Sun Telecom AN1000 User Manual

Flex numeric pager
Hide thumbs Also See for AN1000:

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the AN1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Sun Telecom AN1000

Summary of Contents for Sun Telecom AN1000

  • Page 3: Automatic On/Off

    1. FEATURES 2. BUTTONS 3. ICONS AND DESCRIPTIONS 4. TURNING PAGER ON 5. TURNING PAGER OFF 6. RECEIVING AND READING MESSAGES 7. DUPLICATE MESSAGES 8. LOW BATTERY INDICATOR 9. LOCKING AND UNLOCKING MESSAGES 10. MEMORY 11. DELETING INDIVIDUAL MESSAGES 12. DELETING ALL MESSAGES 13.
  • Page 4 30 message slots Automatic On/Off 14 locked messages Time display when power off Date & time display 12 user selectable alerts Message full indication Message Time Stamp Vibe / Chirp / Silent(No alert) option Alarm Individual Message Delete Duplicate message indication Delete all Message Message retained during battery replacement...

  • Page 5: Read Button

    READ BUTTON Read messages. Select setting and features in Function. Turn pager on. FUNCTION BUTTON Enter Function mode. Turn the light on or off. Press the Read Button and Function button simultaneously to escape to the main screen.
  • Page 6 Reception Area : Message Lock : Beep Alert On : Duplicate Message : Melody Alert On : New Unread Message : Vibe Alert On : Low Battery : Alarm On : Message Continuation : Automatic On/Off...
  • Page 7 Press and hold the Read button for 2 seconds while pager is in the Off mode. Time and date will appear on the bottom center of the screen. When inserting the battery, the pager will vibrate and beep briefly as it powers on. If there are new unread messages, the icon will appear.
  • Page 8 Press the Function button to enter the Function mode. Press the Function button 2 times until "POWER OFF?" is displayed on the screen. Press READ to turn Pager Off . Press the Read and Function buttons simultaneously to escape to the main screen.
  • Page 9 When a message is received, the selected Alert will be activated. Press the Read button to stop the Alert and to read messages. The following information will be displayed: Message number, time stamp, message. Messages are displayed starting from newest to oldest. Messages with more than 12 characters will display at the top right corner of the screen.
  • Page 10 The duplicate Message Indicator will be displayed on the screen when the pager receives a message that is identical to a message in memory. When the battery voltage falls below operational level, the low battery icon will be appear. The low battery alert will sound periodically until new battery is inserted.
  • Page 11 A maximum of 14 messages can be locked. Select a message to be locked and press the Function button. When "LOCK?" is displayed, press the Read button to lock the message. The Lock icon will be displayed, and the message will be locked.
  • Page 12 The pager's memory capacity stores 30 numeric messages, with a maximum of 20 characters per message.
  • Page 13 To Delete Individual Messages: After reading message, press the Function button 2 times until "Delete?" is displayed on the screen. Press the Read button. Message will be deleted and the next message is displayed. To Delete a Locked Message: It is necessary to change a locked message to unlocked message before it can be deleted.
  • Page 14 To delete All Messages: Press the Function button to enter the Function mode. To display "DELETE ALL?", press the Function button 2 times until the "DELETE ALL?" function appears onscreen. Press the Read button to delete all messages. Locked and Unread Messages will not be deleted.
  • Page 15 Press Function button once until "SET ALERT?" is displayed on the screen. Press the Read button until the desired Alert appears onscreen. Press the Function button to select alert and complete the process. Press the Read and Function buttons simultaneously to return to the main screen.
  • Page 16 Press Function button 3 times until "SET ALARM?" is displayed on the screen. Press Read button on "SET ALARM?" indicator to select an Alarm setting mode. To choose and set desired condition, press Read button to toggle (Ex. YES NO). To move to each field (hour, minute, am/pm), press the Function button.
  • Page 17 Press Function button 4 times until "DATE-TIME?" is displayed on the screen. Press the Read button to change to time or date, then press the Function button to move to the next field. Press the Read Button and Function button simultaneously to move to the main screen.
  • Page 18 "AUTO ON_OFF?" Automatic On/Off is referred to on this pager as This feature allows you to specify a daily time period where the pager doesn't receive any messages. Press Function button 5 times until "AUTO ON_OFF?" is displayed on the screen. Press the Read button to change the on and off time settings.
  • Page 19 Press the Function button for 2 seconds to turn the backlight on. Press the Function button for 2 seconds again to turn the backlight off. The pager is designed to operate with a "AAA" size alkaline battery. Warning! Replace battery in Non-Hazardous location only. Use only Duracell Mn2400 &...
  • Page 23 This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
