Swann Digital Monitor & Recorder Quick Start Manual

EN
Digital Monitor & Recorder
Quick Start Guide
Welcome!
Lets get started.
I
J
I) Event LED
- This LED will light up blue ning very low, the LED will turn red and
whenever an event has occurred. When that start flashing.
particular event has been viewed on the device,
K) Home Button
the LED will turn off.
access the main menu. Press it again to view
J) Battery LED - This LED will light up green a live video image from your camera(s). For
to indicate that the battery is fully charged. a full explaination of the various icons and
When charging the battery, the LED will options available, please have a look at the
light up orange. When the battery is run- setup guide included.
C
Step Two
Screw the included antenna
clockwise to the gold
coloured connection on the
camera. Continue until it is
securely fastened. Position
the antenna upright for best
reception quality.
A
Congratulations on the purchase of your Digital Monitor & Recorder device. This quick start
guide will assist you with getting your device up and running as soon as possible. We recommend
that you connect everything and give it a try before you do a permanent installation, to make
sure nothing was damaged during shipping.
A) Power Switch - Switch this to the ON
position to turn the device on. Switch to the
OFF position to turn the device off.
B) Micro-SD Card Slot
card into this slot. A Micro-SD card is required
to record video events. It is compatible with
cards up to 32GB in size.
QH_410PK2260214E | © Swann 2014 1 1
L
M
K
L) IR (Infrared) LEDs
these in low-light conditions to generate
a black and white image, even in total
darkness.
M) Power LED
- The power LED will turn
red to indicate that the camera is working.
- Press the home button to
When pressing the pair button on the
camera, the LED will momentarily flash.
N) Light Sensor
- Detects the amount of
light available and turns on the IR LEDs
when necessary.
4
D
7
Getting to know your device
A B C
C) Power Socket - Connect the power
adapter here. As the device has a built-in
battery, disconnecting the power adapter will
not turn the device off. Use the power switch
- Insert a Micro-SD
to turn the device off.
Q
P
N
O
- The camera will use O) PIR (Passive infrared) Sensor
is an electronic sensor that measures
infrared light radiating from objects in its
field of view.
P) Pair Button
- Press to pair the camera
with the Digital Monitor & Recorder device.
Please have a look at the included setup
guide for more information about pairing.
Q) Antenna
- The included antenna
connects here.
Step Three
Connect the DC 9V
power supply to the
other end of the
power cable.
D
F
H
D) Antenna
- Adjust the antenna so they are
placed vertically.
E) Reset - If the device becomes unrespon-
sive, use a paperclip to reset.
F) Speaker - Audio transmitted from the
camera and audio alerts from the device will
be heard from here.
2
B
- This
Peel off the plastic cover that is protecting
the LCD display.
Flick the power switch to the ON position. You
will momentarily see a Swann logo and a "No
Signal" message will appear on-screen. Don't
worry, this is normal.
5
E
Connect to your Home Network
You should now see a live video
image appear on-screen. For a full
explaination of the various icons
and options available, please have
a look at the setup guide included.
8
E
G
G) Stand
- Pull out the stand so you can place
the device on a flat surface for easy viewing.
H) LAN - Connect this to your home network
so you can use the Swann DigiView app on
your mobile device.
3
Step One
Connect the DC 5V power supply
to the power input on the device.
6
An Ethernet connection is required
to use the Swann DigiView app on
your mobile device. Connect the
Ethernet cable (supplied) to the
LAN connection on the device,
and then connect the other end to
a spare port on your router.
