Summary of Contents for ProVisual DH Series

  • Page 1: User Manual

    Standalone Digital Video Recorder ProVisual DVR Series DH Series 4 / 8 / 16 Channels Models User Manual This document contains preliminary information and is subject to change without notice.
  • Page 2 FCC Compliance Statement Notice to Users This equipment has been tested and found to comply with the limits for a Class A digital device. Pursuant to Part 15 of the FCC Rules, these limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 3: Important Safeguards

    Cautions  This product has free voltages (100V and 240V). See installation instructions before connecting to the power supply.  This product uses a Lithium battery.  To avoid any risk of explosion, do not replace the battery on the main board by anything other than a Lithium battery. ...
  • Page 4 12. Servicing  Do not attempt to service this equipment yourself. Refer all servicing to qualified service personnel. 13. Damage Requiring Service  Unplug this equipment from the wall outlet and refer servicing to qualified service personnel under the following conditions: ①...
  • Page 5 The List of Configuration ProVisual DVR DH Series DVR Set 4 / 8 / 16CH CD (ProVisual CMS Pro Software/Manual) Remote Controller Screws HDD Brackets Data Cable Power Cable...
  • Page 6: Operation Precautions

    Operation Precautions  Power Off  Do not turn DVR off, or plug off the power adapter while DVR is in operation (record/playback). Otherwise, it may cause permanent damage to the equipment. Please click ( ) SETUP>SYSTEM>Shutdown sequentially and then remove the power after DVR is shutdown completely.
  • Page 7: Table Of Contents

    Table of Contents DEVICES ................27 PRODUCT FEATURES ............10 4.4.1 Network ..............27 Unpacking ................. 10 4.4.2 Camera / PTZ............. 30 4.4.3 Audio ................31 Service ................10 4.4.4 Alarm In..............31 4.4.5 Alarm Out ..............32 System Connection Diagram ..........10 4.4.6 Serial In ..............
  • Page 8 Program Installation Method ..........52 10.3 Watermark Check System ..........73 Login ................. 53 10.4 Estimator ................ 73 10.5 EXE to AVI Converter ............. 73 FUNCTION AND INSTRUCTIONS ........54 11. CMS WEB CLIENT ..............76 WATCH MODE ..............55 11.1 Setup and Login .............
  • Page 9 12.5 Windows Mobile............104 12.5.1 System Requirements .......... 104 12.5.2 Installation ............104 12.5.3 Site Configuration ..........106 12.5.4 Connection ............107 12.5.5 Uninstall ............... 108 13. SERIAL IN (POS/ATM) ............110 13.1 Usage of Serial-In Function.......... 110 13.2 Connection Method ............110 13.3 Connection Diagram ............
  • Page 10: Product Features

    1.2 Service  If there is any problem in the product, please refer servicing to a supplier or a distributor with qualified service personnel. 1.3 System Connection Diagram ProVisual DVR DH Series - 4 / 8 / 16 Channel Series...
  • Page 11: Installation

    2. Installation 2.1 Hard disk and DVD-RW Installation 2.1.1 SATA Port  Main substrate of this DVR has one SATA port: it is indicated as SATA 1.  Only one SATA device (hard disk) is possible to connect in Serial to the SATA port. Storage SATA 1, 2 Port 4 / 8 / 16 CH DVR...
  • Page 12: Tcp/Ip(Ethernet) Connections

    2.2.4 TCP/IP(Ethernet) Connections  Connect to ‘ETHERNET’ connector with the LAN cable.  When connect to Internet, use an ordinary LAN cable (Non-cross cable). However, when connect directly to a PC, please use only ‘Crossover cable’. 2.2.5 Alarm Connections  Connect Alarm Input (Sensor) to ‘AI 1~AI 2’ connectors and connect Sensor Common to ‘G’ connector. ...
  • Page 13: Input Device And Screen Icons

    3. Input Device and Screen Icons 3.1 Front Panel ProVisual DVR DH Series 4 / 8 / Channel DVR KEYS PTZ KEY Operating mode Setup mode • Up/Down/Left/Right ▲, ▼, ◄, ► • Control Pan/Tilt rotation of up/down/left/right in PTZ mode...
  • Page 14: Screen Icon

