ICE 35, ICE 45, ICE 55
Installation and Operations Manual
531611 1_F

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ICE 35 and is the answer not in the manual?

Questions and answers

Related Manuals for Humminbird ICE 35

Summary of Contents for Humminbird ICE 35

  • Page 1 ICE 35, ICE 45, ICE 55 Installation and Operations Manual 531611 1_F...
  • Page 2 Humminbird® is not responsible for incorrect translations or discrepancies between documents. Humminbird® and ICE Flasher Series™ are trademarked by or registered trademarks of Johnson Outdoors Marine Electronics, Inc. © 2014 Johnson Outdoors Marine Electronics, Inc. All rights reserved.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS How Sonar Works How Ice Flashers Work Installation Overview ICE Flasher Series™ Base Assembly 1. Assembling the Transducer Storage Posts .............. 6 2. Assembling the Base and Handle ................7 3. Assembling the Control Head to the Base and Handle.......... 8 ICE Flasher Series™...
  • Page 4 Please read the manual carefully in order to understand the full capabilities of your model. You can visit our Web site at humminbird.com to order accessories online or contact our Customer Resource Center at 1-800-633-1468.

  • Page 5: How Sonar Works

    HOW SONAR WORKS Sonar technology is based on sound waves. The ICE Flasher Series™ Fishfinder uses sonar to locate structure, bottom composition, as well as depth directly below the transducer. Your ICE Flasher Series™ Fishfinder consists of two components: the control head and the transducer.
  • Page 6 When all the echoes are viewed within the beam, an easy to interpret multicolor palette of sonar return signals appears on the Flasher Dial. The ICE Flasher Series™ Fishfinder plots the depth and intensity of sonar returns from the bottom, fish and structure. The sound pulses are transmitted at various frequencies depending on the application.
  • Page 7 Your ICE Flasher Series™ Fishfinder uses selectable dual-frequency sonar with a wide area of coverage. Selectable dual-frequency gives you the option of two beams, and both beams will cover the bottom and provide high definition. The 9 degree center beam provides the highest definition, while the 19 degree beam provides wider coverage.

  • Page 8: How Ice Flashers Work

    Although the sonar part of an ICE Flasher Series™ Fishfinder works in the same way as any other Humminbird® control head, the return signal is displayed differently. The ICE Flasher Series™ LCD is modeled on the original analog displays and represents what is happening below the transducer the moment it happens.

  • Page 9: Installation Overview

    INSTALLATION OVERVIEW Before you start installation, we encourage you to read these instructions carefully in order to get the full benefit from your ICE Flasher Series™ Fishfinder. You will assemble your control head first, then assemble and install your transducer. When you are done with both of these installation tasks, you should perform a final installation test before operating your ICE Flasher Series™...

  • Page 10: Ice Flasher Series™ Base Assembly

    ICE FLASHER SERIES™ BASE ASSEMBLY Perform the following high-level steps by following the instructions in each numbered section to assemble the ICE Flasher Series™ base assembly: 1. Assembling the transducer storage posts 2. Assembling the base and handle 3. Assembling the control head to the base and handle Assembling the Transducer Storage Posts In this procedure you will install the posts to hold the transducer cable.

  • Page 11: Assembling The Base And Handle

    Assembling the Base and Handle In this procedure, you will install the handle onto the base, and attach the tie-down straps that will be used to secure the battery to the base in a later procedure. 1. Install the handle onto the base, so that the curved part of the handle faces towards the back of the base, towards the battery well.

  • Page 12: Assembling The Control Head To The Base And Handle

    Assembling the Control Head to the Base and Handle In this procedure you will install the ICE Flasher Series™ control head to the base/handle assembly. 1. Place the control head into the gimbal bracket located on the base. 2. Place the 1" diameter black washers as shown in the figure; then, thread the gimbal knob through the bracket and washers, into the housing.

  • Page 13: Ice Flasher Series™ Assembly

    ICE FLASHER SERIES™ ASSEMBLY In this procedure you will connect the power cable to the control head and install the base/handle assembly into the portable bag. Connecting the Power Cable 1. Insert the power cable into the back of the control head.
  • Page 14 Spade Battery Terminals Foam Pad NOTE: Do NOT connect the power cable to the battery at this time. You should wait until just before fishing to connect the power cable to the battery. 3. Move the tie-down straps out of the way so that the battery well is fully accessible. 4.

  • Page 15: Assembling The Portable Bag (Ice 45/55 Only)

    Assembling the Portable Bag (ICE 55 Only) In this procedure, you will install the ICE 55 Flasher into the portable bag. The portable bag is not included with ICE 35/45 Flashers. 1. Unzip the largest opening on the front of the portable bag.

