With the turbo timer mode selected on, after you've arrived at your destination, while the
engine is still running, set the parking brake, pause 2 seconds, then turn the ignition switch
to the off position. The engine will continue to run the allotted time according to the
selection during installation.
If you do not want the vehicle to continue to run for one cycle, simply step on the vehicle's
brake, or release the parking brake, or activate the transmitter's start button two times in
succession. Any of these will cause the engine to turn off.

OPTIONAL REAR DEFROSTER

This system allows independent activation of the rear defogger while the remote start is
engaged. To activate the rear defogger, if this feature is installed, simply while the remote
start is engaged, press the Asterisk button of your keychain transmitter one time. This will
activate or reactivate if already activated, the rear window defogger timer of your vehicle if
so equipped.

OPTIONAL TRUNK RELEASE

This system provides an output that can be used to operate an existing electric trunk release
if the vehicle is so equipped. T o activate this feature, press and hold the TRUNK icon button
of your keychain transmitter for 3 seconds.

OPTIONAL LED

As an added safety feature, an LED can be installed in the dash to indicate when the doors
are Locked. The LED will flash all the time the doors are locked via the hand held transmit-
ter, and will turn off when the doors are unlocked via the hand held transmitter or whenever
the ignition is turned on from the key.
Run Time 5 Min
Door Lock Timer 1 Sec/1 Sec
Lights Pulse
Turbo Timer 3 Min
Rear Defogger Capable

FUNCTION SETTING CHART

To be completed by installer
10 Min 15 Min
3.5 1 Sec/Dbl 1 Sec
Steady
5 Min 10 Min
20 Min
128-