    3.4 Screen Icon Icon Description Icon Description Continuous recording mode In Audio recording Event recording mode CMS access indication/ No. of accesses (Alarm In/Motion) (up to 4) In recording In channel sequencing PTZ registration / PTZ mode Lock Remote Controller Setup in HDD Overwrite mode Setup in HDD No Overwrite mode Setup in HDD No Overwrite mode...
  • Page 15: Setup

    4. Setup 4.1 Login / Logout  At the default setting of DVR, user have to input the password to enter the set up menu.  Please press SETUP key to enter the setup menu and the following screen will appear. ...
  • Page 16: System

    4.2 SYSTEM 4.2.1 Information  Please click ( ) SYSTEM>Information and the following screen will appear. Status Site Description  Decide name of DVR.  Please click ( ) keyboard icon on Site Description frame and the following virtual keyboard will appear. ...
  • Page 17  Import: Copy the Menu setup stored in USB memory stick into DVR. Please plug in the memory stick and then click ( ) Import.  Export: Store the Menu setup of DVR in USB memory stick. Please plug in the memory stick and then click ( ) Export. ...
  • Page 18 Overwrite Setting  Click( ) Overwrite Setting button and the following screen will appear.  User shall designate the total recording days from 1 day to 30 days and unlimited.  User may set for beeping or notifying messages that notify the used percentage of disk. ...
  • Page 19: Admin

    4.2.2 Admin  Please click ( ) SYSTEM>Admin and the following screen will appear. Date / Time Date  This menu will allow user to adjust the settings.  Please follow the procedure below for time adjustment. ① Click ( ) items (Y, M, D) to change. A designated item will be highlighted in a box (Y: Year, M: Month and D: Date). ②...
  • Page 20 Time Format  Set time indication format. Please click ( ) Time Format frame to select a format from the list.  When user complete Date/Time input, please click ( ) NTP and the following screen will appear.  This menu is for accurate setting of time of day clock in DVR. ...
  • Page 21: Account

     Four rows will show as follows: - 1: SATA 1 Port Format  User must format when: - install new HDD - add another HDD - replace HDD - move HDD (change installation port) - remove HDD  Click ( ) Add/Remove frame in Format column and choose ‘OK’ on the dialogue box to start formatting. ...
  • Page 22: New Group

    New Group  Please click ( ) New Group and the following screen will appear.  Click ( ) keyboard icon on the right-hand side of Group Name frame. Then, the virtual keyboard will show. Please click ( ) desired characters (up to 8 characteristics) on the virtual keyboard. ...
  • Page 23  Choose ‘OK’ to confirm the setting. Then, lists of Group and User will show as follows.  Click ( )  to delete the set Group or User.  User may create up to 8 Groups and 8 Users. ...
  • Page 24: System Log

    4.2.4 System Log  Please click ( ) SYSTEM>System Log and the following screen will appear.  System Log displays diverse events as below events by specifying the user account who actually has accessed the DVR. - Setup (Menu) Enter/Exit - Playback Mode Enter/Exit - Network Access Enter/Exit - Archive Success/Fail...
  • Page 25: Display

    4.3 DISPLAY  Please click ( ) DISPLAY and the following screen will appear. 4.3.1  Please click ( ) DISPLAY>OSD and the following screen will appear.  The OSD menu will allow user to configure full features (i.e., on/off every letter and icon) displayed on the screen. ...
  • Page 26: Spot Monitor

     The Main Monitor menu will allow user to adjust channel sequencing interval of Main monitor. Full Seq  Adjust interval for ‘Full screen sequencing’.  Check  check box next to the camera that wish to include in sequencing. Any camera with unchecked check box will be excluded from channel sequencing.
  • Page 27: Spot Monitor Control On Display Mode

