iconBIT XDS100GL User Manual
2.5.5.3 HDMI OUT
(1) Follow the picture and plug one connector on your HDMI cable to the player's HDMI
jack;
(2) Follow the picture and plug the other connector on your HDMI cable to the TV's HDMI
jack.
2.5.5.4 ANT. IN
Follow the picture and plug a TV Aerial to the ANT. IN socket;
2.5.5.5 ANT. / RF OUT
(1) Make sure the player is connecting to power supply;
(2) Make sure a TV Aerial is connecting to the ANT. IN socket;
(3) Follow the picture and plug a TV cable to the ANT. OUT socket then plug the cable to a
TV or other TV receiver.
The player can loop out the DVB-T signal to other TV receiver device. In this way, you can
watch the TV programs with another TV receiver while recording.
12
