, and impairs the vehicle’s driving characte- ristics. NOTE Please consult a Volvo retailer’s Parts department for the most up-to-date speci- fications.
Page 316: Tire Designations
08 Wheels and tires Tire designations Information on the sidewall 1. 215: the width of the tire (in millimeters) 7. M+S or M/S = Mud and Snow, AT = All from sidewall edge to sidewall edge. The Terrain, AS = All Season larger the number, the wider the tire.
Page 317 08 Wheels and tires Tire designations 10. Maximum Load: Indicates the maximum load in pounds and kilograms that can be carried by the tire. Refer to the vehicle's tire information placard located on the B- Pillar for the correct tire pressure for your vehicle.
Page 318: Glossary Of Tire Terminology
41 psi [43 psi (2.9 bar) for • Recommended tire inflation pressure: Metric tires]. Increasing the inflation pres- inflation pressure, established by Volvo, sure beyond this pressure will not which is based on the type of tires that increase the tire's load carrying capabil- are mounted on a vehicle at the factory.
Page 319: Vehicle Loading
08 Wheels and tires Vehicle loading Loads Permissible axle weight 2. Determine the combined weight of the driver and passengers that will be riding The maximum allowable weight that can be Properly loading your vehicle will provide in your vehicle. carried by a single axle (front or rear).
Page 320 Do not use replacement tires with lower load carrying capacities than the tires that were original equipment on the vehicle because this will lower the vehicle's GVW rating. Use only tires with the correct load carrying capacity. Consult your Volvo retailer for informa- tion.
Page 321: Uniform Tire Quality Grading
08 Wheels and tires Uniform Tire Quality Grading Quality grading information test surfaces of asphalt and concrete. A tire WARNING marked C may have poor traction perform- ALL PASSENGER VEHICLE TIRES MUST The temperature grade for this tire is ance. The traction grade assigned to this tire CONFORM TO FEDERAL SAFETY established for a tire that is properly infla- is based on braking (straight-ahead) traction...
Page 322: Snow Chains, Snow Tires, Studded Tires
Check local regulations regarding the • It is important to install winter tires on all use of snow chains before installing. Snow chains can be used on your Volvo with four wheels to help retain traction during the following restrictions: •...
Page 323: Temporary Spare
08 Wheels and tires Temporary Spare Spare tire A spare tire can be purchased for your vehi- cle as an accessory. Follow the instructions included with the spare tire regarding use and stowing in the vehicle. See also page 328 for additional information.
Page 324: Tire Sealing System
12-volt sockets, and a hose used to connect the system to the tire’s inflation valve. NOTE The tire sealing system's compressor has been tested and approved by Volvo. Option/accessory, for more information, see Introduction.
Page 325 08 Wheels and tires Tire Sealing System* • Tire sealing system–overview Inhalation: Move the exposed person WARNING to fresh air. If irritation persists, get Please keep the following points in mind medical attention. when using the tire sealing system: • Ingestion: Do NOT induce vomiting •...
Page 326 Once in place, clearly visible to the driver. the bottle cannot be unscrewed. This must be done by a trained and qualified Volvo Temporarily repairing a flat tire is done in two 2. Ensure that the on/off switch is in posi- service technician.
Page 327 In this occurs. Contact a towing service or case, the hole is too large to be sealed and WARNING Volvo On Call Roadside Assistance if the vehicle should not be driven. applicable. The vehicle´s engine should be running when the tire sealing system is used to 10.
Page 328 Volvo service technician to have the The compressor should not be used for to a Volvo retailer or a recycling station bottle removed and properly disposed more than 10 minutes at a time to avoid that can properly dispose of harmful overheating.
Page 329 08 Wheels and tires Tire Sealing System* Inflating tires WARNING CAUTION The tire sealing system can be used to inflate • The compressor should not be used for The vehicle’s engine should be running the tires. To do so: more than 10 minutes at a time to avoid when the tire sealing system is used to overheating.
Page 330: Changing A Wheel
08 Wheels and tires Changing a wheel Removing a wheel correct tire pressure is stated in the tire pres- WARNING sure table on page 312 and in the tire inflation Current legislation prohibits the use of the placard on the driver's side door jamb at the “Temporary Spare”...
