KitchenAid KGCC566RBB00 Parts List page 2

36" gas glass ceran cooktop
Hide thumbs


Advertisement

COOKTOP, BURNER AND GRATE PARTS
Illus.
Part
No.
No.
DESCRIPTION
1
Literature Parts
8286304 Installation
Instructions
8286305 Use & Care Guide
3192099 Wiring Diagram
9759133 Safe Cooking Tips
8286314 L.P. Conversion
Instructions
2
Grommet, Glass
3180081 White
3180079 Black
3191817 Biscuit
3
Bezel, Cooktop
(RF)(LR)
9753602CG Cumberland Grey
9753602BL Black
9753602MS Moleskin
4
Bezel, Cooktop
(LF)
8285779CG Cumberland Grey
8285779BL Black
8285779MS Moleskin
For Models: KGCC566RBL00, KGCC566RWW00, KGCC566RBB00
(Black)
Illus.
Part
No.
5
9753601CG Cumberland Grey
9753601BL Black
9753601MS Moleskin
6
8286155CG Cumberland Grey
8286155BL Black
8286155MS Moleskin
7
8286174 White
8286172 Black
8286173 Biscuit
8
8286153CG Cumberland Grey
8286153BL Black
8286153MS Moleskin
9
8286156CG Cumberland Grey
8286156BL Black
8286156MS Moleskin
(Pure White)
No.
DESCRIPTION
Bezel, Cooktop
(RR)(Center)
Cap, (RF)(LR)
Cooktop Glass
Cap, (RR)(Center)
Cap, (LF)
2
(Pure Biscuit)
Illus.
Part
No.
No.
DESCRIPTION
10
Grate, Burner
8285879CG Cumberland Grey
8285879BL Black
8285879MS Moleskin
11
Grate, Center
8285881CG Cumberland Grey
8285881BL Black
8285881MS Moleskin
12
Knob, Control (4)
8286094WH White
8286094BL Black
8286094BT Biscuit
15
Holder, Orifice
8286241 Semi Rapid
8286179 Auxi
8286180 Rapid
8286177 Ultra Rapid
16
Head, Burner
8286181 Auxi
8286182 Rapid
8286183 Ultra Rapid
18
4449809 Screw
20
3368921 Screw
8186323
