6.1 For software installation and intructions, please
read the User Guide on CD.
6.2 Software function:
Check the data store off-line record curve graph.
6.3 DC input : For saving battery consumption, please
use 9V 500mA adapter on long period measurement.
(Polarity show on socket label)
7M aintenance .
7.1 Lens cleaning: Blow off lose particles using clean
compressed air. Gently brush remaining debris away
with a moist cotton cloth.
RS232
RS232 socket
Standard DC IN socket
7.2 Case cleaning: Clean the case with a damp sponge
cloth and mild soap.
-08-
9V
DC IN
(Figure5)
1.Introduction
----------------------
Computer software disc
RS232 /USB Input interface
----------------------------------
Main Parts
-----------------------------
English Manual
-------------------------------
Warranty card
----------------------------------
9V battery
------------------------------
PP packing box
Compact, rugged and easy to use. Just aim and push
the button, read current surface temperature in less than
a second. Safely measure surface temperature of hot,
hazardous or hard-to-reach objects without contact.

2.How it works

Infrared thermometer measures the surface temper-
ature of an object. The unit's optics sense emitted, ref-
lected, and transmitted energy which is collect and fo-
cused onto a detector. The unit's electronics translate
the information into a temperature reading which is dis-
played on the unit.
For increased ease and accuracy the laser pointer
makes aiming even more precise.
-01-
1pcs
-------------------
1pcs
1pcs
1pcs
1pcs
1pcs
1pcs
