KitchenAid KGCC506R Dimensions

Gas built-in cooktop
Hide thumbs


Advertisement

PRODUCT MODEL NUMBERS
KGCC506R
KGCK306V
KGCC566R
KGCK366V
Gas Supply: This cooktop is factory set for use
with Natural gas. Cooktop can be converted to LP
gas. The model/serial rating plate located on the
underside of the cooktop has information on the
types of gas that can be used. Provide a gas
supply line of
" (1.9 cm) rigid pipe to the
cooktop location. A smaller size pipe on longer
runs may result in insufficient gas supply. Pipe-
joint compounds that resist the action of LP gas
must be used. Do not use TEFLON
gas, piping or tubing size can be
Usually, LP gas suppliers determine the size and
materials used in the system.
Electrical: A 120-volt, 60-Hz, AC-only, 15-amp
fused, electrical circuit is required. A time-delay
fuse or circuit breaker is also recommended. It is
recommended that a separate circuit serving only
this cooktop be provided.
®
*TEFLON
is a registered trademark of E.I. Du Pont De Nemours
and Company.
CABINET DIMENSIONS
IMPORTANT: If installing a range hood or microwave hood
combination above the cooktop, follow the range hood or
microwave hood combination installation instructions for
dimensional clearances above the cooktop surface.
C
K
M
J
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
®
Gas Built-in Cooktop
PRODUCT DIMENSIONS
®
tape.
With LP
*
" minimum.
A
D
B
F
G
E
H
L
I
"
A. 30
(76.2 cm) on 30
B. Combustible area above countertop (shown by dashed box)
"
C. 30
(76.2 cm) minimum clearance between top of cooktop
platform and bottom of unprotected wood or metal cabinet
"
(24
[61 cm] minimum clearance if bottom of wood or metal
cabinet is protected by not less than
retardant millboard covered with not less than No. 28
MSG sheet steel, 0.015
"
0.024
[0.06 cm] aluminum or 0.020
"
D. 13
(33 cm) recommended upper cabinet depth
"
E. 2
(5.4 cm)
"
F. 19
(48.3 cm)
G. 18" (45.7 cm) minimum clearance from upper cabinet to
countertop within minimum horizontal clearances to cooktop
H. Grounded outlet - Locate within 24" (61 cm) of right rear
corner of cutout
I. 29" (73.7 cm) on 30" models; 35¼" (89.5 cm) on 36" models
³
J. 8
" (21.3 cm) minimum distance to nearest left and right side
combustible surface
K. 2 " (7.3 cm) minimum distance to rear combustible surface
L. Gas line opening - Wall: anywhere 5" (12.7 cm) below
J
underside of countertop. Cabinet floor: Anywhere within
6" (15.2 cm) of rear wall is recommended
M. 24" (61 cm) minimum countertop depth is required
NOTES: After making the countertop cutout, some installations
may require notching down the base cabinet side walls to clear
the cooktop base. To avoid this modification, use a base cabinet
with sidewalls wider than the cutout.
If cabinet has a drawer, a 4" (10.2 cm) depth clearance from the
countertop to the top of the drawer (or other obstruction) in base
cabinet is required. The drawer depth may need to be shortened
to avoid interfering with the regulator.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
"
"
"
models; 36
(91.4 cm) on 36
models
"
[0.6 cm] flame
"
[0.04 cm] stainless steel, or
"
[0.05 cm] copper)
Ref. W10131955B
03-11-09
