Connect One II-EVB-300 User Manual

Instant internet evaluation board
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Instant Internet
Evaluation Board
Pub. No. 23-3460-00 September 2004
II-EVB-300

User Manual

Version 1.0
International:
Connect One Ltd.
2 Hanagar Street
Kfar Saba 44425, Israel
Tel: +972-9-766-0456
Fax: +972-9-766-0461
E-mail: info@connectone.com
http://www.connectone.com
USA:
Connect One Semiconductors, Inc.
15818 North 9th Ave.
Phoenix, AZ 85023
Tel: 408-986-9602
Fax: 602-485-3715
E-mail: info@connectone.com
http://www.connectone.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the II-EVB-300 and is the answer not in the manual?

Questions and answers

Related Manuals for Connect One II-EVB-300

Summary of Contents for Connect One II-EVB-300

  • Page 1: User Manual

    Instant Internet Evaluation Board II-EVB-300 User Manual Version 1.0 International: USA: Connect One Ltd. Connect One Semiconductors, Inc. 2 Hanagar Street 15818 North 9th Ave. Kfar Saba 44425, Israel Phoenix, AZ 85023 Tel: +972-9-766-0456 Tel: 408-986-9602 Fax: +972-9-766-0461 Fax: 602-485-3715 E-mail: info@connectone.com...

  • Page 2: Table Of Contents

    II-EVB-300 User Manual 23-3460-00 TABLE OF CONTENTS Introduction__________________________________________________________3 Unpacking ___________________________________________________________3 Connections__________________________________________________________3 Installing the II-EVB-300 Utilities and Evaluation Program ____________________4 Connectors & Switch Positions __________________________________________5 LED Positions ________________________________________________________6 Dip Switch Tables_____________________________________________________7 Bill of Materials: ______________________________________________________8 Daughter Boards _____________________________________________________10 Appendix 1: Schematics _______________________________________________11...

  • Page 3: Introduction

    Program. Connections • Connect one end of the RS232 cable to the serial port on the II-EVB-300 (J4) and connect the other DB-9 connector to the COM1 or COM2 serial port on your PC or to the serial port of your embedded device.

  • Page 4: Installing The Ii-Evb-300 Utilities And Evaluation Program

    II-EVB-300 User Manual 23-3460-00 • Connect one end of the phone cable to the II-EVB-300 (J10) and connect the other end to the wall phone jack. • Connect one end of the Ethernet cable to the daughter board (J3) and connect the other end to an Ethernet wall socket, Ethernet switch or hub.

  • Page 5: Connectors & Switch Positions

    II-EVB-300 User Manual 23-3460-00 Connectors & Switch Positions HOST HOST HOST RS232 RS485 INPUT INPUT INPUT SELECT Socket Modem DAUGHTER BOARD PHONE LINE EXTERNAL MODEM LAN CONNECTION ON LAN DAUGHTER BOARD September 2004...

  • Page 6: Led Positions

    II-EVB-300 User Manual 23-3460-00 LED Positions TXDH RXDH Socket Modem RXDM TXDM -DTRM -RIM DAUGHTER BOARD RING These LEDs are on the IIDB-SMC-100 daughter board September 2004...

  • Page 7: Dip Switch Tables

    II-EVB-300 User Manual 23-3460-00 Dip Switch Tables SW2.1 SW2.2 SW2.3 SW2.4 iChip Type iChip Plus or CO710AG or CO210AG (Default iChip Plus) iChip LAN (*) iChip (*) Figure 1: iChip type select SW4.1 SW4.2 SW4.3 SW4.4 Host Input Select RS232 INPUT ENABLE (Default)

  • Page 8: Bill Of Materials

    II-EVB-300 User Manual 23-3460-00 Bill of Materials: # Qty Reference Description Manufacturer 1 14 C19,C21,C24,C27,C31, 0.1UF C37,C39,C41,C42,C43,C44, C46,C50,C55 C40,C45,C49,C23 10UF/16V C17,C18 22PF 1UF/16V C25,C26,C28,C29,C51,C52, 0.47UF C53,C54 270UF/35V C47,C48 1NF/3KV D1,D2,D3,D4,D6,D7,D8,D9, GREEN LED 10 1 1N4001 11 1 HEADER 5X2 FEM...
  • Page 9 II-EVB-300 User Manual 23-3460-00 # Qty Reference Description Manufacturer 1.2K R30,R31 2/2010 SW1,SW3 TACK_SW SW4,SW2 SW-DIP-4 SWITCH SW-DIP-2 CO710AG-CM Connect One Ltd. SP708RCN Sipex SP3238ECA Sipex U17,U11 74LV244 On Semi U13,U12 SP3485CN Sipex LT1086CM Linear MT34000SMI Multi-Tech U15 CONNECTOR SQT-109-01-L-S-MW...

  • Page 10: Daughter Boards

    II-EVB-300 User Manual 23-3460-00 Daughter Boards The II-EVB-300 motherboard accepts several daughter boards that enhance the default connectivity options. The daughter boards are: SMsC 10/100BaseT LAN91C111 Ethernet controller. A detailed reference design that shows how to connect this controller to iChip can be found at: http://www.connectone.com/RefDesignFiles/10-...

  • Page 11: Appendix 1: Schematics

    II-EVB-300 User Manual 23-3460-00 Appendix 1: Schematics II-EVB-300 Motherboard Figure 4: iChip Circuit September 2004...
  • Page 12 II-EVB-300 User Manual 23-3460-00 Figure 5: II-EVB-200 Extension BUS September 2004...
  • Page 13 II-EVB-300 User Manual 23-3460-00 Figure 6: Host Interface and In-Circuit Programming (ICP) September 2004...
  • Page 14 II-EVB-300 User Manual 23-3460-00 Figure 7: Power Circuit September 2004...
  • Page 15 II-EVB-300 User Manual 23-3460-00 Figure 6: Modem Circuit September 2004...

  • Page 16: Smsc 10/100Baset Ethernet Lan Daughter Board

    II-EVB-300 User Manual 23-3460-00 SMsC 10/100BaseT Ethernet LAN Daughter Board Figure 7: IIDB-SMC100 Schematic September 2004...

  • Page 17: Asix 10/100Baset Ethernet Lan Daughter Board

    II-EVB-300 User Manual 23-3460-00 ASIX 10/100BaseT Ethernet LAN Daughter Board Figure 8: IIDB-SX200 Schematic September 2004...

  • Page 18: Cirrus Logic Crystal Lan 10Baset Ethernet Lan Daughter Board

    II-EVB-300 User Manual 23-3460-00 Cirrus Logic Crystal LAN 10BaseT Ethernet LAN Daughter Board Figure 9: IIDB-CR200 September 2004...
