2.3 - CCD PlatFoRm sPeCIFICatIoNs - ImaGING seNsoRs

MODEL
Total CCD matrix size (pixels)
Fibre optic taper magnification (std)
Effective CCD pixel size
Effective active area
Image pixel well depth
Register well depth
Read noise (e )
-
50 kHz
1 MHz
3 MHz
5 MHz
Maximum frame and spectral rates
Frame [2 x 2 binning]
Crop mode (frame, 10 rows)
FVB
Crop mode (spectrum, 10 rows)
Fast Kinetics
4 rows
2 rows
Sensitivity
Linearity
Minimum temperature air cooled
[dark current, e /pixel/sec]
-
Coolant chiller, coolant @ 10°C, 0.75 l/min
[dark current, e - /pixel/sec]
Note: All specifications are typical unless otherwise stated
New iStar ICCD
312T
512 x 512
Ø 18 mm II
1:1
24 x 24 μm
100% fill factor
12.3 x 12.3 mm
320,000 e
-
480,000 e
-
5.4 [7]
10 [14]
16 [20]
24 [50]
15.8 fps [28.5 fps]
633 fps
291 sps
5,556 sps
32,150 Hz
55,250 Hz
2 to 10 e /count
-
(software selectable)
Ø 18 mm II
-30°C [0.4]
-40°C [0.12]
Page 21
Introduction to the New iStar
334T
1024 x 1024
Ø 18 mm II
1:1
13 x 13 μm
100% fill factor
13.3 x 13.3 mm
100,000 e
-
150,000 e
-
5 [7]
8 [12]
14 [18]
20 [50]
4.2 fps [7.3 fps]
333 fps
145 sps
3,450 sps
29,850 Hz
-
1 to 5 e /count
-
(software selectable)
Better than 99%
Ø 18 mm II
-30°C [0.2]
-40°C [0.1]
Ø 25 mm II
1.5:1
19.5 x 19.5 μm
100% fill factor
Ø 25 mm II
-25°C [0.4]
-35°C [0.15]
