Magikitch'n LPAGA/LPG & CG Options Installation - Operation

Outdoor grill options for lpaga/lpg/cg series
Hide thumbs
Table of Contents

Advertisement

Quick Links

LPAGA/LPG & CG
OUTDOOR GRILL OPTIONS
INSTALLATION - OPERATION
PITCO FRIALATOR INC.
www.PITCO.com
P.O. Box 501, Jct. I-89 & I-93 Concord, NH 03302-0501 • 509 Route 3A, Bow, NH 03304 USA
Telephone (800) 258-3708 • (603) 225-6684 • Fax: (603) 225-8497
PN L25-007 Rev. 1 (12/01)
© 2001 - Pitco Frialator Incorporated

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LPAGA/LPG & CG and is the answer not in the manual?

Questions and answers

Related Manuals for Magikitch'n LPAGA/LPG & CG

Summary of Contents for Magikitch'n LPAGA/LPG & CG

  • Page 1 LPAGA/LPG & CG OUTDOOR GRILL OPTIONS INSTALLATION - OPERATION PITCO FRIALATOR INC. www.PITCO.com P.O. Box 501, Jct. I-89 & I-93 Concord, NH 03302-0501 • 509 Route 3A, Bow, NH 03304 USA Telephone (800) 258-3708 • (603) 225-6684 • Fax: (603) 225-8497 PN L25-007 Rev.

  • Page 3: Table Of Contents

    Table of Contents 1. Hood Handle and Hood Bracket Assembly ..................2 2. Twin Hoods for the LPAGA/LPG-60 ....................3 3. Single Hood for the LPAGA/LPG-30 ....................4 4. Single (Full size) Hood for the LPAGA/LPG-60 ................5 5. Full Hood for the CG-60 ........................6 6.

  • Page 4: Hood Handle And Hood Bracket Assembly

    1. Hood Handle and Hood Bracket Assembly 4001-0963400 SCREW, 1/4-20 x 3/4”, INT. LOCKWASHER (PART OF 7299-1257300 HDWE KIT) 5602-1190600 HOOD, HANDLE SUPPORT ROD 5602-1190500 HOOD, HANDLE TUBULAR 5402-1187702 HOOD, BRACKET OUTER RIGHT 5402-1187701 HOOD, BRACKET CENTER LEFT/RIGHT HOOD, BRACKET OUTER LEFT 5402-1188002, RIGHT CRADLE 5402-1188001, LEFT...

  • Page 5: Twin Hoods For The Lpaga/Lpg-60

    2. Twin Hoods for the LPAGA/LPG-60 FRONT VIEW (CENTER MOUNTING BRACKET SHOWN) LEFT SIDE RIGHT SIDE OUTER HOOD OUTER HOOD RIGHT SIDE LEFT SIDE INNER HOOD INNER HOOD PIVOT BUSHING CRADLES PAN HEAD SCREW RIV-NUT 10545C1.DWG 9806-0965100 30" HOOD ASSEMBLIES LEFT OUTER MOUNTING BRACKET CENTER MOUNTING BRACKETS,...

  • Page 6: Single Hood For The Lpaga/Lpg-30

    3. Single Hood for the LPAGA/LPG-30 FRONT VIEW 5402-1187702 HOOD,BRACKET 5402-1187701 OUTER RIGHT HOOD, BRACKET INNER HOOD OUTER LEFT CRADLE OUTER HOOD MOUNTING BRACKET PIVOT PAN HEAD BUSHING SCREW RIV-NUT 9806-0965100 30” HOOD ASSEMBLY LEFT OUTER MOUNTING BRACKET RIGHT OUTER MOUNTING BRACKET UNIT BACK UNIT FRONT...

  • Page 7: Single (Full Size) Hood For The Lpaga/Lpg-60

    4. Single (Full size) Hood for the LPAGA/LPG-60 5402-1187702 HOOD, BRACKET 5402-1187701 OUTER RIGHT HOOD, BRACKET OUTER LEFT CRADLE 9806-0427000 60” HOOD ASSEMBLY LEFT OUTER MOUNTING BRACKET RIGHT OUTER MOUNTING BRACKET FRONT VIEW INNER HOOD UNIT BACK OUTER HOOD MOUNTING PIVOT BRACKET BUSHING...

