Electrical Connection; Appliance Features - Avantgarde TBWC-30SFD Instruction Manual

WARNING
Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, have
it replaced by an authorized service center.
This appliance should be properly grounded for your safety. The power cord of this appliance is equipped with a three-
prong plug which mates with standard three prong wall outlets to minimize the possibility of electrical shock.

4. APPLIANCE FEATURES

One T emperature Z one
the zone can hold up to 30 bottles wine
•
5 shelves that can hold 5 bottle
•
Plus 1 bottom that holds 5 (piled up)
•
Engaged Wine Shelves
Any of the shelves can be removed to accommodate larger bottles.
•
To remove a shelf from the TBWC-30SFD/LBWC-30SB2 unit
To remove a sliding shelf :
Remove all bottles
•
Pull out the shelf
•
Take out shelf by lifting the right side bracket and lowering the left side one, (at the same time)
•
then pull out
A
To Replace a Shelf:
Place the sides of the shelves back onto the supporting guides of the cabinet and push back until the shelf
•
tabs slide into place. Please make sure that the tabs are firmly engaged in place before storing any
bottles.
B
15
