EVAPORATOR, ICE CUTTER GRID AND WATER PARTS
For Models: KUIC18PNTS1
(Stainless Steel)
Illus.
Part
No.
No.
DESCRIPTION
1 W10159841 Valve, Complete
Water
2
2217286 Tube, Plastic
3
488208 Screw
4
2185523 Dispenser, Water
5
W10218037
Evaporator
6
2313705 Pump, Drain
7
2313851 Tube, Reservoir
Pump
8
2172593 Tube, Water Fill
9
488660 Nut, Speed
10
836667 Spacer
11
2208539 Fastener, Pushnut
12
489443 Screw
13
2185625 Reservoir,
Water Slide
14
2185626 Tube
15
2313890 Hose, Overflow
16
2217378 Bracket−Reservoir
17
2313603 Bracket, Front
and Rear
18
2313602 Bracket, Side
Left and Right
19
2185681 Harness, Grid
20
2208427 Support, Bracket
Evaporator/Grid
21
2313604 Guide, Ice Grid
22 W10136146 Tube
24
2310169 Wire Assembly
(Valve)
25
8281193 Screw
26
3400886 Screw 8−18 x 1 1/4
28
2313637 Grid Assembly
(Complete)
29
2174754 Wire, Grid Cutter
30
8281192 Screw
31
2208365 Cover, Grid
32
8281228 Thumbscrew
33
2324334 Reservoir, Water
34
3400884 Screw 8−18 x 5/8
35
2185696 Cap, Drain
36
3400909 Nut, Push−In
4
W10165874
