Waldorf GP8600G Operation Manual

800 series gas griddle
Hide thumbs Also See for GP8600G:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operation & Installation Manual
I n s t a l l a t i o n a n d O p e r a t i o n M a n u a l
I n s t a l l a t i o n a n d O p e r a t i o n M a n u a l
Gas Griddle
GP8600G
GP8900G
GP8120G
Date Purchased
Serial Number
Dealer
Service Provider
GPL8600G
GPL8900G
GPL8120G
1
For use in GB & IE
228676-22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP8600G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Waldorf GP8600G

Summary of Contents for Waldorf GP8600G

  • Page 1 I n s t a l l a t i o n a n d O p e r a t i o n M a n u a l I n s t a l l a t i o n a n d O p e r a t i o n M a n u a l Gas Griddle GP8600G GPL8600G GP8900G...
  • Page 2 MANUFACTURED BY Moffat Limited Christchurch New Zealand INTERNATIONAL CONTACTS AUSTRALIA Moffat Pty Limited Web: www.moffat.com.au E.Mail: vsales@moffat.com.au Main Office: (tel) +61 (03) 9518 3888 (fax) +61 (03) 9518 3833 Service: (tel): 1800 622 216 Spares: (tel): 1800 337 963 Customer Service: (tel): 1800 335 315 (fax): 1800 350 281...

  • Page 3: Table Of Contents

    Contents Waldorf Gas Griddle GP(L)8600G Gas Griddle, 600 mm. GP(L)8900G Gas Griddle, 900 mm. GP(L)8120G Gas Griddle, 1200 mm. Introduction ..................... 2 Specifications ................... 3 Model Numbers Covered in this Specification General Gas Supply Requirements Gas Connection Dimensions ....................5 Installation ....................

  • Page 4: Introduction

    Introduction We are confident that you will be delighted with your WALDORF GAS GRIDDLE, and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new Waldorf GAS GRIDDLE, there are two important things you can do.

  • Page 5: Specifications

    The Griddle is constructed as a hob unit and is available in 4 options, on Leg Stand (-LS), Bench Mount (-B), Cabinet Base (-CB) or with Refrigerated Base (RB) models (Not available for GP8600G Models).

  • Page 6: Gas Supply Requirements

    Specifications Gas Supply Requirements - Non CE Only (Australia / New Zealand): Natural Gas LP Gas (Propane) GP8600G GP8900G GP8120G GP8600G GP8900G GP8120G Input Rating 53 MJ/hr 80 MJ/hr 108 MJ/hr 53 MJ/hr 80 MJ/hr 108 MJ/hr (N.H.G.C.) (50,234 BTU)

  • Page 7: Dimensions

    Dimensions Bench Models = Rating Plate Location for GP(L)8600G - B this option. GP(L)8900G - B GP(L)8120G - B...
  • Page 8 Dimensions Cabinet Base Models = Rating Plate Location for GP(L)8600G - CB this option. GP(L)8900G - CB GP(L)8120G - CB...
  • Page 9 Dimensions Leg Stand Models = Rating Plate Location for GP(L)8600G - LS this option. GP(L)8900G - LS GP(L)8120G - LS...
  • Page 10 Dimensions Refrigeration Base Models = Rating Plate Location for this option. GP(L)8900G - RB GP(L)8120G - RB...

  • Page 11: Installation

    Waldorf Gas Griddles are designed to provide years of satisfactory service and correct installation is essential to achieve the best performance, efficiency and trouble-free operation. This appliance must be installed in accordance with National installation codes and in addition, in accordance with relevant National / Local codes covering gas and fire safety.

  • Page 12: Clearances

    Installation Clearances NOTE: Only non-combustible materials can be used in close proximity to this appliance. Combustible Surface Non Combustible Surface Left / Right Hand Side 50mm Rear 50mm Assembly This model is delivered completely assembled. Ensure legs are securely attached. NOTE: ...

  • Page 13: Location

    Gas Connection NOTE: ALL GAS FITTING MUST ONLY BE CARRIED OUT BY AN QUALIFIED PERSON. Waldorf Gas Griddles do not require an electrical connection, as they function totally on the gas supply only. It is essential that the gas supply is correct for the appliance to be installed and that adequate supply pressure and volume is available.

  • Page 14: Gas Connection

    Installation Check gas operating pressure is as shown in ‘Specifications’ section. NOTE: Operating pressure is to be measured at burner operating pressure test point outlet and with one griddle burner operating at the ‘High Flame’ setting. Turn ‘Off’ mains gas supply and bleed gas out of appliance gas lines.

