Summary of Contents for DFI CD102 Series

Page 1 CD102 Series Mini-ITX Industrial Motherboard User’s Manual A30030450...
Page 2: Copyright
Copyright FCC and DOC Statement on Class B This publication contains information that is protected by copyright. No part of it may be re- This equipment has been tested and found to comply with the limits for a Class B digital produced in any form or by any means or used to make any transformation/adaptation without device, pursuant to Part 15 of the FCC rules.
Page 3: Table Of Contents
Table of Contents COM (Serial) Ports ..................22 RJ45 LAN Ports ................... 23 USB Ports ....................23 Audio ......................24 I/O Connectors ................... 25 Copyright ......................2 Digital I/O Connector .................. 25 Digital I/O Power Connector ................ 25 Trademarks ......................2 SATA (Serial ATA) Connectors ..............
Page 4: About This Manual
About this Manual Static Electricity Precautions An electronic file of this manual is included in the CD. To view the user’s manual in the CD, It is quite easy to inadvertently damage your PC, system board, components or devices even insert the CD into a CD-ROM drive.
Page 5: About The Package
About the Package The package contains the following items. If any of these items are missing or damaged, please contact your dealer or sales representative for assistance. • One CD102 motherboard • One Serial ATA data with power cable • One I/O shield •...
Page 6: Chapter 1 - Introduction
Chapter 1 Chapter 1 - Introduction Specifications Processor • Intel ® Atom processors I/O Connectors • 2 connectors for 4 external USB 2.0/1.1 ports - CD102-25N: • 1 vertical USB 2.0/1.1 port (optional) ® : Intel Atom D2550, Dual core, 1M Cache, 1.86GHz, 10W •...
Page 7: Features
Chapter 1 • Wake-On-LAN Features This feature allows the network to remotely wake up a Soft Power Down (Soft-Off) PC. It • Watchdog Timer is supported via the onboard LAN port or via a PCI LAN card that uses the PCI PME (Power Management Event) signal.
Page 8: Power Failure Recovery
Chapter 1 Important: The 5V_standby power source of your power supply must support ≥720mA. • Power Failure Recovery When power returns after an AC power failure, you may choose to either power-on the system manually or let the system power-on automatically. Chapter 1 Introduction www.dﬁ...
Page 9: Chapter 2 - Hardware Installation
Chapter 2 Chapter 2 - Hardware Installation Important: Board Layout Electrostatic discharge (ESD) can damage your board, processor, disk drives, add-in boards, and other components. Perform installation procedures at an ESD workstation only. If such a station is not available, you can provide some ESD protection by wear- ing an antistatic wrist strap and attaching it to a metal part of the system chassis.
Page 10: Installing The Dimm Module
Chapter 2 Installing the DIMM Module The system board supports the following memory interface. Single Channel (SC) Note: The system board used in the following illustrations may not resemble the actual Data will be accessed in chunks of 64 bits (8B) from the memory channels. board.
Page 11: Jumper Settings
Chapter 2 Jumper Settings 5. Grasping the module by its edges, align the module into the socket at an approximately 30 degrees angle. Apply firm even pressure to each end of the module until it slips down into the socket. The contact fingers on the edge of the module will almost completely disappear Clear CMOS Data inside the socket.
Page 12: Auto Power-On Select
Chapter 2 Auto Power-on Select USB Power Select JP19 1-2 On: Power-on via power button (default) USB 0-1/2-3 2-3 On: 1-2 On: +5V (JP5) Power-on via AC power (default) 2-3 On: +5V_standby USB 4-5 USB 6-7 (JP21) (JP14) JP19 is used to select the method of powering on the system. If you want the system to power-on whenever AC power comes in, set JP19 pins 2 and 3 to On.
Page 13: Com1 Rs232/422/485 Select
Chapter 2 COM1 RS232/RS422/RS485 Select Note: When COM1 RS232/422/485 is selected, JP2 and JP4 must be set in accordance to JP3. COM 1 1-3, 2-4 On: RS232 (default) 3-5, 4-6 On: RS422 Full Duplex/RS485 JP2, JP3 and JP4 (for COM 1) are used to configure the Serial COM port to RS232, RS422 (Full Duplex) or RS485.
