Mi-T-M ABS 30 Operator's Manual

Gasoline 30/80 gallon industrial air compressor

Advertisement

Quick Links

GASOLINE
30/80 GALLON INDUSTRIAL

AIR COMPRESSOR

OPERATOR'S MANUAL
CAUTION
RISK OF INJURY! READ ENTIRE MANUAL
BEFORE OPERATING! THIS MANUAL IS AN IMPORTANT
PART OF THE AIR COMPRESSOR AND MUST REMAIN
WITH THIS UNIT WHEN YOU SELL OR RENT IT!
©Copyright 2008, Mi-T-M Corporation®
Form #37-1033-E/S-120508
Mi-T-M
Gasoline Air Compressor Manual

®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ABS 30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mi-T-M ABS 30

  • Page 1: Air Compressor

    RISK OF INJURY! READ ENTIRE MANUAL BEFORE OPERATING! THIS MANUAL IS AN IMPORTANT PART OF THE AIR COMPRESSOR AND MUST REMAIN WITH THIS UNIT WHEN YOU SELL OR RENT IT! ©Copyright 2008, Mi-T-M Corporation® Form #37-1033-E/S-120508 Mi-T-M Gasoline Air Compressor Manual...
  • Page 2: Table Of Contents

    FEATURES DRAWINGS ........................8-9 FEATURES REVIEW ........................10 PREPARATION ............................13 INITIAL SET-UP ..........................13 LOCATION .............................13 GASOLINE ENGINE ........................13 PRE-START CHECKLIST .......................14 OPERATION .............................15 START-UP ............................15 SHUTDOWN ..........................15 MAINTENANCE ............................15 MAINTENANCE CHART ........................16 TROUBLESHOOTING ........................17-18 WARRANTY .............................19 Mi-T-M Gasoline Air Compressor Manual ®...
  • Page 3: Introduction

    Mi-T-M Air Compressor. The contents of this manual are based on the latest product information available at the time of publication. Mi-T-M reserves the right to make chang- es in price, color, materials equipment, specifications or models at any time without notice.
  • Page 4: Safety Warnings

    12 inches openings are restricted, causing away from any wall or obstruction the air compressor to overheat that would restrict proper ventila- and start a fire. tion. Mi-T-M Gasoline Air Compressor Manual ®...
  • Page 5: Risk Of Bursting

    Never repair, weld or make modifications to the air tank or its attachments. Use only genuine Mi-T-M® repair parts for your air compressor. Never make adjustments to the factory set pressures. Never exceed manufacturers maximum allowable pressure rat- ing of attachments.
  • Page 6: Risk To Breathing

    Never allow any part of your body to contact the engine muffler or adjacent areas. Mi-T-M Gasoline Air Compressor Manual ®...
  • Page 7: Risk Of Flying Objects

    Do not operate air compressor in a corrosive environment. Always operate the air compres- sor in a stable, secure position to prevent air compressor from falling. Follow all maintenance instruc- tions listed in this manual. Mi-T-M Gasoline Air Compressor Manual ®...
  • Page 8: Features Drawings

    MI-T-M GASOLINE AIR COMPRESSOR FEATURES (TWO STAGE) ABS BASE MOUNT 1. Decal- Warning: Hot Surfaces 9. Pump Oil Drain 2. Decal- Warning: Risk of Fire 10. Decal- Warning: Hot 3. Engine Throttle Control 11. Air Filter 4. Engine 12. Air Compressor Pump 5.
  • Page 9 MI-T-M GASOLINE AIR COMPRESSOR FEATURES (TWO STAGE) ABS 30 GALLON HORIZONTAL ABS 80 GALLON HORIZONTAL 1. Decal- Warning: Hot Surfaces 2. Decal- Warning: Risk of Fire 3. Engine 4. Engine Throttle Control 5. Decal- Danger/Warning/Caution 6. Pilot Valve 7. Pressure Relief Valve 8.
  • Page 10: Features Review

    NEVER attempt to open the drain valve when more than 10 PSI of air pressure is in the air tank! To open the drain valve, turn the knob counterclockwise. Mi-T-M Gasoline Air Compressor Manual ®...
  • Page 11 NOTES Mi-T-M Gasoline Air Compressor Manual ®...
  • Page 12 DO NOT ATTEMPT TO OPERATE THIS AIR COMPRESSOR UNTIL YOU HAVE READ AND UNDERSTOOD ALL SAFETY PRECAUTIONS AND INSTRUCTIONS LISTED IN THIS MANUAL. INCORRECT OPERATION OF THIS UNIT CAN CAUSE SERIOUS INJURY!! DO NOT ALTER OR MODIFY THIS EQUIPMENT IN ANY MATTER! Mi-T-M Gasoline Air Compressor Manual ®...
  • Page 13: Preparation

    7. Fill the fuel tank according to the engine manual instruction. 8. Refer to the engine manual for all necessary maintenance and adjustments. waRnInG RIsK of eXPlosIon oR fIRe causInG seRIous InjuRy oR Death! Do not Place unIt In an aRea wheRe flaMMable Gas vaPoRs May be PResent. a sPaRK coulD cause an eXPlosIon oR fIRe. always stoRe fuel away fRoM the aIR coMPRessoR whIle It Is RunnInG oR hot. Mi-T-M Gasoline Air Compressor Manual ®...
  • Page 14: Pre-Start Checklist

    10 PSI of air pressure is in the air tank! Remove excessive pressure with an air tool, then open the Air Tank Drain Valve in the bottom of the air tank. Close tightly when drained. Mi-T-M Gasoline Air Compressor Manual...
  • Page 15: Operation

    1. Turn off air compressor. 2. Disconnect spark plug wire from engine. 3. Open all drains. 4. Wait for the air compressor to cool before starting service. Mi-T-M Gasoline Air Compressor Manual ®...
  • Page 16: Maintenance Chart

    The engine oil must be changed after the first 8 hours of operation and every 50 hours or 3 months, which- ever comes first. Every 2 years, an Authorized Service Technician should check the check valve, intake valves and delivery valves. Mi-T-M Gasoline Air Compressor Manual ®...
  • Page 17: Troubleshooting

    Carbon deposits on pistons or Clean or replace. valves. Bearing, piston or connecting rod STOP THE AIR COMPRESSOR! Contact Mi-T-M Customer Service. failure. Pressure drop in air tank or Air leaks at connections. Allow air compressor to build pres- sure to the maximum allowed. Turn rapid pressure loss when air compressor is shut off.
  • Page 18 Torque head bolts: Single Stage= 17 ft./lbs. Two Stage= 33 ft./lbs. Air blowing from Air Intake Defective inlet (reed) valve. Contact Mi-T-M Customer Service. Filter. Moisture in discharge air. Condensation in air tank caused Run air compressor a minimum of...
  • Page 19: Warranty

    MI-t-M GasolIne aIR coMPRessoR stateMent of waRRanty Mi-T-M Corporation warrants all parts, (except those referred to below), of your new air compressor to be free from defects in materials and workmanship during the following periods: For Five (5) years from the date of original purchase:...
  • Page 20 Manufactured by Mi-T-M 8650 Enterprise Drive, Peosta IA 52068 563-556-7484/ Fax 563-556-1235 Mi-T-M Gasoline Air Compressor Manual ®...
