JED T430 User Manual

JED T430/T440 Projector Controller user's manual version V097P part B
(Ed Schoell rev Mar 17th 2015... Projector only code version)
Acer projector family
BenQ MP5/7xx, SP820,Opt. Gr3 3/7
Canon
Casio XJ-M
Dell
Eiki XDP-3500, XIP-2600
Epson VP21, IR to S/W/X5... 13/16
HP projector
Hitachi proj
InFocus / ASK Proxima
Mitsubishi
Acer (Code 70 hex, DVI-I, Code 71, HDMI at 9600,
Code 72 hex, DVI-I, Code 73, HDMI at 115200 baud)
There are many Acer projectors covered by this driver ... all use common codes, but vary as to sources supported.
Drivers 70 and 72 support DVI-D and DVI-A as video 2, Computer 2, and 71 and 72 support HDMI. Baud rates of
9600 are supported by codes 70 and 71, and 115200 by code 72 and 73. Some have RGB2, but no codes for this source
are published (Most RGB2 is actually via a DVI-A interface, it seems).
Acer projectors are shown in groups which have similar properties and protocol ... HDMI at the front of a group
indicates that group as an HDMI interface rather than DVI, and so codes 71 and 73 should be used for these. As for
baud rate, initially models shown below in bold are 115200 bps, but several manuals show that during production of a
particular model, the baud rate changed to 9600. The best option is to try 9600 settings first (codes 70 and 71) and if
that does not work, try at 115200 (codes 72 and 73.)
A: HDMI S5200, S5201/B, P5205, P5206, S5201/B, P5301/WB, P5270, P5271/i, P5290/W, P5390W, P7201, P7209,
P7270i, P7280
B: HDMI P1100/C, P1200/i/B/C/n, P1201B, P1203, P1206, P1303
C: M114, M112
D: HDMI 115200 X1110, X1210, X1210S/K, X1213, D315, S21T, D302, X1111/H/A, X1211/H/S/K, X1213P/PH,
X1311KW, X1313PW/PWH
E: X1161/A/N, X1261, X110, H5360, D110
F: HDMI P7200, P7203, P7205, P7500
G: HDMI 115200 X1130P/PS, X1120PK, X1230S/PK/PS, X1235, X1237
H: HDMI H7530, H7531
I: HDMI X1120, X1220H, X1320WH
J: HDMI H9500/BD
K: DVI:XD1170, DVI:XD1270, XD1280
Channel codes are:
Input1 := '* 0 IR 015' + 0D;
Input2 := '* 0 IR 028' + 0D;
Input3 := '* 0 IR 019' + 0D;
Input4 := '* 0 IR 016' + 0D;
or
Input4 := '* 0 IR 050' + 0D;
* T440: OPT6 switch ON will use S-Video in place of HDMI/DVI. T430: Uses HDMI for Video2
T440 User's manual V096B, © JED Microprocessors Pty Ltd Jan 20

Table of Contents

1 NEC Projector
Optoma Projector Gr.1,2,4,5
8 Panasonic Projector
9/10 Plus: U5, U7
11 ProjectionDesign & Christie
12 Promethean PRM-10, 20A
Ricoh
17 Sanyo/Eiki
18/19 Sharp
20/23 Smart projector
24/26
//Computer1 RGB analog-RGB VGA DB9/1
//Computer2 RGB analog- via DVI-A or DB9/2
//Video1 Comp Video
//Video2 DVI-D (Codes 70, 72) Use OPT1 On for DVI-D for main video.
//Video2 HDMI (Codes 71, 73) Use OPT1 On for HDMI for main video.
27/29 Sony projector RS232/IR
30/33 Toshiba projector
34/36 Taxan/Kaga KG-PV-131S/
37
38/39 ViewSonic
38 Vivitek, Promethean PRM25
40
41/47
48
49
th
2015
50/51
52/54
PS-232 55/57
58/61
62/64
Page 1