     Check (check box next to the camera that wish to include in sequencing. Any camera with unchecked check box will be excluded from channel sequencing.  Adjust the rotation interval of camera by clicking Dwell column. The rotation interval changes to 3>5>10>15>30>60 seconds by each press.
  • Page 28  In DHCP, IP Address, Subnet Mask, Gateway and DNS Server will have input automatically. DNS Server  When user set Network Type to DHCP, DNS server will be inputted automatically.  When user set Network Type to Static, please click ( ) the keyboard icon on the right-hand side of DNS Server frame and manually input the address.
  • Page 29 Port  Please click ( ) Port and the following screen will appear.  Network Throat is for setting an average transfer speed.  Please choose the suitable speed according to the users’ network environment.  If users want to use dual streaming, please click on the check box beside the “Enable Dual Streamming”. If not, please uncheck the check box.
  • Page 30: Camera / Ptz

     The Notification menu allows to send users the message of the Event occurred in DVR via E-Mail.  Click ( ) the keyboard icon on the right-hand side of Add E-Mail frame and the virtual keyboard will appear. Please register E-Mail address.
  • Page 31: Audio

     If a check box is checked  on Covert column, a video is recorded but is not displayed on the monitor.  Click ( ) each frame on PTZ column to select PTZ protocols connected to a corresponding camera. ...
  • Page 32: Alarm Out

     The Alarm In menu will allow user to give title and to select the type of Alarm input.  Click ( ) the keyboard icon on the right-hand side of each frame on Title column and the virtual keyboard will appear. Then, please register the title of Alarm input.
  • Page 33: Setting

     Please click ( ) RECORD and the following screen will appear. 4.5.1 Setting  Please click ( ) RECORD>Settings and the following screen will appear.  There are three kinds of recording mode. - Continuous: record continuously. - Event: record only when Sensor or Motion calls. - Emergency: record when press EMERGENCY key.
  • Page 34  The Event menu will allow user to set Event videos.  Each frame on Title column shows camera title registered in DEVICES>Camera/PTZ. User cannot change camera titles here.  Click ( ) each frame on Resolution column to select recording resolution of a corresponding camera. User may select one of 720x480, 720x240 and 360x240.
  • Page 35: Schedule

    16 Channel DVR 480(400) 240(200) 120(100)  Click ( ) each frame on Quality column to select recording quality of a corresponding camera. User may select one of Super, High and Std.  Click ( ) each frame on Duration column to select recording duration (i.e., 1 second ~3 hours) of a corresponding camera. ...
  • Page 36: Pre Alarm

    4.5.3 Pre Alarm  Please ( ) RECORD>Pre Alarm and the following will appear.  Pre Alarm is effectively used when user selected recording mode by Alarm or Motion.  The Pre Alarm will allow user to check, during playback, the previously recorded video before the record start time. ...
  • Page 37: Holiday

    - Copy to All Cameras: The present channel setup applies to all other cameras. Only when click save button, the changed setup can be saved. - Save: save the new settings and go back to previous menu (page). - Exit: ignore the new settings and go back to previous menu (page). - Cancel: cancel Motion Setup menu.
  • Page 38: Motion Event

     Please follow the setup procedures below. ① Click ( ) Alarm In frame and select Alarm In 1. ② Select cameras for recording when Alarm In 1 is on. Please check  a check box under Link Camera. More than two cameras can be set.
  • Page 39: System Event

     Select cameras for recording while the motion sensor is in operation and alarm outputs and set up E-mail addresses for notification.  Link Notification displays E-mail addresses registered in DEVICES>Network>Notification.  Please follow the setup procedures below. ① Click ( ) Video Loss frame and select Video Loss 1. ②...
  • Page 40  When Motion or Alarm-In is detected, user can select a popup or beep sound for warning, or have a particular channel of interest to pop-up on Spot Screen.  Please follow the setup procedures below. ① Select camera ② Popup: Please Check  a check box under making the popup screen for main monitor. ③...
  • Page 41: Operation Instruction

    5. OPERATION INSTRUCTION 5.1 Viewing 5.1.1 First Image  Power on DVR and the following live video will appear, while viewing and recording at the same time.  The screen will display date/time and icons below. Icon Description Continuous recording mode Event recording mode (Alarm In/Motion) In recording PTZ registration/PTZ mode...
  • Page 42: Digital Zoom

