Dettson AMP105-IE2 Installation Instructions And Homeowner's Manual
Hide thumbs
Also See for AMP105-IE2:
Table of Contents
Advertisement
Quick Links
WARM AIR FURNACE
MULTIPOSITION
INSTALLER / SERVICE TECHNICIAN:
USE
THE
INFORMATION
INSTALLATION / SERVICING OF THE FURNACE AND KEEP THE
DOCUMENT NEAR THE UNIT FOR FUTURE REFERENCE.
HOMEOWNER:
PLEASE KEEP THIS MANUAL NEAR THE FURNACE FOR FUTURE
REFERENCE.
Printed in Canada
Printed on 100% recycled paper
IN
THIS
MANUAL
2013-06-12
Models:
AMP105-IE2
AMP120-IE2
NOMF105D12C
NOMF155E19C
NOMF106D12B
NOMF156E19C
C
Attention:
FOR
THE
Do not tamper with the unit or its
controls.
Call a qualified service technician.
Manufactured by:
Dettson Industries inc.
3400 Industriel Boulevard
Sherbrooke, Qc – Canada – J1L 1V8
www.dettson.ca
US
X40002 Rev.Z
Advertisement
Table of Contents
Related Manuals for Dettson AMP105-IE2
Summary of Contents for Dettson AMP105-IE2
- Page 1 DOCUMENT NEAR THE UNIT FOR FUTURE REFERENCE. Call a qualified service technician. Manufactured by: HOMEOWNER: Dettson Industries inc. PLEASE KEEP THIS MANUAL NEAR THE FURNACE FOR FUTURE 3400 Industriel Boulevard Sherbrooke, Qc – Canada – J1L 1V8 REFERENCE. www.dettson.ca...
-
Page 2: Table Of Contents
TABLE OF CONTENTS FIGURES Figure 1 : Counterflow position, flue pipe protection .....5 SAFETY REGULATIONS --------------------------------3 Figure 2 : Blocked vent shut-off device wiring, upflow installation with vertical exhaut ......7 DANGER, WARNING AND CAUTION ----------------3 Figure 3 : Blocked vent shut-off device wiring, upflow SAFETY INSTALLATION REQUIREMENTS--------3 installation with vertical exhaust......8 Figure 4 : Blocked vent shut-off device wiring, upflow... -
Page 3: Safety Regulations
SAFETY REGULATIONS IMPORTANT: All local and national code requirements governing the installation of oil burning equipment, wiring and flue connections must be followed. Some of the codes FOR YOUR SAFETY that may be applicable are: CSA B139 Installation Code for Oil Burning DO NOT STORE OR USE GASOLINE OR OTHER Equipment FLAMMABLE VAPOURS AND LIQUIDS IN THE VICINITY... -
Page 4: Safe Installation Requirements
SAFE INSTALLATION REQUIREMENTS SAFETY RULES WARNING Your unit is built to provide many years of safe and dependable service, provided it is properly installed and maintained. However, abuse and/or improper use can Installation or repairs performed by unqualified persons shorten the life of the unit and create hazards for you, the can result in hazards to them and others. -
Page 5: Location
LOCATION When installed in a horizontal position, the furnace may be suspended by using an angle iron frame, as long as the total CAUTION weight of both the furnace and the frame are included in the calculations. Other methods of suspension are acceptable. When installed in the horizontal position, this furnace must This furnace is not watertight and is not designed for not be installed on combustible flooring, unless the approved... -
Page 6: Duct Recommendations
ventilation openings, the number of doors to the outside, Also, there is provision on this furnace for a bottom return air internal doors which can close off the unconfined space and duct. Knockouts are provided in the floor of the furnace to the overall air tightness of the building construction. -
Page 7: Draft Regulator
This furnace is certified for uses with a Type “L” vent The following requirements are provided for a safe venting (maximum flue gas temperature 302°C (575°F)). The flue system: pipe clearance knockout in the front top or side panel should Ensure that the chimney flue is clear of any dirt or be removed. -
Page 8: Blocked Vent Shut-Off (Bvso)
Figure 3 : Blocked vent shut-off device wiring, upflow Figure 6: Blocked vent shut-off device wiring, horizontal installation with vertical exhaust installation with vertical exhaust DNS-1043 Rev A Connection to high limit contacts (See Figure 2) Connection to high limit contacts (See Figure 2) DNS-1043 Rev A Figure 4 : Blocked vent shut-off device wiring, upflow... -
Page 9: Oil Burner
For more details, refer to the instructions supplied with the device itself, as well as section 3 of this manual. When replacing any original furnace wiring, use only 105 16 AWG copper wire. It is also essential that the BVSO be maintained annually. For more details please refer to the instructions supplied with Instructions for wiring the thermostat are provided with the the device itself, as well as Section 4 of this Manual. -
Page 10: Horizontal Or Downflow Installation
provided with the BLUE wire must be used between the If a coil blower compartment is used, install air tight, “HEAT” and “COOL” terminals. motorized and automatic air dampers. Cold air coming from the coil and passing across the furnace can cause Table 4 : Blower speed adjustments, 4 speed motor, condensation and shorten the life of the heat exchanger. -