  • Page 8: Full Hood For The Cg-60

    5. Full Hood for the CG-60 The CG-60 hood frame is designed only for use on the CG-60. It cannot be used on the CGL or LPAGA/LPG models. 9806-0427000 60” HOOD ASSEMBLY 5113-0345001 HOOD MOUNTING FRAME 9810-0426600 (60”) 3-PIECE WINDGUARD SET ASSEMBLED CORNER CHARBROILER FRAME...

  • Page 9: Steamer Support, Steamer Pan Set And Magigriddle Options

    6. Steamer Support, Steamer Pan Set and MagiGriddle Options 3616-0529600 30” MAGIGRIDDLE 3615-0294800 DOME COVER 3615-0294900 PERFORATED PAN 5109-0344701 30” STEAMER SUPPORT 3615-0347400 INSERT PAN 3615-0294700 CHAFING PAN RADIANT SUPPORT PAN RADIANT 10545C8.DWG Using the Steamer Support Option Remove the cooking grid from the side of the charbroiler to be used for steamer cooking. Place the steamer support directly on the radiants.

  • Page 10: The Windguard Option

    7. The Windguard Option 9810-0426500 (30”) 9810-0426600 (60”) 3-PIECE WINDGUARD SET ASSEMBLED CORNER 10545C9.DWG Assemble the Windguard ends to the back using the ½” long ¼-20 screws and the acorn nuts from the hardware bag in the Windguard package. Mount the Windguard on the charbroiler frame (either at the back or in the front) using the ¾” screws and the hex nuts, as illustrated in the close-up.

  • Page 11: Split Options For The Lpaga/Lpg-30

    8. Split Options for the LPAGA/LPG-30 9806-1218600 15" HOOD ASSEMBLIES 5109-1186301 15" STEAMER SUPPORT 3616-1186500 15" MAGIGRIDDLE 10545C11.DWG Using the Steamer Support Option Remove the cooking grid from the side of the charbroiler to be used for steamer cooking. Place the steamer support directly on the radiants.

  • Page 12: Cutting Board For The Lpaga/Lpg-30

    9. Cutting Board for the LPAGA/LPG-30 30” Richlite® Cutting Board Option Set for MagiCater, 9825-2000101. Contents: • (1) Left hand bracket, 5403-0989801 • (1) Right hand bracket, 5403-0989802 • (2) Screws, pan head Phillips, 1/4-20 x 3/4” long with captive internal tooth lockwasher, 4001- 0963400 •...

  • Page 13: Cutting Board For The Lpaga/Lpg-60

    10. Cutting Board for the LPAGA/LPG-60 60” Richlite® Cutting Board OptionSet for MagiCater, 9825-2000100. Contents: • (1) Left hand bracket, 5403-0989801 • (1) Right hand bracket, 5403-0989802 • (2) Screws, pan head Phillips, 1/4-20 x 3/4” long with captive internal tooth lockwasher, 4001- 0963400 •...

  • Page 14: Side Shelf For Lpg-30/60 And The Lpaga-30/60

    11. Side Shelf for LPG-30/60 and the LPAGA-30/60 SIDE SHELF ASSEMBLY REAR SPACER BAR TRIM KIT SIDE 10545E12.DW LPG-30/60 Slide side shelf assembly onto the desired side of the unit, and install two ¼-20 screws through the shelf support and into the frame side.
  • Page 15 L25-007 Rev. 1 12/2001...
  • Page 16 In the event of problems with or questions about In the event of problems with or questions about your order, please contact the Pitco Frialator fac- your equipment, please contact the Pitco Frialator tory, from 8:00 a.m. - 5:00 P.M., Eastern Standard Authorized Service and Parts representative Time, Monday through Friday, toll-free at: (ASAP) covering you area, through the National...
