- Page 1 ST-1 Instruction Booklet Issue 1 02/04/2010...
-
Page 2: Table Of Contents
ST-1 Instruction Booklet TABLE OF CONTENTS INTRODUCTION ----------------------------------------------------------1 IMPORTANT PRECAUTIONS ------------------------------------------2 SAFETY INFORMATION ON ELECTROMAGNETIC --------------3 INTERFERENCE (EMI) -------------------------------------------------5 CHARGING THE BATTERIES -----------------------------------------9 DISASSEMBLING YOUR SCOOTER --------------------------------10 TROUBLESHOOTING --------------------------------------------------12 CAUTION -----------------------------------------------------------------13 SPECIFICATION --------------------------------------------------------14 Issue 1 02/04/2010... -
Page 3: Introduction
ST-1 Instruction Booklet INTR ODUC TION Thank you and congratulation on purchasing your new Days Healthcare Ltd. Mobility Scooter. We pride ourselves on providing safe and comfortable products. Our goal is to ensure your complete satisfaction. We sincerely hope you enjoy your Days Healthcare Ltd. -
Page 4: Important Precautions
ST-1 Instruction Booklet IMPORTANT PRECAUTIONS Only one person at a time could ride a Days Healthcare Ltd. Mobility Scooter. Maximum load is 115 kg / 250 lbs. Turn key off before getting on or off your scooter. Always drive carefully with your feet on the scooter and be aware of others in your area. -
Page 5: Safety Information On Electromagnetic
ST-1 Instruction Booklet SAFETY INFORMATION ON ELECTROMAGNETIC INTERFERENCE (EMI) CAUTION : It is very important that you read this information regarding the possible effects of Electromagnetic Interference on your motorized scooter. Powered wheelchairs and motorized scooters may be susceptible to electromagnetic interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources such a radio stations, TV stations, amateur radio (HAM) transmitters, two-way radios, and cellular phones. - Page 6 ST-1 Instruction Booklet Motorized Scooter Electromagnetic Interference : Because EM energy rapidly becomes more intense as one move closer to the transmitting antenna (source), the EM fields from hand-held radio wave sources (transceivers) are of special concern. It is possible to unintentionally bring high levels of EM energy very close to the motorized scooter control system while using these devices.
- Page 7 ST-1 Instruction Booklet IDENTIFICATION OF PARTS Before attempting to drive this scooter on your own, it is important that you familiarize yourself with the controls, and how to operate them. Seat Rotation Tiller Angle Lever Adjustment Circuit Breaker Release Lever Battery Pack Pin Charging Socket Figure 1 - ST-1 Front View...
- Page 8 ST-1 Instruction Booklet FUNCTION OF PARTS Main Key Switch (A) 1.Turn the key to the right - Turn the scooter on 2.Turn the key to the left - Turn the scooter off Always ensure that the scooter is switched off before getting on or off the scooter and (F1) before removing any items of the scooter.
- Page 9 ST-1 Instruction Booklet Tiller Angle Adjustment : 1.Lift up the lever (G) to disengage the pin from hole's position. 2.Simultaneously, adjust the steering fore-aft to most comfortable angle, and ensure pin is well locked in it's position. Seat Rotation Adjustment : 1.Lift lever (H) upward to disengage pin.
- Page 10 ST-1 Instruction Booklet Basket : Basket assembling and disassembling (J2) By using a spanner to lock 3 screws (J2) in front of steering. Remove basket by releasing 3 screws (J2) Armrest assembling and angle adjustment : Figure 9 Figure 9 1.Remove plugs (J3) at both sides.
-
Page 11: Charging The Batteries
ST-1 Instruction Booklet CHARGING THE BATTERIES Your ST-1 scooter is equipped with two sealed, maintanence free 12V. 12Ah. rechargeable batteries and one 24V/1.8A charger. Batteries must be charged before using scooter for first time and should be recharged after each day's use. Be sure power switch is in OFF position and free-wheeling lever is not in freewheel mode. -
Page 12: Disassembling Your Scooter
ST-1 Instruction Booklet DISASSEMBLING YOUR SCOOTER I. Seat Disassembling : Remove seat by pulling up Seat Rotation Lever (H). Then lift up away from scooter. II. Battery Pack Disassembling : As indication, Push Release Lever (L) backward and pull Battery Pack Handle (M) to re-move batteries from scooter. - Page 13 ST-1 Instruction Booklet Steering Fold Method : Lift up the lever (G) to bend down the steering to the lowest hole position; complete image. Re-assembling your scooter by vise versa above disassembling procedures. Figure 15 Figure 15 Fuse Replacement : 1.Follow page 11 Disassembling I~II steps.
-
Page 14: Troubleshooting
ST-1 Instruction Booklet TROUBLESHOOTING Fault Code Fault Description Possible Causes / Corrections Low battery The battery needs warning only to be charged. (no fault generated) Battery voltage The battery must is too low be recharged. The battery is over charged. Battery voltage The speed is too high when is too high... -
Page 15: Caution
ST-1 Instruction Booklet CAUTION 1.Obstacle Climbing : Your scooter can climb obstacles and kerbs of up to 4cm in height. Never attempt to overcome an obstacle when on an uphill or downhill gradient! Always approach obstacles straight on! Ensure that the front wheels and rear wheels move over the obstacle in one stroke, do not stop halfway! 2.The maximum gap the scooter can drive over is 10cm, In unlikely event of a panel display error, you need to re-set the display... -
Page 16: Specification
ST-1 Instruction Booklet SPECIFICATION Overall Length 1000 mm / 39.4" Overall Width 510 mm / 20" Overall Height 890 mm / 35" Wheels: Front 195 mm / 8" Wheels: Rear 195 mm / 8" Weight w/ Batteries 40 kg / 88 lbs Max.
