Catalogue
Product introduction..................................................1
Safety Precautions....................................................2
Installation.................................................................3
Control setting...........................................................7
Center of Gravity......................................................11
Thank you for purchasing for the Freewing F/A 18E
Super Hornet 90mm EDF that includes scale electric
retractable landing gear with suspension,360 degree
thrust vectoring nozzles and working position lights.A
great deal of the assembly is pre-done for you.This is a
receiver ready jet that only requires some simple
assembly and the installation of the flight batteries and
programming of your radio equipment to be ready to fly.
Please read the assembly manual carefully to familiarize
you with all the steps before starting.
Regarding to the different of configuration, the spareparts also is different. Please refer accoring to the
following contents.
RTF
Contents include:
*Pre-painted fuselage
*Pre-painted canopy & nose cone
*Rudder
*Pre-painted Main wing set
*Pre-painted Drop tanks
*Retract landing gear
*LED flash light [pre-installed 7pcs]
*90mm EDF [pre-installed 1pcs]
*AB Glue
*85A ESC
*Out runner brushless motor
*Servo[8pcs]
*6-Cell Li-poly Battery 30C[1pcs]
*Parts bag
*Manual
F/A 18E Super Hornet
Item No.:F1901
Wingspan...................37-3/8" [ 950mm ]
Fuselage length.........52" [ 1320mm ]
Flight weight...............4-1/2 lB. [ <2100g ]
Wing Area..................387 sq.in.approx
EDF Fan....................90mm
Thrust........................84-1/2 oz.
Motor.........................1700kv out-runner brushless motor.
Battery.......................6-cell,22.2V,3700mAh
Speed Control...........85A ESC with 5A switch model BEC
Servos.......................9g 8pcs
Parts Includ ed
ARF
Contents include:
*Pre-painted fuselage
*Pre-painted canopy
*nose cone
*Rudder
*Pre-painted Main wing set
*Pre-painted Drop tanks
*Retract landing gear
*LED flash light [pre-installed 7pcs]
*90mm EDF [pre-installed 1pcs]
*AB Glue
*Water sticker
*Parts bag
*Manual

Parts Included

-1-
Main Specifitions
30C Li-po Battery
