JAGER PRO M.I.N.E. Operation Manual

Hide thumbs Also See for M.I.N.E.:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operator's Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M.I.N.E. and is the answer not in the manual?

Questions and answers

Related Manuals for JAGER PRO M.I.N.E.

Summary of Contents for JAGER PRO M.I.N.E.

  • Page 2 In no event will JAGER PRO, LLC be liable to you, or any third party, for any damages in excess of the purchase price of the product. In addition, JAGER PRO,LLC shall...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Camera Characteristics..........04 Quick Start Programming..........07 Main Menu Tabs............08 Camera Tab..............09 Trigger Tab..............10 System Tab..............11 Wireless Tab..............12 Manually Sending Photos..........15 SMS Command Codes..........16 LOGIN Fail Corrective Action........17 Timing Camera Transmitter to Control Box Receiver..18 Camera Deployment.............

  • Page 4: Camera Characteristics

    CAMERA CHARACTERISTICS This manual is intended to visually guide users through the individual steps to properly program, operate and maintain the 3G GSM version of our JAGER PRO M.I.N.E™ and I.C.E.™ Cameras. Front View 1. Antenna: Standard antenna shown receives cell tower signals. Our 5 decibel booster antenna is available as an accessory for operation in low signal areas.
  • Page 5 Bottom Outside View 1. DC Port Plug: Waterproof seal to protect internal components when external battery (optional equipment) is not in use. 2. Mounting Port: 1/4 x 20 internal threads for securing camera to a T-Post mount. Only thread external devices two complete rotations into the camera mounting port then tighten using the mount’s adjusting nut.
  • Page 6 Inside View 1. Antenna Port: Attachment point to install various antennas depending on local cellular strength. Our 5 db booster antenna is available as an accessory for operation in low signal areas. 2. Display: Screen to observe menus, photos and settings. 3.

  • Page 7: Quick Start Programming

    Left Side View 1. SIM Card Port: Slot for receiving a cellular SIM card from GSM network providers such as AT&T and T-Mobile. 2. SD Card Port: Slot for receiving an SD card. The camera has no internal memory. An SD card smaller than 32GB must be used to store photos, video and GSM data.

  • Page 8: Main Menu Tabs

    immediately power OFF after the logo is displayed. The camera supports up to a 32 GB SD card. Ensure the SD card is not locked and insert it into the SD card port. Move the selector switch from OFF to SETUP. The screen will display “Searching Network” at the bottom center of the screen.

  • Page 9: Camera Tab

    Camera Tab: • Mode: Choose Photo or Video. (Recommend Photo for immediate text information sent to phone.) 720p/WVGA QVGA/1080p options • Photo Size: Choose the image size; 3MP, 5MP, or 8MP. • Video Size: Choose the video size. 1/2/3 burst option •...

  • Page 10: Trigger Tab

    Trigger Tab: Off/High/Normal Low options • Sensitivity- Passive Infrared (PIR) Trigger Sensitivity High: The most sensitive setting and will trigger camera operation when any movement is detected. Low: The least sensitive setting used when foliage, wind or shadows trigger excessive photos. Normal: Average sensitivity.

  • Page 11: System Tab

    System Tab: • Set Clock: Enter correct Date and Time. • Time Stamp: Choose ON or OFF to select the date and time stamp on the picture. • Flash Power: Choose between Low or High. We recommend High to extend infrared illumination beyond trap. •...

  • Page 12: Wireless Tab

    • Default: Restores camera back to factory settings. • Information: Displays firmware Module S150 version of camera and IMEI number. HW Ver 52 Check our website for the latest FW Ver 2014/09/18-18:32:52 firmware version and uploading IMEI 012813002148916 instructions. MENU •...
  • Page 13 Off: GSM function is de-activated. Photos and videos will not be sent to a recipient but will be saved to the SD card. • Send To: Phone: (Recommended) A text photo will arrive to a cell phone much faster than an email can arrive to either a cell phone or computer provided the cell phone has good reception.
  • Page 14 Image From MENU • Phone: Press OK to select an open tab and move right one click to input the recipient phone number. Use the keypad to type the 10-digit phone number. Select SAVE which returns to the Phone submenu. Select SAVE which returns to the WIRELESS submenu.