    - Channel Sequencing: Please press SEQUENCE key to display images in sequencing view format periodically. This automatic sequence function is not limited to the full screen format, but can be used in any view mode. In 8 channel DVR, 4-camera sequencing view mode is possible and in 16 channel DVR, 4 or 9-camera sequencing view modes are possible. 5.1.3 Digital Zoom ...
  • Page 43: System Log

     To use a mouse in Pan/Tilt mode, please move the cursor to the lower portion near the center of the screen. To use front button in Pan/Tilt mode, please push setup button. A key pad control will show as follows: ...
  • Page 44: Search

    5.2 Search  This involves searching recorded video to playback the wanted video of a specific date and time.  Press SEARCH key on the viewing screen, or Click Search menu at “Function Keys” and the following Search menu will appear.
  • Page 45: Event Search

     Follow the procedure below to search video by calendar. ① Select Year and Month by using the arrow buttons in the calendar. : search subsequent ‘Year’ : search previous ‘Year’ : search subsequent ‘Month’ : search previous ‘Month’ ② Click ( ) a date. The date will be displayed in black color. ③...
  • Page 46: Playback

    5.3 Playback  This involves searching recorded video to playback the wanted video of a specific date and time in search mode.  Press SETUP key or please press the mouse right button and click in Playback mode. Then, the following screen will appear. ...
  • Page 47: One-Touch Playback

    FORWARD • Frame-by-frame forward still image playback • Fast forward playback (changes to x2, x4, x8, x16, x32, x64 and Extreme with each press) Go to End • Go to end of recorded data  Press SEARCH key to stop playing back video. 5.4 One-touch Playback ...
  • Page 48: Menu Bar

    (NOTE) WHEN THE TARGET FILE SIZE IS OVER 2GB, PRESS “ ” BUTTON ON THE RIGHT AGAIN AFTER THE FIRST “ARCHIVE SUCCESS”. AND DVR WILL CONTINUE TO ARCHIVE TO ANOTHER FILE WITH THE EXTENSION OF “-002” AUTOMATICALLY ADDED. IN CASE OF DVD MEDIA, CHANGE IT AFTER THE FIRST FILE IS FINISHED AND PRESS “ ”...
  • Page 49: Color Control And Position

    : Enter Calendar Search : Date and Time Search : Enter Event Search : Showing current Date & Time 5.7 Color Control and Position  Please click ( ) Color /Alarm in SEARCH menu and the following input box will appear. (NOTE) THIS FUNCTION IS ENABLED ONLY WHEN LIVE MODE AND 1 CHANNEL MODE ...
  • Page 50  Please click ( ) Color / Alarm in SEARCH popup menu or in front panel and the following input box will appear.  Choose ‘Close’ to confirm the setting.
  • Page 51 Standalone Digital Video Recorder (Central Monitoring Station) User Manual This document contains preliminary information and is subject to change without notice.
  • Page 52: Program Installations

    6. PROGRAM INSTALLATIONS 6.1 System Recommendations  Power on DVR and the following live video will appear, while viewing and recording at the same time. - Processor: Intel Pentium(R) (at 2.8GHz or higher) - Memory: 1.00GB or more - Video: 128 MB AGP VGA card, 1024 x 768 Resolution, 32-bit Color, DirectX® 8.1 version or later - HDD Space: 500 MB of space - Monitor: SVGA or XGA, 1024 x 768 Resolution, 32-bit Color - OS: Windows®...
  • Page 53: Login

    ⑥ When the following screen appears, select folder and click Next. ⑦ When the following screen appears, click Install. ⑧ When the following screen appears, click Finish to complete the installation. 6.3 Login  After install CMS software, CMS icon below appears on desktop. ...
  • Page 54: Function And Instructions

    7. FUNCTION AND INSTRUCTIONS  Below lists are functions of the program. ICON ICON NAME WATCH MODE SEARCH MODE REMARKS System Log DVR System Log PTZ Control DVR PTZ Control System Health Check DVR System Health Check DVR Data Playback DVR Data Playback CMS(PC) Data Playback CMS(PC) Data Playback...
  • Page 55: Watch Mode