Page 331 08 Wheels and tires Changing a wheel 7. If there is a wheel in the bag, strap the bag securely in place in the trunk. WARNING • If there is a wheel in the bag, the bag must be securely restrained using its straps and the load anchoring eyelets in the trunk.
Page 332 08 Wheels and tires Changing a wheel WARNING NOTE • The jack provided with your vehicle is The jack must correctly engage the intended to be used only in temporary sit- jack attachment. uations such as changing wheels in the •...
Page 333 08 Wheels and tires Changing a wheel 3. Install the wheel nuts and tighten hand- tight. Using the lug wrench, tighten cross- wise until all nuts are snug. 4. Lower the vehicle to the ground and alter- nately tighten the bolts crosswise to 103 ft.
Page 334: Tire Pressure Monitoring System (Tpms)
08 Wheels and tires Tire Pressure Monitoring System (TPMS) Introduction and may affect the vehicle's handling and NOTE stopping ability. If a fault occurs in TPMS, the tire pressure NOTE Please note that the TPMS is not a substitute warning light will flash for approximately for proper tire maintenance, and it is the driv- Tire press.
Page 335 TPMS wheels/ refer to the tire inflation pressure table in tires on the vehicle: this chapter or consult your Volvo retailer. CAUTION • Only the factory-mounted wheels are •...
Page 336 In certain cases, it may be necessary to reca- 1. Switch off the engine. Drive carefully; it may be difficult to determine librate TPMS to conform to Volvo's recom- which tire is damaged. To find the damaged 2. Put the ignition in mode I or II (see page...
Page 337 08 Wheels and tires Tire Pressure Monitoring System (TPMS) WARNING • SST tires should only be mounted by service technicians who are familiar with tires of this type. • SST tires may only be mounted on vehicles equipped with TPMS. •...
Page 338 Volvo maintenance................338 Maintaining your car................339 Hood and engine compartment............342 Engine oil....................344 Fluids..................... 346 Replacing bulbs..................348 Wiper blades and washer fluid.............. 355 Battery....................357 Fuses..................... 361 Vehicle care................... 372...
Page 339 M A I N T E N A N C E A N D S P E C I F I C A T I O N S...
Page 340: 09 Maintenance And Specifications
Refer to your Warranty and Service be performed by a qualified technician. To Canadian regulations, the following list of Records Information booklet for a keep your Volvo in top condition, specify warranties is provided. comprehensive service and mainte- time-tested and proven Genuine Volvo Parts nance schedule up to 150,000 miles •...
Page 341: Maintaining Your Car
Wipe driver information displays with a soft cloth. • Visually inspect battery terminals for cor- rosion. Corrosion may indicate a loose terminal connector, or a battery near the end of its useful service life. Consult your Volvo retailer for additional information.
Page 342 09 Maintenance and specifications Maintaining your car Hoisting the vehicle Emission inspection readiness How do states use OBD II for emission If a garage jack is used to lift the vehicle, it should be placed: inspections? What is an Onboard Diagnostic System Many states connect a computer directly to a Front: under either of the two reinforced (OBD II)?
Page 343 OBD II system to "ready" for inspection. Two half-hour trips of mixed stop-and- go/highway driving are typically needed to allow OBD II to reach readiness. Your Volvo retailer can provide you with more information on planning a trip. • Maintain your vehicle in accordance with...
Page 344: Hood And Engine Compartment
09 Maintenance and specifications Hood and engine compartment Opening and closing the hood WARNING Check that the hood locks properly when closed. Engine compartment, overview Engine compartment - 4-cylinder engines only Filler cap-engine oil Coolant expansion tank Radiator Brake fluid reservoir Coolant expansion tank Battery Turn the handle located under the left...
Page 345 09 Maintenance and specifications Hood and engine compartment WARNING The cooling fan (located at the front of the engine compartment, behind the radiator) may start or continue to operate (for up to 6 minutes) after the engine has been switched off. WARNING Before performing any operations in the engine compartment, the ignition should...
Page 346: Engine Oil