Page 14: Com1 Rs232 Power Select
Chapter 2 COM1 RS232/Power Select Mini PCIe Signal Select COM 1 1-3 (RI), 2-4 (DCD) On: 3-5 (+5V), 4-6 (+12V) On: 2-5-8-11, 3-6-9-12 On: 1-4-7-10, 2-5-8-11 On: RS232 (default) RS232 with power PCIe (default) mSATA JP1 (for COM 1) is used to configure the Serial COM port to pure RS232 or RS232 with power. JP8 and JP9 are used to select the Mini PCIe signal: PCIe or mSATA.
Page 15: Lvds Panel Select
Chapter 2 LVDS Panel Select Note: The default setting is eDP. 1. 1366x768: N2000 series processor supports eDP only. 2. 1600x1200: N2000 series processor supports DP only. 3. 1920x1080: D2000 series processor supports eDP only. 4. 1920x1200: D2000 series processor supports DP only. SW1 is used to select the resolution of LVDS panel on the system.
Page 16: Panel Power Select
Chapter 2 Panel Power Select Backlight Brightness Power Select 1-2 On: +12V JP10 3-4 On: +5V 1-2 On: +5V JP12 5-6 On: +3.3V 2-3 On: +3.3V (default) (default) JP10 is used to select the power supplied with the LCD panel. JP12 is used to select the power level of backlight brightness control: +5V or +3.3V.
Page 17: Lcd/Inverter Power Select
Chapter 2 LCD/Inverter Power Select SATA DOM Power Select 1-2 On: +12V (default) JP11 2-3 On: +5V SATA 0 JP11 is used to select the power level of LVDS LCD inverter connector. 2-3 On: +5V 1-2 On: GND (default) JP7 is used to select the power level of SATA DOM. Note: SATA port 0 provides adequate space for SATA DOM.
Page 18: Digital I/O Power Select
Chapter 2 Digital I/O Power Select Digital I/O Output State 1-2 On: +5V_standby (default) DIO 0-3 1-2 On: +5V or JP16 (JP17) +5V_standby (default) 2-3 On: +5V DIO 4-7 2-3 On: GND (JP18) JP16 is used to select the power of DIO (Digital I/O) signal. Based on the power level of DIO (Digital I/O) selected on JP16, JP17 (DIO pin 0-3) and JP18 (DIO pin 4-7) are used to select the state of DIO output: pull high or pull low.
Page 19: Ps/2 Keyboard/Mouse Power Select
Chapter 2 PS/2 Keyboard/Mouse Power Select Dimming Mode Select 1-2 On: Inverter mode (default) 1-2 On: +5V (default) JP13 JP15 2-3 On: Duty mode 2-3 On: +5V_standby JP15 is used to select the power of the PS/2 keyboard/mouse port. Selecting +5V_standby JP13 allows you to select the mode for the lightness control of LVDS panel.
Page 20: Dimming Control Select
Chapter 2 Dimming Control Select 1-2 On: Software mode (default) JP22 2-3 On: Hardware mode JP22 allows you to select the mode for the lightness source of LVDS panel via the Software mode or the Hardware mode. Chapter 2 Hardware Installation www.dﬁ...
Page 21: Rear Panel I/O Ports
Chapter 2 Rear Panel I/O Ports 12V DC-in (default) DC-in COM 1 COM 2 LAN 1 LAN 2 Line-in Line-out DC-in Mic-in USB 2.0 USB 2.0 HDMI The rear panel I/O ports consist of the following: • 1 12V DC-in jack (default) or 4-pin ATX power connector (optional) •...
Page 22: Graphics Interfaces
Chapter 2 Graphics Interfaces COM (Serial) Ports The display ports consist of the following: • 1 HDMI port • 1 VGA port COM 1: RS232/422/485 1 2 3 4 5 COM 1 HDMI COM2: RS232 COM 2 6 7 8 9 COM 4: RS232 RS232 COM 3: RS232...