  • Page 16: Transducer Installation

    TRANSDUCER INSTALLATION Perform the following high-level steps by following the instructions in each numbered section to install the transducer. 1. Testing the transducer 2. Assembling the transducer and float 3. Connecting the cable Testing the Transducer Prior to Installation Prior to installation, test the transducer to make sure that no damage occurred during shipping.
  • Page 17 3. Position the float so that the transducer will be submerged in the water, just below the ice. Ice Layer Float Transducer NOTE: The transducer must be submerged in water for reliable transducer detection. The bottom of the transducer should be even with the bottom of the ice or hang slightly below the bottom of the ice.

  • Page 18: Connecting The Transducer Cable

    Connecting the Transducer Cable This section covers how to connect your transducer cable to your control head. NOTE: If you have an ICE 55 Flasher, remove the control head and base from the portable bag first. 1. Insert the transducer cable into the appropriate terminal slot on the rear of the control head.

  • Page 19: Storing The Transducer

    Storing the Transducer When you are done fishing, store the transducer using the following guidelines: 1. Wipe the cable dry. 2. Tuck the float under the control head, and wrap the cable around the storage posts. Store the transducer in the transducer well. NOTE: You do not have to detach the transducer cable from the control head to store the transducer.

  • Page 20: Test And Finish The Installation

    3. If all connections are correct and power is available, the Humminbird® control head will enter Normal operation, and you should see the bottom on the control head display.

  • Page 21: Getting Started - Using Your Ice Flasher Series™ Fishfinder

    Flasher Dial and Active Display. Refer to the following illustration, and see Key Functions for more information. Flasher Dial Zoom Key Range Scale (ICE 35) Gain/Backlight Key (ICE 45/55) Active Display (ICE 45/55) Noise/Units Key (ICE 45/55)

  • Page 22: Powering Up The Control Head

    POWERING UP THE CONTROL HEAD Power-on your ICE 35/45/55 Flasher by turning the Range/Off dial to any range setting. The ICE Flasher Series™ Fishfinder will immediately enter Normal operation, and the sonar return signals from the bottom will be displayed on the Flasher Dial.
  • Page 23 Zero: Indicates the start of the dial and represents the surface of the water, or the top of the water column. Reading Direction: Read the dial in a clockwise direction. The top of the Flasher Dial represents the top of the water column, and as you read further around the dial, you are reading deeper into the water column.

  • Page 24: What's On The Display

    WHAT’S ON THE ACTIVE DISPLAY (ICE 45/55 ONLY) Your ICE Flasher Series™ control head sends a sound wave signal and determines distance by measuring the time between the transmission of the sound wave and when the sound wave is reflected off of an object. As your Ice Fishing transducer receives sonar signals, it converts them to a digital depth that is shown on the ICE Flasher Series™...

  • Page 25: Power/Range Dial

    Auto Range: Selecting A (Auto) will tell the unit to automatically choose the best range based on the actual depth of the bottom. A (Auto) setting is not available on the ICE 35. Auto Ranges available (ICE 45 and 55 only)

  • Page 26: Selection Dial

    Range scales for the ICE 35 are shown below: Outer Ring: x1 and x10. When set to x10, add 0 behind numbers shown Middle ring: x2 Scale on ring Inner ring: x4 Ring SELECTION DIAL The Selection dial allows you to set levels for the many functions on your ICE Flasher Series™...

  • Page 27: Zoom

    ZOOM When you use the zoom feature, your ICE Flasher Series™ Fishfinder will display a 2x magnified view of the area you choose. The zoomed view will display on the right side of the Flasher Dial between two blue lines. The normal view will display on the left side of the Flasher Dial.

  • Page 28: Gain

    NOTE: If your control head beeps repeatedly as you turn the Selection dial, you have reached the lowest or highest level possible for the Gain. Gain Setting Gain Setting ICE 35 ICE 45/55 The Gain setting is displayed as The Gain setting is shown on the a narrow or wide blue line at the Active Display.

  • Page 29: Noise Rejection

    NOTE: If your control head beeps repeatedly as you turn the Selection dial, you have reached the lowest or highest level possible for the Noise Rejection. Noise Rejection Setting Noise Rejection Setting ICE 35 ICE 45/55 The Noise Rejection setting is The Noise Rejection setting is displayed as a narrow or wide blue shown on the Active Display.

  • Page 30: Beam

    Noise Rejection for more information). 1. Press the Beam key to toggle between 240 kHz and 455 kHz. Wide Beam (240 kHz) Wide Beam (240 kHz) ICE 35 ICE 45/55 The active frequency is displayed The active frequency is shown as...

