DUCTLESS RECIRCULATING (OPTION)
Ductless recirculating is intended for applications where an exhaust duct work is not possible to be installed.
When converted, the one piece liner functions in air "purifying" mode rather than exhausting the air. Fumes
back into the kitchen.
We recommend to always exhaust air outside of the home by employing existing or installing new duct work,
possible should you use the liner in recirculating mode.
Purchase recirculating kit as follows.
Part No. Qty. to Order
ZRC-9000 1
usage of 1 hour a day.
Part No. Qty. to Order
Z0F-C090 1
baffle filter frame
For detailed installation instructions please refer to manual included with recirculating kit.
charcoal
filter
14
www.zephyronline.com
Return Air Vent
top of cabinet