Page 23: Rj45 Lan Ports
Chapter 2 RJ45 LAN Ports USB Ports USB 2.0 LAN 1 LAN 2 USB 1 USB 3 LAN 1 USB 2 USB 0 LAN 2 USB 4-5 USB 6-7 Features • 2 Intel 82574L PCI Express Gigabit Ethernet controllers or 2 Intel WGI210AT PCI Ex- ®...
Page 24: Audio
Chapter 2 Audio Wake-On-USB Keyboard/Mouse The Wake-On-USB Keyboard/Mouse function allows you to use a USB keyboard or USB mouse to wake up a system from the S3 (STR - Suspend To RAM) state. To use this function: • Jumper Setting JP5, JP14 and JP21 must be set to “2-3 On: +5V_standby”.
Page 25: I/O Connectors
Chapter 2 I/O Connectors SATA (Serial ATA) Connectors Digital I/O Connector Digital I/O Power Connector SATA 2.0 3Gb/s (SATA port 0 provides adequate space for SATA DOM.) SATA 0 SATA 1 Digital I/O power SATA power Digital I/O Features The 8-bit Digital I/O connector provides powering-on function to external devices that are con- •...
Page 26: Front Panel Connector
Chapter 2 Front Panel Connector S/PDIF Connector PWR-LED PWR-BTN HDD-LED RESET-SW SPDIF out Ground SPDIF in S/PDIF HDD-LED - HDD LED This LED will light when the hard drive is being accessed. RESET-SW - Reset Switch The S/PDIF connector is used to connect an external S/PDIF port. Your S/PDIF port may be mounted on a card-edge bracket.
Page 27: Parallel Port
Chapter 2 Parallel Port C Connector SMBUS Data Parallel +3.3V_standby SMBUS_Alert SMBUS Clock The 25-pin connector is used to connect an external parallel port. The parallel port connects The 1-channel I C bus interface conforms to the version 2.1 I C bus specification.
Page 28: Chassis Intrusion Connector
When enabled, a warning message will appear when the chassis is open. The utility can also be configured so that a beeping alarm will sound when the chassis is open. Refer to the “DFI The fan connectors are used to connect cooling fans. The cooling fans will provide adequate Utility”...
Page 29: Lvds Lcd Panel Connector
Configure the LCD panel in the Advanced/Chipset Features submenu of the BIOS. Refer to chapter 3 for more information. Panel Power Panel Power Panel Power Panel Power Note: DFI board's LVDS connector: Hirose DF13-40DP-1.25V(91)/40P/1.25mm; cable side connector: Hirose DF13-40DS-1.25C. Chapter 2 Hardware Installation www.dﬁ .com...
Page 30: Ps/2 Keyboard/Mouse Connector
Chapter 2 PS/2 Keyboard/Mouse Connector Wake-On-PS/2 Keyboard/Mouse The Wake-On-PS/2 Keyboard/Mouse function allows you to use the PS/2 keyboard or PS/2 mouse to power-on the system. To use this function: • Jumper Setting JP15 must be set to “2-3 On: 5V_standby”. Refer to “PS/2 Keyboard/Mouse Power Select” in this chapter for more information.
Page 31: Expansion Slots
Chapter 2 Expansion Slots LAN LED Connectors Link_1000 Mini PCI Express Link_100 LAN 1 State (J23) PCI Express x1 LAN 2 State (J21) LAN 2 State (J22) Mini PCIe Slot LAN 1 State (J24) The Mini PCIe socket is used to install a half size Mini PCIe card. Mini PCIe card is a small +3VDU form factor PCI card with the same signal protocol, electrical definitions, and configuration Link Activity...
Page 32: Standby Power Led
Chapter 2 Standby Power LED Battery Battery Standby Power LED This LED will lit red when the system is in the standby mode. It indicates that there is power The lithium ion battery powers the real-time clock and CMOS memory. It is an auxiliary source on the system board.