  • Page 31: Color (Ice 55 Only)

    COLOR (ICE 55 Only) ICE 35 Flasher and ICE 45 Flasher use Color Palette 1 to display sonar returns on the Flasher Dial. The Color Key, available in the ICE 55 Flasher only, allows you to choose between three color palettes so that you can view sonar return signals in higher detail.

  • Page 32: Palette 2 (Ice 55 Only)

    Palette 2 (ICE 55 Only) If you have a high-end ICE 55 Flasher, you will also have the choice of Palette 2 to display your sonar data. Strong Signal Dense, large objects such as fish, thick vegetation, or hard bottom, are usually displayed as thick or thin red lines on the Flasher Dial.

  • Page 33: Palette 3 (Ice 55 Only)

    Palette 3 (ICE 55 Only) If you have a high-end ICE 55 Flasher, you will also have the choice of Color Palette 3, which is a 6-color palette. Strong Signal Dense, large objects such as fish, thick vegetation, or hard bottom, are usually displayed as thick or thin red lines on the Flasher Dial.

  • Page 34: Target (Ice 55 Only)

    TARGET (ICE 55 Only) When you activate the Target key, the ICE 55 Flasher displays the depth reading of a particular point of the Flasher Dial that you choose. (Default = Off) 1. Press the Target key. A purple line will display in the Flasher Dial. Target Symbol on the Active Display Showing Active Target Mode...

  • Page 35: Dual Mode Key Functions

    Battery Gauge Percentage of Empty Battery Power Green Line Indicating Percentage of Battery Power ICE 35 ICE 45/55 The percentage of battery power is The percentage of battery power is indicated on the battery gauge, shown on the Active Display. When...

  • Page 36: Maintenance

    MAINTENANCE To keep both your ICE Flasher Series™ control head and your transducer working properly, perform the following maintenance tasks as needed. ICE FLASHER SERIES™ MAINTENANCE If your ICE Flasher Series™ unit comes into contact with salt spray, simply wipe the affected surfaces with a cloth dampened in fresh water.

  • Page 37: Troubleshooting

    TROUBLESHOOTING Before contacting the Humminbird® Customer Resource Center, please read the following section. Taking the time to review these troubleshooting guidelines may allow you to solve a performance problem yourself, and therefore avoid sending your unit back for repair. NOTE: Do not attempt to repair the unit yourself, as there are no user serviceable parts inside, and special tools and techniques are required for reassembly in order to maintain the waterproof integrity of the housing.

  • Page 38: 2-Year Limited Warranty

    2-YEAR LIMITED WARRANTY We warrant the original retail purchaser that products made by Humminbird® have been manufactured free from defects in materials and workmanship. This warranty is effective for two years from the date of original retail purchase. Humminbird® products found to be defective and covered by this warranty will be repaired or replaced free of charge at Humminbird’s option and returned to the customer freight prepaid.

  • Page 39: Humminbird® Service Policy

    We reserve the right to deem any product unserviceable when replacement parts are no longer available or impossible to obtain. This Service Policy is valid in the United States only. This applies only to Humminbird® products returned to our factory in Eufaula, Alabama. This Service Policy is subject to change without notice.

  • Page 40: Returning Your Unit For Service

    Before sending your unit in for repair, please contact the factory, either by phone or by email, to obtain a Repair Authorization Number for your unit. NOTE: Please do not return your Humminbird® product to the store for service. Please have your product model name and serial number available before calling the factory.

  • Page 41: Specifications

    Power Output (RMS)..................ICE 35: 100 W ICE 45: 225 W ICE 55: 300 W Power Output (Peak to Peak) ................ ICE 35: 800 W ICE 45: 1800 W ICE 55: 2400 W Display................ ICE 45/55: Liquid Crystal Diode (LCD) Unit Housing ..................
  • Page 42 WEEE DIRECTIVE: EU Directive 2002/96/EC “Waste of Electrical and Electronic Equipment Directive (WEEE)” impacts most distributors, sellers, and manufacturers of consumer electronics in the European Union. The WEEE Directive requires the producer of consumer electronics to take responsibility for the management of waste from their products to achieve environmentally responsible disposal during the product life cycle.
  • Page 43 NOTES...

  • Page 44: Contact Humminbird

    Contact Humminbird® Contact the Humminbird® Customer Resource Center in any of the following ways: By Telephone (Monday - Friday 8:00 a.m. to 4:30 p.m. Central Standard Time): 1-800-633-1468 By e-mail (typically we respond to your e-mail within three business days): service@humminbird.com...
