Selecon High Performance Fresnel Operation Manual

1200 series

Advertisement

Quick Links

1200 HIGH PERFORMANCE & COMPACT
THANK YOU FOR PURCHASING A SELECON LUMINAIRE. WE HAVE
DESIGNED THIS LUMINAIRE TO PROVIDE YOU WITH A SUPERIOR
FITTING IN PERFORMANCE, DESIGN AND ENGINEERING.
WE ARE CONFIDENT THAT IT WILL PERFORM TO YOUR
EXPECTATIONS FOR MANY YEARS TO COME.
Before operating your new luminaire please read this information to assist
you in making maximum use of your luminaire, its maintenance and care.
If you would like further assistance contact your Selecon dealer or
Selecon.

LAMPING YOUR LUMINAIRE

Before lamping – DISCONNECT THE LUMINAIRE FROM THE POWER SUPPLY. Be aware also that the
lamp or luminaire may still be hot, so exercise the necessary caution to avoid burns. Please note also
that these luminaires are not suitable for mounting on a normally flammable surface.
The Selecon 1200W Fresnel and PC range comprises four models: the High Performance Fresnel, High
Performance PC, Compact Fresnel and Compact PC. The Selecon 1200 range is designed for use with
either the T/29 1200W or T/19 1000W lamp.
To facilitate the use of these two lamps which are of different sizes the height of the GX9.5 lampbase is
adjustable. The adjustment is by means of two machined mounting posts. In the lower position the base is
aligned for use with the T/29 1200W lamp. In the top slot the base is aligned for use with the 1000W lamp.
To make the adjustment, loosen the front mounting post with a screwdriver, slide it forward to free the lamp
base. Position the base in the top (1000W) or bottom (1200W) slot, push the post back home and tighten the
screw post.
Lamps able to be used in the 1000/1200 range are: 1200W – T/29: 1000W – T/11, T/19, CP24, CP70.
Release the clip fastener and swing down the rear door.
Insert lamp taking care not to touch the quartz envelope with your fingers.
Close door and lock off the fastener.
The luminaire should be at least 1m away from the nearest object it is
lighting.
Version 2: September 2004
FRESNELs AND PCs
OPERATION MANUAL
© 2004 Selecon New Zealand Limited All Rights Reserved
Before
IMPORTANT NOTE:
discarding the packaging
ensure you have the
suspension bolt set, colour
frame & /or the lamp.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the High Performance Fresnel and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Selecon High Performance Fresnel

  • Page 1 The Selecon 1200W Fresnel and PC range comprises four models: the High Performance Fresnel, High Performance PC, Compact Fresnel and Compact PC. The Selecon 1200 range is designed for use with either the T/29 1200W or T/19 1000W lamp.
  • Page 2 Finger tight pressure only is necessary to lock the lamp / reflector assembly off in the chosen positions. A reference scale is provided to record focus settings on the 1200 High Performance Fresnel. When focusing, first spot the beam down, position the luminaire and then flood the beam to cover the area required.
  • Page 3 Consult your Selecon distributor for assistance. Only replace damaged parts with authorised Selecon spares. N.B. Luminaire Cable – your Selecon luminaire is fitted with a special heat-resistant, flexible cable, replace with genuine Selecon spare part cable kit only – refer to your Selecon distributor. (Replacement cables are supplied complete with necessary terminal connectors).
  • Page 4 However, the owner shall bear the cost of freight and insurance on the luminaire, both ways. If Selecon does not wish to service, repair or replace the defective luminaire, it shall refund the purchase price. Selecon’s sole responsibility is to repair, replace or service a luminaire subject to a valid warranty claim. Under...

This manual is also suitable for:

Highperformance pcCompact fresnelCompact pc