Page 33: Default Configuration
Chapter 3 Chapter 3 - BIOS Setup Legends Overview Keys Function The BIOS is a program that takes care of the basic level of communication between the CPU and peripherals. It contains codes for various advanced features found in this system board. Right and Left arrows Moves the highlight left or right to select a menu.
Page 34: Ami Bios Setup Utility
Chapter 3 AMI BIOS Setup Utility Intel RC Version The field only displays the version of the Intel reference code. Main The Main menu is the first screen that you will see when you enter the BIOS Setup Utility. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset...
Page 35: Advanced
Chapter 3 Advanced PCI Subsystem Settings This section is used to configure the PCI, PCI-X and PCI Express settings. The Advanced menu allows you to configure your system for basic operation. Some entries are defaults required by the system board, while others, if enabled, will improve the performance of your system or let you set some features according to your preference.
Page 36 Chapter 3 ACPI Settings Trusted Computing This section is used to configure the system ACPI parameters. This section configures settings relevant to Trusted Computing innovations. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Advanced Advanced Conﬁ...
Page 37 Chapter 3 CPU Configuration IDE Configuration This section is used to configure the CPU. It will also display the detected CPU information. This section is used to configure IDE devices. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Page 38 Chapter 3 Port 0 and Port 1 Speed Limit USB Configuration Selects the limitation of the Serial ATA port AHCI speed rate: No Limit, Gen 1 or Gen2. This section is used to configure USB pararmeters. SATA Port 0 and 1 Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Page 39 Chapter 3 Super IO Configuration Serial Port 0 Configuration to Serial Port 3 Configuration This section is used to configure the I/O functions supported by the onboard Super I/O chip. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Page 40 Chapter 3 Parallel Port Configuration Sets parameters of Parallel port (LPT/LPE). Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Advanced Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Serial Port 2 Conﬁ guration Enable or Disable Serial Port (COM) Advanced Serial Port...
Page 41 Chapter 3 Hardware Monitor System/CPU Fan Mode This section displays the hardware monitor status. Selects the smart fan mode. When the Manual Mode is selected, it will display the following information: Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Advanced PC Health Status Enable or Disable Smart...
Page 42 Chapter 3 When the Fan Speed CruiseTM Mode is selected, it will display the following informa- When the SmartFan TM IV Mode is selected, it will display the following information: tion: Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Page 43 Chapter 3 Power Failure Control WatchDog Configuration This section is used to control the status when the power failures. This field sets system WatchDog parameters. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Advanced Advanced Power Failure Control...
Page 44: Chipset
Chapter 3 Chipset Host Bridge This field configures Host Bridge parameters. This field configures relevant chipset functions. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save &...
Page 45 Chapter 3 South Bridge TPT Device This field configures South Bridge parameters. Enables or disables Intel(R) IO Controller Hub (TPT) devices. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Chipset Chipset ...
Page 46: Boot
Chapter 3 Boot UHCI #1~UHCI#4 Controls the USB UHCI (USB 1.1) function. Disables from highest to lowest controller. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. USB 2.0(EHCI) Support Main Advanced Chipset Boot Security Save & Exit Enables or disables the USB 2.0 (EHCI) support. Boot Conﬁ...
Page 47: Security
Chapter 3 Security CD/DVD ROM Drive BBS Priorities This field is used to select the boot sequence of the CD/DVD-ROM drives. Move the cursor to this field then press <Enter>. Use the Up or Down arrow keys to select a Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Page 48: Save & Exit
Chapter 3 Save & Exit Updating the BIOS To update the BIOS, you will need the new BIOS file and a flash utility, AFUDOS. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. EXE. Please contact technical support or your sales representative for the files. Main Advanced Chipset...
Page 49: Chapter 4 - Supported Software
Chapter 4 Chapter 4 - Supported Software Auto Run Page (For Windows XP) The CD that came with the system board contains drivers, utilities and software applications required to enhance the performance of the system board. Insert the CD into a CD-ROM drive. The autorun screen (Mainboard Utility CD) will appear. If after inserting the CD, “Autorun”...
