Studer VarioString User Manual page 26

Studer Innotec SA
VarioString
Info. no. Name
15010 Ppv
15011* Ppv1
15012* Ppv2
15013* Mode
15014* Mod1
15015* Mod2
15016 Cd
15017 Ed
15018* Ed1
15019* Ed2
15020 kWhR
15021* kWh1
15022* kWh2
15023 MWhT
15024* MWh1
15025* MWh2
15026 Cd-1
15027 Ed-
15028* Ed1-
15029* Ed2-
15030* Sd
15031* Sd-1
15032 Tbat
15033* Upmx
15034* Upm1
15035* Upm2
15036* Ibmx
15037* Ppmx
15038* Ppm1
15039* Ppm2
15040* Ubmx
15041* Ubmn
15042 Tabs
15049* Err
15050 Sync
15051 Sync
15052* EqIn
15053* Bset
15108 VS state
*Some values can't be displayed in the multi-unit display. They will be visible while going in the sub-
screen of the Multi-unit display, showing every unit individually.
26
Unit Description
kW PV power
kW PV1 power
kW PV2 power
PV operating mode (Night, Security, OFF, Charge, ChargeV,
Text
Charge I, ChargeP, ChargeIpv, ChargeT, ---)
PV1 operating mode (Night, Security, OFF, Charge, ChargeV,
Text
Charge I, ChargeP, ChargeIpv, ChargeT, ---)
PV2 operating mode (Night, Security, OFF, Charge, ChargeV,
Text
Charge I, ChargeP, ChargeIpv, ChargeT, ---)
Ah Production PV in (Ah) for the current day
kWh Production PV in (kWh) for the current day
kWh Production PV1 in (kWh) for the current day
kWh Production PV2 in (kWh) for the current day
kWh Produced PV energy resettable counter
kWh Produced PV1 energy resettable counter
kWh Produced PV2 energy resettable counter
MWh Total PV produced energy
MWh Total PV1 produced energy
MWh Total PV2 produced energy
Ah Production PV in (Ah) for the previous day
kWh Production PV in (Wh) for the previous day
kWh Production PV1 in (Wh) for the previous day
kWh Production PV2 in (Wh) for the previous day
h Number of irradiation hours for the current day
h Number of irradiation hours for the previous day
°C Battery temperature
Vdc Max PV voltage for the current day
Vdc Max PV1 voltage for the current day
Vdc Max PV2 voltage for the current day
Adc Max battery current of the current day
kW Max PV power for the current day
kW Max PV1 power for the current day
kW Max PV2 power for the current day
Vdc Max battery voltage for the current day
Vdc Min battery voltage for the current day
h Time in absorption of the current day
Type of error (None, OverV_B, OverV_PV, OverV_PV1,
OverV_PV2, OverI_PV, OverI_PV1, OverI_PV2, GroundBat,
Text
GroundPV, GroundPV1, GroundPV2, OverTemp, UnderV_B,
Cabling, Other)
Text Synchronized with Xtender battery cycle (No, Yes)
Synchronisation state (---, ---, ---, ---, XTslave, VTslave, ---, ---,
Text
VTmaster, Autonom, VSslave, VSmaster)
days Number of days before next equalization
Vdc Battery set point
Text State of the VarioString (Off, On)
V 1.0 User manual