• Oil that is lower than the specified quality can damage the engine. • Volvo does not recommend the use of oil additives. • Always add oil of the same type and viscosity as already used.
Page 347 09 Maintenance and specifications Engine oil 3. Add oil if necessary. If the level is close to the MIN mark, add approximately 0.5 US quarts (0.5 liters) of oil. 4. Recheck the level and add more oil if necessary until the level is near the MAX mark.
Page 348: Fluids
MIN and changed. If the system must be drained, con- MAX marks. If it is not kept filled, there sult a trained and qualified Volvo service can be high local temperatures in the technician. engine which could result in damage.
Page 349 MIN and MAX marks. For display: DO NOT DRIVE. Have the car capacities and recommended fluid grade, see towed to a trained and qualified Volvo page 388. service technician and have the brake system inspected.
Page 350: Replacing Bulbs
The following bulbs should only be replaced fingers. Grease and oils from your fingers not mentioned in this section, please by a trained and qualified Volvo service tech- vaporize in the heat and will leave a contact your Volvo retailer or a trained...
Page 351 09 Maintenance and specifications Replacing bulbs Headlight housing 2. Reinstall the headlight housing and lock- CAUTION ing pins. The short locking pin should be The entire headlight housing must be lifted When disconnecting the connector, pull on closest to the grille. Check that they are out when replacing all front bulbs.
Page 352 09 Maintenance and specifications Replacing bulbs 1. Remove the headlight housing from the 1. Remove the headlight housing from the NOTE vehicle (see page 348). vehicle (see page 348). Before starting to replace a bulb, see 2. Remove the cover over the bulbs (see 2.
Page 353 09 Maintenance and specifications Replacing bulbs Turn signals Taillight housing Extra high beam 1. Remove the headlight housing from the The bulbs in the taillight cluster are replaced 1. Remove the headlight housing from the vehicle (see page 348). from inside the trunk (not the LED functions). vehicle (see page 348).
Page 354 09 Maintenance and specifications Replacing bulbs License plate lighting Backup lights 4. Insert a new bulb, press it in slightly and turn it clockwise. 5. Press the bulb holder back into place and reinstall the cover. Location of taillight bulbs 1.
Page 355: Trunk Lighting
09 Maintenance and specifications Replacing bulbs Trunk lighting Vanity mirror lighting Bulb specifications Lighting Wat- Bulb Removing the lens function tage Extra high beam H7 LL (models with Active Bending Lights*) Low beam (hal- H11 LL ogen) High beam (hal- ogen) The trunk lighting is located on opposite Front turn sig-...
Page 356 09 Maintenance and specifications Replacing bulbs Lighting Wat- Bulb function tage Brake light P21W LL Trunk lighting SV8.5 (length 38mm) Front footwell W2, 1x9.5d lighting type T10 NOTE Please consult a Volvo retailer’s Parts department for the most up-to-date bulb specifications.
Page 357: Wiper Blades And Washer Fluid
09 Maintenance and specifications Wiper blades and washer fluid Wiper blades Replacing the windshield wiper blades 1. Insert the remote key into the ignition slot and press the START/STOP Service position ENGINE button briefly to put the ignition in mode I (see page 89 for detailed infor- mation about the ignition modes).
Page 358 09 Maintenance and specifications Wiper blades and washer fluid 4. Press the wipers back against the wind- The windshield and headlight washers share shield. a common reservoir. To return the wipers from the service position The washer fluid reservoir is located on the to the normal position, fold the wipers back driver's side of the engine compartment.
Page 359: Battery
The infotainment system's energy-saving environmentally responsible manner. Con- feature may not function correctly or at all, sult your Volvo retailer or take the battery and/or a message may be displayed if a See the owner's manual. to a recycling station.
Page 360 09 Maintenance and specifications Battery • Never disconnect the battery when the WARNING CAUTION engine is running, or when the key is in • • Never expose the battery to open Always use distilled or deionized water the ignition. This could damage the vehi- flame or electric spark.