Page 50 Chapter 4 Microsoft .NET Framework 3.5 (For Windows XP only) 3. Click Exit. Note: Before installing Microsoft .NET Framework 3.5, make sure you have updated your Windows XP operating system to Service Pack 3. To install the driver, click “Microsoft .NET Framework 3.5” on the main menu. 1.
Page 51: Intel Chipset Software Installation Utility
Chapter 4 Microsoft DirectX 9.0C (For Windows XP only) Intel Chipset Software Installation Utility To install the utility, click “Microsoft DirectX 9.0C Driver” on the main menu. The Intel Chipset Software Installation Utility is used for updating Windows INF files so that ®...
Page 52 Chapter 4 3. Go through the readme Intel Graphics Drivers (For Windows XP) document for system re- quirements and installation Note: tips then click Next. Before installing Intel Graphics Drivers, make sure you have installed Microsoft .NET Framework 3.5 SP1. To install the driver, click “Intel Graphics Drivers”...
Page 53: Intel Graphics Drivers (For Windows)
Chapter 4 Intel Graphics Drivers (For Windows 7) 4. Click “Continue Anyway“. To install the driver, click “Intel Graphics Drivers” on the main menu. 1. Setup is now ready to install the graphics driver. Click Next. 5. Click “Yes” to restart this com- puter now in order to complete installlation.
Page 54: Audio Drivers
Chapter 4 Audio Drivers 3. Go through the readme docu- ment for system requirements and installation tips then click To install the driver, click “Audio Drivers” on the main menu. Next. 1. Setup is now ready to install the driver. Click Next. 2.
Page 55: Intel Lan Drivers
Chapter 4 Intel LAN Drivers 4. Click Install to begin the installation. To install the driver, click “Intel LAN Drivers” on the main menu. 1. Setup is ready to install the driver. Click Next. 5. After completing installa- tion, click Finish. 2.
Page 56: Intel Rapid Storage Technology
Chapter 4 Intel Rapid Storage Technology 3. Go through the readme document for more installa- tion tips then click Next. To install the driver, click “Intel Rapid Storage Technology” on the main menu. 1. Setup is ready to install the driver.
Page 57: Dfi Utility
DFI Utility This is used to create a floppy driver diskette needed when you install Windows DFI Utility provides information about the board, Watchdog, DIO, and Backlight. ® XP using the F6 installation method. This will allow you to install the operating To access the utility, click “DFI Utility”...
Page 58 Chapter 4 3. Click “Install” to begin the The DFI Utility icon will appear on the desktop. Double-click the icon to open the utility. installation. 4. After completing installa tion, click “Finish”. Information HW Health Chapter 4 Supported Software www.dﬁ .com...
Page 59 Chapter 4 HW Health Set WatchDog Backlight Chapter 4 Supported Software www.dﬁ .com...
Page 60 Chapter 4 Adobe Acrobat Reader 9.3 To install the reader, click “Adobe Acrobat Reader 9.3” on the main menu. 1. Click Next to install or click Change Destination Folder to select another folder. 2. Click Install to begin installa- tion. 3.
Page 61: Chapter 5 - Digital I/O Proramming Guide
Chapter 5 Chapter 5 - Digital I/O Programming Guide The Configuration Register (register 3) configures the direction of the I/O pins. If a bit in this register is set to 1, the corresponding port pin is enabled as an input with a high-impedence Register Description output driver.
Page 62: Sample Code
Chapter 5 Function Description GPIO Output Process I2CWriteByte(SlaveAddr, SubAddr, Data): #deﬁ ne SLAVE_ADDR 0x40 Write a Byte data to a specified I2C Device. #deﬁ ne INPUT_PORT 0x00 #deﬁ ne OUTPUT_PORT 0x01 I2CReadByte(SlaveAddr, SubAddr, *Data): 0x02 #deﬁ ne INVERSION_PORT Read a Byte data from a specified I2C Device. 0x03 #deﬁ...