    8. WATCH MODE 8.1 LOGIN Screen  When user login CMS, the following screen will appear. This screen is of Watch mode.  Because it is not connected to DVR, images do not show.  Please do Local Setting first before connecting to DVR. 8.2 Local Setting ...
  • Page 56: Remote Site

     Save Option: allow user to select Drive(C, D) and folder to save data.  Choose ‘OK’ to confirm the setting. 8.2.2 Remote Site  This menu is for Network setup.  Make CMS IP address and Port coincide with DVR. ...
  • Page 57 - Click “Scan DVR” button then IP address of DVR will be listed which is currently connected with PC in the network. - Select the IP address and click “Add site” then the connected DVR is automatically registered in the CMS. ...
  • Page 58: Live Video

    8.3 Live Video 8.3.1 Network Connection  As the setup is completed, user should connect CMS to DVR over Network.  Please click in REMOTE DVR on the screen.  It will turn to blue, while being activated.  Please click REMOTE CONNECT button. ...
  • Page 59: Watch Mode

     The list below describes functions of each part of the screen. Tool Bar Watch Mode Date/Time LED Site Tree (DVR and Channels) Color Control Bar Instant Record Button System Log Alarm Out Channels Audio Channels Two way Audio Video Display Screen Network Connect/Disconnect Button/Exit CMS 8.3.2 Watch Mode...
  • Page 60: Multi Screen

    64-Split Screen Mode: Click on 64-SPLIT button and 64-split screens will display.  Zoom Mode: Click on Zoom button. Then, the setup screen will disappear and only the video image will be zoomed  in(scaled to fit the screen). To cancel, please press the right mouse button. E Map: load and close E Map image program.
  • Page 61: Audio

    8.3.5 Audio  Click an audio channel to listen to the corresponding channel.  User may adjust the audio volume with a mouse.  Click a MIC Icon to use to two way audio. 8.3.6 System Log  Click on LOG button on Watch screen. This will allow user to check System Log of Remote Site (DVR). 8.3.7 Alarm Out ...
  • Page 62 ① ② ③  Buttons on the screen have the following functions. ① Up/Down/Left/Right direction buttons ② Up/Down/Left/Right direction buttons Zoom Out/ In Focus Near / Far Iris Close / Open Preset Control / Go to Preset ③ Preset Control button The completed Preset ...
  • Page 63: Health Check

    8.5 Health Check  This function allows user to check operating status of each unit in DVR connected to CMS.  Click on Health Check button in Watch mode and the following screen will appear. ① ② ③ ④ ⑤ ⑥...
  • Page 64: Recording Status

    8.5.3 Recording Status  Camera is in normal operation.  Recording is stopped.  Above the maximum number of cameras allowed. 8.5.4 Motion Recording Status  Camera is in normal operation.  Recording is stopped.  Above the maximum number of cameras allowed. 8.5.5 Alarm In Connection and Operating Status ...
  • Page 65  The setup procedure is same as that of DVR.  When the setup is completed, do not click Exit button on the SETUP screen, but click OK or Cancel button on the Remote Setup screen.
  • Page 66: Search Mode

    9. SEARCH MODE 9.1 Search Screen  This menu is for playing back recorded data.  Click on REMOTE SEARCH button in Watch mode and the following Screen mode screen will appear.  Search mode provides three search functions. One is for searching DVR video by clicking REMOTE SEARCH button and another is for searching video stored in CMS (HDD of PC) by clicking LOCAL SEARCH button and the other is for searching event recorded data stored in DVR by clicking REMOTE EVENT button.
  • Page 67: Remote Search

    9.2 Remote Search  The REMOTE SEARCH button allows user to playback recorded video of DVR.  Select Date - In Calendar, dates with recorded data are marked in blue. - Click the wanted date among the dates marked in blue. In background of Time Select Bar, data recorded time is displayed in bar shape.
  • Page 68: Event Search

