- Page 2 The only tool needed to complete the installation of the Platinum ID Portable is a phillips head screwdriver. Your new Platinum ID Portable case incorporates the Humminbird All-in-One Mounting and Connector system, where all cable connections are a part of the mounting bracket.
- Page 3 Locate the connector hardware kit (the smaller of the two hardware bags). The illustration on the hardware bag shows the proper orientation of the various cables into the connector. The power cable (identified by a “1” on the plug) is prewired to the battery compartments of the portable case.
- Page 4 The Platinum ID Portable battery compartments have been designed to accept commercially available batteries with an overall height within industry tolerance. However, some batteries may be slightly shorter, preventing the spring terminals from contacting the brass terminal strips in the lower case.
- Page 5 Assembling the Portable Transducer Position the bracket and tooth washers between the mounting “ears” of the transducer. Then, insert the thumbscrew through the entire assembly and attach the flat washer and wing nut on the thumbscrew. This design allows you to adjust the transducer angle without tools. Attach the bracket to the suction cup with the Phillips head screw, being careful not to over tighten the screw.
- Page 6 Humminbird is not responsible for any damage due to the suction cup coming loose.
