ProForm Power 995i PFTL99513.0 User Manual page 17

17. Attach the upper end of the Storage Latch (53)
to the bracket on the Latch Crossbar (38) with a
5/16" x 2 1/4" Bolt (3) and a 5/16" Nut (12).
Lower the Frame (56) (see HOW TO LOWER
THE TREADMILL FOR USE on page 28).
18. Firmly tighten the six 3/8" x 4" Screws (7) (only
one side is shown).
Press the Left Base Cover (82) and the Right
Base Cover (83) onto the Base (94).
19. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of plastic
on the treadmill decals, remove the plastic. To protect the fl oor or carpet, place a mat under the treadmill. To
avoid damage to the console, keep the treadmill out of direct sunlight. Keep the included hex keys in a secure
place; one of the hex keys is used to adjust the walking belt (see pages 30 and 31). Note: Extra parts may be
included.
17
12
56
18
82
17
38
3
53
94
83
7
