Air Live AirMax2 Quick Setup Manual

Declaration of Conformity

We, Manufacturer/Importer
OvisLink Corp.
5F., NO.6, Lane 130, Min-Chuan Rd., Hsin-Tien City, Taipei County, Taiwan
Declare that the product
802.11G Wireless Outdoor CPE
AirLive AirMax2
is in conformity with
In accordance with 2004/108/EC Directive, 1999/5 EC-R & TTE Directive and 2009/125/EC Directive
Clause Description
■ EN 300 328 v1.7.1
Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband
transmission equipment operating in the 2.4GHz ISM band
And using spread spectrum modulation techniques; Part 1：technical
Characteristics and test conditions Part2：Harmonized EN covering Essential
requirements under article 3.2 of the R&TTE Directive.
■
EN 301 489-01 v 1.8.1 Electromagnetic compatibility and Radio spectrum Matters (ERM);
■
EN 301 489-17 v 1.3.2 Electromagnetic compatibility(EMC) standard for radio equipment and
Services; Part 17：Specific conditions for wideband data and HIPERLAN equipment
■ EN 50385:2002
Product standard to demonstrate the Compliance of radio base stations
and Fixed terminal stations for wireless Telecommunication System with
the Basic restrictions or the reference levels related to human exposure
to radio Frequency electromagnetic fields ( 110 MHz– 40 GHz ) - General public
■ EN 60950-1 2006+A11:2009
Safety for information technology equipment including electrical Business equipment
■ CE marking
Manufacturer/Importer
Signature：
Name：Albert Yeh
Position/ Title : Vice President Date：2009/11/26

Regulatory Approvals

FCC Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interferences when the equipment is
operating in a commercial area. This equipment generates, uses and may radiate radio
frequency energy, and if not installed in accordance with the user guide, may cause
interference in the transmission of radio communications. If operating in a residential
area, it is probable this equipment will cause harmful interference, in which case the
user will be required to try to correct this interference using his own means.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter
CE Marking Warning
This is a Class B product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
CE Statement
This product complies with the 99/5/EEC directives, including the following safety and
EMC standards:
■
EN 300 328 v1.7.1
Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband transmission
equipment operating in the 2.4GHz ISM band And using spread spectrum modulation techniques;
Part 1：technical Characteristics and test conditions Part2：Harmonized EN covering Essential
requirements under article 3.2 of the R&TTE Directive
■ ■
EN 301 489-01 V1.8.1 EN 301 489-17 V1.3.2
Electromagnetic compatibility and Radio spectrum Matters (ERM); Electromagnetic
compatibility(EMC) standard for radio equipment and Services; Part 17：Specific conditions for
wideband data and HIPERLAN equipment
■
EN 50385:2002
Product standard to demonstrate the Compliance of radio base stations and Fixed terminal stations
for wireless Telecommunication System with the Basic restrictions or the reference levels related to
human exposure to radio Frequency electromagnetic fields ( 110 MHz– 40 GHz ) - General public
■
EN 60950-1 2006+A11:2009
Safety for information technology equipment including electrical Business equipment
AirMax2
802.11G Wireless Outdoor CPE

Quick Setup Guide

1
Remove the screws
2 Hold and pull down the bottom housing
3
Install the PoE cable
(not included, please use CAT-5E
Outdoor Ethernet Cable)
4
Install the PoE cable and power cable to
the DC Injector
1
2
3
Ecodesign Directive
■
(EC) No 1275/2008
Implementing Directive 2009/125/EC of the European Parliament and of the
Council with regard to ecodesign requirements for standby and off mode
electric power consumption of electrical and electronic household and office
equipment.
■
(EC) No 278/2009
Implementing Directive 2009/125/EC of the European Parliament and of the
Council with regard to ecodesign requirements for no-load condition electric
power consumption and average active efficiency of external power supplies.
Directive 1999 / 5 / EC
This equipment may be used in AT, BE, CY, CZ, DK, EE, FI, FR, DE, GR, HU, IE, IT,
LV, LT, LU, MT, NL,PL,PT, SK, SI, ES, SE, GB, IS, LI, NO, CH, BG, RO, TR
OvisLink Corporation declares that this device is in
compliance with the essential requirements and
other relevant provisions of directive 1999/5/EC.
4
To PC
Power
To CPE
Tested To Comply
With FCC Standards.
FOR HOME OR OFFICE USE
P1
