Summary of Contents for JAGER PRO M.I.N.E. CAM
- Page 2 In no event will JAGER PRO, LLC be liable to you, or any third party, for any damages in excess of the purchase price of the product. In addition, JAGER PRO,LLC shall...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Camera Characteristics..........04 Getting Started.............. 07 Initial SD Card Programming........07 Main Menu Tabs............13 CAM Tab............... 14 PIR Tab................. 14 GSM Tab............... 15 SYS Tab................ 17 Camera Quick Setup.............17 SMS Command Codes..........19 Care and Maintenance..........20 Accessories.............. -
Page 4: Camera Characteristics
CAMERA CHARACTERISTICS Front View 1. Antenna: Standard antenna shown receives cell tower signals. Our 5 decibel booster antenna is available as an accessory for operation in low signal areas. 2. IR Illuminators: Twin banks using 52 infrared LEDs that illuminate the target area when camera functions at night. 3. - Page 5 Bottom Outside View 1. Transmitter Port Plug: Waterproof seal to protect internal components when transmitter is not in use. 2. Mounting Port: 1/4 x 20 internal threads for securing camera to a T-Post mount. Only thread external devices two complete rotations into the camera mounting port then tighten using the mount’s adjusting nut.
- Page 6 Left Inside View 1. Antenna Port: Attachment point to install various antennas depending on local cellular strength. Our 5 db booster antenna is available as an accessory for operation in low signal areas. 2. Display: Screen to observe menus, photos and settings. 3.
-
Page 7: Getting Started
Right Inside View Battery Polarity Symbols: Located on the front of the battery tray. Aids in proper battery polarity and installation. GETTING STARTED We recommend an AT&T SIM card as their data package has unlimited text and photo messaging for only $19.99 per month. The camera was designed with this concept. - Page 8 6. Using the arrow buttons, scroll right to the GSM tab. Then scroll 2 clicks up until the Download Tool option is visible. 7. Press OK to SAVE the UOV Setup tool to the SD card. The screen will revert back to the initial display. 8.
- Page 9 NOTE: Change the folder name by deleting GSMSETUP from the text box. Only the drive letter of the SD card should remain (see example below). 10. Click the “Extract” button. 11. The three items below should appear in the SD card file. 12.
- Page 10 • Send Mode Instant: (Recommended) The camera sends a photo immediately when it takes a photo. It will only send an SMS text message of the sequence number when a video is taken (Video: 3/99). The Max Num field indicates the maximum number of photos or texts allowed to be sent within 24 hours.
- Page 11 • Operator Parameter Choose the country and GSM wireless carrier of the SIM card. Custom must be selected if an AT&T or T-Mobile SIM card is NOT used. Click Custom and manually input the parameters for the URL, APN, IP and Port according to the alternate GSM service provider settings.
- Page 12 Browse Button Rename When ON, up to eight letters can be entered in the field on the right such as the example above. The name appears on every photo which makes it easier to identify each camera site when multiple cameras are being used. Max Size The allowable range is 60-200KB.
-
Page 13: Main Menu Tabs
SD Card Programming Complete The SD card has been properly programmed when an icon named PROFILE.BIN is visible on the SD card screen. NOTE: Click on “This program installed correctly” if the above pop up window appears after step 13. 14. -
Page 14: Cam Tab
Press the ▲ or ▼ buttons to cycle through the tab settings. Press ◄ or ► to select items with white highlights to view the choices. Press OK to save the new setting which will change the highlight to red. Press ▲ or ▼ to view the next setting. Cycle to the top ▲... -
Page 15: Gsm Tab
• Time Lapse OFF: Camera triggers only during PIR event. (Recommend) ON: Camera automatically triggers at selected intervals. • Start - Stop OFF: Camera triggers 24 hours per day. ON: Camera only triggers between the START and STOP times programmed. Could be used to avoid high traffic from non-target species during specified times. - Page 16 • Send To: Phone: (Recommended) A text photo will arrive to a cell phone much faster than an email can arrive to either a cell phone or computer provided the cell phone has good reception. A phone number must appear in Recipients. Email: The image will be sent to email.
-
Page 17: Sys Tab
SYS Tab: • Set Clock: Enter correct Date and Time. • Time Stamp: Choose ON or OFF to select the date and time stamp on the picture. • Flash Range: Choose between 6m/20ft or 12m/40ft. We recommend 12m/40ft to maximize infrared illumination. •... - Page 18 5. The camera has successfully acquired a cellular signal when six numbers or the service provider’s initials appear on the display. Failure to connect will prevent the camera from sending texts and photos via MMS. 01-03-2013 15:43:35 00002 / 15797m Note: Allow approximately 10-20 seconds for the camera to acquire a cellular signal.
-
Page 19: Sms Command Codes
SMS COMMAND CODES The M.I.N.E.™ Cam is able to receive text commands from four phone numbers to perform various functions remotely. The SMS Switch must be ON for the camera to receive these text commands. The phone number in position one is the Commander and has the ability to add/delete subordinate phone numbers and emails via text. -
Page 20: Care And Maintenance
CARE AND MAINTENANCE Exterior 1. Inspect the outside of the camera body for any cracks which may cause water or moisture damage to electronics. 2. Check for condensation in both IR LED bank covers. 3. Ensure the antenna is not loose, bent, broken or cracked. 4. -
Page 21: Accessories
CAMERA ACCESSORIES JAGER PRO™ offers several items for the M.I.N.E.™ Cam to increase the versatility and function of the camera. These www.jagerpro.com items may be purchased online at External 5 db Booster Antenna This antenna is designed for areas where cellular coverage is weak and enables users to expand the usable range of the M.I.N.E.™... -
Page 22: Purchasing A Sim Card
PURCHASING A SIM CARD AT&T SIM cards must be purchased in person from an AT&T corporate store; not an AT&T authorized retailer. Type “AT&T corporate store” into a search engine (i.e. Google or Bing) and enter your zip code to find the nearest location. Users cannot request unlimited messaging packages online. -
Page 23: Glossary
GLOSSARY CDMA - Code Division Multiple Access is a competing cell phone service technology to GSM, which is the world’s most widely used cell phone standard. Sprint, Verizon, and Virgin Mobile use CDMA. GPRS - General Packet Radio Service was early technology to enable data communication on GSM networks. - Page 24 JAGER PRO offers a complete line of Hog Control Products, Services and Education View our instructional video series online at: Like us on Facebook www.facebook.com/JAGERPROHCS PO Box 4006 Columbus, GA 31914 Phone: 706-718-9789 Email: info@jagerpro.com Website: www.jagerpro.com...
