SPY-DVR4KIT1 / SPY-DVR4KIT2
Quick Setup Guide
The SPY-DVR4KIT1 / SPY-DVR4KIT2 are a complete home surveillance kit that has everything needed for a
simple plug-n-play operation. Below is the list of components that come in the kits:
SPY-DVR4KIT1
(1) 4 channel DVR with 500GB Hard Drive
(2) Plastic mini dome cameras
(2) Weather resistant mini bullet cameras
(1) 120v to 12v AC/DC power supply
(1) 5 way splitter for power supply
(4) 18 meter video/power cables for the cameras
(1) BNC to RCA cable for connection to a TV or monitor
(1) Mouse
SPY-DVR4KIT2
(1) 4 channel DVR with 500GB Hard Drive
(4) Weather resistant mini bullet cameras
(1) 120v to 12v AC/DC power supply
(1) 5 way splitter for power supply
(4) 18 meter video/power cables for the cameras
(1) BNC to RCA cable for connection to a TV or monitor
(1) Mouse

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPY-DVR4KIT1 and is the answer not in the manual?

Questions and answers

Related Manuals for Spyclops SPY-DVR4KIT1

Summary of Contents for Spyclops SPY-DVR4KIT1

  • Page 1 SPY-DVR4KIT1 / SPY-DVR4KIT2 Quick Setup Guide The SPY-DVR4KIT1 / SPY-DVR4KIT2 are a complete home surveillance kit that has everything needed for a simple plug-n-play operation. Below is the list of components that come in the kits: SPY-DVR4KIT1 (1) 4 channel DVR with 500GB Hard Drive...
  • Page 2 Making the Connections Once you have unpacked the equipment and found a suitable location for the DVR, begin making the connections as follows: MONITOR 1. 4 channel DVR with 500GB Hard Drive 6. 120v to 12v AC/DC power supply 2. Weather resistant mini bullet cameras 7.
  • Page 3 SPYCLOPS BASIC DVR SETUP All steps are given in order as if from home screen. If after completing a step and returning to the home screen you see a message that says “Configuration changed! To save the latest configuration?” Click “Yes”...
  • Page 4 If you want the Username to be different than “admin” you will need to add user. To add new “User” Setup System Tools-- User management   Add User.  Type in User Name.  Select User Access Level.  OK. ...
  • Page 5 Step 4: Basic Network Setup To generate the Esee ID the DVR must be connected to the network through an Ethernet cable. Setup System setup – Network setup.   Check the DHCP box to dynamically assign an IP through the router and click the Esee box to populate the Esee ID.
  • Page 6  Select the recording block in which you want to view and click playback. For more detail instructions such as setting up the Spyclops DVR, Network settings, Recording settings, and info about the free Smartphone app, please visit our website: www.spyclopsusa.com...