    9.4 Event Search  The REMOTE SEARCH button allows user to search event recorded data of DVR. ① Designate Event Search start time. ② Designate Event Search end time. ③ Select camera (video) to search data. ④ Check a check box (Motion/Alarm In/Emergency/Serial in) Check box. ⑤...
  • Page 69: Print

    9.5.2 Print  This is for printing a selected image (within the red outline).  Click IMAGE PRINT button and the following screen will appear.  Choose ‘OK’ to confirm the setting. Then, the printing proceeds. 9.5.3 Save  This is for saving still image(s) in Bitmap or JPEG file. ...
  • Page 70 ① Designate Archive start time. ② Designate Archive end time. ③ Designate file name. ④ Select camera (video) to save. ⑤ Click on Start button to begin Archive.
  • Page 71: Others

    10. Others 10.1 Viewer  The Format of archive file is .exe(executable file).  Please double click on the icon to execute the program. PLAY • Playback mode: 1X PLAY PAUSE • Playback mode: PAUSE • Frame-by-frame backward still image BACKWARD playback •...
  • Page 72  Please click on the icon to load the image file.  To move the icon just drag and drop.  You can also rotate the icon.  Please click on the icon and input the name of the E Map file to save and execute. ...
  • Page 73: Watermark Check System

    10.3 Watermark Check System  Mouse double click WCS.exe program in the CMS program folder (Default: C:\Program Files\CMS\WCS.exe).  To open the check .exe or .jpg or .bmp file just click Load File button.  To click the check button, user will get following message; - Result: - Verification OK ! - Corrupted or Modified...
  • Page 74  Click “File Open” and choose an Archived file(EXE format).  Click “EXE to AVI File” and select a directory to save the converted AVI file.  Select a channel to convert (Only one channel can be converted at once). ...
  • Page 75: Cms Web Client

    CMS Web Client CMS Web Client User`s Manual This document contains preliminary information and is subject to change without notice.
  • Page 76: Setup And Login

    11. CMS WEB CLIENT 11.1 Setup and Login  MS Explorer web browser is required for installation and using this program.  Open a browser and type the IP address of DVR.  It is required to install ActiveX in the first connection. ...
  • Page 77: Live Display

    11.2 Live Display  After Login, the following screen will appear. ④ ① ③ ② ⑤  The screen contains following features: ① Display current live video ② Setting display mode - Playback : Transferring search mode. - Freeze : Pause current display. - Resume : Resume paused display.
  • Page 78: Playback Screen

    11.3 Playback Screen  Click [Playback] then following screen will appear. ① ⑤ ③ ④ ⑥ ②  The screen contains following features: ① Searched playback video displays. ② Transferring Live mode. ③ Setting Date/Time to search. - Click a date in calendar, then recorded data will be showed up in Time bar. - Start Time : Setting start time.
  • Page 79: Cms Mobile Viewer

    CMS Mobile Viewer CMS Mobile Viewer User Manual This document contains preliminary information and is subject to change without notice.
  • Page 80: Iphone Mobile

    12. CMS MOBILE VIEWER 12.1 iPhone Mobile 12.1.1 System Requirements  There are no other requirements to run this program because it is specialized to perform on iPhone interface. 12.1.2 Installation  Turn on the iPhone then connect to App Store. ...
  • Page 81  Select “ ” program which is offered from dvrdomain by free.  When user clicks a “ ” button, it will be turned to “ ”  Click “ ” to start installation.  If user already has a iTunes account, then input user’s account to download the program. ...
  • Page 82: Site Registration

     When user registered the account, the program will be automatically installed. 12.1.3 Site Registration  Click “ ” icon on iPhone menu then below will show.  Move to “ ” and enter site information which are same as CMS site registration. ...
  • Page 83: Connection

     Enter ID/Password.  Click “ ” to save the setting. 12.1.4 Connection  On “ ” window, click one of the registered site and click “ ”.  Click “ ” to connect the DVR to the iPhone.  To select other channels, click the channel bar below the Site Name. ...
  • Page 84: Search

