- Page 1 ✇ ✇ PRO AUDIO AFFAIRS ✇ ✇ PRO AUDIO AFFAIRS Quick Reference Guide to Studer A807: Page: Mechanical Adjustment & Motor Control PCB’s critical capacitors location Jog potentiometer wiring diagram (behind button panel) Monitor volume potentiometer wiring diagram (front panel) www.reeltoreel.nl...
- Page 2 ✇ ✇ Mechanical adjustment PRO AUDIO AFFAIRS located behind the left tape cutter page 147 PLAY adjust to 70p, adjust X to 56-58mm WIND adjust X to 57mm REWIND adjust X to 67mm LIBR WIND adjust X to 65mm SHUTTLE adjust that the tape does not move Motor Control PCB’s critical capacitors location =FRAKO...
- Page 3 ✇ ✇ Jog potentiometer wiring diagram (behind button panel) PRO AUDIO AFFAIRS potentiometer brown orange wheel Panel PCB Monitor volume potentiometer wiring diagram (front panel) yellow grey black green orange brown Bottom view Bottom view www.reeltoreel.nl Philip van der Matten ver 1.0 9 mrt 2023 page 3/3...
