  • Page 1 C o n t r o l t h e E l e me n t s Ow n e r ’ s Ma n u a l F i n e F u r n i t u r e f o r F i n e Wi n e s...
  • Page 2 Website: www.cellarpro.com Serial Number*: ____________________ *We recommend that you take a minute to fill-in your CellarPro serial number above. The serial number has seven-digits and can be found on the printed label on the left side of your cooling unit.

  • Page 3: Table Of Contents

    T a b l e o f C o n t e n t s Prior to Installation Installation Instructions – Wine Cellars III. Replacement Instructions – Wine Cabinets IV. Operating Instructions Troubleshooting VII. Limited Warranty...

  • Page 4: Prior To Installation

    I . P r i o r t o I n s t a l l a t i o n • Wait 24 hours before operating your CellarPro cooling unit. • Test the unit before installing it. 1. Remove the unit from the box. SAVE THE BOX AND PACKING MATERIALS.

  • Page 5: Installation Instructions - Wine Cellars

    I I . I n s t a l l a t i o n I n s t r u c t i o n s – W i n e C e l l a r s • CellarPro Cooling Capacity The cooling capacity for each CellarPro model is shown in the table below. These capacities are estimates and are based on certain heat load assumptions, such as minimum of R-11 insulation, ambient temperatures of 80 degrees or below, and adequate clearance and airflow inside and outside the cellar.
  • Page 6 • Insulation CellarPro cooling units are designed to be installed inside wine cellars that have proper insulation, moisture barriers and an airtight seal from the environment outside the cellar. Interior walls floor should have a minimum of R-11 insulation, and a vapor barrier on the warm side of the insulation.
  • Page 7 CellarPro cooling units must always be mounted in the upright position and located as close to the ceiling as possible inside the cellar. As warm air rises to the top of the cellar, the cooling unit pulls the warm air through the evaporator coils and removes the heat from the warm air.
  • Page 8 Assuming 4 1/2 inch interior wall thickness, the front 12 inches will be inside the cellar. The front of the cooling unit can be mounted using optional mounting clips (available for purchase from CellarPro), as follows: Alternatively, the front of the cooling unit can be supported by a shelf and a diagonal brace.
  • Page 9 Once the cooling unit is installed, all cracks and gaps between the cooling unit and the cellar should be sealed. We provide butyl tape (shipped in the cavity of the exhaust vent) for sealing these gaps. The butyl tape becomes pliable by rolling it in your hands.
  • Page 10 OUTSIDE THE CELLAR Proper ventilation is critically important for the proper operation of your CellarPro cooling unit. The CellarPro cooling unit creates a significant amount of hot air, which must be exhausted into an appropriately-sized space in order for the heat to dissipate.
  • Page 11 1. Evaporator Air Intake. The evaporator coils are located on the face of the cooling unit behind the grill. CellarPro cooling units are designed to be mounted at the highest point inside wine cellars, so that warm air – which rises – will be the first to pass over the evaporator coils, which will remove the heat from the air.

  • Page 12: Replacement Instructions - Wine Cabinets

    2. If your cellar comes with a grill(s), remove and discard the grill(s) on top of the cellar. You do not need a grill with the CellarPro cooling unit. 3. Pull the power cord through the back of the cellar.
  • Page 13 Do not let the cooling unit drop on unprotected bottle racks. TO INSTALL NEW COOLING UNIT 1. Wait 24 hours before plugging in and operating your CellarPro cooling unit. 2. Carefully remove the new cooling unit from the packaging. You may reuse this packaging for shipping or storing the old cooling unit 3.
  • Page 14 8. Attach the mounting clips to the new cooling unit so that they line up with the holes in the cellar. First, remove the front grill (attached with two screws on each side of the cooling unit), attach the mounting clips and then replace the front grill. 9.
  • Page 15 2. If your cellar comes with a grill(s), remove and discard the grill(s) behind the cellar. You do not need a grill with the CellarPro cooling unit. 3. Roll up cord and place in fan cavity at rear of cooling unit. If your cellar came with a hard-wired light, separate the lamp cord from black and white leads at the back of the cooling unit.
  • Page 16 Do not let the cooling unit drop on unprotected bottle racks. TO INSTALL NEW COOLING UNIT 1. Wait 24 hours before plugging in and operating your CellarPro cooling unit. 2. Carefully remove the new cooling unit from the packaging. You may reuse this packaging for shipping or storing the old cooling unit 3.
  • Page 17 9. Some cellars have three pieces of foam located on the bottom and on each side of the bracket that supports the back of the cooling unit. These foam pieces should be placed in their original locations 10. Follow the removal instructions described above in reverse. 11.

  • Page 18: Operating Instructions

    I V . O p e r a t i n g I n s t r u c t i o n s Overview Please follow the instructions in Chapter I prior to turning on your CellarPro cooling unit.
  • Page 19 Minimum Set Point to reduce the cycle “on” time. Most wine collectors store their wine in the range of 55 - 60°F. CellarPro cooling units are designed to maintain appropriate levels of humidity, ranging from 50 to 70 percent, inside wine cellars. In order to increase or decrease humidity inside the cellar, the Fon setting can be changed as described in the “Advanced Operation”...
  • Page 20 Power On/Off Button Press “Power On/Off” to turn the unit on and off When the “Compressor On” indicator light is on, the Compressor is running. When the “Fan On” indicator light is on, the Fan is running Up and Down Buttons To view the “High Temp”...
  • Page 21 Energy Saver Button To activate and deactivate the “Energy Saver” mode, press the “Energy Saver” button The “Energy Saver” indicator light will turn on when the cooling unit is in “Energy Saver” mode In “Energy Saver” mode, the Minimum Set Point increases 4°F and the Temperature Differential is unchanged Quick Chill Button...
  • Page 22 Advanced Operation CellarPro cooling systems can be programmed with advanced settings to achieve more control over conditions inside the cellar. Conditions like humidity, the Temperature Differential, and alarm settings all can be modified for custom applications. To access the advanced settings, do the following: •...
  • Page 23 Optional Protection Mechanisms CellarPro cooling systems can be programmed to turn off the compressor and condenser fan in the event of an HA2 alarm, as described below. If you’d like to turn on this protection mechanism, please call us toll-free at 877.726.8496 P3 >...
  • Page 24 The control panel also will flash a code for each alarm, as follows: Alarm Code What it means What to do P1, P2, P3 Probe Failure Call CellarPro at 877.726.8496 The temperature inside Check seals; the cellar is too warm Check if door was left open; (above 70°F for more...

  • Page 25: Troubleshooting

    V . T r o u b l e s h o o t i n g • The Cooling Unit Runs Constantly The cooling unit is designed to turn on when the air temperature in the cellar rises ABOVE the Minimum Set Point + Temperature Differential, and turn off when the air temperature falls below the Minimum Set Point.
  • Page 26 125°F for more than 2 hours, the HA2 alarm will display on the control panel. If this alarm happens when you first receive and start operating your CellarPro cooling unit, check for appropriate installation and ventilation (Chapter II). Also, make sure that there aren’t any obstructions to the intake and/or exhaust vents.

  • Page 27: Limited Warranty

    All service provided by CellarPro under the above warranty must be performed by a designated repair center, unless otherwise specified by CellarPro. Purchaser is responsible for shipping the cooling unit to and from CellarPro or to and from a designated repair facility, and for removing and reinstalling the cooling unit from the wine cellar.