    12.1.5 Search  Users are able to search the recorded data in the mobile CMS program.  Click “ ” to use search function of the application.  click “ ” for date setting.  If users click “ ”, then the month with recorded data will show up.
  • Page 85  Choose the month that wish to search and click “ ”.  Click “ ” to select the date in the month and click “ ”  Click “ ” to select the time of the date of the recorded data. ...
  • Page 86: Ptz Control

    12.1.6 PTZ Control  Users are able to control PTZ with iPhone by touching the screen.  Touch and drag upside on the center of the screen to zoom out.  Touch and drag downside on the center of the screen to zoom in. ...
  • Page 87: Disconnection

    12.1.8 Disconnection  When disconnecting, please click “ ” and exit the mobile viewer program. 12.1.9 Uninstallation  Click the “ ” icon and hold for a while until the program icon shows x mark on the top-left side.  Click the “ ”...
  • Page 88: Android Phone

    12.2 Android Phone 12.2.1 System Requirements  This program is designed and applied only for Android OS(version 1.6 or higher) based Smart phones. 12.2.2 Installation  Turn on the phone then connect to Android Market.  Move to search menu and type “mviewer” then select “ ”...
  • Page 89: Site Registration

     Click “ ” then “ ” to start installation.  The program will be automatically installed in user’s application menu. 12.2.3 Site Registration  Click “ ” icon on application menu then below will show.  Move to “ ”...
  • Page 90: Connection

     Enter Admin/Stream port value.  Enter ID/Password.  Click “ ” to save the setting. 12.2.4 Connection  Click “ ” icon and select one of the registered site and click “ ”.  Move to “ ” tab and click “ ”...
  • Page 91: Audio

     Users are able to search the recorded data in the mobile CMS program.  Click “ ” to use search function of the application.  click “ ” to select the month, the date and the time in order. ...
  • Page 92: Information

     Touch sides and corners of the screen to change the direction as user want.  Touch right side of the screen to move right and left side to move left.  Touch up side of the screen to move up and down side to move down. ...
  • Page 93: Uninstallation

     When disconnecting, please click " ” and exit the mobile viewer program. 12.2.10 Uninstallation  Move to Setup > Application > Manage Applications then select “ ”.  Click “ ” icon then it will ask to delete the program. ...
  • Page 94: Site Registration

     Click “search” icon and type “DVR Viewer” program.  Select the “DVR viewer” which is offered from dvrdomain by free and start to install the program by clicking the icon. 12.3.3 Site Registration  After downloading the program, click “ ”...
  • Page 95: Connection

     Enter Site Name and IP/Domain.  Enter Admin and Stream port.  Enter ID and Password.  Click “Add” to save the setting. 12.3.4 Connection  If the site is registered appropriately, the following screen will be shown.  Click “Menu>Connect” to connect the site. ...
  • Page 96: Ptz Control

    12.3.5 PTZ Control  Users are able to control PTZ by blackberry phone.  Press volume up button on the right side of the phone to zoom in.  Press volume down button on the right side of the phone to zoom out. ...
  • Page 97: Symbian Mobile

    12.4 Symbian Mobile 12.4.1 System Requirements  This program is designed and applied only for Symbian OS based Smart phones. 12.4.2 Installation  Turn on the phone then connect to ovi store.  Move to “Search all items” and Type “dvr viewer” then click “Search” ...
  • Page 98  When user clicks a DVR Viewer icon, it will be changed to login page.  If user does not have the account, then click “create a Nokia account” and it is registered by free.  Type e-mail address and password and select country and type the identified text shown at the below, then you can click “OK”...
  • Page 99: Site Registration

     When users registered the account, then click “download”  When downloading has been completed, Click “Launch” to complete the installation. 12.4.3 Site Registration  Click “DVR Viewer” icon on Symbian menu then below will show.
  • Page 100: Connection