  • Page 15: Manually Sending Photos

    Will not be used for normal daily operations. Copy Para: Will not be used for normal daily operations. If you have any questions, refer to the JAGER PRO™ M.I.N.E. & I.C.E. (3G) Camera Operations Video at 04:20 MAIN MENU TABS for more information.

  • Page 16: Sms Command Codes

    10 seconds to receive the photo as an SMS text to a programmed phone when the 3G signal is strong. If you have any questions, refer to the JAGER PRO™ M.I.N.E. & I.C.E. (3G) Camera Operations Video at 12:45 MANUALLY SENDING PHOTO for more information.

  • Page 17: Login Fail Corrective Action

    Slide the rubber waterproof boot over the booster antenna cable connector. If you have any questions, refer to the JAGER PRO™ M.I.N.E. & I.C.E. (3G) Camera Operations Video at 17:13 LOGIN FAIL CORRECTIVE ACTION...

  • Page 18: Timing Camera Transmitter To Control Box Receiver

    SMS text command *777# to test transmitter and receiver calibration and gate operation. If you have any questions, refer to the JAGER PRO™ M.I.N.E. & I.C.E. (3G) Camera Operations Video at 18:41 TIMING CAMERA TRANSMITTER TO CONTROL BOX RECEIVER for more information.

  • Page 19: Camera Deployment

    CAMERA DEPLOYMENT Align the 1/4 by 20 threads of the T-Post mounting bracket to the camera mounting port. Thread the mounting bracket no more than three complete rotations into the camera mounting port. Then tighten using the adjusting nut. Forcing external threads to the bottom will damage the camera mounting port and the camera housing.
  • Page 20 81 degrees Fahrenheit. The battery symbol is “H” which indicates the batteries are at a high charge. The final step is to register your new equipment on the JAGER PRO website via the camera IMEI number so we may provide appropriate firmware updates.

  • Page 21: Care And Maintenance

    CARE AND MAINTENANCE Exterior: 1. Inspect the outside of the camera body for any cracks which may cause water or moisture to damage electronics. 2. Check for condensation in the IR LED bank. 3. Ensure the antenna is not loose, bent, broken or cracked. 4.

  • Page 22: Accessories

    CAMERA ACCESSORIES JAGER PRO™ offers several items for the M.I.N.E.™ Cam to increase the versatility and function of the camera. These items may be purchased online at www.jagerpro.com. External 5 db Booster Antenna This antenna is designed for areas where cellular coverage is weak and enables users to expand the usable range of the M.I.N.E.™...

  • Page 23: Purchasing A Sim Card

    PURCHASING A SIM CARD We recommend an AT&T SIM card as their data package has unlimited text and photo messaging for only $19.99 per month. It does not matter which cellular company offers the best coverage in your area. Verizon and Sprint network providers use CDMA technology and the camera requires GSM technology (AT&T or T-Mobile) to operate.

  • Page 24: Glossary

    GLOSSARY CDMA - Code Division Multiple Access is a competing cell phone service technology to GSM, which is the world’s most widely used cell phone standard. Sprint, Verizon, and Virgin Mobile use CDMA. GPRS - General Packet Radio Service was early technology to enable data communication on GSM networks.

  • Page 25: Sms Command Code List

    SMS COMMAND CODE LIST Ensure the SMS Switch is ON in order for the camera to receive text commands. The M.I.N.E™ Cam is able to receive text commands from up to four phone numbers to perform these 22 different functions remotely. All four phone numbers have the ability to send and receive SMS commands to control the camera.