Page 361 09 Maintenance and specifications Battery WARNING WARNING Connect and disconnect the positive and PROPOSITION 65 WARNING! negative cables in the correct sequence. Battery posts, terminals, and related accessories contain lead and lead com- pounds, chemicals known to the state of Removal California to cause cancer and reproduc- Switch off the ignition, remove the remote key...
Page 362 09 Maintenance and specifications Battery Installation 1. Remove the hatch in the bulkhead on both sides of the engine compartment 1. Lower the battery into the battery box. (pry them up carefully with a plastic knife or similar object). 2. Remove the screw on each side of the engine compartment holding the rally bar in place.
Page 363: Fuses
If fuses burn out repeatedly, have the electri- Engine compartment cold zone (Start/ cal system inspected by a trained and quali- Stop only) fied Volvo service technician. WARNING Never use metal objects or fuses with higher amperage than those stated on the following pages.
Page 364 09 Maintenance and specifications Fuses Engine compartment...
Page 365 ABS valves circuit breakers and should only be trunk removed or replaced by a trained and Headlight washers qualified Volvo service technician. Circuit breaker: central electrical module • Fuses 16 – 33 and 35 – 41 may be Active Bending Lights- under the glove com- changed at any time when necessary.
Page 366 09 Maintenance and specifications Fuses Function Function Function Heated washer noz- Relay-coils A/C, relay A/C compressor (5-/6- zles* coils in engine com- cyl. engines), engine partment cold zone for valves, engine control Start/Stop module (6-cyl. engines), solenoids (6- Lighting panel Starter motor relay cyl.
Page 367 09 Maintenance and specifications Fuses Function Fuel leakage detection (5-/6-cyl. engines), control module for radiator shutter (5-cyl. engines) Fuel leakage detection, A/C relay (4-cyl. engines) Coolant pump (4-cyl. engines) Cooling fan 60 (4/5- cyl. engines) 80 (6-cyl. engines) Power steering This position is not used on vehicles with the optional Start/Stop function, refer to the table "Engine compart- ment cold zone"...
Page 368 09 Maintenance and specifications Fuses Under the glove compartment Fusebox A: General fuses Positions: fusebox A Function Function Fusebox B: Control module fuses Keyless drive* (door handles) Fold aside the upholstery covering the fuse- Circuit breaker for the info- boxes. tainment system and for fuses 16-20 1.
Page 369 09 Maintenance and specifications Fuses Function Function Function Keyless drive* Heated rear seat* (driver's Front courtesy lighting, driv- side) er's door power window con- Power driver's seat* trols, power seat(s)*, Home- ® LInk Wireless Control Sys- Power front passenger's seat* tem* Heated front passenger's seat*...
Page 370 09 Maintenance and specifications Fuses Function Alarm, On-board diagnostic system Airbag system, occupant weight sensor Collision warning system* Accelerator pedal sensor, auto-dim mirror function, heated rear seats* Brake lights Power moonroof* Immobilizer Option/accessory, for more information, see Introduction.
Page 371 09 Maintenance and specifications Fuses Cargo area Located behind the upholstery on the left side of the trunk Positions Function Function Function 12-volt socket in trunk Trailer socket 1* Electric parking brake (left side) Electric parking brake (right side) Heated rear window Trailer socket 2* Option/accessory, for more information, see Introduction.
Page 372 Fuses A1, A2 and 1–11 are relays/circuit breakers and should only be removed or Circuit breaker: central elec- Circuit breaker: fusebox B replaced by a trained and qualified Volvo trical module in the engine under the glove compartment service technician.
Page 373 09 Maintenance and specifications Fuses Function Circuit breaker: fusebox A under the glove compartment (see page 366) Circuit breaker: central elec- trical module in the trunk Climate system blower – – – – Starter motor relay Internal diode Auxiliary battery Central electrical module: auxiliary battery reference voltage, auxiliary battery...
Page 374: Vehicle Care
Washing the car considerably and also helps prolong the Exterior components service life of the wiper blades. Volvo recommends the use of special clean- The following points should be kept in mind • ing products, available at your Volvo retailer,...
Page 375 These coat- ings have not been tested by Volvo for Polishing and waxing compatibility with your vehicle's clear coat. CAUTION •...
Page 376 • Leather should be allowed to breath. conditioning your vehicle's leather two to four Never cover the steering wheel with a times a year. Ask your Volvo retailer about plastic protector. Leather Care Kit 951 0251 and Leather Soft- •...