Page 11: Purging The Oil Line
is recommended that a Bacharach True Spot Smoke Test kit or equivalent be used; CAUTION Follow the next steps to do the combustion check verification: Drill a minimum proper diameter (about 9/32”) test Do not tamper with the unit or its controls. Call a hole in the flue pipe, approximately 18 inches from qualified service technician. -
Page 12: Heating
however, the fan motor speed may need to be changed to If cleaning is necessary, the following steps should be taken: obtain the necessary cooling airflow. Turn “OFF” all utilities upstream from the furnace; HEATING Disconnect the flue pipe (only with chimney venting and rigid flue pipe);... -
Page 13: Furnace Information
Remove the two screws holding down the BVSO Do not dent or scratch the surface of the thermal switch. assembly cover; If the thermal switch is damaged, it must be replaced. Remove the cover; Clear and remove any build-up or obstruction inside the Remove the two screws holding the control box to the heat transfer tube;... -
Page 14: Table 5 : Technical Specifications
Table 5 : Technical Specifications Model: AMP & NOMF 105 / 106 120 / 155 / 156 RATING AND PERFORMANCE Firing rate (USGPH)* 0.65 0.75 0.85 1.00 1.10 Input (BTU/h)* 70 000 91 000 105 000 119 000 140 000 154 000 Heating capacity (BTU/h)* 56 000... -
Page 15: Figure 9 : Model Amp 105 And Nomf 105 / 106
Figure 9 : Model AMP 105 and NOMF 105 / 106 Table 7 : Minimum clearances to combustible materials LOCATION APPLICATION UPFLOW DOW NFLOW HORIZONTAL FURNA CE Ø 5.08 cm (2") 5.08 cm (2") SIDES SUPPLY PLENUM WITHIN 6 f t. OF FURNA CE 2.54 cm (1") 5.08 cm (2") 2.54 cm (1") -
Page 16: Figure 10 : Model Amp 120 And Nomf 155 / 156
Figure 10 : Model AMP 120 and NOMF 155 / 156 Table 8 : Minimum clearances to combustible materials LOCATION APPLICATION UPFLOW DOWNFLOW HORIZONTAL FURNACE Ø 5.08 cm (2") 5.08 cm (2") SIDES SUPPLY PLENUM WITHIN 6 ft. OF FURNACE 2.54 cm (1") 5.08 cm (2") 2.54 cm (1") -
Page 17: Figure 11 : Wiring Diagram, Beckett Burner
Figure 11 : Wiring diagram, Beckett burner DNS-0989 Rev C... -
Page 18: Figure 12 : Wiring Diagram, Riello 40-F Or Bfr Burner
Figure 12 : Wiring diagram, Riello 40-F or BFR burner (without 24 VAC control) DNS-0991 Rev D... -
Page 19: Figure 13 : Wiring Diagram, Riello 40-F Or Bf Burner
Figure 13 : Wiring diagram, Riello 40-F or BF burner (with 24 VAC control) DNS-1089 Rev I DNS-1077 Rev I... -
Page 20: Figure 14 : Parts List Amp & Nomf 105/106, Beckett Afg
Figure 14 : Parts list AMP & NOMF 105/106, Beckett AFG and 40-F Riello burner (without 24 VAC control) B50058 Rev B... -
Page 21: Table 9 : Parts List Amp & Nomf 105/106, Beckett Afg And 40-F Riello Burner
Table 9 : Parts list AMP & NOMF 105/106, Beckett AFG and 40-F Riello burner (without 24 VAC control) ITEM PART # DESCRIPTION COMMENTS B01667 HEAT EXCHANGER B01728 REAR PANEL ASSEMBLY INCLUDES PANEL. INSULATION AND BAFFLE B01986 INSULATION, REAR PANEL B01898 REAR BAFFLE B01885-01... -
Page 22: Figure 15 : Parts List, Amp & Nomf 120/155/156, Beckett Afg And Riello 40-F Burner
Figure 15 : Parts list, AMP & NOMF 120/155/156, Beckett AFG and Riello 40-F burner (without 24 VAC control) B50062 Rev C... -
Page 23: Table 10 : Parts List Amp & Nomf 120/155/156, Beckett Afg And Riello 40-F Burner
Table 10 : Parts list AMP & NOMF 120/155/156, Beckett AFG and Riello 40-F burner (without 24-VAC control) ITEM PART # DESCRIPTION COMMENTS B01787 HEAT EXCHANGER B01877 REAR PANEL ASSEMBLY INCLUDES PANEL. INSULATION AND BAFFLE B01526-25 INSULATION B01988 REAR BAFFLE B01875-01 PANEL ASSEMBLY, RIGHT SIDE INCLUDES PANEL. -
Page 24: Figure 16 : Parts List Amp & Nomf 120/156, Riello 40-F
Figure 16 : Parts List AMP & NOMF 120/156, Riello 40-F burner (with 24 VAC control) B50085 Rev B... -
Page 25: Table 11 : Parts List Amp & Nomf 120/156, Riello 40-F
Table 11 : Parts list AMP & NOMF 120/156, Riello 40-F burner (with 24 VAC control) ITEM PART # DESCRIPTION COMMENTS B01787 HEAT EXCHANGER ASSEMBLY BAFFLE AND GASKETS NOT INCLUDED B01988 REAR BAFFLE B01877 REAR PANEL ASSEMBLY INCLUDES PANEL, INSULATION ANS BAFFLE B01987 REAR PANEL INSULATION B01874... -
Page 26: Figure 17 : Parts List Amp120, Riello 40-Bf Burner
Figure 17 : Parts list AMP120, Riello 40-BF burner B50078 Rev B... -
Page 27: Table 12 : Parts List Amp120, Riello 40-Bf Burner
Table 12 : Parts list AMP120, Riello 40-BF burner ITEM PART # DESCRIPTION COMMENTS B01787 HEAT EXCHANGER B01877 REAR PANEL ASSEMBLY INCLUDES PANEL. INSULATION AND BAFFLE B01526-25 INSULATION B01988 REAR BAFFLE B01875-01 PANEL ASSEMBLY, RIGHT SIDE INCLUDES PANEL. INSULATION AND BAFFLE B01800-01 INSULATION, SIDE PANEL B01805-01...
