ProForm Power 995i PFTL99513.0 User Manual page 12

6. Identify the Left and Right Base Covers (82, 83).
Slide the Left Base Cover onto the Left Upright
(89), and slide the Right Base Cover onto the
Right Upright (90). Do not press the Base
Covers into place yet.
Identify the Right and Left Bottom Handrail
Covers (84, 85). Slide the Left Bottom Handrail
Cover onto the Left Upright (89), and slide the
Right Bottom Handrail Cover onto the Right
Upright (90).
7. Attach the Left Handrail (86) to the Left Upright
(89) with two 5/16" x 2 1/2" Screws (28) and two
5/16" Star Washers (11). Firmly tighten the
Screws.
Attach the Right Handrail (87) to the Right
Upright (90) in the same way.
Remove the wire tie from the Upright Wire (81).
6
89
85
82
7
28
11
86
12
90
84
28
89
11
87
90
Wire
Tie
83
81