Page 377 Spots on textile mats can be removed with a mild detergent. For best protection in Type 1 (ink, wine, coffee, milk, sweat or winter, Volvo recommends the use of Volvo blood) rubber floor mats. Consult your Volvo retailer. –...
Page 378 09 Maintenance and specifications Vehicle care Repairing stone chips Minor stone chips and scratches Material: • Primer – can • Paint – touch-up pen • Brush • Masking tape If the stone chip has not gone down to the bare metal and an undamaged color coat remains, you can add paint immediately after removing dirt.
Page 379 09 Maintenance and specifications...
Page 380 Label information.................. 380 Specifications..................382 Overview of information and warning symbols........390 Volvo programs..................393...
Page 381: Specifications
S P E C I F I C A T I O N S...
Page 382: Label Information
10 Specifications Label information Location of labels...
Page 383 (FMVSS) specifications (USA) and Vehicle Emission Control Information. Ministry of Transport (CMVSS) stand- Your Volvo is designed to meet all appli- ards (Canada). Your Volvo is designed to cable emission standards, as evidenced meet all applicable safety standards, as...
Page 384: 10 Specifications
10 Specifications Specifications Dimensions–S60 Position Dimension in (mm) Wheelbase 109.3 (2776) Length 182.5 (4635) Load length, floor, seatback down 68.9 (1749) Load length, floor 38.0 (965) Height 58.4 (1484) Load height 18.3 (465)
Page 385: Specifications
10 Specifications Specifications Position Dimension in (mm) Track, front 62.5 (1588) 62.1 (1578) Track, rear 62.4 (1585) 62.0 (1575) Load width, floor 36.2 (919) Width 73.4 (1865) Width incl. door mirrors (folded out) 82.6 (2097) Width incl. door mirrors (folded in) 74.8 (1899) with 16"...
Page 386 10 Specifications Specifications Weights Category Canada Gross vehicle weight 4720 lbs 2140 kg 4-cyl. FWD 4610 lbs 2090 kg 5-cyl. FWD 4770 lbs 2165 kg 5-cyl. AWD 5050 lbs 2290 kg 6-cyl. AWD Capacity weight 1025 lbs 465 kg 4-cyl. FWD 1025 lbs 465 kg 5-cyl.
Page 387 10 Specifications Specifications Category Canada Permissible axle weights, rear 2270 lbs 1030 kg 4-cyl. FWD 2160 lbs 980 kg 5-cyl. FWD 2270 lbs 1030 kg 5-cyl. AWD 2490 lbs 1130 kg 6-cyl. AWD Curb weight 3490 - 3800 lbs 1580 - 1730 kg Max.
Page 388 ACEA A5/B5 must be used. Lower quality oils may not offer the same fuel economy, engine NOTE performance, or engine protection. This vehicle comes from the factory with Volvo recommends: synthetic oil. Oil additives must not be used. Oil viscosity Incorrect viscosity oil can shorten engine life...
Page 389 SAE 0W-30 oil meeting ACEA A5/B5 require- ments is recommended for extreme driving conditions. CAUTION 4-cylinder engines only: Volvo oil VCC RBS0-2AE/SAE 0W20 is recommended for extreme driving conditions. This oil must never be used in 5- or 6-cyl- inder engines.
Page 390: Electrical System
Power steering Power steering fluid WSS M2C204-A2 or equivalent product. Washer fluid 6.8 US qts (6.5 liters) Use a washer antifreeze recommended by Volvo, mixed with water. 4.7 US qts (4.5 liters Fuel tank volume 17.8 US gallons (67.5 liters) See page 293 for fuel recommendations Under normal driving conditions the transmission oil does not need changing during its service life.
Page 391 10 Specifications Specifications Motor Voltage (V) Cold start capacity Reserve capacity CCA (Cold Cranking Amperes) (A) (minutes) Engines with Start/Stop* All other engines 520–800 100–160 AGM (Absorbed Glass Mat) batteries have to be used on models with Start/Stop CAUTION If the battery is replaced, replace it with a battery of the same cold start capacity and reserve capacity as the original (see the decal on the battery).
Page 392: Overview Of Information And Warning Symbols
10 Specifications Overview of information and warning symbols Introduction Symbols in the main instrument panel Indicator symbols in the instrument panel The symbols in the vehicle's various displays Warning symbols in the instrument are divided into three main categories: Symbol Description panel •...
Page 393 10 Specifications Overview of information and warning symbols Symbol Description Symbol Description Pg. no. Symbol Description Pg. no. Camera sensor, 179172 Driver Alert System* laser sensor (Lane Departure Left turn signal indicator Warning/Lane Keeping Aid) Right turn signal indica- Collision Warning Driver Alert System* with Full Auto-brake (Lane Departure...
