Page 1: Electric Griddle
I n s t a l l a t i o n a n d O p e r a t i o n M a n u a l I n s t a l l a t i o n a n d O p e r a t i o n M a n u a l Electric Griddle GP8600E GPL8600E GP8900E... - Page 2 MANUFACTURED BY Moffat Limited PO Box 10001 Christchurch New Zealand (03) 389 1007 Fax: (03) 389 1276 WORLD-WIDE BRANCHES UNITED KINGDOM Blue Seal 67 Gravelly Business Park Gravelly Park Birmingham West Midlands B24 8TQ (121) 327 5575 Fax: (121) 327 9711 UNITED STATES Moffat Inc 3765 Champion Blvd...
-
Page 3: Table Of Contents
Contents Waldorf Electric Griddle GP(L)8600E Electric Griddle, 600 mm. GP(L)8900E Electric Griddle, 900 mm. GP(L)8120E Electric Griddle, 1200 mm. Introduction ..................... 2 Specifications ................... 3 Model Numbers Covered in this Specification General Electrical Supply Requirements Electrical Connection Dimensions Installation ....................9... -
Page 4: Introduction
Introduction We are confident that you will be delighted with your WALDORF ELECTRIC GRIDDLE, and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new WALDORF Appliance, there are two important things you can do. -
Page 5: Specifications
Specifications Model Numbers Covered in this Specification GP[1]8600E - B Electric Griddle 600 mm wide Bench Model. GP[1]8600E - CB Electric Griddle 600 mm wide with Cabinet Base. GP[1]8600E - LS Electric Griddle 600 mm wide on Leg Stand. GP[1]8900E - B Electric Griddle 900 mm wide Bench Model. -
Page 6: Electrical Supply Requirements
Electrical supply connection point is located at the rear of the appliance, approximately 130 mm from the right hand side and 32 mm from the rear and 710 mm from the floor. When connecting a Waldorf electric appliance to the main supply, ensure that the following is carried out:- •... -
Page 7: Dimensions
Dimensions Dimensions for Bench Models = Rating Plate Location for this option. GP(L)8600E - B GP(L)8900E - B GP(L)8120E - B... - Page 8 Dimensions Dimensions for Cabinet Base Models = Rating Plate Location for this option. GP(L)8600E - CB GP(L)8900E - CB GP(L)8120E - CB...
- Page 9 Dimensions Dimensions for Leg Stand Models = Rating Plate Location for this option. GP(L)8600E - LS GP(L)8900E - LS GP(L)8120E - LS...
- Page 10 Dimensions Dimensions for Refrigeration Base Models = Rating Plate Location for this option. GP(L)8900E - RB GP(L)8120E - RB...
-
Page 11: Installation
Waldorf Electric Griddles are designed to provide years of satisfactory service and correct installation is essential to achieve the best performance, efficiency and trouble-free operation. This appliance must be installed in accordance with National installation codes and in addition, in accordance with relevant National / Local codes covering electrical and fire safety. -
Page 12: Assembly
Connect the mains supply to L1, L2 and L3 fuse carrier connections for 3 phase and L1 for single phase (GP8600E). Connect neutral and earth conductors to neutral stud and earth stud respectively. -
Page 13: Commissioning
Installation Commissioning Before leaving the new installation; a. Check the following functions in accordance with the operating instructions specified in the ‘Operation’ section of this manual. • Check the current draw and loading for the equipment. Refer specification section for correct electrical requirements. -
Page 14: Operation
Only qualified service persons are to carry out installation and servicing of this appliance. Waldorf Electrical Griddles have been designed to provide simplicity of operation and 100% safety protection. Improper operation is therefore almost impossible, however bad operation practices can reduce the life of the griddle and produce a poor quality product. -
Page 15: Cleaning And Maintenance
Cleaning and Maintenance AUTIO N Always turn off the electrical supply at the mains before cleaning. This appliance is not water proof. Do Not use water jet spray to clean interior or exterior of this appliance. General Clean the griddle regularly. A clean appliance looks better, will last longer and will perform better. Carbonised grease on the surface or on the griddle plate will hinder the transfer of heat from the cooking surface to the food. -
Page 16: Daily Cleaning
Cleaning and Maintenance Daily Cleaning The grease drawer should be checked and emptied frequently to prevent overflow and spillage. Remove the grease drawer while still warm so that the grease is in a liquid state. Empty any grease from the drawer and wash thoroughly in the same manner as any cooking utensil. Clean the Control Panel with a damp cloth lightly moistened with a solution of mild detergent and water. -
Page 17: Periodic Maintenance
Cleaning and Maintenance a. Remove and clean the grease collection drawer frequently to prevent over spills. b. Clean the griddle surface thoroughly with the supplied scraper tool. c. Allow the plate to cool, then clean the plate with a scrubbing brush, a mild non-abrasive detergent and water. -
Page 18: Fault Finding
Fault Finding This section provides an easy reference guide to the more common problems that may occur during the operation of your equipment. The fault finding guide in this section is intended to help you correct, or at least accurately diagnose problems with your equipment. Although this section covers the most common problems reported, you may encounter a problem not covered in this section. -
Page 19: Circuit Schematics
Circuit Schematics GP8600E (1 P+N+E Connection) REAR SUPPLY ENTRY EARTH STUD M6 LABEL 019207 EARTH STUD M6 GRIDDLE PLATE NEON AMBER 227963 THERMOSTAT 229146 OVERTEMP THERMOSTAT 229353 NEON GREEN 227962 SWITCH EARTH STUD 229145 3/16" CONTROL PANEL... - Page 20 Circuit Schematics GP8600E (3 P+N+E Connection) REAR SUPPLY ENTRY EARTH STUD M6 LABEL 229043 LABEL 19234 EARTH STUD M6 GRIDDLE PLATE NEON AMBER 227963 THERMOSTAT 229146 OVERTEMP THERMOSTAT 229353 NEON GREEN 227962 SWITCH EARTH STUD 229145 3/16" CONTROL PANEL...
- Page 21 Circuit Schematics GP8900E (3 P+N+E Connection)
- Page 22 Circuit Schematics GP8120E (3 P+N+E Connection)
-
Page 23: Replacement Parts List
Replacement Parts List Replacement Parts List IMPORTANT: Only genuine authorized replacement parts should be used for the servicing and repair of this appliance. The instructions supplied with the parts should be followed when replacing components. For further information and servicing instructions, contact your nearest authorized service branch (contact details are as shown on the reverse of the front cover of this manual).