Page 63: Appendix A - Nlite And Ahci Installation Guide
Appendix A Appendix A - NLITE and AHCI Installation Guide 4. Insert the XP installation disc into an optical drive. nLite 5. Launch nLite. The Welcome screen will appear. Click nLite is an application program that allows you to customize your XP installation disc by Next.
Page 64 Appendix A 7. Click Next. 9. Click Insert and then select Multiple driver folder to select the drivers you will integrate. Click Next. Select only the drivers ap- 8. In the Task Selection dialog propriate for the Windows box, click Drivers and version that you are using Bootable ISO.
Page 65 Appendix A If you are uncertain of The program is currently the southbridge chip used integrating the drivers on your motherboard, and applying changes to select all RAID/AHCI the installation. controllers and then click When the program is finished applying the changes, click Next.
Page 66 Appendix A To create an image, You have finished cus- select the Create Image tomizing the Windows mode under the General XP installation disc. Click section and then click Finish. Next. Enter the BIOS utility to configure the SATA con- troller to RAID/AHCI.
Page 67 Appendix A AHCI 5. In the Hardware Update Wizard dialog box, select “No, not this time” then The installation steps below will guide you in configuring your SATA drive to AHCI mode. click Next. 1. Enter the BIOS utility and configure the SATA controller to IDE mode. 2.
Page 68 Appendix A A warning message 8. Click “Have Disk”. appeared because the se- lected SATA controller did not match your hardware device. Ignore the warning and click Yes to proceed. Click Finish. 9. Select C:\AHCI\iaAHCI.inf and then click Open. The system’s settings have been changed.
Page 69: Appendix B - Watchdog Sample Code
Appendix B Appendix B - Watchdog Sample Code ;Software programming example: ;--------------------------------------------- ;(1) Enter Super IO Conﬁ guration mode ;--------------------------------------------- DX,2EH AL,87H DX,AL DX,AL ;------------------------------------------------------------------------------------------- ;(2) Conﬁ guration Logical Device 7, register CRF5/CRF6 (WDT Control /WDT timer) ;------------------------------------------------------------------------------------------- DX,2EH AL,07H ;Ready to Program Logical Device DX,AL DX,2FH...
Page 70: Error Messages
Appendix C Appendix C - System Error Message Hard Disk(s) fail (20) When the BIOS encounters an error that requires the user to correct something, either a beep HDD initialization error. code will sound or a message will be displayed in a box in the middle of the screen and the message, PRESS F1 TO CONTINUE, CTRL-ALT-ESC or DEL TO ENTER SETUP, will be shown in Hard Disk(s) fail (10) the information box at the bottom.
Page 71: Appendix D - Troubleshooting
Appendix D Appendix D - Troubleshooting Checklist The picture seems to be constantly moving. Troubleshooting Checklist 1. The monitor has lost its vertical sync. Adjust the monitor’s vertical sync. 2. Move away any objects, such as another monitor or fan, that may be creating a magnetic This chapter of the manual is designed to help you with problems that you may encounter field around the display.
Page 72: Hard Drive
Appendix D Hard Drive System Board 1. Make sure the add-in card is seated securely in the expansion slot. If the add-in card is Hard disk failure. loose, power off the system, re-install the card and power up the system. 1.
Page 73: Appendix E - Bios Status Code
Appendix E Appendix E - BIOS Status Code PEI Status Codes Status Code Ranges Standard Status Codes SEC Status Codes Appendix E BIOS status code www.dﬁ .com...
Page 74 Appendix E PEI Beep Codes DXE Status Codes Appendix E BIOS status code www.dﬁ .com...
Page 75 Appendix E Appendix E BIOS status code www.dﬁ .com...
Page 76 Appendix E OEM-Reserved Status Code Ranges DXE Beep Codes ACPI/ASL Status Codes Appendix E BIOS status code www.dﬁ .com...