Page 394 10 Specifications Overview of information and warning symbols Symbol Description Bluetooth-connected cell phone Bluetooth hands-free HD radio Park Assist* Information symbols in the ceiling console Symbol Description Seat belt reminder Occupant Weight Sensor Option/accessory, for more information, see Introduction.
Page 395: Volvo Programs
10 Specifications Volvo programs Volvo On Call Roadside Assistance Your new Volvo comes with a four year ON CALL roadside assistance. Additional infor- mation, features, and benefits are described in a separate information package in your glove compartment. If you require assistance, dial: In the U.S.
Page 396: 11 Index
11 Index All Wheel Drive......... 128 Automatic transmission 1, 2, 3 ... Eco (driving function)......132 Ambient temperature sensor..... 85 12-volt sockets........240 Geartronic........... 126 Anti-freeze........290, 346 general description..... 125, 126 Anti-lock brake system oil............388 warning light......... 83 shiftlock override........
Page 397 11 Index fluid............. 388 ISOFIX/LATCH anchors......49 Corner traction control......148 general information......139 top tether anchors........ 51 Courtesy lighting........104 Bulbs Child safety..........38 Crash event data......... 9 headlights......348, 349, 350 booster cushions........48 Crash mode..........36 introduction......... 348 child restraint systems......
Page 398 11 Index Driver distraction warning......13 Engine Fog lights........... 83 overheating........... 84 rear............102 Driving economically........ 288 specifications........385 Four C (active chassis system)....237 Driving in cold weather......290 Start/Stop........... 135 Front airbags..........23 Driving through water......289 starting..........120 disconnecting passenger’s side air- switching off........
Page 399 11 Index Geartronic automatic transmission..126 High beams..........99 Infotainment active............ 99 Menu navigation......... 247 Generator warning light......84 Hill Start Assist (HSA)......125 Infotainment system........ 244 Glossary of tire terminology..... 316 AUX/USB sockets....... 267 Hoisting the vehicle......... 340 Grocery bag holder........298 ®...
Page 400 11 Index Lighting panel..........98 retractable........... 110 vanity..........240 Load anchoring eyelets......297 Jack Moonroof..........115 Loading the vehicle......297, 317 attaching..........329 roof loads..........299 Motor oil location of........... 328 checking..........344 Locking............69 Jump starting........... 123 volumes..........387 Locking the vehicle........
Page 401 11 Index Power windows........108 Refueling.......... 292, 293 fuel filler cap........295 Pregnancy, using seat belts during... 21 Paint, touching up........375 fuel filler door........294 Private locking........... 65 fuel tank volume......... 388 Park assist........194, 196 PROPOSITION 65 WARNING.. 123, 359, 388 Registering child restraints......
Page 402 11 Index SiriusXM™ satellite radio......257 Studded tires........... 320 Snow chains..........320 Sunroof (moonroof)........115 Safety, occupant........16 Sun shade........108, 109 Snow tires..........320 Safety defects, reporting......17 Spare tire..........321 Supplemental restraint system....22 Seat belt warning light......... 84 Spin control..........
Page 403 322 Turn signals..........103 Volvo maintenance........338 tread wear indicator......307 changing bulbs........351 Volvo On Call Roadside Assistance..393 uniform tire quality grading....319 indicator lights........83 Volvo programs........393 Tire sealing system........322 Volvo Sensus........... 212 Top tether anchors (child restraint sys- tems)............
Page 404 11 Index Water, driving through......289 Waxing............. 373 Weights............ 384 Wheels............. 306 changing........328, 329 storing..........308 Whiplash Protection System..... 34 Windows power..........108 sun shade........... 108 Windshield heated......... 111, 227 rain sensor.......... 106 washers..........107 wipers/washers........106 Windshield washer fluid....356, 388 Windshield wipers........

Volvo 2015 S60 Owner's Manual

Introduction

1 Safety

2 Locks and Alarm

3 Your Driving Environment

4 Driver Support

5 Comfort and Driving Pleasure

6 Infotainment

7 During Your Trip

8 Wheels and Tires

9 Maintenance and Specifications

Specifications

11 Index

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Volvo 2015 S60

Summary of Contents for Volvo 2015 S60

Table of Contents