     Click options and select “New”.  Enter the information which is similar as CMS site registration.  Enter site Name, IP.  Enter Admin/Stream port value.  Enter ID/Password  Click “Submit” to save the setting. 12.4.4 Connection  Click one of the registered site and then select “options” to click “Connect” to choose connection.
  • Page 101  Choose available connection and it will start connecting the DVR to the Symbian.  Choose required channel to display.  Selected channel will be displayed.
  • Page 102: Ptz Control

    12.4.5 PTZ Control  Users are able to control PTZ with Symbian by touching the screen.  Touch sides and corners of the screen to change the direction as user want.  Touch right side of the screen to move right and left side to move left. ...
  • Page 103: Information

    12.4.6 Information  Click “Options” and select “About” to check the information of the application. 12.4.7 Disconnection  When disconnecting, please click “Disconnect” and exit the mobile viewer program. 12.4.8 Uninstallation  Click “option” and select “Remove” to uninstall the program. ...
  • Page 104: Windows Mobile

    12.5 Windows Mobile 12.5.1 System Requirements  OS : Windows Mobile Professional 6.1 or higher version.  Memory : 512Kb or Higher.  Device : Smartphone  Network : Available all wireless networking method. I.e. Wi-fi, HSDPA, Wibro. 12.5.2 Installation ...
  • Page 105  Click accepting the license agreement, then click “Finish” button.  Installation box will appear.  Click [OK] to start installation.  When installation completed, following pop-up will appear.  Click [OK].  If following message appeared, it has successfully installed. (NOTE) Depending on mobile device, successful installation message may not appear.
  • Page 106: Site Configuration

    12.5.3 Site Configuration  Click [Add] to appear following screen.  Fill in correct information. - Site Name : Insert the name of site. - IP/Domain : Insert the IP address or Domain name of the site. - ID : Input the registered ID of the site. - Password : Input the password of the registered ID.
  • Page 107: Connection

     Correct items then click [Save]. Delete  Select a site and click [Del].  Confirmation message will pop up.  Click [Yes] then the site information will be removed. 12.5.4 Connection  Select a site then click [Connect].  Live display screen of the site will appear if it is successfully connected.
  • Page 108: Uninstall

     Users are able to select a camera by clicking camera button.  Click [Disconnect] then, live display screen will be closed and Site list box will appear. 12.5.5 Uninstall  Move to [Program Menu> System] then click [Remove Programs]. ...
  • Page 109 Serial In (POS / ATM) Serial In (POS / ATM) User Manual...
  • Page 110: Serial In (Pos/Atm)

    This document contains preliminary information and is subject to change without notice. 13. SERIAL IN (POS/ATM) 13.1 Usage of Serial-In Function  Enables to record/search/display all transactions on monitoring screen by connecting POS/ATM/Cash Register.  User can choose the data whether to record/display on their taste without limitedly designated protocols. 13.2 Connection Method ...
  • Page 111: Link

    13.4 Link 13.4.1 Link Setup  Click “Setup>Link>” then shows as below. (NOTE) The above menu is only available on the DVR model with Serial-In function.  Click “Serial In” to appear following screen.  Select POS/ATM port by clicking ‘Serial In’ button. ...
  • Page 112: Setup

     Tick the box(□) item Alarm In.  Click the Time/Date that wishes to activate ATM/POS function on schedule.  It is possible to activate all the time by clicking top-right side of table.  Click “OK” to save the schedules. (NOTE) Please do not select the Alarm In and Motion simultaneously on schedule setup.
  • Page 113: Osd Display

    13.5.3 OSD Display  OSD items are to decide whether to display the information from the serial port connected to the rs232 port on OSD screen.  They have 4 menus as followings: - None : displays nothing on the OSD screen. - Live : displays incoming information from the serial port in real time on the OSD screen.
  • Page 114  Input a certain repeated string to “Line Delimiter”.  Decide the number of minimum characters in “MCPL” item to hide data under the designated number of characters.  Input the pattern of dummy data to Discard Pattern.  Choose the data which willing to display and enter the Start Pattern and End Pattern.
  • Page 115: Search

     Then tick the Auto box off in order to make the DVR recognizes the data between the Start and End patterns.  Finally, test again and adjust data to remove missed dummy data. 13.6 Search  Using event search function. ...