  • Page 15: Operation

    / operator. Waldorf Gas Griddles have been designed to provide simplicity of operation and 100% safety protection. Improper operation is therefore almost impossible, however bad operation practices can reduce the life of the gas griddle and produce a poor quality product.

  • Page 16: Lighting Pilot Burner

    Operation Lighting Pilot Burner These griddles are fitted with a pilot as a standard option and flame failure protection, which is incorporated for each main burner, by way of a thermo-electric system. Flame failure protection will shut off gas supply to that burner should the pilot for that burner go out, so that un-burnt gas is not expelled. This is an important safety feature which is slowly becoming law throughout the world Partially depress gas control knob whilst turning anti- clockwise to ‘Pilot’...

  • Page 17: Re-Setting Overtemp Device (All Uk And Optional Non-Uk Models

    Operation Re-Setting Overtemp Device (All UK and Optional Non-UK Models). This griddle is fitted with an overtemp device which isolates gas supply to burners should gas control system or thermostat malfunction, thus preventing griddle overheating. If pilot fails to ignite after several attempts, check the overtemp to ensure that it has not tripped.

  • Page 18: Cleaning And Maintenance

    Cleaning and Maintenance General Caution Always turn ‘Off’ gas supply before cleaning. This appliance is not water proof. Do not use water jet spray to clean interior or exterior of this appliance. Clean griddle regularly. A clean appliance looks better, will last longer and will perform better. Carbonised grease on surface or on griddle plate will hinder transfer of heat from cooking surface to food.

  • Page 19: Daily Cleaning

    Cleaning and Maintenance Daily Cleaning The grease drawer should be checked and emptied frequently to prevent overflow and spillage. Remove grease drawer while still warm so that grease is in a liquid state. Empty any grease from drawer and wash thoroughly in same manner as any cooking utensil. Clean Control Panel with a damp cloth lightly moistened with a solution of mild detergent and water.

  • Page 20: Periodic Maintenance

    Cleaning and Maintenance d. Occasionally bleach griddle plate with vinegar when cold. e. Dry griddle thoroughly with a dry cloth and polish with a soft dry cloth. f. Griddle should be switched ‘On’ briefly to ensure griddle plate becomes dry. Griddle Cooking Area a.

  • Page 21: Fault Finding

    Fault Finding This section provides an easy reference guide to the more common problems that may occur during operation of your equipment. The fault finding guide in this section is intended to help you correct, or at least accurately diagnose problems with your equipment. Although this section covers the most common problems reported, you may encounter a problem not covered in this section.

  • Page 22: Gas Conversion And Specifications

    Gas Conversion and Specifications Conversion Procedure Caution Ensure Appliance is isolated from gas supply before commencing servicing. NOTE:  These conversions should only be carried out by qualified persons. All connections must be checked for leaks before re-commissioning appliance.  Adjustment of components that have adjustments / settings sealed (e.g. paint sealed) can only be adjusted in accordance with following instructions and shell be re-sealed before re -commissioning this appliance.

  • Page 23: Gas Regulator

    Gas Conversion and Specifications Gas Regulator NOTE, Pin rotated for Natural Gas NOTE: Gas regulator supplied convertible between Natural Gas and LP Gas, but it’s outlet pressure is fixed ex-factory and NOTE, Pin rotated is NOT to be adjusted. for LPG Gas Type Labels On completion of gas conversion, replace gas type labels located at:- - Rear of unit, above gas connection.

  • Page 24: Gas Specifications

    Gas Conversion and Specifications Gas Specifications - Non CE Only (Australia / New Zealand): Natural Gas LP Gas (Propane) GP8600G GP8900G GP8120G GP8600G GP8900G GP8120G Main Burner Injector 3.60mm 3.00mm 2.85mm 2.10mm 1.80mm 1.70mm Pilot Burner Injector 0.41 0.25 Low Fire Adjustment...

  • Page 25: Replacement Parts List

    Gas Control Knob - 100°C to 290°C. 032360 Main Injector (Nat) Ø 3.60mm (GP8600G - Non-UK). 032340 Main Injector (Nat) Ø 3.40mm (GP8600G - UK only). 032300 Main Injector (Nat) Ø 3.00mm (GP8900G). 032285 Main Injector (Nat) Ø 2.85mm (GP8120G).
  • Page 26 Replacement Parts List Gas Conversion Kits Gas Type to Convert to Australia / New Zealand Only UK Only Models Nat. Gas Nat. Gas GP8600G 232025 232024 232029 232028 GP8900G 232033 232032 232033 232032 GP8120G 232037 232036 232037 232036 Accessories 228566 Griddle Scraper Tool.
