Technoline WT-553 Instruction Manual

Radio controlled projection clock with outdoor temperature transmitter
Hide thumbs
Table of Contents

Advertisement

Quick Links

RADIO CONTROLLED PROJECTION CLOCK WITH OUTDOOR TEMPERATURE
TRANSMITTER
Instruction Manual
INTRODUCTION
Congratulations on purchasing this Projection Clock with DCF-77 radio-controlled time. The operation of this
product is simple and straightforward and by reading this operating manual, users will receive the optimum
benefits of all its features.
FEATURES
Adjustable projector
SNOOZE key
PROJECTION CLOCK:
AL/HR key
MODE/MIN key
Brightness key
Direction key
DISPL key
Projector lens
Battery cover
Adapter socket
• DCF-77 Radio controlled time with manual setting option
• 24 hours time display (hour, minute, second)
• Calendar display (weekday, date, month)
• Alarm setting with snooze function
• Time zone (±9 hours)
• Temperature display in degree Celsius
• Indoor temperature display
• Outdoor temperature display
• Weather forecasting with 3 weather icons
• Weather tendency indicator
• Time projection display (hour and minute)
• Outdoor temperature projection display (degree Celsius)
• Alternate projection display mode selectable
• E.L. Back-light
• Projection with adjustable brightness and different orientations possible
OUTDOOR TEMPERATURE TRANSMITTER:
Holder
•
Remote transmission of outdoor temperature via 433 MHz signals to Projection Clock.
•
Wall mounting holder.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WT-553 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Technoline WT-553

Summary of Contents for Technoline WT-553

  • Page 1 • DCF-77 Radio controlled time with manual setting option RADIO CONTROLLED PROJECTION CLOCK WITH OUTDOOR TEMPERATURE • 24 hours time display (hour, minute, second) TRANSMITTER • Calendar display (weekday, date, month) Instruction Manual • Alarm setting with snooze function • Time zone (±9 hours) INTRODUCTION •...

  • Page 2: Batteries Installation

    TO INSTALL AND REPLACE BATTERIES IN THE PROJECTION CLOCK BATTERIES INSTALLATION The Projection Clock uses 3 x AA, IEC LR6, 1.5V batteries. To install and replace the batteries, please follow Insert the 2 x AAA, IEC LR3, 1.5V batteries into the transmitter (See “To install and replace batteries in the steps below (the battery cover is located at the back of the unit): the Temperature Transmitter”...

  • Page 3: To Use The Projector Power Adapter

    TO USE THE PROJECTOR POWER ADAPTER Projection Clock will be finally positioned (see notes on “Positioning” and “Checking for 433 MHz Reception”). The unit comes with an AC-DC adapter for using the projector for an extended period of time, such as If after 10 minutes the DCF time has not been received, manually enter the time.

  • Page 4: Function Keys

    RESETTING Enter manual time setting mode and time zone setting mode. Stop alarm and snooze function. The Projection Clock and the transmitter need to be reset when one of the following conditions occur: Set the minute, weekday, month and year. •...

  • Page 5: Alarm Setting

    M 2 – projecting by switching the display of the current time and the current outdoor temperature for general direction of the Frankfurt/Main transmitter (avoid positioning within close proximity of metal every 5 seconds. frames or structures). Adjust the intensity of the projector light with the key (The intensity of the projector light cannot be Note: adjusted when operated in battery mode).

  • Page 6: Lcd Screen Descriptions

    TO SET ALARM: LCD SCREEN DESCRIPTIONS Press and hold the AL/HR key, the (((•))) and ALM icon will appear and the alarm time on the LCD will The Projection Clock can display information of time; indoor and outdoor temperature; second; weekday and start flashing.

  • Page 7: Manual Time Setting

    MANUAL TIME SETTING Press the SNOOZE key again to enter the month and date setting (flashing). Use the AL/HR key to set the day and the MODE/MIN key to set the month. Minute Setting Hour Setting Press the SNOOZE key again to enter the weekday setting (flashing). (flashing) (flashing) Use the MODE/MIN key to set the weekday.
  • Page 8 WEATHER FORECAST AND TENDENCY Common to weather forecasting, absolute accuracy cannot be guaranteed. The weather forecasting feature is estimated to have an accuracy level of about 75% due to the varying areas the Projection Clock has been THE WEATHER FORECASTING ICONS: designed for use in.

  • Page 9: Checking For 433 Mhz Reception

    STORM WARNING: Using other electrical products such as headphones or speakers operating on the 433MHz-signal frequency may prevent correct signal transmission or reception. Neighbors using electrical devices When the air pressure drops continuously within a period of 8 hours, the “Rainy” icon will display; the operating on the 433MHz-signal frequency can also cause interference.

  • Page 10: Battery Change

    TO AFFIX USING DOUBLE-SIDED TAPE, FOLLOW THESE STEPS: Transmission frequency 433.92 MHz Transmission distance maximum 25 meters in open field Clean both surfaces before affixing double-sided tape. Power source Peel one side of the tape and press it firmly against the back of the holder. Projection Clock 3 x AA, IEC LR6, 1.5V batteries Now peel the other side of the tape and stick the holder firmly onto the...
  • Page 11 R&TTE Directive 1999/5/EC Summary of the Declaration of Conformity: We hereby declare that this wireless transmission device does comply with the essential requirements of R&TTE Directive 1999/5/EC.
