The functions described below must be done locally at the NVR.
SPY-NVR4720W & SPY-NVR8720W
Before You Start:
• You must have a PC monitor or TV that supports 1024x768, 1280x1024, 1366x768,
1440x900 or 1080p resolution connected to the NVR via a HDMI cable or VGA
cable.
• The NVR MUST be hardwired to your network with an Ethernet cable coming
from your router/switch to the WAN input on the back of the NVR as it will NOT
connect wirelessly to a WIFI network.
• All cameras and NVR must have power connected to them using the included
power supplies.
Once the NVR and cameras are all powered on and connected please follow the
steps on the following pages for a fast and easy setup.
S U R V E I L L A N C E S Y S T E M S b y E T H E R E A L
Quick Setup Guide
460 Walker St., Holly Hill, FL 32117 MetraHomeTheater.com
© COPYRIGHT 2017 ME TR A ELEC TRONICS CORPOR ATION
Advertisement
Table of Contents
Related Manuals for Spyclops SPY-NVR4720W
Summary of Contents for Spyclops SPY-NVR4720W
- Page 1 S U R V E I L L A N C E S Y S T E M S b y E T H E R E A L The functions described below must be done locally at the NVR. SPY-NVR4720W & SPY-NVR8720W Quick Setup Guide Before You Start: • You must have a PC monitor or TV that supports 1024x768, 1280x1024, 1366x768,...
- Page 2 S U R V E I L L A N C E S Y S T E M S b y E T H E R E A L The functions described below must be done locally at the NVR. Step 1.
- Page 3 S U R V E I L L A N C E S Y S T E M S b y E T H E R E A L The functions described below must be done locally at the NVR. Step 2.
- Page 4 S U R V E I L L A N C E S Y S T E M S b y E T H E R E A L The functions described below must be done locally at the NVR. Step 3.
- Page 5 The functions described below must be done locally at the NVR. Step 4. Network Setup Let’s connect the NVR to the network for remote access 1. Right click 2. (Left Click) on System Setup 3. (Left Click) on Network Setup 4. (Left Click) on the DHCP & SPYCLOPS ID/P2P ID 5. Go to the bottom and (Left Click) Apply, then (Left Click) OK. 6. Right click 7. (Left Click) on Exit System 8. (Left Click) on Reboot (Rebooting the NVR will allow it to initiate a UPNP request for network access) Once NVR reboots, at the bottom right corner of your monitor should say (ON- LINE) within a few minutes.
- Page 6 S U R V E I L L A N C E S Y S T E M S b y E T H E R E A L Step 5. Connecting to Android or iOS devices Download SPYCLOPS app from your app store and open the app. 1. Select ‘Trial’ or register 2.Touch the ‘+’ located at with the app. *Note – The...
- Page 7 S U R V E I L L A N C E S Y S T E M S b y E T H E R E A L 7. Password: Enter in your 8.Select the number of Password (That was creat- channels your NVR has. (4 ed on the NVR). or 8 channels) 9.Click ‘Submit’ 10.Once you have followed the steps above, your mo- bile device is ready to re- motely view your cameras. Click anywhere within the preview grid. This will open your live streaming expe-...
