ENGINE-DRIVEN
30/80 GALLON INDUSTRIAL
AIR COMPRESSOR
OPERATOR'S MANUAL
PARTS LIST
CAUTION
RISK OF INJURY! READ ENTIRE MANUAL
BEFORE OPERATING! THIS MANUAL IS AN IMPORTANT
PART OF THE AIR COMPRESSOR AND MUST REMAIN
WITH THIS UNIT WHEN YOU SELL OR RENT IT!
©Copyright 2008, Mi-T-M Corporation®
Form #37-1033-E/S-030823
Mi-T-M
Gasoline Air Compressor Manual
1
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mi-T-M ABS-14V-30H
Summary of Contents for Mi-T-M ABS-14V-30H
- Page 1 RISK OF INJURY! READ ENTIRE MANUAL BEFORE OPERATING! THIS MANUAL IS AN IMPORTANT PART OF THE AIR COMPRESSOR AND MUST REMAIN WITH THIS UNIT WHEN YOU SELL OR RENT IT! ©Copyright 2008, Mi-T-M Corporation® Form #37-1033-E/S-030823 Mi-T-M Gasoline Air Compressor Manual...
-
Page 2: Table Of Contents
RISK OF FLYING OBJECTS .........................6 RISK FROM MOVING PARTS........................6 RISK FROM NEGLIGENCE ..........................6 RISK OF AIR COMPRESSOR DAMAGE .....................6 MI-T-M GASOLINE AIR COMPRESSOR FEATURES ...........7 (TWO STAGE) ........................7 EXPLODED VIEW & EXPLANATION OF AIR COMPRESSOR FEATURES* ....9 PREPARATION ......................11 INITIAL SET-UP: ............................11 LOCATION: ..............................11... -
Page 3: Introduction
Mi-T-M Air Compressor. The contents of this manual are based on the latest product information available at the time of publication. Mi-T-M reserves the right to make chang- es in price, color, materials equipment, specifications or models at any time without notice. -
Page 4: Important Safety Instructions
If air tank develops a leak, replace the air tank immediately. Never repair, weld or make modifications to the air tank or its attachments. Use only gen- uine Mi-T-M® repair parts for your air compressor. Never make adjustments to the factory set pressures. -
Page 5: Risk To Breathing
Never allow any part of your body or other materials to make contact with any exposed metal parts on the air compressor. Mi-T-M Gasoline Air Compressor Manual ®... -
Page 6: Risk Of Flying Objects
Do not operate air compressor without an air filter. Do not operate air compressor in a corrosive environment. Always operate the air compressor in a stable, secure position to prevent air compressor from falling. Follow all maintenance instructions listed in this manual. Mi-T-M Gasoline Air Compressor Manual ®... -
Page 7: Mi-T-M Gasoline Air Compressor Features
MI-T-M GASOLINE AIR COMPRESSOR FEATURES (TWO STAGE) ABS BASE MOUNT 1. Engine 6. Engine Throttle Control 2. Air Filter 7. Pilot Valve 3. Air Compressor Pump 8. Pump Oil Sight Glass 4. Ventilation Openings 9. Pump Oil Drain 5. Beltguard... - Page 8 MI-T-M GASOLINE AIR COMPRESSOR FEATURES (TWO STAGE) ABS 30 GALLON HORIZONTAL ABS 80 GALLON HORIZONTAL 1. Engine 2. Engine Throttle Control 3. Pilot Valve 4. Pressure Relief Valve 5. Pressure Gauge- Tank PSI* 6. Pressure Regulator* 7. Pump Oil Sight Glass 8.
-
Page 9: Exploded View & Explanation Of Air Compressor Features
NEVER attempt to open the drain valve when more than 10 PSI of air pressure is in the air tank! To open the drain valve, turn the knob counterclockwise. *Some Features Not available on all Models Mi-T-M Gasoline Air Compressor Manual ®... - Page 10 DO NOT ATTEMPT TO OPERATE THIS AIR COMPRESSOR UNTIL YOU HAVE READ AND UNDERSTOOD ALL SAFETY PRECAUTIONS AND INSTRUCTIONS LISTED IN THIS MANUAL. INCORRECT OPERATION OF THIS UNIT CAN CAUSE SERIOUS INJURY!! DO NOT ALTER OR MODIFY THIS EQUIPMENT IN ANY MATTER! Mi-T-M Gasoline Air Compressor Manual ®...
-
Page 11: Preparation
WARNING RISK OF ASPHYXIATION! DO NOT OPERATE IN AN ENCLOSED AREA. USE THIS PRODUCT ONLY IN WELL VENTILATED AREAS! THE EXHAUST FROM THE ENGINE CONTAINS CARBON MONOXIDE, A POISONOUS, ODORLESS AND INVISIBLE GAS. BREATHING THE GAS CAN CAUSE SERIOUS INJURY, ILLNESS AND POSSIBLE DEATH. Mi-T-M Gasoline Air Compressor Manual ®... -
Page 12: Pre-Start Checklist
10 PSI of air pressure is in the air tank! Remove excessive pressure with an air tool, then open the Air Tank Drain Valve in the bottom of the air tank. Close tightly when drained. Mi-T-M Gasoline Air Compressor Manual... -
Page 13: Operation
1. Turn off air compressor. 2. Disconnect spark plug wire from engine. For electric start engine, remove wire from negative post on battery. 3. Open all drains. 4. Wait for the air compressor to cool before starting service. Mi-T-M Gasoline Air Compressor Manual ®... -
Page 14: Maintenance Chart
The engine oil must be changed after the first 8 hours of operation and every 50 hours or 3 months, which- ever comes first. Every 2 years, an Authorized Service Technician should check the check valve, intake valves and delivery valves. **Gasoline engines only. Mi-T-M Gasoline Air Compressor Manual ®... -
Page 15: Troubleshooting
Defective gaskets. Torque head bolts: Single Stage= 17 ft./lbs. Two Stage= 33 ft./lbs. Air blowing from Air Intake Defective inlet (reed) valve. Contact Mi-T-M Customer Service. Filter. Moisture in discharge air. Condensation tank Run air compressor a minimum of one hour to caused by high level of at- prevent condensation buildup. - Page 16 Oil leaks. Torque head bolts: Single Stage= 17 ft./lbs. Two Stage= 33 ft./lbs. Worn piston rings or scored Contact Mi-T-M Customer Service. cylinder. Oil has milky appearance. Water in oil due to condensa- Change oil and move air compressor to a less tion.
-
Page 17: Statement Of Warranty
STATEMENT OF WARRANTY Mi-T-M Corporation warrants all parts, (except those referred to below), of your new air compressor to be free from defects in materials and workmanship during the following periods: For Five (5) years from the date of original purchase:... - Page 18 Manufactured by Mi-T-M 50 Mi-T-M Drive, Peosta IA 52068 563-556-7484/ Fax 563-556-1235 Mi-T-M Gasoline Air Compressor Manual ®...
