Table of Contents 1. Parts Identifications 1. Parts Identifications PRINTER COVER 2. Setting up the printer CONTROL PANEL Open this cover is load or replace paper Features LED indicators 2.1 Unpacking to indicate printer status and switches to operate 2.2 Connecting the cables the printer.
2. Setting Up the Printer 2-1. Unpacking Your printer box should be included these items. If any items are damaged or missing, please contact 2-2. Connecting the Cables your dealer for assistance. You can connect up the cables required for printing to the printer. They all connect to the connector panel on the back of the printer, which is shown below : The Printer User's Manual...
Page 5
2-2-2. Cash Drawer Connector 2-2-1. Interface Connector The printer can operate two cash drawers with a 6 pin RJ-11 modular connector. The driver is capable of supplying a maximum current of 1.0A/24VDC for 510ms or less when not printing. < RS-232 > SIGNAL DESCRIPTION Signal GND...
5. Be sure to note the correct direction that the paper comes off the roll. 2-3. Loading the Roll Paper Notes: Be sure to use paper rolls that meet the specifications. Do not use paper rolls that have the paper glued to the core because the printer cannot detect the paper end correctly. 2-3-1.
♣CAUTION: 2-4. Di p Switch Setting Turn off the printer while removing the DIP switch cover to prevent an electric short, which can damage the printer. The printer is set up at the factory to be appropriate for almost all users. On the other hand, offers some more settings for users with special requirements.
3. Control panel and other functions ♣CAUTION: 3-1. Control panel When the paper is jammed with cutter, the top cover might be stuck. In this case, repeat power on You can control the basic paper feeding operations of the printer with the button on the control panel. and off several times.
4. Self Test 5. Hexadecimal Dump The self-test lets you know if your printer is operating properly. It checks the control circuits, printer This feature allows experienced users to see exactly what data is coming to the printer. This can be mechanisms, print quality, ROM version and DIP switch settings.
6. Specifications (8) Overall dimension Important! When connecting or disconnecting the power supply from the printer, be sure that the following cautions are observed. Use a power supply (Limited Power Supply) of DC 24V±10% and more than 2.5A. Be careful about installing the printer in an area where there is noise. Take the appropriate measure to protect against electrostatic AC line noise, etc.
♣Important! 6-2. Auto Cutter Specifications (1) Cutting Frequency Max. 30 cuts per minute When connecting or disconnecting the power supply from the printer, be sure that the following cautions are observed. (2) Thickness of paper 0.065 ~ 0.1mm (1) Use a power supply (Limited Power Supply) of DC 24V±10% and more than 2.5A. (2) Be careful about installing the printer in an area where there is noise.
7. Command List Command Function REMARKS Command Function REMARKS Horizontal tab ESC t Select character code table Print and line feed ESC { Turn upside-down printing mode on/off Print and carriage return FS p Print NV bit image Print and return to standard mode(in page mode) FS q Define NV bit image Cancel print data in page mode...
